STEP 1
DETERMINE HOOD AND DUCTWORK LOCATIONS
MARK LOCATION OF WOOD SUPPORT
Draw the line to ceiling height.
to the cooking surface, 30" min. to 36" max.
indicating the bottom of the hood.
measure 16" up and draw another line for the location
of the wood support.
measure 28" up and draw another line for the location
of the top of the hood. See illustration.
FOR VERTICAL (Straight Up) DUCTING:
hood to ceiling or soffit.
8-1/2"
HOUSE WIRING LOCATION:
and to the left of the centerline as shown in the
illustration.
31-2000730 Rev. 1
Installation Instructions
8-1/2" hole
2-3/4"
7"
2"
Top of Hood
Wood
Support
16"
Bottom of Hood
FOR DUCTING THROUGH REAR WALL:
Top of Hood
8-1/2" hole
Wood
Support
Bottom of Hood
Top of Hood
6"
6"
Wood
Support
28"
4-3/4"
Locate House Junction
Box Here
5
