5. Click the "Color Management" tab from the Display Properties dialog box.
6. Click the "Add..." button to add your monitor profile from the Profile List.
7. Select the monitor profile "Diamond Compatible 9300K G2.2", and click "Set
8. Click the "OK" button to close the dialog box.
8
After selecting your monitor profile, you will see the same profile being applied
to ScanWizard Pro TX, as well as to your image editing application, e.g.,
Photoshop 5.0 (or later).
NOTE : You must restart your application and ScanWizard Pro TX to have the new
monitor profile take effect.

ICC Profile-Aware vs. non-ICC Profile-Aware applications

It is important that you know whether the image-editing or page-layout
application you are using to edit or process scanned images is ICC profile-aware
or not. This is because the Color Matching Setup dialog box of ScanWizard Pro
TX needs to be setup to match the profile type of the image-editing application
you are using.
120 ScanWizard Pro TX for Mac & PC
As Default" button.
6
5
7
