TrynEx International, LLC, 531 Ajax Drive, Madison Heights, MI 48071‑2429 • www.snowexproducts.com
June 1, 2016
Lit. No. 70440, Rev. 01
Bulk Pro™ 1575, Bulk Pro 1875
Low‑Profile Tailgate Spreader
SP‑1575‑1, SP‑1875‑1
Owner's Manual
CAUTION
Read this manual before installing or operating
the spreader.
This manual is for SnowEx
®
Bulk Pro spreaders with serial numbers
beginning with 160501 and higher.
This document supersedes all editions with an earlier date.
Advertisement
Table of Contents
Related Manuals for Trynex International SnowEx Bulk Pro 1875
Summary of Contents for Trynex International SnowEx Bulk Pro 1875
- Page 1 TrynEx International, LLC, 531 Ajax Drive, Madison Heights, MI 48071‑2429 • www.snowexproducts.com June 1, 2016 Lit. No. 70440, Rev. 01 Bulk Pro™ 1575, Bulk Pro 1875 Low‑Profile Tailgate Spreader SP‑1575‑1, SP‑1875‑1 Owner's Manual CAUTION Read this manual before installing or operating the spreader.
-
Page 3: Table Of Contents
TABLE OF CONTENTS OPERATING THE SPREADER ........ 13 INTRODUCTION ............5 Owner's Information Form ........5 Driving and Spreading on Snow and Ice .... 13 SAFETY INFORMATION ..........6 Powering the Control .......... 14 Safety Definitions ..........6 Starting and Stopping Spreader ......14 Warning/Caution Labels ........ -
Page 5: Introduction
INTRODUCTION Warranty Registration This manual has been prepared to acquaint you with the safety information, operation and maintenance of your new tailgate spreader. Please read this manual ® Follow the directions on the SnowEx Warranty carefully and follow all recommendations. This will Registration and Customer Survey form included in help ensure profitable and trouble-free operation of ... -
Page 6: Safety Information
SAFETY INFORMATION SAFETY DEFINITIONS WARNING/CAUTION LABELS Please become familiar with the Warning and Caution WARNING labels on the spreader. Indicates a potentially hazardous situation NOTE: If labels are missing or cannot be read, see that, if not avoided, could result in death or serious personal injury. -
Page 7: Serial Number Label
SAFETY INFORMATION SERIAL NUMBER LABEL TrynEx International, LLC 531 Ajax Drive Madison Heights, MI 48071 Definition Code LOW-PROFILE TAILGATE SPREADER 2-Digit Year 2-Digit Month YYMMDDLLXXXXZZZZ 2-Digit Day 2-Digit Location Code YYMMDDLLXXXXZZZZZ XXXX 4-Digit Sequential Number 5−7-Digit Assembly Part Number ZZZZZZ Lit. No. 70440, Rev. 01... -
Page 8: Safety Precautions
SAFETY INFORMATION SAFETY PRECAUTIONS CAUTION • Do not operate a spreader in need of Improper installation and operation could cause maintenance. personal injury and/or equipment and property • Before operating the spreader, reassemble damage. Read and understand labels and the any parts or hardware removed for cleaning Owner's Manual before installing, operating or making or adjusting. -
Page 9: Fire And Explosion
SAFETY INFORMATION FIRE AND EXPLOSION FUSES The spreader electrical system contains several WARNING blade-style automotive fuses. If a problem should Gasoline is highly flammable and gasoline occur and fuse replacement is necessary, the vapor is explosive. Never smoke while replacement fuse must be of the same type and working on vehicle. -
Page 10: Loading
LOADING APPROXIMATE MATERIAL WEIGHTS This Manual covers vehicles which have been recommended for carrying the spreader. Please see your local dealer for proper vehicle applications. WARNING Overloading could result in an accident or CERTIFICATION damage. Do not exceed GVWR or GAWR WARNING as found on the driver-side cornerpost of vehicle. -
Page 11: Mounting The Spreader
MOUNTING THE SPREADER MODEL 1875 CAUTION During removal or mounting, securely grip Mounts are sold separately for the model 1875 spreader to avoid dropping. spreader. Refer to the instructions packed with the selected mount. The spreader shall be installed according to instructions supplied. -
Page 12: License Plate Installation
MOUNTING THE SPREADER LICENSE PLATE INSTALLATION (IF REQUIRED) Install the license plate to the mounting holes in the frame using two 1/4" x 1/2" machine screws and two 1/4" locknuts. License Plate Mounting Holes Model 1575 Model 1875 (2 Options) Lit. -
Page 13: Operating The Spreader
OPERATING THE SPREADER DRIVING AND SPREADING ON SNOW Here are some tips for driving in these conditions: AND ICE • Drive defensively. • Do not drink, then drive or spread ice-control CAUTION materials. Drinking and then driving or spreading is •... -
Page 14: Powering The Control
OPERATING THE SPREADER – CAB CONTROL If any button is pressed on the control, it will wake and WARNING check again for spreader connection. If no spreader is Never operate equipment when under the detected, it will act as described above. If a spreader influence of alcohol, drugs, or medications that is detected, it will transition to Ready Mode. -
Page 15: Controlling Material Application
OPERATING THE SPREADER – CAB CONTROL CONTROLLING MATERIAL APPLICATION Ready Mode The material application settings can be adjusted Vehicle ignition is set to ACC or ON; cab control is OFF. while spreader is ON or OFF. Settings are shown by Control has power. -
Page 16: Cab Control Codes
OPERATING THE SPREADER – CAB CONTROL CAB CONTROL CODES Setup Codes Definition Code Procedure Calibrate the Empty Hopper setting. With control in ON mode, press and hold the left control knob until the Cb code displays. Calibration cycle is automatic.* Clear calibration data for Empty Hopper Press the right control knob to clear all calibration data during the setting;... - Page 17 OPERATING THE SPREADER – CAB CONTROL Error Codes – Spreader Operation Stopped – continued Code Definition Suggested Solution Possible Cause Not applicable to tailgate Not applicable to tailgate Reset the control by pressing the ON/OFF spreaders. See suggested spreaders. button. If CP code continues to display, contact solution.
-
Page 18: Setup Procedures
OPERATING THE SPREADER – CAB CONTROL SETUP PROCEDURES Adjust LED Brightness Level (LS and SL Codes) Calibrate the Empty Hopper Setting The brightness setting of the cab control lights can be (Cb and EH Codes) adjusted from 1 to 16. The factory default setting is 8. Calibrating the empty hopper setting enables the cab 1. -
Page 19: Auto-Reverse Feature
OPERATING THE SPREADER AUTO‑REVERSE (Ar) FEATURE VIBRATOR FUNCTION The spreader, after initial setup, is automatically able A heavy-duty vibrator is standard equipment on the to sense and clear material jams. The sensitivity level model 1575 and 1875 spreaders. Turn the vibrator ON as needed to keep dense material flowing and prevent ... -
Page 20: Maintenance
MAINTENANCE AFTER EACH USE WARNING Never remove the spreader with material in CAUTION the hopper. DO NOT leave unused material in hopper. Material can freeze or solidify, CAUTION causing unit to not work properly. Disconnect electric power at spreader Empty and clean after each use. electrical wiring harness connection and tag out if required before servicing or performing •... -
Page 21: Harness Wiring Diagram
HARNESS WIRING DIAGRAM Cab Control 18 ga Red 4-Way Connector To Vehicle Switched Accessory To Vehicle CHMSL Signal Vehicle Control Harness (tap located in cab) Connectors 18 ga Shielded Twisted-Pair Cable 6 ga Red 50 Amp Fuse 6 ga Red 12 ga Black 6 ga Black Vehicle... -
Page 22: Troubleshooting Guide
TROUBLESHOOTING GUIDE Please see your distributor for service. The troubleshooting reference table below may guide you in diagnosing the issue. For a reference table of the cab control error codes, see the "Operating the Spreader – Cab Control" section of this manual. - Page 23 TROUBLESHOOTING GUIDE Suggested Solution Problem Possible Cause Unplug the spreader harness and tag out, if required, before performing any of the following repairs. 1. Open access cover and check motor, 1. Electrical connections are loose. harness and module connections. Motor does not run. 2.
- Page 24 TrynEx International outlets or spreader owner is granted. TrynEx International reserves the right under its product improvement policy to change construction or design details and furnish equipment when so altered without reference to illustrations or specifications used. TrynEx International or the vehicle manufacturer may require or ...
