- Page 1 Range Hood Model:HIH-V60HM-C HIH-V75HM-C HIH-V90HM-C INSTALLATION GUIDE/USER GUIDE...
-
Page 2: Table Of Contents
The models shown in this user guide may not be available in all markets and are subject to change at any time. For current details about model a -nd specification availability in your country, please contact your local Haier dealer. -
Page 3: Introduction
INTRODUCTION Thank-you for purchasing a Haier range hood. This user guide explains the features and functions, and will help you get the most out of your range hood. We hope you enjoy your new range hood. -
Page 4: Safety And Warnings
SAFETY AND WARNINGS ！ WARNINGS Electric Shock Hazard Read and follow the safety and warnings outlined in this user guide before operating this appliance. Never touch the power plug or electrical components, or manipulate the power switch with wet hands. Altering of the internal wiring is strictly prohibited, unless performed by professional maintenance personnel. - Page 5 ● If the power supply cord is damaged, it must only be replaced by your Haier trained and supported service technician or qualified person. ● Use a dedicated power outlet; the power cord must not be connected to an extension cord or multi-socket power board.
-
Page 6: Installation Instructions
INSTALLATION INSTRUCTIONS Installation WARNING! This product is heavy and requires two persons for installation. WARNING! Failure to install the screws or fixing device in accordance with these instructions may result in electrical hazards. The range hood must have secure grounding. It has a 3-pin plug. The plug must be connected to a socket with grounding.The grounding could offer an electricity circuit to avoid electric shock caused by electricity leakage. - Page 7 INSTALLATION INSTRUCTIONS ● The suitable height of mounting shall be 350-400mm above the cooking stove. The real installation height is subject to the construction of kitchen and user’s height. The installation instruction of gas stove has given the suitable installation distance, please take it into consideration. Fig.1 ●...
- Page 8 INSTALLATION INSTRUCTIONS 1. Install the wall plate ● Use an impact drill with a φ9 mm masonry bit to drill 40mm deep holes in the wall in the locations of the wall plate holes as shown in Fig.3. ● Fit the expansion plugs into the holes. ●...
- Page 9 INSTALLATION INSTRUCTIONS 3. Fix the chimney to the main unite ● Install 2pcs of self tapping screws to the mounting plate at the botton of the chimney, tighten the screws, make sure the botton of the chimney is well attached to the main body. Fix the other 2pcs of self tapping screws to the top of the chimney.
- Page 10 INSTALLATION INSTRUCTIONS 5.Connect the universal ducting hose ●Connect one end of ducting hose with the check valve and seal it. ●Connect the other end of the hose to a shared flue or external wall hole as shown in Fig8. ●The length of the universal ducting hose should not exceed 3 metres to prevent impact on venting performance.
-
Page 11: About Your Rangehood
ABOUT YOUR RANGEHOOD Technical Data LED Lamp 2x1.5W Type of Power Rated Voltage:220-240V Rated Frequency:50Hz Motor Rated Power Input 200W Heater Power Liner Motion Power Rated Power Input 257W Max Air Flow 1200m³ /h Noise 58dB(A) Max Air Pressure 310Pa Universal Ducting Hose Outer Diameter 150mm, Length 180mm Net Weight... -
Page 12: Operating Instructions-Control Panel
OPERATING INSTRUCTIONS - CONTROL PANEL CONTROL PANEL FEATURES 1.Press this button the hood will connect to electricity. 2.When fan is on, press this button the hood will enter Delay off mode and turns off in 3 minutes. 3.In Delay off mode press this button to turn off the hood. Touch this button on the panel, the cooker hood will start operating on LOW speed. - Page 13 OPERATING INSTRUCTIONS - CONTROL PANEL HEAT AUTO-CLEAN A unique "Heat Auto-Clean" function has been provided in this range hood. This range hood comes with an oil collector. During cooking, the oil and dirt may go into the oil collector. Over the time,some stubborn grease and oil can get stuck inside the range hood. This unique function was designed to eliminate the stubborn grease ane oil and keep the range hood clean.
-
Page 14: Cleaning And Maintenance
CLEANING AND MAINTENANCE We recommend following ‘Cleaning and maintenance’ instructions for safety and optimal performance of your range hood. Preparation for cleaning and maintenance ● Be sure to unplug the power cord before commencing cleaning or servicing of the range hood. ●... - Page 15 CLEANING AND MAINTENANCE Cleaning the filter(weekly) ● Remove oil collector (refer to instructions above). The lower glass panel is detacheble. Remove the lower glass panel by hands. ● ● Loosen the screws securing the filter. ● The filter should be washed in warm water with detergent and left to soak. Wipe clean with a rag and rinse with fresh water.
-
Page 16: Troubleshooting
Solutions for common faults In case of a fault, first try the suggestions below. If the problem cannot be fixed, please get in touch with your local Haier after-sales service centre. Only professional technicians may dismantle and repair the range hood. - Page 17 TROUBLESHOOTING PROBLEM POSSIBLE CAUSE WHAT TO DO Oil leak. Too much oil in the oil Remove waste oil in the oil collector. collector. Filter has not been Clean the filter in accordance with cleaned. the instructions. Main housing hasn't been Wipe the main housing every day cleaned.
- Page 18 Inspired Living Inspired Living...
