Elements of the Advanced Image Correction screen

1
3
1 Left Thumbnail: This shows the image
before enhancements are applied.
2 Right Thumbnail: This shows the image
after enhancements are applied.
3 Advanced Image Correction Tools (AIC):
These tools adjust or enhance your
images. Click any tool in this area, and
see how the core of the AIC screen (#6)
changes to reflect the properties of that
tool.
4 Preview option: If checked, changes or
enhancements are applied immediately
to the Preview window prescan image. If
unchecked, changes are seen only after
you close the AIC dialog box.
74 Microtek ScanWizard Pro TX for Mac & PC
5 Thumbnail Show/Hide option:
For Mac For Mac - Check to show the before For Mac
For Mac For Mac
and after thumbnails. Uncheck to hide
thumbnails in the AIC screen.
For PC For PC For PC - Click the thumbnail For PC For PC
Show/Hide button to toggle
between hide and show.
6 Core of the AIC screen: This is the
heart of the AIC screen, and the
content here changes to reflect
your selected AIC tool.
7 Action Buttons: These carry out a
specific action. See the next section for
more details.
2
4
5
6
7
Thumbnail Show/
Hide arrow
