Abus WAPPLOXX PRO Fitting Instructions Manual

E le ctronic lock cylinder
Hide thumbs Also See for WAPPLOXX PRO:
Table of Contents

Advertisement

Quick Links

Download this manual
ABUS l Security Center GmbH & Co. KG
abus.com
Linker Kreuthweg 5
86444 Affing
Germany
Phone: +49 82 07 959 90-0
©
Fax: +49 82 07 959 90-100
All rights reserved.
sales@abus-sc.com
07 / 2024

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WAPPLOXX PRO and is the answer not in the manual?

Questions and answers

Related Manuals for Abus WAPPLOXX PRO

Summary of Contents for Abus WAPPLOXX PRO

  • Page 1 ABUS l Security Center GmbH & Co. KG abus.com Linker Kreuthweg 5 86444 Affing Germany Phone: +49 82 07 959 90-0 © Fax: +49 82 07 959 90-100 All rights reserved. sales@abus-sc.com 07 / 2024...

  • Page 2: E L E C T R O N I C L O C K

    W A P P L O X X P R O | T E C T I Q E L E C T R O N I C L O C K C Y L I N D E R Fitting instructions abus.com...
  • Page 3 Thank you for choosing a product from ABUS Security Center ("ABUS" for short). ABUS access control systems make an important contribution to securing your property and ensure that only authorised persons can enter the secured areas. About this manual This manual contains all the important information for safe handling of the described product. The information in this manual has been compiled to the best of our knowledge and is regularly checked and updated.

  • Page 4: Table Of Contents

    Contents General 1.1. ABUS TECTIQ 1.2. ABUS wAppLoxx Pro / Pro Plus 1.3. Intended use 1.4. Target groups 1.5. Notices in these instructions Product description 2.1. Function 2.2. Scope of delivery 2.3. Variants 2.4. Accessories 2.5. Technical data 2.6. Dimensions 2.7.
  • Page 5 12.4. Opening the door when the battery is flat 12.5. Firmware update 13. Taking out of service and disassembly 13.1. Deregistering cylinders from the locking system 13.2. Disassembling cylinder 13.3. Resetting to factory setting 14. Disposal wAppLoxx | TECTIQ lock cylinder...

  • Page 6: General

    The wAppLoxx Pro Plus app also makes it possible to turn the smartphone into a key or to control access remotely. All door components are connected wirelessly to their access control panel. wAppLoxx Pro Plus works according to the wireless online operating principle, where access rights and information are stored centrally in the control unit database.

  • Page 7: Target Groups

    Architects, technical building planners (technical building services) and other consulting institutions are required to obtain all necessary product information from ABUS in order to fulfil their information and instruction obligations. Specialist dealers and installers are required to observe the information in the ABUS documentation and to pass it on to their customers.

  • Page 8: Product Description

    2. Product description 2.1. Function TECTIQ and wAppLoxx Pro lock cylinders are electronic lock cylinders for entrance doors to public or private buildings. The Euro profile, round profile and oval cylinders cover all typical European lock cylinder profiles. The product types enable variable solutions for different installation situations and requirements, such as single-sided or double-sided access control.

  • Page 9: Variants

    2.3. Variants Euro profile cylinder Lock cylinders are available in a wide range of variants, whereby individual equipment options can also be combined, e.g: Double knob cylinder with reader outside Double knob cylinder with reader on both sides Half cylinder -OPZ With shaft extension for doors with core pulling protection -LA-P...

  • Page 10: Accessories

    Transmission power 14 dBm Connection USB2-Micro-B Line type ABUS Updater cable → see Chapter 2.4 Accessories Internal clock Battery life (at 20 °C) up to 45 000 locking cycles, approx. 2 years (with 20 operations per day), up to 3 years if not operated) Number of locking cycles >200 000...
  • Page 11 Conformity 2014/35/EU Low Voltage Directive (LVD) 2014/30/EU Electromagnetic Compatibility Directive (EMC) 2014/53/EU Radio Equipment Directive (RED) Regulation EU 305/2011 Construction Products (CPR) 2001/95/EC General Product Safety 2011/65/EU Restriction of Hazardous Substances Directive (RoHS) EN 15684 EN 179 / EN 1125 SKG *** (Netherlands;...

  • Page 12: Dimensions

    2.6. Dimensions Measure the external and internal length of profile cylinders from the centre of the screw inwards or outwards. Euro profile cylinder Euro profile cylinders are available ex works in different lengths. Dimensions may vary depending on the equipment variant. 30 mm 30 mm 35 mm...

  • Page 13: Labelling

    2.7. Labelling On the inside of the reader, on the basket: • Manufacturer name/address • Battery installation position • Conformity mark • Symbol for safe disposal • QR code • Internal identification • Serial number • Product type 2.8. Structure and individual parts Reader Cylinder body (inside) Status display (LED)

  • Page 14: Safety Information

    3. Safety information 3.1. General safety information WARNING! Explosion hazard! Installing and operating the fittings and cylinders in potentially explosive atmospheres can lead to serious injury or death. • Do not install or operate the fittings/cylinders in potentially explosive atmospheres. CAUTION! Risk of injury from swallowing small parts! Children can swallow small parts.

  • Page 15: Fitting Instructions

    1.5 mm 2.5 mm Opening pliers Closing pliers Opening key for outside cap Hexagon key 1.5 mm for fitting/removing the inside knob Hexagon key 2.5 mm for length adjustment by the ABUS specialist retail partner wAppLoxx | TECTIQ lock cylinder...

  • Page 16: Preparations Before Fitting

    The lock cylinder is usually supplied to match the thickness of the door leaf and the position of the lock. Euro profile cylinders can adapt subsequently with an extension set, see → Chapter 5.3. Round profile cylinders are available in all standard sizes. If you have any questions, please contact your ABUS specialist retail partner.

  • Page 17: Fitting The Profile Cylinder

    5. Fitting the profile cylinder 5.1. Fitting profile cylinders -LA and -HZ The -LA and -HZ variants are installed from the outside of the door. If the profile cylinder does not match the thickness of the door leaf, it can be adapted to the door leaf using the appropriate extension set.

  • Page 18: Fitting Profile Cylinders -Lb, -La-P, -Opz

    5.2. Fitting profile cylinders -LB, -LA-P, -OPZ To fit the -LB, -LA-P and -OPZ variants, first remove the electronic knob and then fit the lock cylinder from the inside of the door. NOTICE: If installed incorrectly, the electronic knob can draw moisture during operation. Condensed water can damage the electronics.
  • Page 19 Step 3: Completely dismantle the outside knob ▹ Use a PH0 screwdriver to undo the 4 retaining screws (1) on the base of the basket (2). ▹ Remove the basket (2) from the cylinder. ▹ Also remove the lock washer (3) from the cylinder shaft. Step 4: Fit the profile cylinder in the door ▹...
  • Page 20 Step 6: Insert electronics in outside knob NOTICE: Do not bend the EMC contact (1) on the circuit board when inserting the electronics! ▹ Insert the electronics with holder (2) into the basket (3) so that the plug connector fits into the socket in the shaft.

  • Page 21: Adapting The Profile Cylinder To The Door Thickness

    5.3. Adapting the profile cylinder to the door thickness If the lock cylinder does not match the thickness of the door leaf on site, the lock cylinder can be adapted to the specific door thickness using an extension set. Depending on requirements, the profile cylinder can be extended on the inside or outside (5 to 30 mm in each case).
  • Page 22 Step 2: Disassemble cylinder shaft NOTICE: Component tolerances can lead to malfunctions if parts are installed incorrectly. Do not mix up the removed shaft end pieces on the outside and inside. Extension on the cylinder inner side: ▹ Pull the loosened cylinder shaft out of the cylinder body. Extension on the cylinder outer side: ▹...
  • Page 23 Step 5: Assemble cylinder body, body extension and cam ▹ Assemble the cylinder bodies inside (1) and outside (2), body extension (3), shaft extension (4) and cam (5). ▹ If the cam does not rotate properly: Check whether the cam has been twisted. Correct the position of the cam. ▹...

  • Page 24: Fitting Round Cylinders

    6. Fitting round cylinders 6.1. Fitting double knob cylinder with Swiss round profile Cylinders with a Swiss round profile are fitted from the inside of the door. Preparation • The door plate and door handle on the outside of the door are fitted. •...
  • Page 25 Step 3: Completely dismantle the outside knob NOTICE: Do not lose the screws for the outside knob! ▹ Use a PH0 screwdriver to loosen the 4 retaining screws (1) on the base of the basket (2). ▹ Remove the basket (2) from the cylinder. ▹...
  • Page 26 Step 6: Fit the outside knob NOTICE: If installed incorrectly, protection class IP67 is no longer guaranteed. The electronics knob can draw moisture and permanently damage the electronics. Use new electronics screws with undamaged paint coating for each assembly. Alternatively, apply new screw locking varnish to the screws.

  • Page 27: Fitting Half Cylinder With Swiss Round Profile

    Step 9: Close outside knob NOTICE: The electronic cylinder can be irreparably damaged if the cap is fitted forcibly. Do not tilt the cap when fitting it! Ensure the correct position of the "•" marking! ▹ Place the cap (1) on the outside knob (2) so that the lug (3) fits into the recess in the cap –...

  • Page 28: Fitting Oval Cylinder

    7. Fitting oval cylinder For doors with mortice lock to SS 817375. Existing oval cylinders or rococo cylinders are replaced with the corresponding electronic cylinder on the outside or inside of the door, depending on the user's requirements. This means that various configurations are possible: •...

  • Page 29: Fitting Electronic Oval Cylinder

    7.1. Fitting electronic oval cylinder The electronic oval cylinder is mounted on the outside of the door and combined with a knob or rococo cylinder on the inside. Step 1: Cut retaining screws for cylinder to size The retaining screws connect the oval cylinder on the outside, the mortice lock and the cylinder or knob on the inside.

  • Page 30: Fitting Electronic Rococo Cylinder

    Step 4: Fitting oval cylinder with escutcheon ▹ Fit the escutcheon and the oval cylinder on the outside. ▹ Tighten the oval cylinder with the retaining screws. Tightening torque typ. 2 Nm. ▹ Fit the inside knob on the inside – the inside escutcheon in the case of a rococo cylinder. ▹...
  • Page 31 Step 3: Completely disassemble the electronic knob NOTICE: Do not lose the screws for the outside knob! ▹ Use a PH0 screwdriver to loosen the 4 retaining screws (1) on the base of the basket (2). ▹ Remove the basket (2) from the cylinder. ▹...
  • Page 32 Step 7: Cut the retaining screws for the escutcheon to size The length of the retaining screws for the escutcheon takes into account the thickness of the mechanical knob or inside escutcheon, the door thickness and the outside escutcheon. ▹ Cut the retaining screws to the required length. Step 8: Fit the inside escutcheon ▹...
  • Page 33 Step 11: Pull out the battery insulation The battery can also be activated later. The electronic cylinder does not function until this is done. ▹ Pull out the insulating tag (2) at the battery compartment (1). Depending on the delivery condition: Insert the battery, see →...

  • Page 34: Removing Battery Insulation

    8. Removing battery insulation For lock cylinders with inserted battery. This step is necessary if the battery insulation has not yet been removed during installation. Step 1: Open electronic knob ▹ Use the opening spanner to reach into the notch in the lock washer behind the electronic knob and loosen the lock washer.

  • Page 35: Inserting Battery

    9. Inserting battery Important! Sudden functional failure possible if incorrect batteries are used. The electronics are designed for the specified battery type. If other battery manufacturers, battery types or used batteries are used, permanent and fault-free function cannot be guaranteed. In particular, the low battery warning is not guaranteed so that the door may remain locked without warning.

  • Page 36: Start-Up

    10. Start-up Start-up of the product is described in the system documentation for ABUS wAppLoxx Pro Plus or ABUS TECTIQ, depending on the system family. TECTIQ abus.com/product/TTCO10000 11. Operation wAppLoxx Depending on the system family, operation of the product is described in the system documentation for ABUS wAppLoxx Pro Plus or ABUS TECTIQ.

  • Page 37: Changing The Battery

    • by delayed opening on access (5 seconds) • by changed signalling (see → System documentation ABUS TECTIQ or ABUS wAppLoxx Pro Plus) • by display in the TECTIQ Access Manager or wAppLoxx Pro Plus Access Manager) •...
  • Page 38 ▹ Remove the cap from the electronics knob, see → Chapter 8. ▹ Connect the USB battery pack, power bank, PC or similar to the USB port. ▹ With ABUS TECTIQ: Synchronise date/time, e.g. with parameter card. ▹ Present locking medium with current access authorisation and open door.
  • Page 39 Lock cylinders that are removed from the system should be deregistered from the locking system using the locking software. This ensures that invalid access authorisations are deleted from the system. ▹ For deregistration, follow the instructions in the system documentation for ABUS TECTIQ or ABUS wAppLoxx. 13.2. Disassembling cylinder ▹...
