- Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. FISHER PRICE 73610 Owner's Manual Shop genuine replacement parts for FISHER PRICE 73610 Find Your FISHER PRICE Ride On Parts - Select From 999 Models -------- Manual continues below --------...
- Page 2 ™ Product features may vary from the picture above. Please read this manual and save it with your original sales receipt. Tools needed for assembly: Phillips Screwdriver, Hammer and Safety Scissors (all not included). Use only with a Power Wheels ®...
-
Page 3: Table Of Contents
• Use this vehicle ONLY outdoors. Most interior floor- www.powerwheels.com or call 1-800-348-0751. ing can be damaged by riding this vehicle indoors. • To register your vehicle please visit us on-line at Fisher-Price ® will not be responsible for damage to www.powerwheels.com. -
Page 4: Warnings And Cautions
Warnings and Cautions ELECTRICAL HAZARD WARNING • Battery can fall out and injure a child if vehicle tips over. Always use battery clamp. • PREVENT FIRE - Never modify the electrical system. Alterations could cause a fire resulting in serious injury and could also ruin the electrical system. -
Page 5: Parts
Parts • If you experience a problem with this product, or are missing a part, please call us at 1-800-348-0751, rather than return this product to the store. • Please identify all parts before assembly and save all packaging material until assembly is complete to ensure that no parts are discarded. - Page 6 Parts Steering Wheel Roll Bar Steering Wheel Cap Brush Guard Steering Linkage Front Axle - 2 Hood (Located in motors in back end of vehicle body.) Steering Column Rear Axle...
- Page 7 Parts Bushing - 2 Spacer - 2 Long Bushing - 2 Assembly Tool ™ Super 6 Volt Charger 6 Volt Battery Not Shown: Label Sheet - 2 *Note: For your convenience, we have included two extra cap nuts, and one extra washer and 1" screw. .437"...
-
Page 8: Parts Diagram
Parts Diagram Hint: Some parts shown are assembled on both sides of the vehicle. Vehicle Body Hood Latch - 2 Super 6 ™ Volt Charger Dashboard Brush Guard 6 Volt Battery Windshield Steering Column Asembly Tool Hubcap - 4 Steering Wheel Long Bushing - 2 Driver - 2 Steering Wheel Cap... -
Page 9: Battery Charging
Battery Charging About Thermal Fuses ELECTRICAL HAZARD Your Power Wheels 6 volt battery with A-style connector is equipped with a built-in thermal fuse. The thermal fuse WARNING is a self-resetting safety device which automatically “trips” and shuts down operation of the vehicle if the vehicle is overloaded or the driving conditions too severe. - Page 10 Battery Charging Battery Compartment Battery Clamp • Plug the charger into a standard 120 volt wall outlet. Note: If power flow to the wall outlet is controlled by a switch, make sure the switch is “ON”. • Before first time use, charge the battery for at least 18 hours.
-
Page 11: Assembly
Assembly WARNING Driver (Ring Side Down) Children can be harmed by small parts, Groove sharp edges and sharp points in the vehicle’s unassembled state, or by electrical items. Care should be taken in unpacking and assembly of the vehicle. Children should not handle parts, including the battery, or Wheel (Flat Side Down) - Page 12 Assembly Rear Wheel .437 Cap Nut (Indented Side First) Vehicle Body Driver Hubcap (Pointed Side First) Rear Axle Motor Rear Wheel Assembly • Slide the rear wheel assembly through a motor and the back end of the vehicle body. .437" Motor •...
- Page 13 Assembly .437 Cap Nut Front Axle Short End Vehicle Body of Front Axle Washers Short End of Front Axle .437" • Fit a .437 cap nut onto the end of each front axle. • Slide a washer onto the short end of each front axle. •...
- Page 14 Assembly Seat Wheel (Indented Side First) Hubcap (Pointed Side First) .437 Washer Bushing Front Axle (Ring Side First) Bushing Ring Side .437" • Insert a #10 x 1" screw through the back of the seat and into the vehicle body. Tighten the screw. •...
- Page 15 Assembly .437 Cap Nut Dashboard End of Steering Column .437" • Fit a .437 cap nut on the end of the steering column. • Tap the cap nut with a hammer to secure the cap nut on the steering column. Pull on the cap nut to be sure it is secure.
- Page 16 Assembly Windshield Large Large Large Hole in Steering Column Dashboard Dashboard Bend Up Slot Slot Large Opening “UP” • Position the windshield so that the wipers face the front end of the vehicle. • Insert and "snap" the two large tabs on the windshield into the large slots in the dashboard.
- Page 17 Assembly Dashboard Slots Hood Tabs Brush Guard • Insert the tabs on the rear edge of the hood into the slots • Fit the brush guard on the front end of the vehicle. in the front of the dashboard. • Insert two #10 x 1" screws through the lower holes in the brush guard and into the front end of the vehicle.
-
Page 18: Label Decoration
Label Decoration Proper label application will help to keep the labels looking their best! When applying labels, keep the following guidelines in mind: • Wash your hands before applying the labels. • Before applying the labels, wipe the surface of the vehicle with a clean, dry cloth to remove any dust or oils. •... - Page 19 Label Decoration Left Side Right Side...
-
Page 20: Battery Installation
Battery Installation IMPORTANT! Use only a Power Wheels ® 6 volt battery Motor with A-style connector and built-in thermal fuse. Use of Harness any other battery will damage your vehicle. Make sure that Connector you charge the battery for at least 18 hours using the ™... -
Page 21: Battery Care And Disposal
Battery Care Battery Care and Disposal and Disposal Care Disposal If a battery leak develops, avoid contact with the leaking • Your Power Wheels ® battery is sealed lead-acid battery. acid and place the damaged battery in a plastic bag. See They must be recycled or disposed of in an environ- information below for proper disposal. -
Page 22: Rules For Safe Driving
Rules for Safe Driving RIDING HAZARD 7. Do not allow your child to drive on sloped or inclined WARNING surfaces. Restrict your child’s driving to generally level ground ONLY! 8. Do not allow your child to drive down or across a Prevent Injuries and Deaths steep slope. -
Page 23: How To Operate Your Vehicle
How to Operate Your Vehicle IMPORTANT! Use this vehicle ONLY outdoors. Most interior flooring can be damaged by riding this vehicle indoors. Fisher-Price ® will not be responsible for damage to the floor if the vehicle is used indoors. FORWARD... -
Page 24: M Statement Of Limited Warranty
Bumper-to-Bumper* Limited Warranty *One year limited warranty from the date of purchase on the Power Wheels ® vehicle. Six month limited warranty on the 6 volt battery. For the original purchaser, this one year limited warranty covers the Power Wheels ®... -
Page 25: Problems And Solutions Guide
Problems and Solutions Guide IMPORTANT! If you experience a problem with your vehicle, first check the Problems and Solutions Guide below. If you still experience a problem, please contact Power Wheels Consumer Relations, ® toll-free at 1-800-348-0751 between 8 AM and 6 PM (EST) Monday through Friday. Or, contact your local Power Wheels authorized service center. - Page 26 Problems and Solutions Guide Problem Possible Cause Solution Vehicle was running but Loose wire or loose connectors Check all wires and connectors. Make sure the battery suddenly stopped connector is tightly plugged into the motor harness con- nector, and that there are no loose wires around the motors. Tripped thermal fuse The built-in thermal fuse may "trip"...
- Page 27 Problems and Solutions Guide Problem Possible Cause Solution Problem Possible Cause Solution Vehicle runs sluggishly (cont.) Battery needs charging Be sure to charge the battery after each use. Battery is old and will not accept Even with proper care, a rechargeable battery does not accept full charge last forever.
- Page 29 For the location nearest you, visit us on-line at www.powerwheels.com. Fisher-Price and Power Wheels by Fisher-Price are U.S. trademarks of Mattel, Inc. Fisher-Price, Inc., a subsidiary of Mattel, Inc., East Aurora, New York 14052 U.S.A. ©2003 Mattel, Inc. All Rights Reserved. PRINTED IN CHINA...
