INSTALLATION AND CARE GUIDE
ข้ อ แนะนํ า การติ ด ตั ้ ง และการดู แ ลรั ก ษา
PARALLEL SHOWER SCREEN WITH SHELF
ฉากกั ้ น อ่ า งอาบนํ ้ า บานเลื่ อ นพร้ อ มชั ้ น วางของ รุ ่ น พาราเรล
K-36965X/K-36965T
BEFORE YOU BEGIN
•
Before you install your shower door, please read these
instructions carefully to familiarize yourself with the
required tools, materials, and installation sequences.
Follow the sections that pertain to your particular
installation. This will help you avoid costly mistakes. In
addition to proper installation, read all operating and
safety instructions.
•
All information is based on the latest product information
available at the time of publication. Kohler Ltd.reserves
the right to make changes in product characteristics,
instructions, illustrations, packaging, or availability at
any time without notice.
•
These instructions contain important care and cleaning
information-please leave these instructions for the
consumer.
•
Make sure that the bath and the finished wall material
are completely and correctly installed prior to installing
your shower door. Prepare waterproof layer to wall and
floor of the showering area. It is not allowed for any
presence of electric switches and sockets. Make sure
the floor drain runs smoothly.
•
Before starting the door installation, lay out and identify
all the parts. Use the exploded view illustrated on page
2 for reference.
CAUTION: Risk of injury or product damage.
Tempered glass cannot be cut, drilled or knocked
by hard object. Make sure corner area of the glass
refraining from knocking so as to cause personal
injury due to broken glass.
IMPORTANT: Please check the door open direction before
install the product.
IMPORTANT: This instruction covers several door models.
They will vary in size of the product .
IMPORTANT: Please inatall dividers or receptors install
shower door.
IMPORTANT: The shower door requires a flat vertical
finished wall. The squareness of the wall is recommended
no more than 3 mm/m. KOHLER Company won't take
responsibility of the installation quality.
©2012 Kohler Co.
PARALLEL SHOWER WITH SHELF
ฉากกั ้ น บานเลื่ อ นพร้ อ มชั ้ น วางของ รุ ่ น พาราเรล
ฉากกั ้ น อ่ า งอาบนํ ้ า บานเลื่ อ น รุ ่ น พาราเรล
ก่ อ นการติ ด ตั ้ ง
โปรดอ่ า นคู ่ ม ื อ ก่ อ นการติ ด ตั ้ ง ตู ้ อ าบนํ ้ า อย่ า งละเอี ย ดเพื ่ อ ศึ ก ษา
•
เครื ่ อ งมื อ , วั ส ดุ และขั ้ น ตอนในการติ ด ตั ้ ง ให้ ป ฏิ บ ั ต ิ ต ามขั ้ น ตอน
การติ ด ตั ้ ง อย่ า งเคร่ ง ครั ด เพื ่ อ หลี ก เหลี ่ ย งความเสี ย หายที ่ เ กิ ด ขึ ้ น
จากการติ ด ตั ้ ง อี ก ทั ้ ง เพื ่ อ ความเหมาะสมในการติ ด ตั ้ ง โปรดอ่ า น
คํ า แนะนํ า และข้ อ สํ า คั ญ เกี ่ ย วกั บ ความปลอดภั ย
ข้ อ มู ล ในคู ่ ม ื อ นี ้ ม าจากข้ อ มู ล ผลิ ต ภั ณ ฑ์ ล ่ า สุ ด ที ่ ม ี อ ยู ่ ใ นช่ ว งเวลา
•
การจั ด พิ ม พ์ บริ ษ ั ท ฯขอสงวนสิ ท ธิ ์ ใ นการเปลี ่ ย นแปลงข้ อ มู ล
ผลิ ต ภั ณ ฑ์ , การติ ด ตั ้ ง , ภาพประกอบหรื อ บรรจุ ภ ั ณ ฑ์ ท ี ่ ม ี อ ยู ่ โ ดย
มิ ต ้ อ งแจ้ ง ให้ ท ราบล่ ว งหน้ า
คู ่ ม ื อ นี ้ ม ี ข ้ อ มู ล การดู แ ลรั ก ษาและการทํ า ความสะอาด โปรดมอบ
•
เอกสารให้ ก ั บ เจ้ า ของผลิ ต ภั ณ ฑ์
ให้ แ น่ ใ จว่ า ติ ด ตั ้ ง อ่ า งอาบนํ ้ า และปู พ ื ้ น กระเบื ้ อ งเข้ า กั บ ผนั ง ก่ อ น
•
ทํ า การติ ด ตั ้ ง ตู ้ อ าบนํ ้ า เตรี ย มระดั บ นํ ้ า เพื ่ อ ตรวจสอบผนั ง และพื ้ น
บริ เ วณที ่ ต ิ ด ตั ้ ง ตู ้ อ าบนํ ้ า ให้ ไ ด้ ร ะดั บ ห้ า มติ ด ตั ้ ง สวิ ต ซ์ แ ละปลั ๊ ก
ไฟฟ้ า ในพื ้ น ที ่ ให้ แ น่ ใ จว่ า รู ท ่ อ ระบายนํ ้ า ทํ า งานตามปกติ
ก่ อ นทํ า การติ ด ตั ้ ง ตู ้ อ าบนํ ้ า ให้ ต รวจสอบระยะการติ ด ตั ้ ง , อุ ป กรณ์
•
และอะไหล่ โดยอ้ า งอิ ง จากภาพประกอบในหน้ า 2
ข้ อ ควรระวั ง การติ ด ตั ้ ง มี ค วามเสี ่ ย งอาจทำ า ให้ ไ ด้ ร ั บ
บาดเจ็ บ หรื อ ผลิ ต ภั ณ ฑ์ เ สี ย หาย กระจกเทมเปอร์ ไ ม่
สามารถตั ด , เจาะหรื อ ถู ก กระแทกโดยวั ต ถุ แ ข็ ง หลี ก เหลี ่ ย งการ
กระแทกบริ เ วณด้ า นมุ ม ของกระจกซึ ่ ง อาจทํ า ให้ ก ระจกแตก
และได้ ร ั บ บาดเจ็ บ จากเศษกระจก
ข้ อ สำ า คั ญ : โปรดตรวจสอบทิ ศ ทางการเปิ ด ประตู ก ่ อ นการติ ด ตั ้ ง
ผลิ ต ภั ณ ฑ์
ข้ อ สำ า คั ญ : ข้ อ แนะนํ า การติ ด ตั ้ ง นี ้ ใ ช้ ก ั บ ฉากั ้ น อาบนํ ้ า หลายรุ ่ น
ซึ ่ ง จะแตกต่ า งกั น ที ่ ข นาดของผลิ ต ภั ณ ฑ์
ข้ อ สำ า คั ญ : โปรดติ ด ตั ้ ง ธรณี ป ระตู ห รื อ ถาดรองอาบนํ ้ า ก่ อ นการ
ติ ด ตั ้ ง ตู ้ อ าบนํ ้ า
ข้ อ สำ า คั ญ : การติ ด ตั ้ ง ตู ้ อ าบนํ ้ า จํ า เป็ น ต้ อ งใช้ ผ นั ง เรี ย บ, ตั ้ ง ฉากและได้
ระดั บ ความเอี ย งไม่ เ กิ น ไม่ เ กิ น 3 มม./เมตร ถ้ า ไม่ เ ป็ น ไปตามที ่ ก ํ า หนด
ทางบริ ษ ั ท ฯขอไม่ ร ั บ รองผลจากการติ ด ตั ้ ง
1
PARALLEL SHOWER DOOR
ฉากกั ้ น บานเลื่ อ น รุ ่ น พาราเรล
K-36962X/K-36962T
K-36963X/K-36963T
PARALLEL SHOWER SCREEN
K-36964X/K-36964T
1111105-X2-B
