Page 1 Manual No. '22 • HM-T-415 TECHNICAL MANUAL AIR TO WATER HEAT PUMP INDOOR UNIT (SPLIT BOX) HSB60-W HSB100-W (TANK UNIT) PT300 PT500 (CONTROLLER) RC-HY20-W RC-HY40-W OUTDOOR UNIT FDCW60VNX-W FDCW71VNX-W...
Page 2: Table Of Contents
4-way valve　　104 Menu 1- Indoor climate　 Expansion valve　　104 Menu 2- Hot water　 Low pressure sensor　　104 Menu 3- Info　 HSB60-W/HSB100-W　　104 Menu 4- My system　　105 Menu 5- Service　　 Temperature sensor Data for sensor in outdoor unit　　...
Page 3: Safety Precautions
'22 • HM-T-415 When install the unit, be sure to check whether the selection of installation place, power source specifications, usage limitation (piping length, height differences between indoor and outdoor units, power source voltage and etc.) and installation spaces. SAFETY PRECAUTIONS l We recommend you to read this “SAFETY PRECAUTIONS”...
Page 4 '22 • HM-T-415 l Ensure that no air enters in the refrigerant circuit when the unit is installed and removed. If air enters in the refrigerant circuit, the pressure in the refrigerant circuit becomes too high, which can cause burst and personal injury.
Page 5 '22 • HM-T-415 l Do not install the unit where corrosive gas (such as sulfurous acid gas etc.) or combustible gas (such as thinner and petroleum gases) can accumulate or collect, or where volatile combustible substances are handled. Corrosive gas can cause corrosion of heat exchanger, breakage of plastic parts and etc. And combustible gas can cause fire. l Secure a space for installation, inspection and maintenance specified in the manual.
Page 6 '22 • HM-T-415 l Do not shut off the power source immediately after stopping the operation. Wait at least 5 minutes, otherwise there is a risk of water leakage or breakdown. l Do not control the system with main power switch. It can cause fire or water leakage.
Page 7: Technical Data
'22 • HM-T-415 Technical data Technical data - 6 -...
Page 8: Technical Specifications
'22 • HM-T-415 Technical data Technical specifications Technical specifications Specifications ndoor units Split box Model HSB60-W HSB100-W General conditions Power source 230V 50Hz Recommended fuse Gas: OD12.7, Gas: OD15.9, Pipe size refrigerant (ref) Liquid: OD6.35 (1/2”; 1/4”) Liquid: OD9.52 (5/8”; 3/8”)
Page 9 '22 • HM-T-415 Technical data Technical specifications Tank unit Model PT300 PT500 Volume total 279 ℓ 476 ℓ Volume coil 9.4 ℓ 13 ℓ Area coil Material coil Steel - S235 φ33.7 × 2.6 mm Material tank Steel – S275g=3.0 mm Cabinet Side / Top / –...
Page 10 '22 • HM-T-415 Technical data Technical specifications Outdoor units Adapted to RoHS directive Outdoor model FDCW60VNX-W Indoor unit heat exchanger ACH18-52H-F Power source 1 phase 230V 50Hz condition 1 2.70 (2.70 ~ 8.00) Heating nominal capacity High capacity 5.08 (0.90 ~ 7.60) condition 2 Low capacity 2.64...
Page 11 '22 • HM-T-415 Technical data Technical specifications Adapted to RoHS directive Outdoor model FDCW71VNX-W Indoor unit Heat exchanger ACH-30EQ-80H Power source 1 phase 230V 50Hz condition 1 8.00 (3.00 ~ 10.00) Heating nominal capacity condition 2 8.30 (2.20 ~ 9.50) condition 1 2.35 Heating power consumption...
Page 12 '22 • HM-T-415 Technical data Technical specifications Test conditions Water temperature Ambient temperature 45°C out / 40°Cin condition 1 Heating 7°CDB / 6°CWB condition 2 35°Cout / 30°Cin condition 1 7°Cout / 12°Cin Cooling 35°CDB condition 2 18°Cout / 23°Cin *1: Test condition for sound power level *1: Test condition for sound power level Temperature condition: Heating condition 2...
Page 13 '22 • HM-T-415 Technical data Technical specifications Seasonal space heating energy efficiency (ηs) & Rated heat output (Prated) Split box Medium-temperature application FDCW60VNX-W FDCW71VNX-W HSB60-W HSB100-W Seasonal Space Heating Energy Efficiency Class Low-temperature application FDCW60VNX-W FDCW71VNX-W HSB60-W HSB100-W Seasonal Space Heating...
Page 14 '22 • HM-T-415 Technical data Technical specifications Controller RC-HY20-W Electrical data Power source voltage 230V 50Hz Enclosure class IP21 Rated value for impulse voltage 4 kV Electrical contamination Option connections Max number of air/water heat pumps Max number of sensors Max number of charge pumps Max number of outputs for additional heat step Miscellaneous...
Page 15 '22 • HM-T-415 Technical data Technical specifications RC-HY40-W Electrical data Power source voltage 230V 50Hz Enclosure class IP21 Rated value for impulse voltage Option connections Max number of air/water heat pumps Max number of sensors Max number of charge pumps with internal accessory cards Max number of charge pumps with external accessory cards Max number of outputs for additional heat step Miscellaneous...
Page 16: Installation Requirement
'22 • HM-T-415 Technical data Technical specifications Installation requirements Indoor unit HSB60-W HSB100-W Outdoor unit FDCW60VNX-W FDCW71VNX-W Highest recommended supply / return temperature 55/45°C Max pressure, climate system 0.25MPa (2.5 bar) Max temperature, climate system 65°C Max temperature in indoor unit 65°C...
Page 17: Operating Temperature Range
'22 • HM-T-415 Technical data Technical specifications ※当社に無断で複写や譲渡,貸出,使用,ならびに記載情報の開示を禁ず。 Operating temperature range Reproduction ,use and disclosure of the described information without our company permission is strictly prohibited. FDCW60VNX-W Operable temperature range <Heating/Hot Water> with immersion heater olid line: Water Out temperature Two-dot chain line: Water In temperature Ambient temperature ( ℃...
Page 18 '22 • HM-T-415 Technical data Technical specifications ※当社に無断で複写や譲渡,貸出,使用,ならびに記載情報の開示を禁ず。 Reproduction ,use and disclosure of the described information without our company permission is strictly prohibited. FDCW71VNX-W Operable temperature range <Heating/Hot Water> with immersion heater olid line: Water Out temperature Two-dot chain line: Water In temperature Ambient temperature ( ℃...
Page 19 '22 • HM-T-415 Technical data Technical specifications NOTE 1. Avoid installing outdoor unit where wind blows stronger than 5m/s. In strong wind enviroment, operable temperature range is drastically narrowed if wind protection is not used. 2. In case outdoor unit is installed where outdoor air temperature drops below 10°C and wind blows directly into the outdoor unit, install wind protection on outdoor unit.
Page 20: Capacity Diagram
'22 • HM-T-415 Technical data Technical specifications Capacity diagram HSB60-W — FDCW60VNX-W Heating Maximum Maximum (Nominal capacity) Minimum (Nominal capacity) Minimum Outdoor air temperature (°C) Condition Outdoor air temperature (°C) Supply water temperature : 45ºC Condition Water flow rate : 1044 ℓ /h Supply water temperature : 45ºC...
Page 21 '22 • HM-T-415 Technical data Technical specifications HSB100-W — FDCW71VNX-W Heating Maximum (Nominal capacity) Minimum Outdoor air temperature( °C ) Condition Supply water temperature : 45ºC Water flow rate : 1872 ℓ /h Cooling Maximum (Nominal capacity) Minimum Outdoor air temperature( °C Condition Supply water temperature : 7ºC Water flow rate : 1221 ℓ...
Page 22 '22 • HM-T-415 Technical data Technical specifications Capacity correction factor according to piping length and outlet water temperature in cooling HSB60-W — FDCW60VNX-W 1.40 Outlet water temperature 18 ℃ 1.30 1.20 15 ℃ 12 ℃ 1.10 10 ℃ 1.00 9 ℃...
Page 23 (2) Read the capacity correction factor at required water outlet temperature and piping length. (3) Multiply the values (1) and (2). Example: HSB60-W, Ambient temperature 25degC, Water outlet 8degC, piping length 30m (1) Capacity at 25degC ambient and 7degC outlet: 5.6kW (2) Correction factor according to ambient temperature and piping length: 0.97...
Page 24: Dimensions
'22 • HM-T-415 Technical data Dimensions Dimensions Indoor units Packaging Dimensions Split box HSB60-W / HSB100-W XL13 XL14 Climate system supply Meaning of symbol Climate system return Content Symbol Connec�on, liquid line HSB60-W HSB100-W Climate system supply φ 22 mm φ...
Page 25 '22 • HM-T-415 Technical data Dimensions Tank unit PT300 PT300 Inspection opening φ120 i t a i t c ̋ ½ Thermometer enclosure φ10 Female Hot water outlet ̋ 1 i t a ̋ ¾ Temperature sensor enclosure (BT7) φ16 Female Coil supply ̋...
Page 26 '22 • HM-T-415 Technical data Dimensions PT500 Meaning of symbol PT500 Inspection opening φ120 i t a i t c ̋ ½ Thermometer enclosure φ10 Female Hot water outlet ̋ 1 i t a ̋ ¾ Temperature sensor enclosure (BT7) φ16 Female Coil supply ̋...
Page 27: Outdoor Units
'22 • HM-T-415 Technical data Dimensions Outdoor units FDCW60VNX-W Meaning of symbol - 26 -...
Page 28 '22 • HM-T-415 Technical data Dimensions FDCW71VNX-W Meaning of symbol - 27 -...
Page 29 '22 • HM-T-415 Technical data Dimensions (3) Controller Outside：RC-HY20/40 Controller Outside : RC-HY20/40-W Inside：RC-HY20 Inside : RC-HY20-W Meaning of symbol Symbol Content Base card Display unit AA4-XJ3 USB socket AA4-XJ4 Service outlet (No func Extra relay circuit board Miniature circuit breaker Terminal block, incoming electrical supply Terminal block, control signal circula pump, sensors, AUX inputs and heat pump...
Page 30: Electrical Circuit Diagram
Electric circuit diagram - HSB60-W '22 • HM-T-415 Technical data Electrical circuit diagram Electrical circuit diagram Indoor units Split box HSB60-W - 29 -...
Page 31 '22 • HM-T-415 Technical data Electrical circuit diagram Electrical Diagram HSB100-W - 30 -...
Page 32 '22 • HM-T-415 Technical data Electrical circuit diagram Outdoor units FDCW60VNX-W - 31 -...
Page 33 '22 • HM-T-415 Technical data FDCW71VNX-W - 32 -...
Page 34: Technical Data
PSC012D135A - Installer manual 83.pdf 1 2020/10/01 10:27:28 '22 • HM-T-415 Technical data Electrical circuit diagram Technical data Controller RC-HY20-W - sheet 1 sheet 1 Electric circuit diagram - RC-HY20-W - 33 -...
Page 35 '22 • HM-T-415 Technical data Electrical circuit diagram Technical data RC-HY20-W - sheet 2 sheet 2 - 34 -...
Page 36 PSC012D135A - Installer manual 85.pdf 1 2020/10/01 10:28:03 '22 • HM-T-415 Technical data Electrical circuit diagram Technical data RC-HY20-W - sheet 3 sheet 3 - 35 -...
Page 37 '22 • HM-T-415 Technical data Electrical circuit diagram Technical data RC-HY20-W - sheet 4 sheet 4 - 36 -...
Page 38 PSC012D135A - Installer manual 87.pdf 1 2020/10/01 10:28:54 '22 • HM-T-415 Technical data Electrical circuit diagram Technical data RC-HY40-W- sheet 1 sheet 1 Electric circuit diagram - RC-HY40-W - 37 -...
Page 39 '22 • HM-T-415 Technical data Electrical circuit diagram Technical data RC-HY40-W- sheet 2 sheet 2 - 38 -...
Page 40 PSC012D135A - Installer manual 89.pdf 1 2020/10/01 10:29:25 '22 • HM-T-415 Technical data Electrical circuit diagram Technical data RC-HY40-W- sheet 3 sheet 3 - 39 -...
Page 41 '22 • HM-T-415 Technical data Electrical circuit diagram Technical data RC-HY40-W- sheet 4 sheet 4 - 40 -...
Page 42 '22 • HM-T-415 Technical data Electrical circuit diagram Technical data RC-HY40-W- sheet 5 sheet 5 - 41 -...
Page 43 '22 • HM-T-415 Technical data Electrical circuit diagram Technical data RC-HY40-W- sheet 6 sheet 6 - 42 -...
Page 44: Installation
'22 • HM-T-415 Installation Installation - 43 -...
Page 45: Outdoor Unit Installation
'22 • HM-T-415 Installation Outdoor unit installation Outdoor unit installation 1. TOO 1. HAU PSC012D134 60VNX (a) Anch FDCW60VNX-W INSTALLATION MANUAL FOR OUTDOOR UNIT Designed for R32 refrigerant (b) Putty (c) Elec 1) De (d) Con ● (e) Con ◎This installation manual deals with outdoor units and general installation speciﬁcations only. For indoor units, refer to the respective installation manuals supplied with the units. ●...
Page 46 '22 • HM-T-415 Installation Outdoor unit installation 1. TOOLS 1. HAULAGE AND INSTALLATION D134 (Take particular care in carrying in or moving the unit, and always perform such an operation with two or more persons.) Locally procured parts Tools for installation work (a) Anchor bolt(M10-M12)×4 pcs Plus headed driver Spanner wrench...
Page 47 '22 • HM-T-415 Installation Outdoor unit installation 3. PREPARATION FOR WORK 5. ELE 1. Removing service cover 2. Removing terminal cover Remove the screw. Slide service cover downwards and remove it. Remove the screw and take out terminal cover. • Make s cal stan •...
Page 48 Parts No. Code on LABEL,WIRING <Circuit diagram> 250V 20A SSA564A136A Indoor unit : HMK60 Indoor unit : HSB60-W 1.Preparing cable (1) Selecting cable Outdoor unit Outdoor unit 1 2/N 3 1 2/N 3 Select the power source cable and connecting cable in accordanc...
Page 49: Fdcw71Vnx-W
'22 • HM-T-415 Installation Outdoor unit installation FDCW71VNX-W PSC012D168 Notab 202201 ● Do not 71VNX-W INSTALLATION MANUAL FOR OUTDOOR UNIT A cylind ● A unit Designed for R32 refrigerant of a wr strength English is Original ● Do not ◎This installation manual deals with outdoor units and general installation speciﬁcations only. For indoor units, refer to the respective ●...
Page 50 '22 • HM-T-415 Installation Outdoor unit installation Notabilia as a unit designed for R32 Dedicated R32 tools 202201 a） Gauge manifold ● Do not use any refrigerant other than R32. R32 will rise to pressure about 1.6 times higher than that of a conventional refrigerant. (R22 or R407C) b）...
Page 51 '22 • HM-T-415 Installation Outdoor unit installation 4) On-site piping work 71VNX-W 4. ELE ● Take care so that installed pipes may not touch components within a unit. If touching with IMPORTANT an internal component, it will generate abnormal sounds and/or vibrations. Electrical i How to remove the service panel Please remove the screw of a side cover and remove to the front.
Page 52 '22 • HM-T-415 Installation Outdoor unit installation 4. ELECTRICAL WIRING WORK PSC012D168 For details of electrical cabling, refer to the indoor unit installation manual. Electrical installation work must be performed by an electrical installation service provider qualiﬁed by a power provider of the country. Electrical installation work must be executed according to the technical standards and other regulations applicable to electrical installations in the country.
Page 53: Safety Precautions In Handling Air-Conditioners With Flammable Refrigerants
'22 • HM-T-415 Installation Outdoor unit installation Safety precautions in handling air-conditioners with flammable refrigerants PSA012B839J This equipment uses fl ammable refrigerants. If the refrigerant There is information included in the user’s manual and/or is leaked, together with an external ignition source, there is a installation manual.
Page 54 '22 • HM-T-415 Installation Outdoor unit installation CAUTION 4.9 Checks to electrical devices 8. Detection of fl ammable refrigerants 10. Charging procedures • Repair and maintenance to electrical components shall include initial safety checks and component • Under no circumstances shall potential sources of •...
Page 55 '22 • HM-T-415 Installation Outdoor unit installation CAUTION • In addition, a set of calibrated weighing scales shall 13. Recovery 14. Other safety precautions be available and in good working order. • When removing refrigerant from a system, either for •...
Page 56 '22 • HM-T-415 Installation Outdoor unit installation Selection of installation location for the indoor unit Table1. Maximum refrigerant charge Table2. Minimum room area Maximum refrigerant charge (M ) (kg) Minimum room area (A ) (m min total (kg) room H=1.0 m H=1.8 m H=1.0 m H=1.8 m...
Page 57: Indoor Unit Installation
For outdoor unit installation information, see Installation For outdoor unit installation information, see installation manual for outdoor unit. manual for outdoor unit. Over view and design Over view and design HSB60/100-W HSB60-W Pipe connections Pipe connections Sensor, thermostats Sensor, thermostats XL1(Red mark) XL1(Red mark)
Page 58 '22 • HM-T-415 Installation General information for the installer Indoor unit installation PT300/500 Section of the PT300/500 storage tanks Side view of the PT300/500 storage tanks 8. Thermometer 1. Upper insulation of the storage tank 9. Connector pipe for mounting electric heating unit 10.
Page 59: Transport And Storage
'22 • HM-T-415 Installation General information for the installer Indoor unit installation Transport and storage Assembly ■ It is recommended that indoor unit is installed in a room Indoor unit and tank unit must be transported and stored with existing floor drainage, most suitably in a utility room vertically in dry conditions.
Page 60 '22 • HM-T-415 Installation Recommendation for positioning on wall General information for the installer Indoor unit installation HSB60/100-W PT300/500 Recommendation for positioning on wall Min. 200mm Min. 200mm Min. 200mm Min. 200mm is required on top to replace anode bar, and 500 mm is required in front to replace immersion heater if equipped.
Page 61 Use all mounting points and install control unit upright against room. t i l l l a Mounting point Mounting point of appropriate screws. t i l . l l Mounting point Mounting point NOTE Indoor unit weigh A kg excluding water inside. HSB60-W HSB100-W - 60 -...
Page 62: Dimensioning Expansion Vessel
'22 • HM-T-415 Installation General information for the installer Indoor unit installation Dimensioning expansion vessel Recommended installation order The expansion vessel volume must be at least 5% of total water 1. Hang indoor unit and control unit to appropriate position volume in the circulation system.
Page 63 '22 • HM-T-415 Installation General information for the installer Indoor unit installation Symbol Description Total refrigerant charge in the system Installation room area room Allowable maximum refrigerant charge Adjacment room area m² room Required minimum room area m² min total Δm Minimum ventilation opening area cm²...
Page 64: Pipe Installation
'22 • HM-T-415 Installation Indoor unit installation Pipe installation Pipe installation General Pipe installation must be carried out in accordance with current indoor unit can operate with a return temperature of up to 63°C and an outgoing temperature from the unit of 65°C. norms and directives.
Page 65: Overflow Valve
M65 and 75. This graph shows the characteristic of CPD11-25M/65 and 75. (liter) Pressure With underfloor Without underfl oor [kPa] HSB60, HMA60-S cooling application cooling application HSB60-W, HSB100, HMA100-S FDCW60VNX-W FDCW71VNX-A HSB100-W, HSB100, HMA100-S FDCW71VNX-W FDCW100VNX-A HSB140 FDCW140VNX-A Overflow valve NOTE Overﬂow valve...
Page 66: Dimensions And Pipe Connections
Indoor unit installation Pipe installation PT300/500 Dimensions and pipe connections PT300/500 PT300/500 HSB60/100-W PT300/500 XL13 XL14 Pipe connections Content Symbol HSB60-W HSB100-W Climate system supply 22 mm 28 mm φ φ Climate system return 22 mm 28 mm φ φ XL13 Connection, liquid line 1/4”...
Page 67: Water Circuit
'22 • HM-T-415 Installation Pipe installation Indoor unit installation Water circuit Connection to hot water heater For HSB60/100-W indoor unit, it is necessary to connect Connection to heating system PT300/500 tank unit applying 3-way valve in order to use domestic hot water function. Connect XL1 to supply line and X2 to return line from heating system.
Page 68 '22 • HM-T-415 Installation Indoor unit installation Pipe installation Housing and thermal insulation disassembly ■ Tank unit can be aligned using the adjustable feet. Connecting hot water tank to indoor unit ■ Protection against overpressure shall be made in accordance CAUTION with the relevant regulations.
Page 69 '22 • HM-T-415 Installation Pipe installation Indoor unit installation Connecting hot water tank to water main Information ■ Install a mixing valve if the temperature exceeds 60 °C. In order to minimize the ow of water from the safety valve ■...
Page 70: Refrigerant Circuit
'22 • HM-T-415 Installation Indoor unit installation Pipe installation Refrigerant circuit Hot water circulation circuit Hot water circulation function is available for PT300/500. Connecting refrigerant pipes See Installation manual for outdoor unit. PT300/500 If the system has the hot water circulation system, connect it to the port L (see page 65).
Page 71: Electrical Installation
① sure to route the cable grommet (UB1 AND UB2). Power - FDCW71VNX-W 3 cores, 3.5mm (power cable) Power - HSB60-W ■ Be careful to route cables not to be damaged by metal edge ② 3 cores, 1.5mm (power cable) Power - HSB100-W or trapped by panels.
Page 72: Electrical Components
'22 • HM-T-415 Installation Indoor unit installation Electrical installation Electrical components RC-HY20-W HSB60/100-W AA23-X1 AA23-F3 AA23 AA23-X4 AA4 -XJ3 AA23-S3 AA23-X100 AA4 -XJ4 Explanation AA23 Communication board AA23-F3 Fuse for external heating cable AA23-S3 DIP switch, addressing of outdoor unit AA23-X1 Terminal block, incoming supply, connection of KVR...
Page 73 '22 • HM-T-415 Installation Electrical installation Indoor unit installation RC-HY40-W Accessibility, electrical connection for controller The cover of the control module is opened using a Torx 25 screwdriver. Assembly takes place in the reverse order. AA4 -XJ3 AA4 -XJ4 NOTE The cover to access the base board is opened using a Torx 25 screwdriver Explanation...
Page 74 '22 • HM-T-415 Installation Indoor unit installation Electrical installation 4. Secure the display on the panel. 1. Press in the catch on the upper rear side of the display unit 5. When the electrical connection is ready the display must be towards you (a) and move the display unit upwards (b) so reinstalled with three mounting points again, otherwise the that the mountings unhook from the panel.
Page 75: Cable Lock
Communication connected between terminal AA23-X100 in indoor unit and TB Electrical distribution in outdoor unit. Screened 2 cores cable is recommended. unit <HSB60-W with FDCW60VNX-W> Connection for HSB60/100-W NOTE FDCW To prevent interference, unscreened communication and/ or sensor cables to external connections must not be laid...
Page 76 Recommended fuse size The recommended fuse size shown in the following table is reference value. Choose appropriate size according to local laws and regulations. RC-HY20/40-W Recommended fuse size HSB60-W 6A/230V 1AC 50Hz HSB100-W 6A/230V 1AC 50Hz FDCW60VNX-W 20A/230V 1AC 50Hz...
Page 77 S MO RC-HY20-W RC-HY20-W HSB60-W is not equipped with 3-way valve. Install the valves on right position according to the diagram and connect wires on appropriate port according to the type of controller. • 3-way valve for Heating / Hot water (QN10)
Page 78 '22 • HM-T-415 Installation Indoor unit installation Electrical installation SMO Externt RC-HY20-W External AA2-X4 2 3 4 RC-HY20-W RC-HY20-W External Externt RC-HY20-W • Hot water sensor BT7 (tank top) A temperature sensor for hot water top (BT7) can be connected AA2-X4 to RC-HY20 to show the water temperature at the top of the QN12...
Page 79: Option Connections
'22 • HM-T-415 Installation Electrical installation Indoor unit installation • Temperature sensor BT71, return line for heating Option connections This sensor is used in case electric heater is placed after 3-way ◦ Room sensor BT50 valve (QN10) for switching heating/ hot water. Room sensor can be connected to controller.
Page 80 '22 • HM-T-415 Installation Indoor unit installation Electrical installation ◦ Step controlled additional heat ◦ Relay output for emergency mode NOTE NOTE NOTE Mark up any junction boxes with warnings for Mark up any junction boxes with warnings for external voltage. Mark up any junction boxes with warnings for external voltage.
Page 81 '22 • HM-T-415 Installation Electrical installation Indoor unit installation ◦ External circulation pump Connect the external circulation pump (GP10) to terminal Temperature sensor BT64 is required in case 4-pipe system block X4:9 (PE), X4:10 (N) and X4:11 (230V) on the base is used for cooling operation.
Page 82 '22 • HM-T-415 Installation Indoor unit installation Electrical installation ■Contact for activation of “temporary lux” becomes closed between the port 15 and 16. By using this signal, it is possible to switch 3-way valve for 4-pipe cooling Temporary hot water production function “temporary lux” is or to assemble a display circuit indicating cooling mode.
Page 83 • 3-way valve for Heating / Hot water (QN10) Connect the port 5, 6 and 7 on X4 terminal on AA2 board on RC-HY40-W Refer to 3-way valve connection for HSB60-W with RC- RC-HY40-W to the port PE, N and L on circulation pump Externt...
Page 84 '22 • HM-T-415 Installation Indoor unit installation Electrical installation • Hot water sensor BT7 (tank top) A temperature sensor for hot water top (BT7) can be connected QN12 to RC-HY40-W to show the water temperature at the top of the AA3-X7 tank (if it is possible to install a sensor at the top of the tank).
Page 85 '22 • HM-T-415 Installation Electrical installation Indoor unit installation ◦ Room sensor BT50 • Temperature sensor BT64, outlet for cooling This sensor is used in case cooling application is required. Refer to Room sensor BT50 for RC-HY20-W for function and installation place.
Page 86 '22 • HM-T-415 Installation Indoor unit installation Electrical installation ◦ AUX inputs ◦ AUX outputs Up to 6 other external inputs are available on RC-HY40-W. External output is available on the port NC, NO and C on X7 terminal on AA3 board on RC-HY40-W. The relay output can AUX1 through 3 correspond to the port 9/10, 11/12, 13/14 have a max load of 2A at resistive load.
Page 87: Commissioning And Adjusting
'22 • HM-T-415 Installation Commissioning and adjusting Indoor unit installation Commissioning and adjusting CAUTION Preparations Open the hot water intake valves before heating the system up for the rst time or after a longer break in its operation in order to check whether the storage tank is lled with Before starting commissioning, check the followings;...
Page 88: Start-Up And Inspection
5.11.1.1. After that, you can choose cooling mode indication in menu 5.4 for the AUX output. Cleaning particle filter 2. O pen the safety valve (QM20) to ensure that the pressure in HSB60-W drops. - 87 -...
Page 89: Commissioning And Adjusting
'22 • HM-T-415 Installation Commissioning and adjusting Indoor unit installation Start guide Operation in the start guide NOTE Page Name and menu number Fill in the climate system with water before the switch is set language 4.6 to " " 1.
Page 90 '22 • HM-T-415 Installation Commissioning and adjusting Indoor unit installation Start guide - RC-HY20-W 4/18 - Flow set. climate sys. This menu is shown at the first time that the heat pump is started. It ensures that commissioning is carried out correctly and all necessary steps are followed.
Page 91 '22 • HM-T-415 Installation Commissioning and adjusting Indoor unit installation Set the function of each input and output for each terminal (if 9/18 - Addition connected) Setting range: ◦ A ux 1-6 ◦ Temperature sensor, cooling/heating (BT74) ◦ Temperature sensor, external return line (BT71) ◦...
Page 92 '22 • HM-T-415 Installation Commissioning and adjusting Indoor unit installation Set the operating mode of the heat pump. set automatically. Auto Factory setting: 12/18 - MIn. flow line temperature Setting range: ◦ A uto ◦ M anual ◦ Heating ◦...
Page 93 '22 • HM-T-415 Installation Commissioning and adjusting Indoor unit installation Start guide - RC-HY40-W 4/19 - Flow set. climate sys. This menu is shown at the first time that the heat pump is started. It ensures that commissioning is carried out correctly and all necessary steps are followed.
Page 94 '22 • HM-T-415 Installation Commissioning and adjusting Indoor unit installation Setting range: 9/19 - Addition ◦ A ux 1-6 ◦ Temperature sensor, cooling/heating (BT74) ◦ Temperature sensor, heating supply downstream the submersible heater (BT63) ◦ ◦ Temperature sensor, boiler (BT52) ◦...
Page 95 '22 • HM-T-415 Installation Commissioning and adjusting Indoor unit installation 11/19 - Docking 60°C Factory setting: 5–70°C Setting range: 15/19 - Heating curve Set docking for each slave (if installed). 12/19 - Time & date View and set (if desired) the space heating curve. 16/19 - Op.
Page 96 '22 • HM-T-415 Installation Commissioning and adjusting Indoor unit installation 18/19 - Start guide Information message from the controller. No action needed. 19/19 - Start guide Commissioning guide finishes here. You can set it to open again upon restart of the controller or do not open it anymore. - 95 -...
Page 97 '22 • HM-T-415 Installation Commissioning and adjusting Indoor unit installation Heating/cooling curve setting The optimum slope depends on the climate conditions in your location, the type of heating device (radiators or under floor heating) and how well insulated the house is. heating curve 1.9.1.1 system The curve is set when the heating installation is installed, but...
Page 98: Operating Time
'22 • HM-T-415 Installation Commissioning and adjusting Indoor unit installation The figure at the end of the curve indicates the curve number. Hot water circulation setting The figure beside the thermometer icon gives the curve offset. Use the control knob to set a new value. hot water recirc.
Page 99 '22 • HM-T-415 Installation Commissioning and adjusting Indoor unit installation SG Ready This function can only be used in mains networks that support the "SG Ready"-standard . Make settings for the function "SG Ready" here. Low price mode means that the electricity supplier has a low tariff and the system uses this to reduce costs.
Page 100: Control
'22 • HM-T-415 Control Control - 99 -...
Page 101: Control
'22 • HM-T-415 Control Control Control Control Display unit Display Status lamp OK button Back button Control knob Switch USB port A Display F Switch (SF1) Instructions, settings and operational information are shown The switch shows three positions: on the display. The easy-to-read display and menu system, ■...
Page 102: Menu System
'22 • HM-T-415 Control Control Control Menu system Menu system Menu system Menu system Symbols in the display Symbols in the display Menu system Menu system Symbols in the display Symbols in the display Symbols in the display Symbols in the display Menu system Menu system Menu system...
Page 103: Operation
'22 • HM-T-415 Control Control Control Control Menu number – marked sub menu Name and menu number – main menu Menu number – marked sub menu Name and menu number – main menu Menu number – marked sub menu Menu number – marked sub menu Name and menu number –...
Page 104: Use The Virtual Keyboard
'22 • HM-T-415 Control Control Control Control Use the virtual keyboard Help menu In many menus there is a symbol that indicates that extra help is available. To access the help text: 1. U se the control knob to select the help symbol. 2.
Page 105: Menu List
'22 • HM-T-415 Control Control Control Control Menu list "* Accessories are needed. ** Heat pump with cooling function required. 40" MENU RC-HY20-W RC-HY40-W 1 INDOOR CLIMATE 1.1 - temperature 1.1.1 heating ✔ ✔ 1.1.2 cooling ** ✔ ✔ 1.3 - scheduling 1.3.1 heating ✔...
Page 106: Menu 5- Service
'22 • HM-T-415 Control Control Control "* Accessories are needed. ** Heat pump with cooling function required. 40" MENU RC-HY20-W RC-HY40-W 4.1.8.7 tariff per, ext. step ✔ 4.1.10 Solar electricity ✔ ✔ 4.2 op. mode ✔ ✔ 4.3 my icons ✔...
Page 107 '22 • HM-T-415 Control Control Control "* Accessories are needed. ** Heat pump with cooling function required. 40" MENU RC-HY20-W RC-HY40-W 5.11 slave settings 5.11.1 EB101 5.11.1.1 heat pump 5.11.1.2 charge pump (GP12) 5.11.2 EB102 5.11.3 EB103 5.11.4 EB104 5.11.5 EB105 5.11.6 EB106 5.11.7 EB107 5.11.8 EB108...
Page 108 '22 • HM-T-415 Control RC-HY20/40-W – at your service Control RC-HY20/40-W – at your service Menu 1.1 - temperature If the house has several climate systems, this is indicated on Set the indoor climate the display by a thermometer for each system. Choose heating or cooling and then set the desired temperature Overview in the next menu "temperature heating/cooling"...
Page 109 '22 • HM-T-415 Control RC-HY20/40-W – at your service Control The number of steps the value has to be changed to achieve a Menu 1.3 - temperature scheduling degree change of the indoor temperature depends on the In the menu scheduling indoor climate (heating/cooling) is heating installation.
Page 110 '22 • HM-T-415 Control RC-HY20/40-W – at your service Control Time period: The start and stop time for the selected day for Time period: The start and stop time for the selected day for scheduling are selected here. scheduling are selected here. Adjusting: How much the heating curve is to be offset in Adjusting: Here, you set when active cooling will not be relation to menu 1.1 during scheduling is set here.
Page 111: Heating Curve
'22 • HM-T-415 Control RC-HY20/40-W – at your service Control The prescribed heating curve for your house can be viewed in Menu 1.9 - advanced the menu "heating curve". The task of the heating curve is to advanced 1.9 give an even indoor temperature, regardless of the outdoor temperature, and thereby energy efficient operation.
Page 112 '22 • HM-T-415 Control RC-HY20/40-W – at your service Control Flow line temperature – maximum and minimum values Wait 24 hours before making a new setting, so that the This function is used in order to limit max-min supply room temperature has time to stabilise. temperature.
Page 113 '22 • HM-T-415 Control RC-HY20/40-W – at your service Control Menu 1.9.3 - min. flow line temp. Menu 1.9.4 - room sensor settings factor system min. flow line temp. heating 1.9.3.1 room sensor settings 1.9.4 climate system 1 °C control room sensor syst 1 climate system 2 °C heating factor system...
Page 114 '22 • HM-T-415 Control RC-HY20/40-W – at your service Control Menu 1.9.5 - cooling settings time betw. switch heat/cool Setting range: 0 – 48 h cooling 1.9.5 Factory setting: 2 delta at +20 °C °C You can use RC-HY20/40-W to cool the house during hot delta at +40 °C °C periods of the year.
Page 115 flow line temp. at 20 °C °C °C flow line temp. at 30 °C '22 • HM-T-415 flow line temp. at 40 °C °C Control RC-HY20/40-W – at your service Control step difference compressors (RC-HY40-W only) CAUTION Curve 0 in menu 1.9. 1 must be selected for own curve to CAUTION apply.
Page 116 '22 • HM-T-415 Control RC-HY20/40-W – at your service Control Set the hot water capacity CAUTION Overview If comfort mode "luxury" is selected in menu 2.2 no further increase can be carried out. Sub-menus This menu only appears if a water heater is docked to the heat The function is activated immediately when a time period is pump.
Page 117: Start Time
'22 • HM-T-415 Control RC-HY20/40-W – at your service Control Menu 2.3 - scheduling Menu 2.9 - advanced Two different periods of hot water comfort per day can be Menu "advanced" has orange text and is intended for the scheduled here. advanced user.
Page 118 '22 • HM-T-415 Control RC-HY20/40-W – at your service Control Menu 2.9.2 - hot water recirc. (accessory required) hot water recirc. 2.9.2 operating time downtime period 1 period 2 period 3 operating time Setting range: 1 – 60 min Default value: 60 min downtime Setting range: 0 –...
Page 119: Get Information
'22 • HM-T-415 Control RC-HY20/40-W – at your service Control Get information Menu 3.1 - service info Information about the actual operating status of the installation Overview (e.g. current temperatures etc.) can be obtained here. But no changes can be made. Sub-menus The information is on several pages.
Page 120 '22 • HM-T-415 Control RC-HY20/40-W – at your service Control Menu 3.3 - add. heat info Menu 3.5 - indoor temp. log Information about the additional heat's settings, operating Here you can see the average temperature indoors week by status and statistics can be obtained here. But no changes can week during the past year.
Page 121: Stop Temperature
'22 • HM-T-415 Control RC-HY20/40-W – at your service Control Adjust the heat pump Menu 4.1 - plus functions Settings for any additional functions installed in RC- Overview HY20/40-W can be made in the sub-menus. Sub-menus Menu 4.1.1/4.1.2 - Pool 1/Pool 2 For the menu "MY SYSTEM"...
Page 122 '22 • HM-T-415 Control RC-HY20/40-W – at your service Control Menu 4.1.3 - internet Disconnect all users Here you make settings for connecting RC-HY20/40-W to the 1. Mark “switch off all users" and press the OK button. internet. 2. T he installation now communicates with myUpway™ to release your installation from all users connected via the internet 4.1.3 internet.
Page 123 '22 • HM-T-415 Control RC-HY20/40-W – at your service Control Menu 4.1.3.9 - proxy settings Menu 4.1.5 - SG Ready You can set proxy settings for your installation here. This function can only be used in SG Ready 4.1.5 mains networks that support the "SG Ready"-standard .
Page 124 '22 • HM-T-415 Control RC-HY20/40-W – at your service Control connection and an account for myUpway™ are required. Menu 4.1.6 - Smart price adaption™ Deselect "activated" to switch off Smart price adaption™. area Menu 4.1.8 - smart energy source™ (RC-HY40-W In this menu you state where the heat pump is located and how only) great a role the electricity price should play.
Page 125: Control Method
price, extern shunt add. tariff '22 • HM-T-415 price per kWh, low tariff Control price per kWh, high tariff RC-HY20/40 -W– at your service Control price, extern step add. tariff Menu 4.1.8.1 - settings set. price 4.1.8.2 settings 4.1.8.1 price, extern step add. tariff price per kWh, low tariff smart energy source...
Page 126 '22 • HM-T-415 Control RC-HY20/40-W – at your service Control Menu 4.1.8.3 - CO2 impact Menu 4.1.8.6 - tariff per, ext. shunt add Here you can use tariff control for the external shunted CO2 impact 4.1.8.3 additional heat. CO2, electricity date periods per year.
Page 127 '22 • HM-T-415 Control RC-HY20/40-W – at your service Control affect hot water CAUTION Setting range: on/off You cannot change from only additional heat if you do not Default value: off have a heat pump connected. affect pool temperature Setting range: on/off Functions Default value: off "compressor"...
Page 128 '22 • HM-T-415 Control RC-HY20/40-W – at your service Control language 4.6 Menu 4.7 - holiday setting Menu 4.9.1 - op. prioritisation To reduce energy consumption during a holiday you can schedule a reduction in heating and hot water temperature. Cooling can also be scheduled if the functions are connected.
Page 129: Current Value
'22 • HM-T-415 Control RC-HY20/40-W – at your service Control temperature. If the heat pump has the integrated cooling Menu 4.9.4 - factory setting user function and it is activated in the menu you can also select the All settings that are available to the user (including advanced start temperature for cooling.
Page 130 '22 • HM-T-415 Control Conflict: If two settings conflict with each other a red exclamation mark is displayed. RC-HY20/40 – at your service Control Blocking the compressor in the outdoor unit. Blocking additional heat. Blocking additional heat. If you wish to set similar scheduling for every day of the week start by filling in “all”...
Page 131 '22 • HM-T-415 '20 • HM-T-370 Control Control Control Control Sub-menus Menu 5.1 - operating settings Menu SERVICE has orange text and is intended for the Operating settings can be made for the control module in the advanced user. This menu has several sub-menus. sub-menus.
Page 132 '22 • HM-T-415 Control Control Menu 5.1.3 - max diff flow line temp. Menu 5.1.3 - max diff flow line temp. <Add. Type: shunt controlled (RC-HY40 only)> <Add. Type: shurt controlled (RC-HY40 only)> max diff compressor max diff compressor prioritised additional heat prioritised additional heat Setting range: 1 –...
Page 133 '22 • HM-T-415 Control Control Factory setting dT at DOT: 10.0 Menu 5.2 - system settings Setting range DOT: -40.0 – 20.0 °C Make different system settings for your installation here, e.g. Factory setting DOT: -20.0 °C activate the connected heat pump and which accessories are Select the type of heating distribution system.
Page 134 '22 • HM-T-415 Control Control Menu 5.3 - accessory settings Symbol Description The operating settings for accessories that are installed and Compressor (blocked) activated are made in the sub-menus for this. Menu 5.3.2 - shunt controlled add. Heat Compressor (standard) prioritised additional heat Setting range: on/oﬀ...
Page 135 '22 • HM-T-415 Control Control that you have selected. If this function is activated, you can set Default value: 55 °C "cooling flow temp. at +20°C" and "cooling flow temp. at mixing valve amplifier +40°C" for each climate system where the function is Setting range: 0.1 –...
Page 136 '22 • HM-T-415 Control Control Menu 5.4 – soft in/outputs Menu 5.9 - floor drying function You can set the function of in/output for each terminal (AUX1- length of period 1 – 7 6 and output). Setting range: 0 – 30 days Position of the terminal depends on the type of controller.
Page 137 '22 • HM-T-415 Control Control Control speed during operation heating, hot water, Menu 5.11 - heat pump settings cooling Settings for installed heat pump can be made in the submenus. Setting range: auto / manual Menu 5.11.1 - EB101 - EB108 Default value: auto Make settings specifically for the installed heat pump and Manual setting...
Page 138: Service
'22 • HM-T-415 Service Service - 137 -...
Page 139: Operation Control Function By The Indoor Unit Control
'22 • HM-T-415 Service Operation control function by the indoor unit control Operation control function by the indoor unit control Operation mode General The modes mentioned below can be chosen from the control panel. Mode Function (1) Auto ● The mode is automatically switched over between (3) Heating mode and (4) Cooling mode. Automatic switching rule is mentioned below.
Page 140 '22 • HM-T-415 Service Operation control function by the indoor unit control - 139 -...
Page 141 '22 • HM-T-415 Service Operation control function by the indoor unit control Mode transition in Auto mode Change-over of Heating/Cooling operation is controlled by detection with outdoor air temperature sensor (BT1) of the indoor unit. Threshold value depends on setting on Menu 4.9.2. Start cooling If outdoor air temperature is above setting value on Menu 4.9.2, cooling mode is chosen.
Page 142 '22 • HM-T-415 Service Operation control function by the indoor unit control Supply water temperature control in heating Target supply water temperature can be seen in Menu 1.1. Heating curve Supply temperature Heating/cooling curve setting °C Steeper curve slope Brantare kur vlu tni ng heating curve 1.9.1.1 system flow temperature °C...
Page 143 '22 • HM-T-415 Service Operation control function by the indoor unit control Flow line temperature – maximum and minimum values Wait 24 hours before making a new setting, so that the This function is used in order to limit max-min supply room temperature has time to stabilise.
Page 144 '22 • HM-T-415 Service Operation control function by the indoor unit control Water temperature control when deviated from the target When the DM value is significantly small, supply water temperature must be controlled higher than target temperature to reduce the deficit of DM value.
Page 145 '22 • HM-T-415 Service Operation control function by the indoor unit control Cooling thermo-ON / OFF control Principle of the control such as DM value is the same as heating operation. DM (Degree-Minutes) value DM value is limited in Menu 1.9.5 and does not exceed the limit. Operation state transition according to DM value According to the DM value, operating state is changed.
Page 146 '22 • HM-T-415 Service Operation control function by the indoor unit control Hot water operation control Protection control ON/OFF control Current protection Regardless of the DM value, hot water operation when tank Maximum current limit control for the outdoor unit (by indoor water temperature (BT6) lowers below Start temp HW in unit control) Menu5.1.1.
Page 147: Operation Control Function By The Outdoor Unit Control
'22 • HM-T-415 Service Operation control function by the outdoor unit control Operation control function by the outdoor unit control Determination of compressor speed Maximum and minimum compressor speed under normal operating conditions (rps) Model FDCW60VNX-W FDCW71VNX-W Operation mode Cooling Heating Cooling Heating...
Page 148 '22 • HM-T-415 Service Operation control function by the outdoor unit control < > (rps) FDCW71VNX-W Model FDCW71VNX-W A rps Heating mode B rps C rps C rps B rps A rps Normal 58.5 59.3 60.3 FDCW71VNX 54 56.5 （°C） Minimum required compressor speed under high ambient temperature condition.
Page 149 '22 • HM-T-415 Service Operation control function by the outdoor unit control Minimum required compressor speed under high condensing saturated temperature (CST or Thi-L whichever higher) in heating mode. Model FDCW60VNX-W FDCW71VNX-W Cooling mode A rps Heating mode A rps A rps Normal FDCW60VNX-W...
Page 150 '22 • HM-T-415 Service Operation control function by the outdoor unit control The pattern 3 ① Control condition In case all of the following conditions are fulfilled when the operation mode is not "Stop" 　　　 i) Inverter command changes from "STOP" to "RUN". 　　　...
Page 151: Outdoor Fan Control
'22 • HM-T-415 Service Operation control function by the outdoor unit control Outdoor fan control < FDCW60VNX-W > 1) Relations between fan speeds and revolutions Fan speed (rpm) Cooling FDCW60VNX-W Revolutions Heating 2) Control of fan motor speed (a) Starting fan motor speed is fixed by the fan motor speed excepted below case (i) (i) Operation mode is “cooling”...
Page 152 '22 • HM-T-415 Service Operation control function by the outdoor unit control b) Ambient air temperature (Tho-A) is above 41 ℃ . Fan motor speed operates the Up control according to ambient air temperature (Tho-A). Increased by 3 speed Ambient air temperature Tho-A(℃) 5) Fan speed control during normal heating operation a) Ambient air temperature (Tho-A) is below 4 ℃...
Page 153 '22 • HM-T-415 Service Operation control function by the outdoor unit control ＜ FDCW71VNX-W ＞ Outdoor fan speed a) Upper limit According to the relation between the heat exchanger temperature and outdoor air temperature, maximum fan speed is limited as follows. i) Cooling (min Tho-A...
Page 154: Silent Mode
'22 • HM-T-415 Service Operation control function by the outdoor unit control Fan speed control during cooling operation Fan speed is controlled every 15 seconds according to the outdoor heat exchanger temperature (Tho-R1,-R2), whichever the higher. Tho-R Fan speed Less than 30°C Reduced by 10 min 30°C or higher but 45°C or lower Retained...
Page 155: Defrost Operation
'22 • HM-T-415 Service Operation control function by the outdoor unit control Defrost operation < FDCW60VNX-W > Defrost operation starting conditions Defrost operation can be started only when all of the following condition are satisfied. a) After start of heat operation When it elapsed 35 minutes.(Accumulated compressor operating time) b) After end of defrost operation When it elapsed 35 minutes.(Accumulated compressor operation time)
Page 156 '22 • HM-T-415 Service Abstract of control function of AMS20-10 < FDCW71VNX-W > (1) Defrost operation starting conditions If all the following defrost operation starting conditions A or B or C or D are satisfied, defrosting operation starts. [Defrost operation starting conditions A ] (a) When cumulative operating time of the compressor elapses 37minutes or more after the previous defrost opertation ends, and 30 minutes or more after the heating operation starts.
Page 157 '22 • HM-T-415 Service Operation control function by the outdoor unit control Defrost operation ending conditions When any of following conditions is satisfied, the defrost operation end. When it has elapsed 10 minutes and 20 seconds after the start of defrost operation. When the outdoor heat exchanger temperatures (Tho-R1, Tho-R2) , whichever the lower, becomes 12°C or higher continuously for 10 seconds.
Page 158 '22 • HM-T-415 Service Operation control function by the outdoor unit control Protective control/ anomalous stop control by compressor speed Compressor discharge pipe temperature protection Protective control If the discharge pipe temperature (detected with Tho-D) exceed the setting value, the compressor speed (frequency) is controlled in order to suppress the rise of discharge pipe temperature.
Page 159 '22 • HM-T-415 Service Operation control function by the outdoor unit control Anomalous stop control i) If the outdoor heat exchanger temperature (Tho-R) exceeds the setting value, the compressor stop. ii) Whe n the outdoor heat exchanger temperature anomaly is detected 5times within 60 minutes, or 60 minutes continuously including the time of compressor stopping, coolinf overload error is displayed and E35 is recorded in the Error Log and it enters the anomalous stop mode.
Page 160 '22 • HM-T-415 Service Operation control function by the outdoor unit control Heating high pressure protection ＜ FDCW60VNX-W ＞ Protective control If the liquid line temperature of water heat exchanger (BT15=Thi-L) or the condensing saturated temperature (CST), whichever the higher. Exceeds the setting value, the compressor speed is controlled at every 10 seconds to suppress the rise of high pressure.
Page 161 '22 • HM-T-415 Service Operation control function by the outdoor unit control Anomalous stop control i) When a value detected by the low pressure sensor (LPT) satisfies any of the following conditions, compressor stops. ① When the low pressure drops to 0.079MPa or lower for 15 seconds continuously. ii) Under any of the following conditions, LP alarm is displayed and E49 is recorded in Error Log, and it enters the anomalous stop mode.
Page 162 '22 • HM-T-415 Service Operation control function by the outdoor unit control Anomalous power transistor current If the current value of power transistor exceeds the setting value, the compressor stops in order to prevent from overcurrent of inverter. When the current value of power transistor exceeds the specified value and compressor stops 4 times within 30 minutes, Inverter error is displayed and E42 is recorded in the Error Log.
Page 163 '22 • HM-T-415 Service Operation control function by the outdoor unit control Pump down control ＜ FDCW60VNX-W ＞ This function can only be started when operation mode is set to addition heat only on menu 4.2. : op. mode 4.2 auto manual add.
Page 164 '22 • HM-T-415 Service Operation control function by the outdoor unit control ＜ FDCW71VNX-W ＞ It is possible to recover the refrigerant on the piping into the outdoor unit by this function. Pump-down operation starts when the following conditions are fulfilled. Within ten minutes since the operation mode is changed to Add heat.
Page 165: Alarm List
'22 • HM-T-415 Service Disturbance in comfort Alarm list Alarm list In event of an alarm, the red lamp on the remote controller lights up (changes from green to red). First go thourgh the suggested actions shown in the display. The alarms shown on this list apply to all range.
Page 166 '22 • HM-T-415 Service Alarm list Disturbance in comfort Alarm Alarm text on the Indoor module/heat pump Cause May be due to display measures Communication fault Communication with the input Calculated supply Defective communication cables with PCA input board (AA3) is missing temperature is set to min.
Page 167 '22 • HM-T-415 Service Disturbance in comfort Alarm list Alarm Alarm text on the Indoor module/heat pump Cause May be due to display measures Communication with the ● Defective communication cables accessory board for external additional heat ● The accessory is activated in the additional heat has been display while not connected to the missing for 15 seconds...
Page 168 '22 • HM-T-415 Service Alarm list Disturbance in comfort Alarm Alarm text on the Indoor module/heat pump Cause May be due to display measures Failed defrosting Failed 10 consecutive Compressor is blocked. ● System temperature too low and/ defrost operations volume Short operating times Operation was stopped from...
Page 169 '22 • HM-T-415 Service Disturbance in comfort Alarm list Alarm Alarm text on the Indoor module/heat pump Cause May be due to display measures Inv. err Failed start for compressor Compressor is blocked. ● Defective circuit board for inverter in FDCW ●...
Page 170 '22 • HM-T-415 Service Alarm list Disturbance in comfort Alarm Alarm text on the Indoor module/heat pump Cause May be due to display measures Communication with the acces- Blocking relevant compres- ● Defective communication cables EB103/4 -GP12 sory board for GP12 has been sor and stopping relevant ●...
Page 171 '22 • HM-T-415 Service Disturbance in comfort Alarm list Alarm Alarm text on the Indoor module/heat pump Cause May be due to display measures Master is blocking relevant The outdoor unit software could be compressor and frost protec- more recent than the indoor unit's tion is safeguarded alarm.
Page 172 '22 • HM-T-415 Service Alarm list Disturbance in comfort Alarm Alarm text on the Indoor module/heat pump Cause May be due to display measures Inverter protection The inveter detected a tempo- Compressor is blocked. ● Main and group fuses and their rary fault within 10 seconds cable connections after compressor start, 5 times...
Page 173: Information Messages
'22 • HM-T-415 Service Disturbance in comfort Alarm list Information messages In event of an information message, the green light lights up on the front and symbol with a service technician is displayed in the information window, until the message is reset. These messages are not registered in the alarm log.
Page 174 '22 • HM-T-415 Service Alarm list Disturbance in comfort Alarm Alarm text on the Indoor module/heat pump Cause May be due to display measures Anti-freeze Frost protection active. Heating is permitted and Incorrect settings Occurs when the outdoor compressor is permitted if temperature is below 3°C and there is no alarm blocking no heating is permitted, and...
Page 175 '22 • HM-T-415 Service Alarm list Disturbance in comfort Alarm Alarm text on the Indoor module/heat pump Cause May be due to display measures Communication fault has Shuts down step controlled ● Defective communication cables occured additionalheat ● The accessory is activated in the Step controlled additional heat display while not connected to the communication cable...
Page 176 '22 • HM-T-415 Service Alarm list Disturbance in comfort Alarm Alarm text on the Indoor module/heat pump Cause May be due to display measures The cooling accessory room Parallel displacement with ● Sensor not connected sensor has no contact with the room sensor BT50 is set to ●...
Page 177 '22 • HM-T-415 Service Alarm list Disturbance in comfort Alarm Alarm text on the Indoor module/heat pump Cause May be due to display measures Temp. phase drop Compressor phase missing Stops the compressor ● Disruption in supply voltage ● Poor heating medium flow ●...
Page 178 '22 • HM-T-415 Service Alarm list Disturbance in comfort Alarm Alarm text on the Indoor module/heat pump Cause May be due to display measures Starts Display/instlalation has Disruption in supply voltage restarted - 177 -...
Page 179: Outdoor Unit Alarm
'22 • HM-T-415 Service Alarm list Outdoor unit Outdoor unit control PCB Alarm text Alarm INV PCB FDCW60 FDCW71 (only FDCW71) on the Description May be due to (only FDCW71) VNX-W VNX-W display Red LED Green LED(1) Yellow LED When 35 seconds passes -Any circuit breakers for FDCW off 2-time without communications...
Page 180 '22 • HM-T-415 Service Alarm list Outdoor unit Outdoor unit control PCB Alarm text Alarm INV PCB FDCW60 FDCW71 (only FDCW71) on the Description May be due to (only FDCW71) VNX-W VNX-W display Red LED Green LED(1) Yellow LED -Open circuit in connection Communication Communication between boards...
Page 181: Troubleshooting Guide
'22 • HM-T-415 Service Troubleshooting guide Troubleshooting guide 220 - High pressure alarm Are the service valves fully open? Open the service valves. Is the connection of the pressure Correct it. sensor (BP4) OK? Defective the pressure Is the characteristics of the pressure sensor (BP4) →...
Page 182: 228 - Failed Defrosting
'22 • HM-T-415 Service Troubleshooting guide 228 - Failed defrosting Is the refrigerant charged Is the water flow rate bigger than Charge correct amount of correctly according to piping minimum flow rate refrigerant length? Are the characteristics of the condenser Replace the sensor.
Page 183: 294 - Incompatible Heat Pump
'22 • HM-T-415 Service Troubleshooting guide 294 - Incompatible heat pump Is the indoor unit and the outdoor unit Replace indoor unit or outdoor unit. an appropriate combination? Replace the indoor unit or outdoor unit board. Indoor unit : AA23 Outdoor unit : PCB - 182 -...
Page 184: 404 - S. Fault Hp
'22 • HM-T-415 Service Troubleshooting guide Troubleshooting guide 404 - S. fault HP Is the pressure sensor (BP4) Connect it correctly. correctly connected? Is the saturated temperature of Does the pressure (external meter) balanced pressure same or similar Replace the refrigerant. correspond with the value to the outdoor air temperature displayed in the indoor unit?
Page 185: 403,412,415-Sensor Fault From Pca154
'22 • HM-T-415 Service Troubleshooting guide 403, 412, 415, - Sensor fault from PCA154 Is the actual sensor correctly Connect it correctly. connected? Are the characteristics for the Defective sensor - replace. sensor OK?* Replace the RC-HY board. *Refer to page 257. ・RC-HY20-W:AA2 ・RC-HY40-W:AA3 - 184 -...
Page 186: E5 - Communication Error During Operation
'22 • HM-T-415 Service Troubleshooting guide E5 - Communication error during operation Is the connection of signal wires on the oudoor unit terminal block OK? Repair signal wires. Normally, DC is 20V between 2 and 3 terminal block. Is the connection of signal wires Repair signal wires.
Page 187: E35 - High Hx Temp
'22 • HM-T-415 Service Troubleshooting guide E35 - High HX temp Are the characteristics of the heat exchanger sensor (Tho-R) Replace defective sensor. - Is the air circulation at the outdoor If one of the checks is occuring please fix. Then, reset the unit and check the unit operation.
Page 188: E36 - Hot Gas Alarm
'22 • HM-T-415 Service Troubleshooting guide E36 - Hot gas alarm Temperature-resistance characteristics (Broken wire) Are the characteristics of the discharge Replace defective sensor. pipe temperature sensor (Tho-D) OK? Does the fault also occur during Insufficient amount of refrigerant. cooling? Recharge it.
Page 189: E37 - S. Fault Tho-R
'22 • HM-T-415 Service Troubleshooting guide E37 - S. fault Tho-R Is the heat exchanger temperature sensor (Tho-R) correctly Connect it correctly. connected? Are the characteristics of the heat exchanger temperature sensor Defective sensor - replace. (Tho-R) OK? Outdoor unit control PCB defective. Replace PCB.
Page 190: E38 - S. Fault Tho-A
'22 • HM-T-415 Service Troubleshooting guide E38 - S. fault Tho-A Is the outdoor air temperature sensor Connect it correctly. (Tho-A) correctly connected? Are the characteristics of the outdoor Defective sensor - replace. air temperature sensor (Tho-A) OK? Outdoor unit control PCB defective. Replace PCB.
Page 191: E39 - S. Fault Tho-D
'22 • HM-T-415 Service Troubleshooting guide E39 - S. fault Tho-D Is the hot gas temperature sensor Connect it correctly. (Tho-D) correctly connected? Are the characteristics of the hot Defective sensor - replace. gas temperature sensor (Tho-D) OK? Outdoor unit control PCB defective. Replace PCB.
Page 192: E40 - High Pressure Alarm
'22 • HM-T-415 Service Troubleshooting guide E40 - High pressure alarm If the power source voltage to the outdoor unit is switched off and on too quickly, E40 may be displayed. This is normal. Are the service valves fully open? Open the service valves.
Page 193: E41 - Power Transister Overheat
'22 • HM-T-415 Service Troubleshooting guide E41 - Power transister overheat Outdoor unit INV PCB defective. Is DC15V detected between ② and Replace PCB. If not solved, ③ on CNI3? replace noise filter PCB as well. Is DC15V detected after Replace fan motor.
Page 194: E42 - Current Cut
'22 • HM-T-415 Service Troubleshooting guide E42 - Current cut <FDCW60VNX-W> Is the power source voltage OK? Check power source voltage. Are the services valve on the Open the service valves. outdoor unit open? Is the high pressure during Check the amount of refrigerant. operation OK? Check the refrigerant circuit.

Page 195: E42 - Current Cut
'22 • HM-T-415 Service Troubleshooting guide E42 - Current cut <FDCW71VNX-W> Is the power source voltage OK? Check power source voltage. Are the service valves on the Open the service valves. outdoor unit open? Is the high pressure during Check the amount of refrigerant. operation OK? Check the refrigerant circuit.

Page 196: E45 - Inverter Communication Error
'22 • HM-T-415 Service Troubleshooting guide E45 - Inverter communication error Is the communication between Correct the connection. the control PCB and the inverter PCB OK? Are JSW10, 11 on the inverter Set JSW10, 11 correctly. PCB all set correctly ? Note (1): See page 218.
Page 197: E47 - A/F Module Over Current
'22 • HM-T-415 Service Troubleshooting guide E47 - Inverter A/F module over current <FDCW60VNX-W> Check power source voltage. Is the power source voltage OK? Is there any foreign material Remove foreign material. (dust, fouling, etc) on the soldered surfaces on the outdoor unit control PCB? Is F3 fuse(250V,1A) blown? Replace the fuse.

Page 198: E47 - A/F Module Over Current
'22 • HM-T-415 Service Troubleshooting guide E47 - Inverter A/F module over current <FDCW71VNX-W> Check power source voltage. Is the power source voltage OK? Is wiring connection between Correct the wiring connection. inverter PCB and reactor OK? Are the resistance of T51-T62 Outdoor unit reactor PCB defective.

Page 199: E48 - Fan Alarm
'22 • HM-T-415 Service Troubleshooting guide E48 - Fan alarm <FDCW60VNX-W> Is there any foreign material Remove foreign material. obstructing the fan propeller? Replace the fan motor. If the resistance Does the fan rotate freely when between⑥(Vm):red-④(GND):blue is it is turned by hand? detected 1kΩ...

Page 200: E48 - Fan Alarm
'22 • HM-T-415 Service Troubleshooting guide E48 - Fan alarm <FDCW71VNX-W> Is there any foreign material Remove foreign material. obstructing the fan propeller? Replace the fan motor. If the resistance Does the fan rotate freely when between①(Vm):red-④(GND):blue is it is turned by hand? detected 1kΩ...

Page 201: E49 - Lp Alarm
'22 • HM-T-415 Service Troubleshooting guide E49 - LP alarm Is the low pressure sensor Correct it. correctly connected? Check the value on the low pressure sensor, via RC-HY controller, in: (1) stationary compressor, (2) compressor operation. Is the value around 0 MPa, without significant change, both in states (1) and (2)? Check the insulation resistance on...
Page 202 '22 • HM-T-415 Service Troubleshooting guide From previous page Are the service valves fully open? Open the service valves. Are the connections to the low pressure sensor and sensor for Connect it. suction gas temperature OK? Are the characteristics of the low Defective low pressure sensor or sensor for suction gas pressure sensor and sensor for...
Page 203: E51 - Power Transister Error
'22 • HM-T-415 Service Troubleshooting guide E51 - Power transister error <FDCW60VNX-W> Is the power source voltage OK? Check power source voltage. Is there any foreign material (dust, fouling, etc) Remove foreign material. on the soldered surfaces on the outdoor unit control PCB? Is F2 fuse(250V,20A) blown? Replace the fuse.

Page 204: E51 - Inverter And Fan Motor Error
'22 • HM-T-415 Service Troubleshooting guide E51 - Inverter and fan motor error <FDCW71VNX-W> Outdoor unit INV PCB defective. Is the voltage 15VDC detected Replace PCB. If not solved yet, between of CNI3 on replace noise filter PCB as well. the control PCB side? Note (1): Under anomalous conditions, the voltage becomes less than 14VDC.
Page 205: E53 - S. Fault Tho-S
'22 • HM-T-415 Service Troubleshooting guide E53 - S. fault Tho-S Is the sensor for the suction gas temperature (Tho-S) correctly Connect it. connected? Are the characteristics for the Replace the sensor. suction gas sensor OK? Outdoor unit control PCB defective. Replace PCB.
Page 206: E54 - S. Fault Lpt
'22 • HM-T-415 Service Troubleshooting guide E54 - S. fault LPT Is the low pressure sensor Connect it. correctly connected? Does the pressure (external meter) Check the amount of refrigerant. correspond with the value Check the refrigerant circuit. displayed in the RC-HY controller? Replace the low pressure sensor.
Page 207: E58 - Current Safe Stop
'22 • HM-T-415 Service Troubleshooting guide E58 - Current safe stop Adjust the refrigerant amount properly. Is the refrigerant amount normal? Is outdoor ventilation condition good? Secure space for inlet and outlet. Inspect compressor ・Check compressor wiring visually. ・Check insulation resistance. Replace the compressor.
Page 208: E59 - Inverter Error
'22 • HM-T-415 Service Troubleshooting guide E59 - Inverter error <FDCW60VNX-W> In case that compressor does not start at all and no sound or vibration exists. Check power source voltage. Is the power source voltage OK? Defect fan motor. Does compressor operate after Replace fan motor.

Page 209: E59 - Inverter Error
'22 • HM-T-415 Service Troubleshooting guide E59 - Inverter error <FDCW71VNX-W> In case that compressor does not start at all and no sound or vibration exists. Check power source voltage. Is the power source voltage OK? Is DC15V detected between② and Outdoor unit INV PCB defective.Replace PCB.

Page 210: E60 - Rotor Lock
'22 • HM-T-415 Service Troubleshooting guide E60 - Rotor lock Is the power source voltage OK? Check power source voltage. Is the power transister module Outdoor unit control PCB defective. inspection OK ? (Refer pages 213, 219.) Replace PCB. Inspect compressor ・Check compressor wiring visually.
Page 211: Caution - High Voltage
'22 • HM-T-415 Service Troubleshooting guide Model FDCW60VNX-W ◆Check point of outdoor unit CAUTION - HIGH VOLTAGE High voltage is produced in the control box. Don't touch ◆Power source and serial signal inspection electrical parts in the control box for 5 minutes after the : AC220/230/240V unit is stopped.
Page 212 '22 • HM-T-415 Service '09•SRK-DB-087D Troubleshooting guide (a) Inspection of electronic expansion valve (ii) (iii) (iv) • Inspection of electronic expansion valve as a separate unit Measuring point Resistance when normal (b) Outdoor unit fan motor check procedure source ②...
Page 213 '22 • HM-T-415 Service Troubleshooting guide (c) Inspection of resistance valve of temperature sensor Discharge pipe temperature sensor characteristics Temperature sensor characteristics [Outdoor heat exchanger temperature, outdoor air temperature] - 10 Temperature (˚C) Temperature (˚C) - 212 -...
Page 214 '22 • HM-T-415 Service Troubleshooting guide (d) Power transistor module (Including the driver PCB) inspection procedure Is the power transistor module cracked or burnt? Is there a short circuit between the power transistor module ∗ terminals? Compressor operation Is there any difference in the compressor current If there is a 10% or greater difference between phases?
Page 215: Precautions For Safety
'22 • HM-T-415 Service Troubleshooting guide Model FDCW71VNX-W ◆ Check point of outdoor unit Troubleshooting at the outdoor unit When troubleshooting the outdoor unit, firstly assess the overview of malfunction and try to presume the cause and the faulty part by checking the error code dispalyed on the remote control and flashing pattern of indicator lamps (Red LED and Green LED), and then proceed further inspection and remedy it.
Page 216 '22 • HM-T-415 Service Troubleshooting guide PCA012D049A Model FDCW71VNX-W Model FDCW71VNX-W Model FDCW71VNX-W 1) Replace the PCB after elapsing 3 minutes from power OFF. 1) Replace the PCB after elapsing 3 minutes from power OFF. 1) Replace the PCB after elapsing 3 minutes from power OFF. (Be sure to measure voltage (DC) between T26 and T27 on inverter PCB, and check that the (Be sure to measure voltage (DC) between T26 and T27 on inverter PCB, and check that the (Be sure to measure voltage (DC) between T26 and T27 on inverter PCB, and check that the...
Page 217 '22 • HM-T-415 Service Troubleshooting guide (c) Outdoor inverter PCB replacement procedure (c) Outdoor inverter PCB replacement procedure Precautions for Safety Precautions for Safety • Since the following precaution is the important contents for safety, be sure to observe them. •...
Page 218 '22 • HM-T-415 Service Troubleshooting guide Inverter PCB Power source for inverter PCB ：Between T26 and T27 Check that the voltage is discharged sufficiently. After elapsing 3 minutes from power OFF Presence and shape of electric component may vary according to model. Fig.2 Voltage measurement points Remove the harness bands from control unit after Presence and shape of electric component...
Page 219 Keep OFF SW7-2 Reserved Forced defrost Normal SW7-3 SW9 function selection see Table 1 SW8-1 '22 • HM-T-415 SW8-2 Reserved Keep OFF Reserved Keep OFF SW8-3 Service Pump down operation Normal*/Pump down Normal Troubleshooting guide * Default setting (b) Models FDC100, 125, 140VNX, 100, 125, 140VSX Switch Description Default setting...
Page 220 '22 • HM-T-415 Service Troubleshooting guide Power transistor module (Including the driver PCB) inspection procedure Is the power transistor module cracked or burnt? Is there a short circuit between the power transistor module ∗ terminals? Compressor operation Is there any difference in the compressor current If there is a 10% or greater difference between phases?
Page 221 '22 • HM-T-415 Service Troubleshooting guide (3) Inverter checker for diagnosis of inverter output (3) Inverter checker for diagnosis of inverter output Model FDCW71VNX-W Model FDCW71VNX-W Model FDCW71VNX-W Model FDCW71VNX-W (i) Setup procedure of checker. (i) Setup procedure of checker. 1) Power OFF (Turn off the breaker).
Page 222 '22 • HM-T-415 Service Troubleshooting guide Outdoor unit control failure diagnosis circuit diagram Model FDCW71VNX-W • Outdoor unit check points - 221 -...
Page 223 '22 • HM-T-415 Service Troubleshooting guide Electrical wiring diagram t° t° t° t° t° - 222 -...
Page 224: Component Replacement
'22 • HM-T-415 Service Component replacement Component replacement Indoor units HSB60-W / HSB100-W Open HSB unit 1. Remove 2 screws from the bottom part of the unit Screws are located here (bottom) ews are loc ated h here (bot Screws 2.
Page 225 '22 • HM-T-415 Service Component replacement Replace AA23 communication card 1. Disconnect all wiring and remove AA23 card by unlocking plastic PCB holders AA23 communication card munic 2. Place the new AA23 communication card, lock in on plastic holders, connect all cabling and close unit Plastic holders - 224 -...
Page 226 '22 • HM-T-415 Service Component replacement Replace pressure sensor BP4 Before removing pressure the pressure sensor make sure that you pump down the unit and that outdoor unit valves are closed! 1. Unscrew BP4 pressure sensor, remove cabling from AA23 communication card.
Page 227 '22 • HM-T-415 Service Component replacement – HSB 60-W Component replacement Replace temperature sensor BT12 and BT3 As temperature sensors BT12 (heating medium flow) and BT3 (heating medium return) are installed on the water pipes (back of the unit) and covered with insulation there is limitation to access, so it is not possible to remove damaged sensors.
Page 228 '22 • HM-T-415 Service Component replacement PT300 / PT500 Tank of PT300 / PT500 1. Remove the top panel of the tank. Tank: PT300 2. Remove the styrofoam. 3. See the tank. 4. (Details) (1)Remove the temperature gauge, plug of the heating element connector pipe and blanking plate of the inspection opening.
Page 229 '22 • HM-T-415 Service Component replacement RC-HY20-W Opening controller 1. Remove 2 screws from the bottom part of the controller. Screws 2. Remove the lid. - 228 -...
Page 230 '22 • HM-T-415 Service Component replacement Replacing display 1. Unlock display on the top part. 2. While unlocking it pull it up and remove it. - 229 -...
Page 231 '22 • HM-T-415 Service Component replacement 3. Remove communication cable (X1) and Ethernet cable (X9) from the connectors. Ethernet cable (X1) Communication cable (X9) 4. Connect cabling on the new display and place in on the controller and close it. Replace AA2 Card 1.
Page 232 '22 • HM-T-415 Service Component replacement 3. Disconnect all wiring, remove AA27 card relay card from AA2 and remove AA2 card by removing screw. Screw AA27 Relay card 4. Place the new AA2 card, connect AA27 relay card again, connect all cabling and close controller. - 231 -...
Page 233 '22 • HM-T-415 Service Component replacement Replace AA27 Card 1. Open front part by removing two screws in order to access AA27 card. Screws 5. Disconnect cabling from AA27, and remove it. AA27 Relay card - 232 -...
Page 234 '22 • HM-T-415 Service Component replacement 6. Place the new AA27 relay card again, connect all cabling and close controller. Replace AA7 Card 2. Open front part by removing two screws in order to access AA7 card. Screws 7. Disconnect wiring from AA7, and remove screw release Screw 8.
Page 235 '22 • HM-T-415 Service Component replacement RC-HY40-W Opening controller 1. Remove 2 screws from the bottom part of the controller. Screws 2. Remove the lid. - 234 -...
Page 236 '22 • HM-T-415 Service Component replacement Replacing display 1. Unlock display on the top part. 2. While unlocking it pull it up and remove it. 3. Remove communication cable (X1) and Ethernet cable (X9) from the connectors. - 235 -...
Page 237 '22 • HM-T-415 Service Component replacement Ethernet cable (X1) Communication cable (X9) 4. Connect cabling on the new display and place in on the controller and close it. Replace AA2 Card 1. Disconnect circulation pump(s) and valve(s) cabling placed on AA2-X4. 2.
Page 238 '22 • HM-T-415 Service Component replacement 3. Disconnect all cabling, remove AA27 card relay card from AA2 and remove AA2 card by removing screw. Screw AA27 Relay card 4. Place the new AA2 card, connect AA27 relay card again, connect all cabling and close controller. - 237 -...
Page 239 '22 • HM-T-415 Service Component replacement Replace AA27 Card 1. Open front part by removing two screws in order to access AA27 card. Screws 5. Disconnect cabling from AA27, and remove it. AA27 Relay card - 238 -...
Page 240 '22 • HM-T-415 Service Component replacement 6. Place the new AA27 relay card again, connect all cabling and close controller. Replace AA7 Card 2. Open front part by removing two screws in order to access AA7 card. Screws 7. Disconnect cabling from AA7, and remove screw release Screw 8.
Page 241 '22 • HM-T-415 Service Component replacement Replace AA3 Card (only RC-HY40-W) 1. Remove all cabling and screw to replace AA3 card. AA3 card Screw 2. Place the new AA3 card, connect all cabling and close controller. Replace AA5 accessory card (only RC-HY40-W) 1.
Page 242: Dip Switch
'22 • HM-T-415 Service Component replacement Screw 2. Place the new AA5 card, connect all cabling, configure DIP switch and close controller. DIP switch - 241 -...
Page 243: Outdoor Units
'22 • HM-T-415 Service Component replacement Outdoor units FDCW60VNX-W FDCW71VNX-W FDCW71VNX FDCW100VNX - 242 -...
Page 244: Fdcw60Vnx-W
'22 • HM-T-415 Service Component replacement FDCW60VNX-W Fan and fan motor (FMo1) 1. Loosen the screw and remove the top panel and service panel first. Top panel (6 screws) 2. Loosen 7 screws and remove the panel including fan grills. Front panel Service panel (3 screws)
Page 245 '22 • HM-T-415 Service Component replacement Fan and fan motor (FMo1) 5. Remove band and fan cable. Fan cable Control box 6. Release 2 metal clamps. 7. Loosen 4 screws and remove fan motor. 2 metal clamps 4 screws Compressor (CM) 1.
Page 246: Terminal Cover
'22 • HM-T-415 Service Component replacement Compressor (CM) 2. Remove the top and inner insulations. Remove a top 3. Take off sprig leaf and pull out insulation Tho-D sensor (Tho-D). Inner insulation Remove a inner insulation This unit doesn't attachment the crankcase heater.
Page 247 '22 • HM-T-415 Service Component replacement Compressor (CM) 7. Disconnect the pipes for Discharge pipe suction and discharge. 8. Remove the compressor. Suction pipe Control PCB(PWB) 1. Open the top panel. 2. Open the control box cover. Control box Note ： Be sure to do this work after elapsing 3 minutes from OFF.
Page 248 '22 • HM-T-415 Service Component replacement Control PCB (PWB) 1. Disconnect all connectors and remove the control PCB. CNHEAT CNFAN CNEEV (Connector) CNHEAT CNTH CN20S CNROM CN20S CNEEV CNROM CNFAN CNTH S.IN R.IN 2. Disconnect all terminals on the terminal block. (Terminal block) C-2(Herness color:RED) S.IN(Herness color:WHITE)
Page 249: Fdcw71Vnx-W
'22 • HM-T-415 Service Component replacement FDCW71VNX-W Fan and fan motor (FMo1) 1. Loosen the screws and Top panel (5 screws) remove the top panel and service panel first. 2. Loosen 5 screws and remove the front panel including fan grille. Front panel Service panel Service panel...
Page 250 '22 • HM-T-415 Service Component replacement Fan and fan motor (FMo1) 6. Remove tapes and fan cable. Control box Tapes Fan cable 7. Release 2 metal clamps. 8. Loosen 4 screws and remove fan motor. 2 metal clamps 4 screws Compressor (CM) 1.
Page 251 '22 • HM-T-415 Service Component replacement Compressor (CM) 2. Remove the top and inner insulations. 3 Cut off the strap and pull Tho-D out the sensor (Tho-D). Top insulation Inner insulation 4. Remove the terminal cover. 5. Disconnect the fasten terminal connectors from compressor.
Page 252 '22 • HM-T-415 Service Component replacement Control PCB (PWB1) 1. Open the top panel. 2. Open the control box cover. Control box Note: Be sure to do this work after elapsing 3 minutes from power OFF. 3. Loosen 4 screws. Control PCB 4.
Page 253 '22 • HM-T-415 Service Component replacement Inverter PCB (PWB2) 1. Remove control PCB first. Note: Be sure to do this work after elapsing 3 minutes from power OFF. 2. Disconnect the connectors. 3. Pinch the head of locking support and remove inverter Inveter PCB PCB.
Page 254 '22 • HM-T-415 Service Component replacement Noise filter PCB (PWB3) 1. Remove control PCB first. Note: Be sure to do this work aftter elapsing 3 minutes from power OFF. 3. Cut straps. CNW2 4. Disconect the connectors Noise filter PCB CNA2 and CNO2 on the noise filter PCB.
Page 255: Components
'22 • HM-T-415 Components Components - 254 -...
Page 256: Outdoor Unit
'22 • HM-T-415 Components Outdoor unit Outdoor unit Compressor Expansion valve Coil (stator) Discharge gas Suction gas Terminal block Permanent magnet (rotor) Rotor (motor) Needle valve Stator (motor) Refrigerant Crankshaft Cylinder Accumulator Rotor Refrigerant 4-way valve Low pressure sensor From discharge Electric signal Valve Pressure sensitive...
Page 257: Hsb60-W/Hsb100-W
'22 • HM-T-415 Components Outdoor unit HSB60-W / HSB100-W Installation with indoor unit HSB60-W, tank PT300, controller RC-HY20/40-W with step controlled additional heat before reversing valve for hot water and cooling function (4-pipe system) -EQ1 RC-HY20/40-W -AA25 -AA25 -RN10 -CP6...
Page 258: Temperature Sensor
'22 • HM-T-415 Service Components Temperature sensor Service External additional heat is active if it is connected to the emergency mode relay (K1, terminal block X1). Service actions Ensure that the heating medium circulates through the external Temperature sensor additional heat. NOTE Data for sensor in outdoor unit Data for sensor in indoor unit...
Page 259: Component Positions
'22 • HM-T-415 Components Component positions Component positions Indoor units Over view and design XL14 HSB60-W / HSB100-W XL13 AA23-F3 AA23-X4 AA23-X100 AA23-S3 AA23 AA23-X1 BT15 BT12 Symbol Pipe connection Symbol Sensor, thermostats Climate system supply φ 22 mm (60),...
Page 260 '22 • HM-T-415 Components Component positions Electrical components RC-HY20-W HSB60-W / HSB100-W HSB60-W AA23-X1 AA23-F3 AA23 AA23-X4 AA4 -XJ3 AA23-S3 AA23-X100 Explanation AA23 Communication board AA23-F3 Fuse for external heating cable AA23-S3 DIP switch, addressing of outdoor unit AA23-X1 Terminal block, incoming supply, connection...
Page 261 '22 • HM-T-415 Components Component positions PT300 φ - 260 -...
Page 262 '22 • HM-T-415 Components Component positions PT300 PT300 A(mm) 1634 B(mm) φC(mm) φ - 261 -...
Page 263 '22 • HM-T-415 Components Component positions PT500 φ φ φ - 262 -...
Page 264 '22 • HM-T-415 Components Component positions PT500 PT500 A(mm) 1835 B(mm) φ C(mm) φ - 263 -...
Page 265: Electrical Installation
'22 • HM-T-415 Components Component positions Electrical installation RC-HY20-W onents RC-HY20-W AA4 -XJ3 AA4 -XJ4 ion board rnal heating cable ddressing of outdoor unit ck, incoming supply, connection ck, communication with indoor Explanation trol module Base card ck, communication outdoor Display unit AA4-XJ3 USB socket AA4-XJ4...
Page 266 '22 • HM-T-415 Components Electrical installation Component positions Accessibility, electrical connection RC-HY40-W for controller The cover of the control module is opened using a Torx 25 screwdriver. Assembly takes place in the reverse order. AA4 -XJ3 AA4 -XJ4 NOTE The cover to access the base board is opened using a Torx 25 screwdriver Explanation Base card...
Page 267 '22 • HM-T-415 Components Component positions Electrical installation 4. Secure the display on the panel. 1. Press in the catch on the upper rear side of the display unit 5. When the electrical connection is ready the display must be towards you (a) and move the display unit upwards (b) so reinstalled with three mounting points again, otherwise the that the mountings unhook from the panel.
Page 268: Outdoor Units
'22 • HM-T-415 Components Component positions Outdoor units Component image FDCW60VNX-W FMo1 QM35 QM36 FDCW71VNX-W PCB2 List of components PCB1 Solenoid for 4-way valve PCB3 Compressor Expansion valve FMo1 Fan motor 63H1 Inverter & control PCB FMo1 QM35 Service valve, liquid side QM36 Service valve, gas side EEV-H...
Page 269: Accessories
'22 • HM-T-415 Components Accessories Accessories Accessories Accessory parts RC-HY20-W RC-HY40-W Model name Designation Part No. Connection Connection ECS-40M MCD291A008/ Extra climate system ECS-41M MCD291A009 RTS40M Room sensor MCD291A010 (Included) RMU40M Room unit MCD291A011 AXC30M Accessories MCD291A012 EMK300M MCD291A013 Energy meter kit EMK500M MCD291A014 - 268 -...
Page 270 '22 • HM-T-415 Components Accessories Accessories RC-HY20-W RC-HY40-W Model name Designation Part No. Connection Connection ELK9M1 Immersion heater 9kW MCD291A015A CPD11-25M/65 MCD291A016 Charging pump CPD11-25M/75 MCD291A017 VST05M MCD291A018 VST11M MCD291A019 Hot water control VST20M MCD291A020 VCC05M MCD291A021 Shuttle valve VCC11M MCD291A022 - 269 -...
Page 271: Option Parts (For Pt Tank)
'22 • HM-T-415 Components Accessories Accessories RC-HY20-W RC-HY40-W Model name Designation Part No. Connection Connection POOL40M Pool heating MCD291A030 SOLAR42M Solar heating MCD291A033 Modbus communication MODBUS40M MCD291A031 module EME20M Solar electricity MCD291A032 Option parts (for PT tank) Model name Designation Part No.
Page 272 '22 • HM-T-415 Components Accessories Model name Designation Part No. Anode M300 MCD291A026 Magnesium anode Anode M500 MCD291A027 - 271 -...
Page 273: Wind Protection
'22 • HM-T-415 Components Accessories Wind protection (prepared on site) At the site where the following conditions are satisfied, wind protection for outdoor unit is required to avoid capactity drop or abnormal stop for protection. ● Natural wind directly blows into outdoor unit. ●...
Page 274 '22 • HM-T-415 Components Accessories <For FDCW60VNX-W> Front wind guard Rear wind guard - 273 -...
Page 275 '22 • HM-T-415 Components Accessories <For FDCW71VNX-W> Front wind guard (Screw position) 4−φ6 Use M4×10 self-drilling screw to attach it where screw hole is not available. - 274 -...
Page 276 '22 • HM-T-415 Components Accessories Rear wind guard φ8 5−φ6 30゜ Side wind guard 212.5 45゜ 4−φ6 258.5 - 275 -...
Page 277: Piping System
III. Working diagram Indoor unit A: Refrigerant flow Split box B: Refrigerant return C: Space heating return HSB60-W / HSB100-W D: Space heating flow A: Refrigerant flow B: Refrigerant return 1: Condenser C: Space heating return 2: Filter D: Space heating flow...
Page 278: Outside Unit
'22 • HM-T-415 Components Piping system Outside unit FDCW60VNX-W Tho-A Tho-D Heat exchanger temperature sensor Tho-R - 277 -...
Page 279: Temperature Sensor
'22 • HM-T-415 Components Piping system FDCW71VNX-W 4-way valve Temperature sensor Temperature sensor Temperature sensor Temperature sensor Accumulator Temperature sensor 6.35 - 278 -...
Page 280: Air To Water Heat Pump
Because of our policy of continuous improvement, we reserve the right to make changes in all specifications without notice. Because of our policy of continuous improvement, we reserve the right to make changes in all specifications without notice. Copyright MITSUBISHI HEAVY INDUSTRIES THERMAL SYSTEMS, LTD. Copyright MITSUBISHI HEAVY INDUSTRIES THERMAL SYSTEMS, LTD.

This manual is also suitable for:

Hsb100-w Pt300 Pt500 Rc-hy20-w Rc-hy40-w Fdcw60vnx-w ... Show all

Mitsubishi Heavy Industries HSB60-W Technical Manual

Quick Links

Need help?

Questions and answers

Related Manuals for Mitsubishi Heavy Industries HSB60-W

Summary of Contents for Mitsubishi Heavy Industries HSB60-W

This manual is also suitable for:

Table of Contents
