Page 7: Preface
Preface This document describes the hardware features of the HPE Aruba Networking 7205 Controller. It provides a detailed overview of the physical and performance characteristics of the controller and explains how to install the controller and its accessories. Guide Overview... - Page 8 | Preface HPE Aruba Networking 7205 Controller | Installation Guide...
-
Page 9: 7205 Controller
M6 x 15 mm Phillips Pan Head Screws M4 x 8 mm Phillips Flat Head Screws M6 x 7 mm Grounding Screws AC Power Cord Retaining Clip Power Cable Micro-USB Cable Rubber Feet HPE Aruba Networking 7205 Controller | Installation Guide 7205 Controller |... -
Page 10: 7205 Components
Installation Guide (this document, printed) Quick Start Guide (Printed) End User License Agreement (printed) Optional accessories are available for use with the HPE Aruba Networking 7205 controller and are sold separately. Contact your HPE Aruba Networking sales representative for details and assistance. 7205 Components This section introduces the different components of the 7205 controller, and specifies their locations in the controller. -
Page 11: Dual-Media Ports
Figure 3 illustrates the CAT-5 pin-out on an RJ-45 connector. The CAT-5 pin-out pairs the following pins on a 10/100/1000BASE-T Gigabit Ethernet port: 1/2, 3/ 6, 4/5, and 7/8. HPE Aruba Networking 7205 Controller | Installation Guide 7205 Controller |... -
Page 12: 1000Base-X (Sfp) Ports
HPE Aruba Networking tests and supports HPE Aruba Networking optics within their controller systems. Third party optics are not tested or supported; therefore, HPE Aruba Networking does not guarantee proper functionality of third party optics when used in an HPE Aruba Networking system. -
Page 13: 10Gbase-X Ports
HPE Aruba Networking tests and supports HPE Aruba Networking optics within their controller systems. Third party optics are not tested or supported; therefore, HPE Aruba Networking does not guarantee proper functionality of third party optics when used in an HPE Aruba Networking system. -
Page 14: Sfp/Sfp+ Modules And Dac Cables
For the list of HPE Aruba Networking approved SFP/SFP+ modules and DAC cables for controllers, see Table 8 Table Other non-approved third-party optics or DAC cables are not tested or supported by HPE Aruba Networking on controllers; therefore, HPE Aruba Networking does not guarantee their proper functionality when used with HPE Aruba Networking controllers. -
Page 15: Usb Interface
5). This port is an RJ-45 female connector that accepts an RS-232 serial cable with a male connector. Figure 5 Serial Console Port Pin-Out Serial RJ-45 Female Console Port Pin-Out Direction Input Output HPE Aruba Networking 7205 Controller | Installation Guide 7205 Controller |... -
Page 16: Serial Console Port Adapter
SNMP, and Web interface for complete system management and troubleshooting. It can also be used to connect to a separate management network. The management port has a LINK/ACT LED on its top left and | 7205 Controller HPE Aruba Networking 7205 Controller | Installation Guide... -
Page 17: Power, Status, And Peered Leds
Menu— Allows navigation through the menus of the LCD panel Enter— Confirms and executes the action currently displayed on the LCD panel LCD Menu The LCD menu includes four modes as shown in the following table: HPE Aruba Networking 7205 Controller | Installation Guide 7205 Controller |... -
Page 18: Disabling The Lcd Screen
To disable the LCD screen, enter the Enable mode and use the following CLI commands: (host) #configure terminal (host) (config) #lcd-menu | 7205 Controller HPE Aruba Networking 7205 Controller | Installation Guide... -
Page 19: Cpu Module
CPU Module The 7205 controller is equipped with a pre-installed CPU module on the back panel of the controller. Do not remove the CPU module unless directed by an authorized HPE Aruba Networking technician. The CPU module is not hot-swappable. - Page 20 | 7205 Controller HPE Aruba Networking 7205 Controller | Installation Guide...
-
Page 21: Installation
19-inch Telco rack. Only use the included or HPE Aruba Networking specified cables, power cords, AC power supplies, and batteries. The power cord should not be used with other electric equipment than what is specified by HPE Aruba Networking. CAUTION Utilisez uniquement les câbles, cordons d’alimentation, alimentations c.a. -
Page 22: Rack Mounting - Standard/Front
To install a 7205 controller from the front in a standard two-post 19-inch Telco rack: 1. Place the mounting brackets over the mounting holes near the front on either sides of the controller (see Figure | Installation HPE Aruba Networking 7205 Controller | Installation Guide... -
Page 23: Rack Mount Installation- Mid
7205 controller from the middle in standard two-post 19-inch Telco rack. For more information about this accessory kit, contact your HPE Aruba Networking sales representative. Each 7205 controller must have its own mounting equipment. Do not place other networking equipment directly on top of a mounted 7205 controller. -
Page 24: Required Tools And Equipment
3. If the rack requires cage nuts or clip nuts, insert them on the front rails (two per rail, aligned horizontally) 4. Mount the controller in the rack using the four screws for system rack mount (two per bracket) and suitable screwdriver (see Figure 10). | Installation HPE Aruba Networking 7205 Controller | Installation Guide... -
Page 25: Required Tools And Equipment
1. Attach the rubber feet to the bottom of the controller (see Figure 11). 2. Place the controller on the desired flat table or shelf. Figure 11 Attaching Rubber Feet HPE Aruba Networking 7205 Controller | Installation Guide Installation |... -
Page 26: Wall Mounting
Wall Mounting An optional accessory kit (SPR-WL2-MNT, must be purchased separately) is available that allows you to mount the 7205 controller to a wall. For more information about this accessory kit, contact your HPE Aruba Networking sales representative. Required Tools and Equipment... -
Page 27: Connecting And Disconnecting The Ac Power Cord
2. Insert the coupler end of the AC power cord into the AC power connector. 3. Lower the power cord retaining clip over the AC power cord. The 7205 controller should now be receiving power. HPE Aruba Networking 7205 Controller | Installation Guide Installation |... -
Page 28: Disconnecting The Ac Power Cord
2. Insert the fiber optic cable into the SFP/SFP+ module. Ensure that the latch on the cable faces the top of the SFP/SFP+ module (see Figure 15). 3. Slide the cable into place until a connection is made and an audible click is heard. | Installation HPE Aruba Networking 7205 Controller | Installation Guide... -
Page 29: Disconnecting An Lc Fiber Optic Cable
Removing an SFP/SFP+ Module To remove an SFP/SFP+ module: 1. Open and release the latch on the SFP/SFP+ module. 2. Pull and remove the module from the port. HPE Aruba Networking 7205 Controller | Installation Guide Installation |... - Page 30 | Installation HPE Aruba Networking 7205 Controller | Installation Guide...
-
Page 31: Specifications, Safety, And Compliance
The HPE Aruba Networking controllers must be installed by a professional installer. The professional installer is responsible for ensuring that grounding is available and it meets applicable local and national electrical codes. -
Page 32: Regulatory Model Name
Cet appareil numérique respecte les limites de bruits radioélectriques applicables aux appareils numériques de Classe A prescrites dans la norme sur le matériel brouilleur: “Appareils Numériques,” NMB- 003 édictée par le ministère des Communications. | Specifications, Safety, and Compliance HPE Aruba Networking 7205 Controller | Installation Guide... -
Page 33: Europe
This product is CE marked according to the provisions of the EMC Directive (2004/108/EC) - CE. HPE Aruba Networking, hereby declares that 7205controller device models are in compliance with the essential requirements and other relevant provisions of Directive (2004/108/EC) – CE. The Declaration of Conformity made under Directive 1999/5/EC is available for viewing in the EU community. -
Page 34: Proper Disposal Of Hpe Aruba Networking Equipment
(including Solder used in printed circuit assemblies), Cadmium, Mercury, Hexavalent Chromium, and Bromine. Some HPE Aruba Networking products are subject to the exemptions listed in RoHS Directive Annex 7 (Lead in solder used in printed circuit assemblies). Products and packaging will be marked with the “RoHS”... -
Page 35: India Rohs
India RoHS This product complies with RoHS requirements as prescribed by E-Waste (Management & Handling) Rules, governed by the Ministry of Environment & Forests, Government of India. HPE Aruba Networking 7205 Controller | Installation Guide Specifications, Safety, and Compliance |... - Page 36 | Specifications, Safety, and Compliance HPE Aruba Networking 7205 Controller | Installation Guide...
