- Page 1 SPA SALT CHLORINATOR SKU: 90155 WITH CONTROL BOX ASSEMBLY AND USER’S GUIDE 90155 IMPORTANT Review the instruction manual thoroughly before operating the machine. Keep it for future reference.
-
Page 3: Table Of Contents
TABLE OF CONTENTS TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS Legends and Symbols OVERVIEW (PRODUCT INFORMATION) PRODUCT INTRODUCTION PRODUCT OVERVIEW INSTALLATION PREPARE THE SPA INSTALLATION INSTRUCTIONS OPERATION STARTUP STANDBY MODE CHLORINATION CYCLE CHLORINE PRODUCTION SCHEDULE ENERGY LEVEL ADJUSTMENT SALINITY MONITORING ELECTRODE LIFE INITIALIZATION ELECTRODE MAINTENANCE PROTECTION MODES TROUBLESHOOTING... -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS This guide provides instructions for installing and using the SPA Salt Chlorinator. If you have any questions about the equipment, please contact XtremepowerUS. This guide contains important information about safely installing and operating this product. After installation, make sure to share this information with the owner/operator or leave it with them for their reference. - Page 5 • Use only the provided power supply to prevent damage to XtremepowerUS Spa Salt Chlorinator. • Water temperature must be a minimum of 95° for XtremepowerUS Spa Salt Chlorinator to work. CAUTION • Ensure compatibility with the spa by consulting the manufacturer.
-
Page 6: Overview (Product Information)
OVERVIEW (PRODUCT INFORMATION) OVERVIEW (PRODUCT INFORMATION) PRODUCT INTRODUCTION XtremepowerUS Spa Salt Chlorinator is a semi-automatic chlorine generator designed for portable spas. It efficiently creates chlorine by utilizing common table salt (NaCl) dissolved in the water, at a concentration typically undetectable by taste. -
Page 7: Installation
INSTALLATION INSTALLATION PREPARE THE SPA Drain, clean, refill with water, add salt, heat to above 95°F, and balance the water chemistry. INSTALLATION INSTRUCTIONS NOTE Power Supply Guidelines • Use the included power supply. • Protect the power supply with a weather-resistant cover. •... - Page 8 INSTALLATION Draping the Electrode • Place the electrode in the spa's deepest part for maximum chlorine generation. • Maintain a vertical orientation for efficient chlorine production. • Avoid placing in the filter area to ensure optimal chlorine distribution. • Use the provided cable clip to secure the electrode cable to the spa side if needed.
-
Page 9: Operation
OPERATION OPERATION STARTUP • Connect to power: Control box LED flashes 3 times, then enters standby mode. • LED flashes at startup indicate electrode life: 1 lights (below 25% life), 2 lights (25-50% life), 3 lights (50-75% life), and 4 lights (over 75% life). <... -
Page 10: Salinity Monitoring
OPERATION ENERGY LEVEL ADJUSTMENT • Hold GENERATING key for 3-5 seconds until buzzer sounds. • Count continuous Salt_Low light flashes every 2 seconds to determine current level. • Exits adjustment mode after three cycles. • Restart at new energy level after adjustment. Level Run Time Per Run Time Per... -
Page 11: Troubleshooting
TROUBLE SHOOTING TROUBLE SHOOTING Excessive Salt Indication • If both the Green (Salt High) and Red (Salt Low) lights are on, it indicates excess salt. The Chlorinator will shut down to prevent damage. Remove the electrode, press "Boost," and observe the lights. If they remain on, the issue is not with the water itself. •... -
Page 12: Disclaimer
DISCLAIMER DISCLAIMER PLEASE READ THE FOLLOWING CAREFULLY The manufacturer and/or distributor have provided the parts list and assembly diagram in this manual for reference purposes only. They do not make any representation or warranty to the buyer that they are qualified to make repairs to the product or replace any parts of the product. In fact, the manufacturer and/or distributor expressly state that all repairs and parts replacements should be undertaken by certified and licensed technicians, and not by the buyer.
