ENGLISH
11. Tank emptying system
12. Access tray and robot bracket
Mixed tank. Fig. 3:
1. Dirt tank
2. Tank opening
3. Top dirt tank cover
4. High-efficiency filter + primary filter + sponge filter
NOTE:
The graphics in this manual are schematic representations and may not exactly match the
device.

2. BEFORE USE

- This robot vacuum cleaner includes a package designed to protect it during transport.
Take the robot vacuum cleaner out of the box. Keep the original box and other elements
in a safe place, as this will help you prevent damage to the robot vacuum cleaner when
transporting it in the future. In case the original packaging is disposed of, make sure all
packaging materials are recycled accordingly.
- Make sure all parts and components are included and in good conditions. If there is any
piece missing or not in good condition, contact the official Cecotec Technical Support
Service immediately.
Warnings
- Remove all objects around the robot vacuum cleaner such as clothing, papers, cables,
curtains, or other fragile objects which may block or slow down the operation of the robot
vacuum cleaner. Fig. 4
- If the room to be cleaned is near a balcony or stairs, a physical barrier should be placed to
prevent the robot vacuum cleaner from falling and getting damaged, thus ensuring safe
operation. Fig. 5.
- Do not use the robot vacuum cleaner to vacuum up liquids. Fig. 6.
- Direct exposure to sunlight or heavy light contrasts may affect the correct operation of the
sensors. If this happens, the robot vacuum cleaner will cease operation. Move it to a new
location for it to start operating again.
- Please note that the total height of the robot vacuum cleaner is 10 cm, and the sensors
are at the bottom, so it is advisable to prevent access to all areas below 10 cm to avoid
damaging the laser.
70
CONGA 13090 SPIN REVOLUTION HOME&WASH
Charging base installation
- Place the charging base against a wall and leave a minimum free space of 1.5 metres to the
front and 0.5 metres to each side. Fig. 7
- Connect the charging base to a power socket. Wind and store the remaining cable to
prevent accidents.
- Press and hold the Start/Pause button for a few seconds.
- When the indicator light turns on, place the robot vacuum cleaner in the charging base and
make sure the charging terminals on the robot match those on the charging base. If the
indicator light is flashing blue, it means the battery is not completely charged. To ensure
the maximum cleaning time, wait until the indicator light turns into steady blue, as this
indicates that the battery is fully charged, and that the robot vacuum cleaner is ready to
clean.
Note
- Take the robot vacuum cleaner to the charging base if the battery is low. The robot vacuum
cleaner may not turn on if battery is too low.
- The robot vacuum cleaner will automatically turn on when placed on the charging base.
- The robot vacuum cleaner cannot be turned off during recharge.
Clean water tank installation Fig. 8
- Pull out the clean-water tank (tank with transparent cover) in the direction shown.
- Lift up the cover and fill the water tank with clean water. Do not exceed the "MAX" mark
on the tank.
- Install again the clean-water tank in its original position.
Recommendations
- Add a few drops of cleaning agent to the water, if necessary, as long as it is non-corrosive.
- Using cleaning agents in excess might block water outlets.
- In order to get perfect scrubbing, it is suggested to moisten the mop before using it and
washing it after each use.
First use
- Once the robot vacuum cleaner and the charging base are installed, follow these steps
before the first cleaning.
- First of all, fully charge the robot vacuum cleaner. It is suggested to allow the robot to
charge overnight. Once fully charged, it may carry out the first cleaning cycle and save
the first map. To do so, activate the Auto mode and select the Eco suction level. It is very
important to follow these instructions so that the robot vacuum cleaner recognises every
corner of your house and can carry out a complete mapping of it.
- If your house is very large and the robot vacuum cleaner runs out of battery, it will return
to the charging base, save both complete and incomplete maps, and, once charged, it will
ENGLISH
