Section A - Mount IQ System Controller 3 INT

Tools/additional items required provided by the installer
S . N O I T E M N A M E
1 MCB/RCD/RCBO of applicable ratings
2 Conduits/Cable gland (with fittings and fitting tools) - IP55 and above (for non-rear entry systems)
3 IP55 conduit ground locknut (for non-rear entry systems)
4 M6 pilot bit
5 Wrench
6 Adjustable wrench
7 Torque wrench (up to 10 N m)
8 Level gauge
9 4 mm hex bit and multi-bit screwdriver
10 Conductor insulation stripper
11 Electrician's hole saw, punch set, or step drill
12 Stud finder
13 Drill and drill bit extender
M6 lag bolts or screw 80 mm long (depending on wall construction) for each wall-mount
14
bracket
15 Control cable*
16 Phillips size #2 screwdriver
17 2.5 mm, 3 mm, 6 mm, and 7.5 mm slotted screwdrivers
* For Enphase-qualified control cable, refer to
For AUS/NZ the recommended control wires are Electra EAS7302PHV and LAPP 1270802.
IQ System Controller 3 INT quick install guide
https:/ /link.enphase.com/control-cable-table-eu.
M I N I M U M Q U A N T I T Y
As required
As required
1
1
1
1
1
1
2
1
1 set
1
As required
2
As required
1
1 each
4
