ROUGHING-IN
Reference Value
27
36.5
INSTALLATION
1. Fasten the bolts to the pre-installed anchors on the tub;
2. Attach the gaskets to the grip rail, and align the gasket
holes with the grip rail mounting holes;
3. Make sure the screw holes on the side of the grip rail face
down, and align the mounting holes with the bolts fastened
to the bath, then attach the grip rail to the bath;
4. If needed, adjust the gaskets so that they match the grip
rail perfectly, then tighten the screws into the screw holes
on the side of the grip rail.
-CP -Polished Chrome -
-RGD -Polished Rose Gold -
1523896-T2-A
Kohler reserves the right to change marked dimensions without prior notice.
SHANGHAI KOHLER LTD.,
FENG XIAN DISTRICT, SHANGHAI, CHINA
361
12
223
250
1.
2.
3.
4.
Bath Anchor
-** include: -**
-BL -Matte Black -
-2MB -Vibrant Brushed Moderne Brass -
NO.368, MIN LE ROAD,
POST CODE: 201419
368
©
Copyright Kohler China Investment Co., Ltd. 2022
-1-
©
BATHTUB GRIP RAILS
INSTALLATION INSTRUCTIONS
Bolt
Gasket
Grip Rail
Screw
201419
K-36362T
Unit:mm
2022
