Summary of Contents for Haier HC60BMB2
- Page 1 Built-in Integrated Rangehood and Wall Rangehood Wall Rangehood, Box Chimney HC60BMB2, HC90BMB2 Built-in Integrated Rangehood HPH60IMB2, HPH90IMB2 USER GUIDE NZ AU...
-
Page 3: Table Of Contents
CONTENTS Safety and Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . First Use . -
Page 5: Safety And Warnings
Integrated (HC60B) rangehoods must be installed onto secure cabinetry. 11 kg Weight of the products are: (HC90B) • HC60BMB2 is 9kg 9 kg • HC90BMB2 is 11kg (HPH60I) 12 kg • HPH60IMB2 is 9kg (HPH90I) •... - Page 6 SAFETY AND WARNINGS If the supply cord of this equipment is damaged, it must only be replaced by the manufacturer, its service agent or similarly qualified person in order to avoid a hazard. Ducting accessories are not supplied. All ducting must comply with local requirements and building codes.
- Page 7 COOKING CONSIDERATIONS Installation with Induction Cooktop Induction cooktops use energy-efficient technology that only heats the contents of a cooking pot, not the surrounding air . As a result, there is more likelihood of condensation on rangehood filters, splashbacks and surrounding cabinetry than when you use traditional electric or gas cooktops . Other factors that influence condensation are room temperature, humidity, natural ventilation of the room, size of the cookware and how the induction cooktop is being used .
-
Page 8: First Use
FIRST USE CONTROL PANEL Press to turn the rangehood on/off. The lights and turns LOW FAN SPEED Power on automatically . Press to change to , it illuminates to indicate fan speed has LOW FAN SPEED Low fan speed been selected . Press to change to , it illuminates to indicate fan speed... -
Page 9: Standard Use
STANDARD USE Turning on the Rangehood Press to turn rangehood on . POWER The lights and will LOW FAN SPEED turn on automatically . Fan Speed There are 3 fan speed settings, LOW FAN SPEED, MID FAN SPEED HIGH FAN SPEED Boost , hold down BOOST... - Page 10 STANDARD USE Lights For lights press the button LIGHT to turn on/off . Lights can be turned on/off independently of rangehood power . Wi-Fi/App connection Connect to the to be WI-FI/APP able to control remotely . Refer 'WI-FI/APP CONNECTION' more information . Hob-to-Hood Hob-to-Hood connects the rangehood to the cooktop .
- Page 11 STANDARD USE Extraction+ Extraction+ filters the air and helps remove cooking smells once a cook is finished . It will continue to extract on the last fan speed selected and will automatically turn off after 5 minutes . Hold button for 3 seconds POWER until the Power icon flashes, flashing indicates the Extraction+ has...
-
Page 12: Wi-Fi/App Connection
WI-FI/APP CONNECTION Your rangehood can be connected to your home wireless network and operated remotely using the Smart HQ app . Getting started Ensure your home Wi-Fi network is turned on . You will be given step by step guidance on your mobile device . It may take up to 10 minutes to connect your appliance . - Page 13 WI-FI/APP CONNECTION Disconnecting from your home Wi-Fi 1. Hold for 3 seconds the LIGHT button and button HOB-TO-HOOD together . The flashing light indicates paring mode . 2. The Wi-Fi/App icon light will continue flashing, after 15 minutes the connection will then disconnect, and the Wi-Fi/App light will turn off .
-
Page 14: Hob-To-Hood
HOB-TO-HOOD This feature enables a compatible Haier rangehood to be paired with your Haier cooktop . Once paired the extraction speed automatically adjusts based on the cooktop power level . Ensure you are connected to Hob-to-Hood to use Auto and Manual modes (the product can still be used without Hob-to-Hood connection, refer to for more information . - Page 15 HOOD-TO-HOB CONNECTION 1. Press and hold the cooktop button for 3 seconds HOB-TO-HOOD until the icon beeps and flashes 0 .5s on/off . 2. On the rangehood press and hold for 3 seconds until the button until the icon HOB-TO-HOOD beeps and flashes 0 .5s on/off .
-
Page 16: Auto
AUTO Reconnect to Auto 1. From mode press the MANUAL button on the HOB-TO-HOOD cooktop to reconnect mode . AUTO 2. Once in the rangehood and AUTO cooktop icon will have HOB-TO-HOOD a constant illumination . Auto to Manual To disconnect the rangehood from mode, press any button except AUTO button . -
Page 17: Maintenance
CARE AND CLEANING WARNING! Before servicing or cleaning your rangehood, switch the power off at the control panel and disconnect the power to prevent power from being switched on accidentally. Allow the appliance to cool after the power has been turned off before servicing. There is a risk of fire if cleaning is not carried out in accordance with these instructions. -
Page 18: Aluminium Filters
ALUMINIUM FILTERS HC60BMB2/HC90BMB2 1. Remove any protective film around the perimeter of new grease filters. 2. Angle the filter into the slots at the back of the hood . 3. Push the button on the handle of the filter . -
Page 19: Carbon Filters
CARBON FILTERS Carbon filters are optional and for use in recirculation mode only . They are disposable and must be replaced at least every three months to ensure the performance of the rangehood . In the event of a fire, grease- laden filters could be flammable . -
Page 20: Trouble Shooting
TROUBLE SHOOTING If there is a problem with your rangehood, please check the following points before contacting your local Haier trained and supported service technician or the Customer Care Centre . PROBLEM POSSIBLE CAUSES WHAT TO DO The external motor The thermal protector has Turn off the rangehood. - Page 21 TROUBLE SHOOTING PROBLEM POSSIBLE CAUSES WHAT TO DO CONNECT TO WIFI/APP Wi-Fi is not Not enough time allowed The connection process can take up to 10 minutes . Try to connect again connecting Internet connection is off or Check that your modem is connected and working . the network is bad HOB TO HOOD Rangehood does...
-
Page 22: Parts And Acessories
PARTS AND ACESSORIES ITEM REFERENCE NUMBER HC60BMB2/HC90BMB2 Aluminium filter H0530090426 (HC60BMB2) H0530090422 (HC90BMB2) Chimney extension 900mm H0530073719 (HC60BMB2) H0530073719 (HC90BMB2) Recirculation carbon filters H0530060509 T-shape recirculation outlet kit H0530062211 HPH60IMB2/HPH90IMB2 Aluminium filter H0530090406 (HPH60IMB2) H0530090413 (HPH90IMB2) Recirculation carbon filters H0530060509... -
Page 23: Manufacturer's Warranty
. You must produce both warranty card and proof of purchase in the event of a warranty repair being required . When you purchase any new Haier Product you automatically receive a two year Manufacturer's Warranty covering parts and labour for servicing . - Page 24 MANUFACTURER'S WARRANTY Note: This Warranty is an extra benefit and does not affect your legal rights and applies only to product purchased in New Zealand and Australia . Please keep this Warranty Card in a safe place . For Australian customers: Our goods come with guarantees that cannot be excluded under the Australian Consumer Law .
-
Page 25: Customer Service
CUSTOMER SERVICE We recommend our Haier Customer Service and the use of original spare parts . If you have a problem with your appliance, please first check TROUBLESHOOTING . If you cannot find a solution there, please contact: Your local dealer The Service &... - Page 26 WWW .HAIER .COM .AU WWW .HAIER .CO .NZ 432390A H0530090423 H0530090409 07.24...
