cecotec CONGA 13090 SPIN REVOLUTION HOME&WASH Instruction Manual page 38

ENGLISH
Edge mode
- When this mode is selected, the robot vacuum cleaner will clean along walls and around
furniture (e.g., table or chair legs).
- The robot will return to the charging base to clean the mops and moisten them again to
continue cleaning, according to the frequency selected in the application.
- Press the edge cleaning mode in the app.
Spiral mode
- When this mode is enabled, the robot vacuum cleaner will thoroughly clean a specific area.
It will start cleaning at a specific spot and will move outwards in a spiral motion, and it will
return to the starting spot in an inwards spiral motion again.
- When it finishes and returns to the starting spot, the robot vacuum cleaner will return to
the charging base directly.
- Before using this mode, place it in the spot you wish to clean.
- Select the spiral cleaning mode on the app.
Manual mode
The robot vacuum cleaner can be moved manually by selecting manual mode in the app and
using the arrow keys.
Back Home mode
Press the Back Home button on the robot vacuum cleaner or select the option in the app to
send the robot vacuum cleaner to the charging base in any cleaning mode.
Smart Area mode
- Once the home's map has been saved, select this mode for the robot to clean a specific area
in zigzag motion. The robot vacuum cleaner will clean the selected area and then return
directly to the charging base. You can select more than one area on the map at a time. The
robot vacuum cleaner will only clean the area selected on the map. It will therefore go to
the selected area and return to the base without vacuuming.
- To activate this mode, select the Smart Area option on the app.
Spot mode
- Select this mode if you want to thoroughly clean a specific point in the map, making the
most of the robot vacuum cleaner's maximum power. The robot vacuum cleaner will clean
an area of 1.6m x 1.6m in a zigzag pattern and return directly to the charging base once
finished. The robot vacuum cleaner will only clean the area selected on the map. It will
therefore go to the selected area and return to the base without vacuuming.
- To activate this mode, select the spot cleaning option on the app.
74
CONGA 13090 SPIN REVOLUTION HOME&WASH
Restricted Area mode
Mark out specific areas on the map that you do not want the robot vacuum cleaner to clean.
The robot vacuum cleaner will detect the defined area and will not clean it.
You can select more than one restricted area on the map.
Complete cleaning mode
Select this mode to perform a deep cleaning of your house. The robot vacuum cleaner will
clean in Edge mode and continue zigzagging horizontally and vertically. It will then return to
the charging base.
To activate this mode, select the Complete Cleaning option on the app.
Power level function
Select the power level on the app to control the robot vacuum cleaner's suction power during
cleaning. There are four suction power levels: 3: Off, Eco, Normal and Turbo.
Cleaning schedule
- To make cleaning easier, the robot vacuum cleaner has a function that allows it to be
programmed daily from the app. According to the setting, the robot vacuum cleaner will
automatically start cleaning in the selected days at the desired time.
- Before adjusting the time and settings, make sure the robot vacuum cleaner is switched
on.
- In addition, you can select different predefined cleaning programmes for different
situations in your daily life.
Other Functions
Sleep mode
A Do Not Disturb time slot can be selected to control the operation of the robot vacuum cleaner,
and it can be modified or cancelled from the app. During the set time, the robot vacuum cleaner
will disable the automatic, continuous cleaning and timer functions.
Map editing function
This function allows you to edit the generated maps: rename cleaning areas, split or combine
areas, and edit cleaning mode, mark restricted areas and select different suction powers.
Robot vacuum cleaner's Location function
Allows to locate the robot vacuum cleaner on the map.
ENGLISH
CONGA 13090 SPIN REVOLUTION HOME&WASH
75
