Trynex International SnowEx V-Maxx 8500 Manual

Spreaders for snow & ice control
Hide thumbs

Advertisement

Quick Links

Download this manual
This Manual Must Be Read Before Operating The Equipment
Owner / Operator's Manual
Spreaders for Snow & Ice Control
FOR MODELS
V-Maxx 8500
CUSTOMER COPY
Warren, Michigan 48089
Protected by the following patents, #6,089,478, #6,088,865, #Des.425,915
and other pending U.S. and foreign patent applications.
800-725-8377
© Trynex International 2006
L1159
4 — 1

Advertisement

loading
Need help?

Need help?

Do you have a question about the SnowEx V-Maxx 8500 and is the answer not in the manual?

Questions and answers

Related Manuals for Trynex International SnowEx V-Maxx 8500

Summary of Contents for Trynex International SnowEx V-Maxx 8500

  • Page 1 Spreaders for Snow & Ice Control FOR MODELS V-Maxx 8500 CUSTOMER COPY Warren, Michigan 48089 Protected by the following patents, #6,089,478, #6,088,865, #Des.425,915 and other pending U.S. and foreign patent applications. 800-725-8377 © Trynex International 2006 L1159 4 — 1...
  • Page 2 Warranty ....................34 L1159 © Trynex International 2006 4 — 2...
  • Page 3 (ORANGE) Information that, if not carefully followed, can cause serious personal injury or death! (YELLOW) Information that, if not carefully followed, can cause minor injury or damage to equipment. © Trynex International 2006 L1159 4 — 3...
  • Page 4 Please fill out the warranty card with all the necessary information to validate it. This will also give us a record so that any safety or service information may be communicated to you. L1159 © Trynex International 2006 4 — 4...
  • Page 5 The unit, or any part of it should be altered without prior written permission from the manufacturer. Never use V-Maxx 8500 with foreign debris in the spreader. These units are designed to handle clean, free-flowing material. Note: Can not spread water softner salt. © Trynex International 2006 L1159 4 — 5...
  • Page 6 Always wear safety glasses with side shields when servicing spreader. Failure to do this could result in serious injury to the eyes. CHMSL light must be installed and plugged in to meet DOT FMVSS-108 standards. L1159 © Trynex International 2006 4 — 6...
  • Page 7 Safety and Warning Labels D 6546 D 6859 D 6545 D 6544 D 6335 D 6548 © Trynex International 2006 L1159 4 — 7...
  • Page 8 V-Maxx 8500 Component Assembly Views Spinner Drive Auger Drive Assembly Assembly Electrical System Assembly Frame Hopper Assembly Assembly L1159 © Trynex International 2006 4 — 8...
  • Page 9 V-Maxx 8500 Side and Bottom Views © Trynex International 2006 L1159 4 — 9...
  • Page 10 V-Maxx 8500 Auger Drive Assembly Parts Breakdown L1159 © Trynex International 2006 4 — 10...
  • Page 11 D 6873 3/16" Key Stock D 6875 3/8"-16 x 1-1/2" Carriage Bolt D 6877 #8 x 3/4 Self Drilling HWH D 6452 3/8"-16 x 1" Type F HH TCS Auger Drive Assembly © Trynex International 2006 L1159 4 — 11...
  • Page 12 V-Maxx 8500 Spinner Drive Assembly Parts Breakdown L1159 © Trynex International 2006 4 — 12...
  • Page 13 Heavy Duty Spinner Tubular Guard D 6563 Spinner Drive Pin D 4134 Drive Pin Clip D 6824 Spinner Hub Weldment D 6854 1/4"-20 x 1" HWH Serrated SS Complete Drive Assembly (D6850) © Trynex International 2006 L1159 4 — 13...
  • Page 14 V-Maxx 8500 Hopper Assembly Parts Breakdown L1159 © Trynex International 2006 4 — 14...
  • Page 15 Discharge Baffle D 6809 Salt Baffle D 6811 Inverted V Backing Plates D 6848 One Piece Top Screen D 6874 #14 x 1.5" HWH Self Driller D 6847 Baffle Extension Hopper Assembly © Trynex International 2006 L1159 4 — 15...
  • Page 16 V-Maxx 8500 Frame Assembly Parts Breakdown L1159 © Trynex International 2006 4 — 16...
  • Page 17 D 6536 Right Stop Bracket D 6537 Left Stop Bracket D 6801 Side Frame Weldment D 6804 Upper/Lower Front Rail D 6805 Rear Apron D 6806 Auger Motor Trans Support Frame Assembly © Trynex International 2006 L1159 4 — 17...
  • Page 18 Step 8: Push the ON/OFF button on the controller to check for power, when that has been confirmed turn power OFF. The electrical portion of the installation is complete. NOTE: If adding an inline fuse, use a 60 amp slow blow fuse. L1159 © Trynex International 2006 4 — 18...
  • Page 19 D 6837 Control Power Cable D 6838 Spreader Harness D 6839 6 GA. Breaker Wire D 6840 80 AMP Resetable Breaker D 6874 #14 x 1.5" HWH Self Driller D 6118 Dust Cap © Trynex International 2006 L1159 4 — 19...
  • Page 20 6 GA. Breaker Wire D 6840 100 AMP Resetable Breaker 1 Connect to control mating half * NOTE: A) Leads must only be attached to battery. B) 100 Amp breaker must be inserted. L1159 © Trynex International 2006 4 — 20...
  • Page 21 Yellow Positive (+) VIBRATOR AUGER Green Negative (–) Black Negative (–) MAIN POWER PLUG SPREADER Yellow Positive (+) Orange Negative (–) Green Negative (–) Blue Positive (+) VIBRATOR SPINNER POWER PLUG POWER PLUG © Trynex International 2006 L1159 4 — 21...
  • Page 22 SPINNER OUTPUT Black Negative (–) Blue Positive (+) SPINNER OUTPUT SPINNER Orange Negative (–) AUGER Blue Positive (+) Red Positive (+) SPINNER Orange Negative (–) * NOTE: Reference Bumper Plug for Color Code L1159 © Trynex International 2006 4 — 22...
  • Page 23 Butt Connectors D 6513 CHMSL Vehicle Harness D 6523 Scotch Locks D 6560 Hex Head Screw White Positive (+) D 6561 Cable Mounts Black Ground (–) Splice into vehicle harness stop lamp/CHMSL circuit. © Trynex International 2006 L1159 4 — 23...
  • Page 24 D 4121 3/8 - 16 x 1" Hex Bolt D 4124 3/8" Lock Nut D 6503 Ratchet Strap D 6536 Adj. Stop Bracket RT D 6537 Adj. Stop Bracket LT D 6855 Tarp L1159 © Trynex International 2006 4 — 24...
  • Page 25 Step 9: Connect the spreader power cord to vehicle main power plug mounted at rear of vehicle (see Electrical Installation). Step 10: Connect Center High Mount Stop Lamp (CHMSL) cord from the spreader to mating half attached to vehicle (see Electrical Installation). © Trynex International 2006 L1159 4 — 25...
  • Page 26 • The Vibrator Switch is needed for dense material or to increase the flow to the auger. This eliminates bridging of material in hopper. • In case spreader becomes jammed, it will go into an auto-reverse program to free itself. Auger display will show (AR) while t rying to clear obstruction. L1159 © Trynex International 2006 4 — 26...
  • Page 27 • If you are using a sand/salt mixture, remove baffle extension. Part No. Description Qty. D 6847 Salt Baffle Extension D 6807 Discharge Baffle D 6874 #14 x 1-1/2" TEK w/Neo Washer © Trynex International 2006 L1159 4 — 27...
  • Page 28 • You may repeat Steps 1 & 2 for a second and third time. • If after the third try the controller displays “OL” — you must extract the material that is causing the problem. • Follow all warning directions when clearing jams. L1159 © Trynex International 2006 4 — 28...
  • Page 29 Motor is not getting power. Turn off. Check all connections. display shows EO. Audible alarm beeping Vehicle battery is extremely low, Turn off. Charge battery. display shows LB. or a poor connection exists. © Trynex International 2006 L1159 4 — 29...
  • Page 30 BAD CONTROLLER TO BLUE WIRE LIGHTS NO DISPLAY CHECK WITH TEST KIT NOTHING HAPPENS BAD CONTROLLER NO DISPLAY CHECK POWER SOURCE ON/OFF SWITCH WILL TO CONTROLLER CHECK WITH TEST KIT NOT LIGHT UP L1159 © Trynex International 2006 4 — 30...
  • Page 31 MATERIAL VIBRATOR FLOW INCREASE AUGER SPEED MATERIAL ISSUE * Spreader capable of speading most granular bulk material, including coarse 50/50 salt/sand mix. NOTE: Optional Optimum Flow Kit Available, To Increase Material Flow © Trynex International 2006 L1159 4 — 31...
  • Page 32 If motor cover is removed for any reason, use silicone sealant to ensure weather proofing of enclosure. • Grease bearings after every 20 hours use. • After first use, tighten all nuts and bolts on spreader and mount. • WARNING: Never remove spreader with material in hopper. L1159 © Trynex International 2006 4 — 32...
  • Page 33 3/4-10 7/8-9 Metric Grade 8.8 (ft.-lb.) SIZE TORQUE SIZE TORQUE M 12 M 14 M 10 M 16 These torque values apply to mount assembly fasteners except those noted in the instruction. © Trynex International 2006 L1159 4 — 33...
  • Page 34 NO DEALER HAS AUTHORITY TO MAKE ANY REPRESENTATION OR PROMISE ON BEHALF OF TRYNEX INTERNATIONAL, OR TO ALTER OR MODIFY THE TERMS OR LIMITATIONS OF THIS WARRANTY IN ANY WAY. L1159 ©...
  • Page 35 NOTE: I have read the owner’s manual and all safety precautions and I understand that this equipment could be dangerous if not operated with care and under the proper conditions. 14) Owner’s signature: PLEASE FOLD AND SEAL WITH TRANSPARENT TAPE BEFORE MAILING. © Trynex International 2006 L1159 4 — 35...
  • Page 36 Warm Up to with a F R E E F R E E Winter Hat! Simply Fill Out Your Warranty Registration and Return It to the Factory! From: Postage Required Post Office will not deliver without proper postage. 23455 REGENCY PARK DR. WARREN MI 48089-2667...
