1030 Serial Ultrabay Enhanced device or travel bezel

For access, remove this FRU:
• "1010 Battery pack" on page 65
Table 11. Removal steps of Serial Ultrabay Enhanced device or travel bezel
Holding the bay lock latch in the unlocked position
2
, and then pull out the Serial Ultrabay Enhanced device or the travel bezel in the direction shown by arrow
3
to completely remove it
1
, slide the bay eject latch in the direction shown by arrow
4
.
.
Chapter 8 Removing and replacing a FRU
67
