Trynex International Snowex V-Maxx 9500 Assembly Instructions Manual

Spreaders for snow & ice control
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
© Trynex International 2007
© Trynex International 2007
L11
L1185
Spreaders for Snow & Ice Control
(REV.002)
FOR MODEL
V-Maxx 9500
5 — 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Snowex V-Maxx 9500 and is the answer not in the manual?

Questions and answers

Related Manuals for Trynex International Snowex V-Maxx 9500

Summary of Contents for Trynex International Snowex V-Maxx 9500

  • Page 1 Spreaders for Snow & Ice Control FOR MODEL V-Maxx 9500 © Trynex International 2007 © Trynex International 2007 L1185 5 — 1 (REV.002)
  • Page 2 V-Maxx 9500 Auger Drive Assembly Parts Breakdown 5 — 10 L1185 © Trynex International 2007...
  • Page 3 Transmission/Auger Coupler D6873 3/6” Keyway Stock D6843 Urethane Coupler Spyder INCLUDED Coupler Set Screw D6894 Auger Transmission D6872 9500 Auger Motor D6463 Push Pin Fastener D6868 Auger Motor Cover Auger Drive Assembly © Trynex International 2007 L1185 5 — 11...
  • Page 4 V-Maxx 9500 Spinner Drive Assembly Parts Breakdown 5 — 12 L1185 © Trynex International 2007...
  • Page 5 5-16”-18 x 1/2 “ Hex Head Bolt D6133 Spinner Hub Weldment D6891 1/4” Nylock Nut D4289 Heavy Duty Spinner Tubular Guard D6820 Plastic Spinner Deflector D6858 Extended Plastic chute D6885 Extended Plastic chute D6859 Complete Drive Assembly D-6863 © Trynex International 2007 L1185 5 — 13...
  • Page 6 V-Maxx 9500 Hopper Assembly Parts Breakdown L1185 © Trynex International 2007 5 — 14...
  • Page 7 D 6811 Inverted-V Backing Plates 3/8”-16 Nylock Nut D 4124 D 6899 Heavy Duty Vibrator D 6860 Vibrator Backing Plate D 4125 3/8” Flat Washer D 6898 Hopper Cross Bar Support Hopper Assembly © Trynex International 2007 L1185 5 — 15...
  • Page 8 V-Maxx 9500 Frame Assembly Parts Breakdown 5— 16 L1185 © Trynex International 2007...
  • Page 9 9500 Frame Weldment D 6882 Upper/Lower Front Rail D 6884 Auger Motor/Transmission Support D 6880 Rear Apron With Light Hole Knock Outs D 6528 1/2”-13 x 1” Serrated Hex Head Bolt Frame Assembly © Trynex International 2007 L1185 5 — 17...
  • Page 10 Step 7: Push the ON/OFF button on the controller to check for power, when that has been confirmed turn power OFF. The electrical portion of the installation is complete. 5 — 18 L1185 © Trynex International 2007...
  • Page 11 D 6837 D 6896 Vehicle Harness Spreader Harness D 6895 Vehicle Harness Dust Cap D 6343 Spreader Spinner Plug Dust Cap D 6118 CHMSL Vehicle Harness D 6513 CHMSL Light Assembly D 6514 © Trynex International 2007 L1185 5 — 19...
  • Page 12 Warranty ..................33-34 5 — 2 © Trynex International 2007 L1185...
  • Page 13 6 GA. Breaker Wire D 6840 100 AMP Resetable Breaker 1 Connect to control mating half * NOTE: A) Leads must only be attached to battery. B) 100 Amp breaker must be inserted. L1185 © Trynex International 2007 5 — 20...
  • Page 14 Red Positive (+) Red Positive (+) VIBRATOR AUGER Black Negative (–) Black Negative (–) MAIN POWER PLUG SPREADER Positive (+) Black Negative (–) Black Negative (–) Positive (+) VIBRATOR POWER PLUG SPINNER POWER PLUG © Trynex International 2007 L1185 5 — 21...
  • Page 15 SPINNER OUTPUT Black Negative (–) Blue Positive (+) SPINNER OUTPUT SPINNER Orange Negative (–) AUGER Blue Positive (+) Red Positive (+) SPINNER Orange Negative (–) * NOTE: Reference Bumper Plug for Color Code L1185 © Trynex International 2007 5 — 22...
  • Page 16 Left Front Stop Bracket D 6760 Right Front Stop Bracket " 2 D 4116 1/2”-13 x1-1/2” Hex Bolt Flat Washer D 4121 3/8”-16 x 1” Lock Nut CROSS FRONT STRAPS " 8 AS SHOWN © Trynex International 2007 L1185 5 — 23...
  • Page 17 NOTE: (Do not use ratchet straps exclusively.) Step 9: Connect the spreader power cord to vehicle main power plug mounted at rear of vehicle (see Electrical Installation). L1185 © Trynex International 2007 5— 24...
  • Page 18 V-Maxx 9500 Mounting Instructions (Continued) Recommended Installation For Platform Bodies Through Floor Chain Tie Downs (6) Places Weld On Stake Pockets (6) Places. 5— 25 L1185 © Trynex International 2007...

  • Page 19: Operating The Spreader

    • The Vibrator Switch is needed for dense material or to increase the flow to the auger. This eliminates bridging of material in hopper. • In case spreader becomes jammed, it will go into an auto-reverse program to free itself. Auger display will show (AR) while trying to clear obstruction. © Trynex International 2007 L1185 5— 26...
  • Page 20 • You may repeat Steps 1 & 2 for a second and third time. • If after the third try the controller displays “OL” — you must extract the material that is causing the problem. • Follow all warning directions when clearing jams. L1185 © Trynex International 2007 5 — 27...
  • Page 21 LIGHT HOLE KNOCK OUT INSTRUCTIONS (For Use With 6” Oval Light Kits) STEP 1 Press top or lower center to rotate knock out until it breaks off. STEP 2 Insert 6” oval lamps 5 — 28 © Trynex International 2006 L1185...

  • Page 22: Troubleshooting

    Motor is not getting power. Turn off. Check all connections. display shows EO. Audible alarm beeping Vehicle battery is extremely low, Turn off. Charge battery. display shows LB. or a poor connection exists. © Trynex International 2007 L1185 5 — 29...
  • Page 23 (ORANGE) Information that, if not carefully followed, can cause serious personal injury or death! (YELLOW) Information that, if not carefully followed, can cause minor injury or damage to equipment. © Trynex International 2007 L1185 5 — 3...
  • Page 24 BAD CONTROLLER TO BLUE WIRE LIGHTS NO DISPLAY CHECK WITH TEST KIT NOTHING HAPPENS BAD CONTROLLER CHECK POWER SOURCE NO DISPLAY ON/OFF SWITCH WILL TO CONTROLLER CHECK WITH TEST KIT NOT LIGHT UP © Trynex International 2007 L1185 5 — 30...
  • Page 25 AT AUGER MOTOR AUGER RUNS REPLACE SPREADER FOR REVERSE VIBRATOR BACKWARDS HARNESS POLARITY SLOW TURN ON MATERIAL VIBRATOR FLOW INCREASE AUGER SPEED MATERIAL ISSUE * Spreader capable of speading most granular bulk material. © Trynex International 2007 L1185 5 — 31...

  • Page 26: Spreader Maintenance

    If motor cover is removed for any reason, use silicone sealant to ensure weather proofing of enclosure. • Grease bearings after every 20 hours use. • After first use, tighten all nuts and bolts on spreader and mount. • WARNING: Never remove spreader with material in hopper. 5 — 32 © Trynex International 2007 L1185...

  • Page 27: Determining Vehicle Payload

    3/4-10 7/8-9 Metric Grade 8.8 (ft.-lb.) SIZE TORQUE SIZE TORQUE M 12 M 14 M 10 M 16 These torque values apply to mount assembly fasteners except those noted in the instruction. © Trynex International 2007 L1185 5 — 33...

  • Page 28: Limited Warranty

    NO DEALER HAS AUTHORITY TO MAKE ANY REPRESENTATION OR PROMISE ON BEHALF OF SNOWEX, OR TO ALTER OR MODIFY THE TERMS OR LIMITATIONS OF THIS WARRANTY IN ANY WAY. 5 — 34 L1185 © Trynex International 2007...
  • Page 29 NOTE: I have read the owner’s manual and all safety precautions and I understand that this equipment could be dangerous if not operated with care and under the proper conditions. 15) Owner’s signature: PLEASE FOLD AND SEAL WITH TRANSPARENT TAPE BEFORE MAILING. © Trynex International 2007 L1185 5 — 35...

  • Page 30: General Information

    Please fill out the warranty card with all the necessary information to validate it. This will also give us a record so that any safety or service information can be communicated to you. 5 — 4 L1185 © Trynex International 2007...
  • Page 31 The unit, or any part of it should be altered without prior written permission from the manufacturer. Never use 9500 with foreign debris in the spreader. These units are designed to handle clean, free-flowing material. Note: Can not spread water softner salt. © Trynex International 2007 L1185 5 — 5...
  • Page 32 CHMSL light must be installed and plugged in to meet DOT FMVSS-108 standards. Spreader is designed for 10,000 pound G.V.W.R and above. Failure to do so could cause death. 5 — 6 L1185 © Trynex International 2007...

  • Page 33: Safety And Warning Labels

    Safety and Warning Labels SERIAL NUMBER ON REVERSE SIDE D 6546 D 6859 D 6545 D 6544 D 6335 D 6548 © Trynex International 2007 L1185 5 — 7...
  • Page 34 V-Maxx 9500 Component Assembly Views Spinner Drive Auger Drive Assembly Assembly Electrical System Assembly Hopper Frame Assembly Assembly 5 — 8 L1185 © Trynex International 2007...
  • Page 35 V-Maxx 9500 Side and Bottom Views © Trynex International 2007 L1185 5 — 9...
