Summary of Contents for Haier HC60BMB2
- Page 1 Wall Rangehood, Box Chimney Black HC60BMB2 and HC90BMB2 Models INSTALLATION GUIDE NZ AU...
-
Page 3: Table Of Contents
CONTENTS Safety and Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Components Required . -
Page 5: Safety And Warnings
The rangehood must be installed 9 kg onto a solid wall, stud, beam or truss. (HC60) Weight of the products are: 11 kg • HC60BMB2 is 9kg (HC90) • HC90BMB2 is 11kg WARNING! Electric Shock Hazard Always disconnect the appliance from the mains power supply before carrying out any maintenance or repairs. - Page 6 SAFETY AND WARNINGS If the supply cord of this equipment is damaged, it must only be replaced by the manufacturer, its service agent or similarly qualified person in order to avoid a hazard. Ducting accessories are not supplied. All ducting must comply with local requirements and building codes.
-
Page 7: Components Required
2x Recirculation carbon filters 4x Screw (ST4 x 8mm) H0530060509 (not supplied) 1x Pair v-flap (150mm diameter) T-shape recirculation outlet kit 2x Black aluminium filters (HC60BMB2) H0530062211, includes: 3x Black aluminium filters (HC90BMB2) 1x T-shaped plastic outlet 1x Installation bracket... -
Page 8: Product Dimensions
PRODUCT DIMENSIONS Power Cord HC60BMB2 HC90BMB2 Overall height of product min . 550-max . 1030 min . 550-max . 1030 Overall height of product - recirculating min . 650-max . 1030 min . 650-max . 1030 Depth of chimney Overall depth of product... -
Page 9: Clearances
CLEARANCES HC60BMB2 and HC90BMB2 MINIMUM CLEARANCE Installation height Ducted min .550 - max .1030 Recirculation min .650 - max .1030 Height from top of cooktop to base of rangehood min .600 - max . recommended 750 This rangehood must be installed no lower than the minimum height indicated in the table above. Minimum installation height may be greater if required by the cooktop manufacturer or safety and warnings section on this user guide. -
Page 10: Venting Requirements
VENTING REQUIREMENTS Recirculate with carbon filters To enable the product to operate with the air recirculating, please purchase a recirculation diverter and carbon filters . The recirculation diverter is required to channel the air out the side vents at the top of the chimney and the carbon filters are required to remove odours . -
Page 11: Electrical Requirements
Before connecting the rangehood to the power supply, ensure the voltage and frequency indicated on the rating plate match that of the installation location: MODEL FREQUENCY VOLTAGE TOTAL POWER HC60BMB2 50 Hz 220-240 V 223 W HC90BMB2 50 Hz 220-240 V... -
Page 12: Preparing For Installation
PREPARING FOR INSTALLATION WARNING! This product is heavy and requires two persons for installation. Installation work and electrical wiring must be done by qualified person(s) in accordance with all applicable codes and standards. Failure to install the screws or fixing device in accordance with these instructions may result in electrical hazards. -
Page 13: Installation Chimney Mounting Brackets And Screws
INSTALLATION CHIMNEY MOUNTING BRACKETS AND SCREWS There are two installation methods available to attach rangehood to the wall . 1. Use the supplied brackets and screws . Refer to 'Bracket Attachment Points' for details . 2. Use the supplied screws . Refer to Screw Attachment Points' for details . -
Page 14: Bracket Attachment Points
Hood mounting bracket attachment point Lower rangehood attachment point HC60BMB2 and HC90BMB2 Inside chimney bracket attachment point width Inside chimney bracket attachment point height Hood mounting bracket attachment point width Hood mounting bracket attachment point height Outside chimney bracket attachment point width Outside chimney bracket attachment point height 27 .5... -
Page 15: Screw Attachment Points
Hole for hook (2*wall plugs+ 2*ST4*30mm screws) Safety hole (2*wall plugs+ 2*ST4*30mm screws) HC60BMB2 and HC90BMB2 Safety hole attachment point width Safety hole attachment point height Hook hole attachment point width Hook hole attachment point height 293 .5 Inside chimney hole attachment point width Inside chimney hole attachment point height 27 .5... -
Page 16: Installation Recirculation
INSTALLATION RECIRCULATION T-shaped plastic outlet ST 3x12mm screws 1. Attach the installation bracket to the T-shaped plastic outlet using 4 pcs ST3*12mm screws . installation bracket adjusted pipe 2. Adjust the width of the outlet to the width of the inside chimney and secure it using 2pcs ST3*12mm screws . - Page 17 INSTALLATION RECIRCULATION 4. Fix the inside chimney bracket to the wall with 2pcs ST4*30mm screws . Use wall plugs if required . Refer to 'Installation Chimney Mounting Brackets and Screws' for details on attaching chimney bracket to the wall . inside chimney 5.
-
Page 18: Carbon Filter
CARBON FILTER Carbon filters are for use in recirculating mode . They are disposable and must be replaced at least every three months to ensure the performance of the rangehood . In the event of a fire, grease-laden filters could be flammable . -
Page 19: Assembling V-Flap
ASSEMBLING V-FLAP Body - outer 1. Mount the two V-flap half-parts into the body . V-flap Body - inside 2. The pins should be facing upwards . 3. Insert the axis into the holes on the body . Body - inside... -
Page 20: Installation Rangehood
INSTALLATION RANGEHOOD ducting assembled v-flap in outlet 1. Place 150mm ducting around the rangehood outlet . 2. Fix ducting to rangehood outlet duct tape or with duct tape or cable tie . cable tie inside chimney outside chimney bracket 3. Fix the outside chimney bracket to the chimney with supplied ST4*8mm screws . - Page 21 INSTALLATION RANGEHOOD 4. Hang the rangehood on the upper bracket or screws (tighten the two screws if needed) . 5. Fix the rangehood chimney with the safety screws, 2pcs ST4*30mm . They are accessible from underneath when the grease filters are removed . 6.
- Page 22 INSTALLATION RANGEHOOD 7. Plug in the rangehood and turn on . Remove blue protective film from filters . 8. Adjust the height of the inside chimney to the position of the inside chimney bracket and fix it with screws 2pcs ST4*8mm .
-
Page 23: Installer Checklist
INSTALLER CHECKLIST TO BE COMPLETED BY THE INSTALLER Have all packaging been removed? Rangehood is correctly installed All connections are secure The ducting is not bent or crushed in any areas Check rangehood suction External vent is sealed appropriately All local regulations have been met Operation has been tested (refer to rangehood user guide) Check for unusual noises Complete and keep for safe reference:... - Page 24 WWW .HAIER .COM .AU WWW .HAIER .CO .NZ 432392A H0530090592 07.24...
