DSC Power608 PC5008 Installation Manual

DSC Power608 PC5008 Installation Manual

Dls2002 software and higher
Hide thumbs Also See for Power608 PC5008:
Table of Contents

Advertisement

Quick Links

Download this manual
WARNING
This manual contains information on limitations regarding product use and function and information on the
limitations as to liability of the manufacturer. The entire manual should be carefully read.
Installation
Manual
PC5008 v3.0 / DLS2002 and higher
See Back Cover for New Features in Version 3.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Power608 PC5008 and is the answer not in the manual?

Questions and answers

Related Manuals for DSC Power608 PC5008

Summary of Contents for DSC Power608 PC5008

  • Page 1 WARNING This manual contains information on limitations regarding product use and function and information on the limitations as to liability of the manufacturer. The entire manual should be carefully read. Installation Manual PC5008 v3.0 / DLS2002 and higher See Back Cover for New Features in Version 3.0...

  • Page 2: Please Read Carefully

    Locks and latches on windows and doors must be secure and operate as intended. Windows, doors, walls, from DSC. Custom products are only warranted to the extent that they do not function upon deliv- ceilings and other building materials must be of sufficient strength and construction to provide the level of ery.

  • Page 3: Table Of Contents

    Table of Contents Section 1: System Introduction 5.4 Assigning Keypad Zones ..........17 1.1 Specifications ................1 5.5 Communicator – Dialing ..........17 1.2 Additional Devices ..............2 5.6 Communicator – Account Numbers ......17 1.3 Out of the Box ...............2 5.7 Communicator – Telephone Numbers ......17 5.8 Communicator –...
  • Page 4 PC5008 Wiring Diagram...

  • Page 5: Section 1: System Introduction

    Section 1: System Introduction 1.1 Specifications • Two account numbers • Supports LINKS1000 cellular communication Downloading Software Support • Supports LINKS2X50 long range radio transmitter • PC5008 v3.0 uses DLS 2002 and higher • DTMF and pulse dialing Flexible Zone Configuration •...

  • Page 6: Additional Devices

    LINKS. In addition to the information below, see the back cover for a DSC module compatibility table. LINKS2X50 Either the LINKS2150 or LINKS2450 may be used to transmit PC5102-433 Wireless Receiver alarm information over a long range radio network.

  • Page 7: Section 2: Getting Started

    After you have attached the Connect the RED battery lead to the positive battery terminal; cabinet to the wall, stick the provided DSC logo sticker on the connect the BLACK lead to negative. front of the cabinet.

  • Page 8: Keybus Operation And Wiring

    Programmable Output Terminals – PGM1 and PGM2 (YEL) and green (GRN) terminals are clock and data respec- tively. PGM1 can sink up to 50mA or 300mA (depending on the PGM NOTE: The four Keybus terminals of the panel must be con- build option) of current.

  • Page 9: Keypad Assignment

    G e t t i n g S t a r t e d : 2 . 5 K e y p a d A s s i g n m e n t 2.5 Keypad Assignment 2.8 Zone Wiring There are eight available slots for keypads.

  • Page 10: Fire Zone Wiring

    2.11 LINKS Zone Wiring LINKS Support When using the LINKS1000 cellular communicator, con- nect the LINKS to the main panel according to the fol- lowing diagram: NOTE: This option can only be selected if Normally Closed (NC) detection devices or contacts are being used. NOTE: Only one NC contact can be connected to each zone.

  • Page 11: Keypad Zones

    G e t t i n g S t a r t e d : 2 . 1 2 K e y p a d Z o n e s 2.12 Keypad Zones Each “z” keypad on the system has a zone input to which a device - such as a door contact - can be connected.

  • Page 12: Section 3: Keypad Commands

    Section 3: Keypad Commands Use any system keypad to enter commands and/or program the panel will do nothing until the next day at the auto-arm the PC5008 security system. The LED keypad uses function time, when it will check the system again. If the system is dis- and zone indicator lights to represent alarm functions and sta- armed at the auto-arm time, the panel will sound the buzzer of tus.
  • Page 13 K e y p a d C o m m a n d s : 3 . 4 [ * ] C o m m a n d s [*][2] Trouble Display When using an LCD keypad, the trouble conditions will be The panel constantly monitors itself for several different trou- listed on the display.
  • Page 14 [*][4] Door Chime On/Off codes are silent. To do this, enable attribute [7] on all access codes associated with wireless keys. The door chime feature is used to sound a tone from the key- pad whenever a zone programmed as a chime zone is acti- NOTE: If you enable the Bell Squawk on Arming/Disarming vated.

  • Page 15: Function Keys

    K e y p a d C o m m a n d s : 3 . 5 F u n c t i o n K e y s 3.5 Function Keys Brightness Control You can select from 10 different backlighting levels. Use the There are five function keys on each keypad labelled Stay, arrow keys (<...

  • Page 16: Features Available For The Lcd5500Z

    [13] [*][7][1] Command Output Option #1: A valid access code may need to be entered. [14] [*][7][2] Reset (Command Output Option #2): As described above. [15] General Voice Prompt Help: This feature can only be programmed if both the Escort5580 and the PC5928 Audio Matrix module are being used.

  • Page 17: Section 4: How To Program

    Section 4: How to Program The following section of the manual describes the Installer’s 4.2 Programming Decimal Data Programming function and how to program the various sec- A set number of programming boxes are allotted for each sec- tions. tion requiring decimal data (e.g.: codes, telephone numbers). NOTE: Read the following section of the manual very carefully If a digit is entered for each program box, the panel will auto- before you begin programming.

  • Page 18: Programming Toggle Option Sections

    4.4 Programming Toggle Option Sections Some programming sections contain several toggle options. The panel will use zone lights 1 through 8 to indicate if the dif- ferent options are enabled or disabled. Press the number cor- responding to the option to turn it ON or OFF. Once all the toggle options have been selected correctly, press the [#] key to exit the section and save the changes.

  • Page 19: Section 5: Program Descriptions

    Section 5: Program Descriptions The following section explains the operation of all programma- [02] Delay 2 Zone ble features and options and provides a summary of all corre- The Delay 2 entry delay time can be set independently of sponding programming locations. Delay 1 in programming section [005] (System Times).

  • Page 20: Zone Attributes

    A violated Fire zone will be displayed on all keypads and can “LINKS Zone Wiring” ) Refer to the LINKS1000 Installation Manual for more information. be delayed at any keypad. Typically this zone is used for latching smoke detectors. NOTE: Do not wire LINKS Answer zones on keypad zone ter- minals.

  • Page 21: Assigning Keypad Zones

    P r o g r a m D e s c r i p t i o n s : 5 . 4 A s s i g n i n g K e y p a d Z o n e s NOTE: Any zone with the wireless attribute enabled will not the system is disarmed.

  • Page 22: Communicator - Reporting Codes

    NOTE: Telephone numbers can be up to 32 digits. This allows secured, regardless of whether or not the alarm output is you to add special digits if required. To program the telephone active. number, enter the numbers 0 through 9 as required. The fol- NOTE: 24-hr type zones will report the restoral immediately lowing is a list of programmable HEX digits and the functions when the zone is secured.

  • Page 23: Communicator - Reporting Formats

    P r o g r a m D e s c r i p t i o n s : 5 . 9 C o m m u n i c a t o r – R e p o r t i n g F o r m a t s When Delinquency Follows Zone Activity (hours) is grammed as a ‘0’.

  • Page 24: Downloading

    2. If the reporting code for an event is programmed as any- Post Dial Wait for Handshake Timer ..Section [161] thing from [01] to [FF], the panel will automatically gener- ate the zone or access code number. 5.10 Downloading If the SIA Sends Programmed Reporting Codes option is The required downloading software is DLS 2002, with the...

  • Page 25: Pgm Output Options

    P r o g r a m D e s c r i p t i o n s : 5 . 1 1 P G M O u t p u t O p t i o n s NOTE: When a zone status upload is performed through PC- Once an access code is entered to arm the system and the LINK, the information uploaded may not be accurate.
  • Page 26 [6]..Priority (Gas, Heat, Sprinkler and 24-hr Latching NOTE: Only ONE of options [03] Sensor Reset and [20] [*][7][2] Command Output Option #2 may be programmed on Zones) the same system. [7]..Holdup (Holdup zones) [23] Silent 24 Hour (PGM2 Only) [8]..

  • Page 27: Telephone Line Monitor (Tlm)

    P r o g r a m D e s c r i p t i o n s : 5 . 1 2 T e l e p h o n e L i n e M o n i t o r ( T L M ) 5.12 Telephone Line Monitor (TLM) Transmission cycle will be counted in minutes or days.

  • Page 28: Arming/Disarming Options

    [F] Key Enable..... . . Section [015]: [1] Quick Arm Enable....Section [015]: [4] [P] Key Audible Bell and Buzzer .

  • Page 29: Swinger Shutdown

    P r o g r a m D e s c r i p t i o n s : 5 . 1 9 S w i n g e r S h u t d o w n Audible Exit Fault Enabled/ Disabled..Section [013]: [6] also come on if a key is pressed or, if a valid access code is Bell Squawk Options .

  • Page 30: Additional System Modules

    NOTE: You may need to program an additional Delay Between 5.27 Additional System Modules Dialing Attempts in order to ensure proper LINKS1000 operation. The following modules are programmed through the module NOTE: If a LINKS1000 is connected to the system, make sure programming sections [801]-[804]: the PC5400 Printer mod- the Maximum Number of Dialing Attempts is programmed to ule, the PC59XX Audio Interface module, the Links2X50 Long-...

  • Page 31: Installer's Lockout

    4. Apply AC power to the main panel. When any zone is violated the panel will activate the Bell Out- put for two seconds, log the event to the event buffer and 5. When Zone Light 1 is lit on the keypad the default is com- communicate the alarm to central station.

  • Page 32: Section 6: Programming Worksheets

    Se ct ion 6 : Prog ram mi n g Work s he e ts For the Record Customer: _______________________________________________________________________________________________________ Address: ________________________________________________________________________________________________________ Telephone: ___________________________________________ Installation Date: ___________________________________________ Installer’s Code: __________________________________________________________________________________________________ Module Name Description Location PC5008 Main Panel I________________________________________________________________________________________________________________I PC5132 Wireless Receiver I________________________________________________________________________________________________________________I PC5204 Power Supply Module...
  • Page 33 P r o g r a m m i n g W o r k s h e e t s Zone Programming Summary Zone programming can be found in sections [001] - [004], [101] - [132], [020] and [202] - [205]. Use this area to record a sum- mary of your zone programming.

  • Page 34: Keypad Programming

    Keypad Programming [000] Keypad Enrollment (Section 2.5 “Keypad Assignment”) NOTE: This must be done at each keypad requiring programming. [0] Slot [Valid entries are 11-18; i.e. enter [11] for slot 1, [12] for slot 2, etc.] [1] Function Key 1 Assignment (Valid entries are 00-21) [2] Function Key 2 Assignment (Valid entries are 00-21) [3] Function Key 3 Assignment (Valid entries are 00-21) [4] Function Key 4 Assignment (Valid entries are 00-21)
  • Page 35 P r o g r a m m i n g W o r k s h e e t s NOTE: Zones 9-32 are only available for wireless zones. [002] Zone 9-16 Definitions (Section 5.2 “Zone Programming”) Default Default Zone 9 Zone 13 I_______I_______I...
  • Page 36 [010] PC5208 PGM Output Programming (PGM 3-10) (Section 5.11 “PGM Output Options”) Default Default PGM 3 PGM 7 I_______I_______I I_______I_______I PGM 4 PGM 8 I_______I_______I I_______I_______I PGM 5 PGM 9 I_______I_______I I_______I_______I PGM 6 PGM 10 I_______I_______I I_______I_______I Program PGM Option Attributes in sections [143] - [150]. [011] PC5204 PGM Output Programming (PGM 11-14) (Section 5.11 “PGM Output Options”) Default...
  • Page 37 P r o g r a m m i n g W o r k s h e e t s [016] Fourth System Option Code Default Option Section AC Trouble Displayed AC Trouble Not Displayed I________I Trouble Light Flashes if AC Fails Trouble Light Does Not Follow AC Status I________I Blank Keypad When Not Used...
  • Page 38 Advanced System Programming Zone Attributes (Section 5.3 “Zone Attributes”) Zone Attribute Defaults (Y = Option ON; N = Option OFF): Attribute: Audible Steady Chime Bypass Force Swing Tx. Delay Wireless Zn. Silent Pulsed Zone Type: 00 Null Zone 01 Delay 1 02 Delay 2 03 Instant 04 Interior...
  • Page 39 P r o g r a m m i n g W o r k s h e e t s [116] I________I I________| I________| I________| I________| I________| I________| I________I [117] I________I I________| I________| I________| I________| I________| I________| I________I [118] I________I I________| I________|...
  • Page 40 Section PGM Output Type* Main Board [141] I________I I________| I________| I________| I________| I________| I________| I________I [142] I________I I________| I________| I________| I________| I________| I________| I________I PC5208 [143] I________I I________| I________| I________| I________| I________| I________| I________I [144] I________I I________| I________| I________| I________| I________| I________| I________I...

  • Page 41: Communicator Programming

    P r o g r a m m i n g W o r k s h e e t s Communicator Programming NOTE: For sections [301] to [353], the content of every section by default is [F]. [301] First Telephone Number (32 Digits) (Section 5.7 “Communicator –...
  • Page 42 Tamper Restoral Reporting Codes, Zones 1-8 (Section 5.8 “Communicator – Reporting Codes” & Appendix A) Section [334] Zone 1 Zone 2 Zone 3 Zone 4 Zone 5 Zone 6 Zone 7 Zone 8 I_______I_______I I_______I_______I I_______I_______I I_______I_______I I_______I_______I I_______I_______I I_______I_______I I_______I_______I [335] Zone 9...
  • Page 43 P r o g r a m m i n g W o r k s h e e t s [350] Maintenance Restoral Reporting Codes (Section 5.8 “Communicator – Reporting Codes” & Appendix A) 1. Battery Trouble Restoral 5. Auxiliary Power Supply Trouble Restoral I_______I_______I I_______I_______I 2.
  • Page 44 [367] System Maintenance Alarm/Restore Communicator Call Directions (Section 5.5 “Communicator – Dialing”) Default Option 1st Telephone Number Disabled I________I 2nd Telephone Number Disabled I________I 1st Telephone Number (via LINKS) Disabled I________I 2nd Telephone Number (via LINKS) Disabled I________I For future use I________I [368] System Test Transmissions Communicator Call Directions (Section 5.5 “Communicator –...

  • Page 45: Downloading Options

    P r o g r a m m i n g W o r k s h e e t s [381] Second Communicator Option Code Default Option ON Section Open After Alarm Kypd Ringback enabled Open After Alrm Kypd Ringback disabled 5.17 I_______I Open After Alarm Bell Ringback enabled...
  • Page 46 International Programming [700] Clock Adjust (Section 5.28 “Clock Adjust”) Default: 60 (Valid entries are 01-99 seconds) I_______I_______I [701] First International Options Code Default Option Section 50 Hz AC 60 Hz AC I_______I Time Base is Internal Crystal Time Base is AC Line 5.29 I_______I AC/DC Arming Inhibit enabled...

  • Page 47: Special Installer Functions

    P r o g r a m m i n g W o r k s h e e t s Module Programming [801] PC5400 Printer Module Programming Please refer to your PC5400 Installation Manual for installation and programming instructions. [802] PC59XX Audio Interface Programming Please refer to your PC59XX Installation Manual for installation and programming instructions.

  • Page 48: Appendix A: Reporting Codes

    A p p e n d i x A : R e p o r t i n g C o d e s The following tables contain Contact ID and Automatic SIA for- SIA Format - Level 2 (Hardcoded) mat reporting codes.
  • Page 49 R e p o r t i n g C o d e s Dialer Contact SIA Auto Rep Section # Reporting Code Code Sent When... Direction* ID Codes Codes** [350] TLM Restore Telephone line trouble restore MA/R (3) 51 LR-00 [349-350] Gen System Trouble/Rest.

  • Page 50: Appendix B: Programming Keypads

    Appendix B: Programming Keypads If you have an LCD5500Z keypad, additional programming is required for proper operation. All LCD programming is done per key- pad. If more than one LCD keypad are present on the system, labels programmed at one keypad can be broadcast to all other LCD keypads.
  • Page 51 [60] First User Display Mask Default Option Hold [P]anic Keys prompt ON Hold [P]anic Keys prompt OFF I_______I Zone Bypassing prompt ON Zone Bypass prompt OFF I_______I Troubles prompt ON Troubles prompt OFF I_______I Alarm Memory prompt ON Alarm Memory prompt OFF I_______I Door Chime Control prompt ON Door Chime Control prompt OFF...
  • Page 52 [66] Keypad Options Default Option Display Access Code when Programming Display ‘X’ when Programming I_______I Local Clock Display Enabled Local Clock Display Disabled I_______I Local Clock Displays 24-hr time Local Clock Displays AM/PM I_______I Auto Alarm Memory Scroll Enabled Auto Alarm Memory Scroll Disabled I_______I Local Display of Temperature Enabled* Local Display of Temperature Disabled...
  • Page 53 R e p o r t i n g C o d e s : 5 . 3 3 Daylight Savings Time Programmable Labels Refer to the following chart: Zone labels and other LCD display identifiers can be customized to [1] - A, B, C, 1 [6] - P, Q, R, 6 make operation of the system easier for the end user.
  • Page 54 [075] Fourth User Display Mask Default Option User Initiated Call-up prompt ON User Initiated Call-up prompt OFF I_______I Last Code to Disarm/Arm prompt ON Last Code to Disarm/Arm prompt OFF I_______I Walk Test Prompt ON Walk Test Prompt ON I_______I Command Output #1 prompt ON Command Output #1 prompt OFF I_______I...
  • Page 55 R e p o r t i n g C o d e s : 5 . 3 3 Daylight Savings Time Command Output Labels Default: “Command_O/P_1” - “Command_O/P_4” Program a label for each Command Output used, as it will appear at each partition. Section Partition Command Output...
  • Page 56 [997] View Software Version [998] Initiate Global Label Broadcast All LCD programming is done per keypad. If more than one LCD keypad are present on the system, and the PC5400 receives labels, labels programmed at one keypad can be broadcast to all other LCD keypads. Perform the following procedure in order to broadcast labels: Step 1 - Program one LCD keypad completely.
  • Page 57 N O T E S...
  • Page 58 N O T E S...

  • Page 59: Fcc Compliance Statement

    FCC COMPLIANCE STATEMENT CAUTION: Changes or modifications not expressly approved by Digital Security Controls Ltd. Equipment Maintenance Facility could void your authority to use this equipment. If trouble is experienced with this equipment PC5008, for repair or warranty information, please contact the facility indicated below.
  • Page 60 • Automatic clock adjustment for daylight savings time • Priority communications option • Revised zone indentifiers for Contact ID ©2002 Digital Security Controls Ltd. Direct all comments concerning this Toronto, Canada • www.dsc.com publication to pubs@dscltd.com Printed in Canada 29034580 R001...
