MC91BL-SC
MC91BL-SC
USER/INSTALLER MANUAL
ANT
PWR
LMP
V+ Y R G B
LO
LS FO FC
V
LO
LS FO FC
U
V
W
+
SEC 2
SEC 1
BAT
MOT
MENU
UP
CMD
DW
LE LA LB
LE LA FB TS
EN
v1.1 REV. 07/2024
Compatible hardware versions:
HW 0.1.0 | FW H0.REV105

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MC91BL-SC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Motorline professional MC91BL-SC

  • Page 1 MC91BL-SC MC91BL-SC USER/INSTALLER MANUAL MENU V+ Y R G B LS FO FC LE LA LB LS FO FC LE LA FB TS SEC 2 SEC 1 v1.1 REV. 07/2024 Compatible hardware versions: HW 0.1.0 | FW H0.REV105...
  • Page 2: Table Of Contents

    00. CONTENT 01. SAFETY INSTRUCTIONS INDEX This product is certified in accordance with European Community 01. SAFETY INSTRUCTIONS (EC) safety standards. STANDARDS TO FOLLOW This product complies with Directive 2011/65/EU of the European Parliament and of the Council, of 8 June 2011, on the restriction 02.
  • Page 3: Safety Instructions

    01. SAFETY INSTRUCTIONS GENERAL WARNINGS • Children shouldn’t play with the product or opening devices to avoid the motorized door or gate from being triggered involuntarily. • This manual contains very important safety and usage information. • If the power cable is damaged, it must be replaced by the Read all instructions carefully before beginning the installation/ manufacturer, after-sales service or similarly qualified personnel usage procedures and keep this manual in a safe place that it can...
  • Page 4: Warnings For Users

    01. SAFETY INSTRUCTIONS the power supply cable. Please note that all the cables must enter conditions have been met. the control board from the bottom. • In the event of tripping of circuits breakers of fuse failure, locate • If the automatism is to be installed at a height of more than 2,5m the malfunction and solve it before resetting the circuit breaker or from the ground or other level of access, the minimum safety and replacing the fuse.
  • Page 5: Control Board

    02. CONTROL BOARD 02. CONTROL BOARD TECHNICAL SPECIFICATIONS CONNECTORS The MC91BL-SC is an electronic control board for controlling brushless motors with a built-in radio control system, developed for automating sliding gates. 20 21 22 23 24 25 26 • Motor power supply...
  • Page 6: Buttons And Leds 5A

    02. CONTROL BOARD 03. INSTALLATION CONNECTORS INSTALACIÓN DEL MCONNECT LINK (OPCIONAL) 29 30 29 30 MENU MENU MENU MENU MENU MENU MENU MENU 27 • Type-C input for MCONNECT LINK connection LINK 28 • Conector para Encoder do motor 29 • Antenna connector (hot pole) 30 •...
  • Page 7: Programming

    03. INSTALLATION 04. PROGRAMMING ESSENTIAL STEPS FOR INSTALLATION REMOTE CONTROLS 01 • Make the connections of all the accessories according to the connection scheme (page 15 and 16). 02 • Connect the transformer to a power supply. 03 • Make sure that the gate movement is the same as the one shown on the display: Programming a remote control for pedestrian Programming a remote control for full opening opening...
  • Page 8: P Menu Functions 7A

    04. PROGRAMMING 04. PROGRAMMING "P" MENU FUNCTIONS PROGRAMMING "P" FACTORY MENU FUNCTION MIN. MÁX. STATE PAGE COURSE PROGRAMMING VALUE Automatic Programming Automatic course programming Manual Programming COURSE PROGRAMMING This menu allows you to automatic motor programming and slowdown. Left opening Right opening Automatic programming: Opening slowdown...
  • Page 9 04. PROGRAMMING 04. PROGRAMMING PROGRAMMING "P" PROGRAMMING "P" RAMP ADJUSTMENT PARTIAL COURSE ADJUSTMENT This menu allows to set the slowdown time at opening and closing. Partial mode allows the gate to be opened to allow people to pass through. In this function you can define the percentage of course that you want the gate to open in Opening slowdown partial mode, in relation to the total course (100%).
  • Page 10 04. PROGRAMMING 04. PROGRAMMING PROGRAMMING "P" PROGRAMMING "P" PHOTOCELLS PROGRAMMING 1 PHOTOCELLS PROGRAMMING 2 Allows to program the security behavior LE (photocell 1). Allows to program the security behavior LA (photocell 2). Disable photocells Disable photocells Enable or disable security entry. Enable or disable security entry.
  • Page 11 04. PROGRAMMING 04. PROGRAMMING PROGRAMMING "P" PROGRAMMING "P" OPERATING LOGIC REMOTE PROGRAMMING This menu allows to set the operating logic of the automation. This menu allows to enable or disable the programming of new remote control without directly accessing the control board, using a previously stored remote control Automatic Mode (memorize remote controls page 6A).
  • Page 12: E Menu Functions 11A

    02. CONTROL BOARD 04. PROGRAMMING "E" MENU FUNCTIONS PROGRAMMING "E" FACTORY HUMAN PRESENCE/PUSHBUTTON MENU FUNCTION MIN. MÁX. STATE PAGE VALUE Disables human presence Disables Human presence Active at closing Whenever a order to is sent to the Active during opening and closing LO input and the motor performs a Human presence HUMAN PRESENCE...
  • Page 13 04. PROGRAMMING 04. PROGRAMMING PROGRAMMING "E" PROGRAMMING "E" UNUSED FOLLOW ME This parameter has no assigned function. Function disabled This menu allows activating Function activated after opening the Follow me option. COURTESY LIGHT TIME The control board activates the closing With this function activated, only after completing the opening, based whenever the safety device...
  • Page 14 04. PROGRAMMING 04. PROGRAMMING PROGRAMMING "E" PROGRAMMING "E" UNUSED RESET - RESET FACTORY VALUES This parameter has no assigned function. Disabled (Default value) Reset enabled SLOWDOWN SPEED This menu allows you to adjust the slowdown speed. 01 • Press MENU for 8 sec. until it appears 02 •...
  • Page 15: Display

    05. DISPLAY DISPLAY INDICATIONS MENU DESCRIPTION MENU DESCRIPTION In stop position, fully open Processing error In stop position, intermediate position Overvoltage error In stop position, fully closed Under voltage error Full opening button pressed Startup error Pedestrian opening button pressed Encoder error Control board performs the opening course EEPROM memory error...
  • Page 16: Connection Diagram

    06. CONNECTION DIAGRAM SLIDING GATES...
  • Page 17: Mmblbrake-Sc Module (Optional)

    06. CONNECTION DIAGRAM MMBLBRAKE-SC MODULE (OPTIONAL) In installations where the gate has a steep slope, it is recommended to use the MMBLBRAKE-SC brake module to reduce the reversibility of the motor. V+ Y R G B LS FO FC LE LA LB LO LS FO FC LE LA FB TS SEC 2...
  • Page 18: Troubleshooting

    07. TROUBLESHOOTING INSTRUCTIONS FOR FINAL CONSUMERS/TECHNICIANS Anomaly Procedure Behavior Procedure II Discovering the origin of the problem • Make sure you have power 1 • Open control board and check if it has power supply. • Motor doesn’t 2 • Check input fuses of the control board. supply connected to the •...
