LEVER ACTION GREASE GUN
PISTOLA PARA GRASA CON PALANCA
Item Number W54296
OWNER'S MANUAL /
INSTRUCTIVO
SPECIFICATIONS /
CARACTERÍSTICAS
Capacity:................................... Bulk - 16 oz. (473 ml), Cartridge - 14 oz. (414 ml)
Develops up to:..................................................................................... 10,000 PSI
Delivers:......................................................................... 1 oz. / 7 Strokes (29.5 ml)
Hose Type / Length: ............................................................ 6 in. Rigid 1/8 in. NPT
Specifications are subject to change without notice.
WARNING: READ, UNDERSTAND AND FOLLOW ALL INSTRUCTIONS AND
WARNINGS BEFORE OPERATING THIS TOOL. FAILURE TO DO SO MAY
RESULT IN PERSONAL INJURY AND/OR PROPERTY DAMAGE AND WILL
VOID WARRANTY.
Advertisement
Related Manuals for Performance Tool W54296
Summary of Contents for Performance Tool W54296
- Page 1 LEVER ACTION GREASE GUN PISTOLA PARA GRASA CON PALANCA Item Number W54296 OWNER'S MANUAL / INSTRUCTIVO SPECIFICATIONS / CARACTERÍSTICAS Capacity:........Bulk - 16 oz. (473 ml), Cartridge - 14 oz. (414 ml) Develops up to:..................10,000 PSI Delivers:................. 1 oz. / 7 Strokes (29.5 ml) Hose Type / Length: ............
- Page 2 GREASE CARTRIDGE LOADING/ PARA LLENAR CARTUCHO DE GRASA NOTE: This is a basic instruction manual which covers various models of grease guns. The illustrations below may not depict exactly your specific gun. 1. Rotating counter clockwise, unscrew Head Cap from gun Barrel. (Fig. 1) NOTA: Este es un manual de instruciones basico que cubre varios modelos de pistolas de grasa.
- Page 3 BULK LOADING WITH DISPENSER /RELLENO EN VOLUMEN CON DISPENSADOR NOTE: Used cartridges must be removed prior to bulk loading. 1. Make sure the bulk loading filler valve is compatible with the adapter on the pump. (Figure 5) 2. Attach the filler valve to the adapter by pushing in and rotating slightly. 3.
- Page 4 PERFORMANCE TOOL® does not authorize any other person to make any warranty or to assume any liability in connection with its products.
