Page 1 Manual No. '13 HM-T-193 • updated December 18, 2014 TECHNICAL MANUAL AIR TO WATER HEAT PUMP INDOOR UNIT HMA100V1 HMA100V2 HMA100VM1 HMS140VA1 HMS140VA2 HMS140V1 HMS140V2 OUTDOOR UNIT FDCW71VNX-A FDCW100VNX-A FDCW140VNX-A TANK UNIT HT30 Service code MT300 Changes Outdoor unit History of service code FDCW71VNX-A 1 →...
Page 2 '13 • HM-T-193 Table of Contents 　　　53 Safety precautions　 Dealing with comfort disruption Operatingmode“Add.heatonly”　　54 Emergencymode　　54 　　　55 Alarm indications Technical data　 Whathappensintheeventofanalarm?　　55 Recommendedactions　　55 Resettingalarms　　55 　　...
Page 3: Table Of Contents
'13 • HM-T-193 Table of Contents 　 E47-InverterA/Fmoduleovercurrent　 System description　 E48-Fanalarm　 E49-LPalarm　 E51(E41)-Inverterandfanmotorerror　　 Principle of operation Hydrolution E53-S.faultTho-S　 Function　 E54-S.faultLPT　　 General E57-Lowrefrigerant　 Explanation　 E59-Invertererror　　 Function check, components 　...
Page 4: Safety Precautions
'13 • HM-T-193 When install the unit, be sure to check whether the selection of installation place, power supply specifications, usage limitation (piping length, height differences between indoor and outdoor units, power supply voltage and etc.) and installation spaces. SAFETY PRECAUTIONS l We recommend you to read this “SAFETY PRECAUTIONS” carefully before the installation work in order to gain full advantage of the functions of the unit and to avoid malfunction due to mishandling. l The precautions described below are divided into and . The matters with possibilities leading to serious consequences such as death or serious personal injury due to erroneous handling are listed in the and the matters with possibilities leading to personal injury or damage of the unit due to erroneous handling including probability leading to serious consequences in some cases are listed in . These are very important precautions for safety. Be sure to observe all of them without fail. l Be sure to confirm no anomaly on the equipment by commissioning after completed installation and explain the operating methods as well as the maintenance methods of this equipment to the user according to the owner's manual. l Keep the installation manual together with owner’s manual at a place where any user can read at any time. Moreover if necessary, ask to hand them to a new user WARNING l Installation must be carried out by the qualified installer. If you install the system by yourself, it may cause serious trouble such as water leaks, electric shocks, fire and personal injury , as a result of a system malfunction. l Install the system in full accordance with the instruction manual. Incorrect installation may cause bursts, personal injury, water leaks, electric shocks and fire. l Use the original accessories and the specified components for installation. If parts other than those prescribed by us are used, It may cause water leaks, electric shocks, fire and personal injury. l When installing in small rooms, take prevention measures not to exceed the density limit of refrigerant inthe event of leakage. Consult the expert about prevention measures. If the density of refrigerant exceeds the limit in the event of leakage, lack of oxygen can occur, which can cause serious accidents. l Ventilate the working area well in the event of refrigerant leakage during installation.
Page 5 '13 • HM-T-193 l Do not open the service valves for liquid line and gas line until completed refrigerant piping work, air tightness test and evacuation. If the compressor is operated in state of opening service valves before completed connection of refrigerant piping work, air can be sucked into refrigerant circuit, which can cause bust or personal injury due to anomalously high pressure in the refrigerant. l Do not put the drainage pipe directly into drainage channels where poisonous gases such as sulphide gas can occur. Poisonous gases will flow into the room through drainage pipe and seriously affect the user’s health and safety l Only use prescribed optional parts. The installation must be carried out by the qualified installer. If you install the system by yourself, it can cause serious trouble such as water leaks, electric shocks, fire. l Do not run the unit with removed panels or protections. Touching rotating equipments, hot surfaces or high voltage parts can cause personal injury due to entrapment, burn or electric shocks. l Be sure to fix up the service panels. Incorrect fixing can cause electric shocks or fire due to intrusion of dust or water. l Do not perform any repairs or modifications by yourself. Consult the dealer if the unit requires repair. If you repair or modify the unit, it can cause water leaks, electric shocks or fire. l Do not perform any change of protective device itself or its setup condition. The forced operation by short-circuiting protective device of pressure switch and temperature controller or the use of non specified component can cause fire or burst. l Be sure to switch off the power supply in the event of installation, inspection or servicing. If the power supply is not shut off, there is a risk of electric shocks, unit failure or personal injury due to the unexpected start of fan. l Consult the dealer or an expert regarding removal of the unit. Incorrect installation can cause water leaks, electric shocks or fire. l Stop the compressor before disconnecting refrigerant pipes in case of pump down operation. If disconnecting refrigerant pipes in state of opening service valves before compressor stopping, air can be sucked, which can cause burst or personal injury due to anomalously high pressure in the refrigerant circuit. CAUTION l Carry out the electrical work for ground lead with care.
Page 6 '13 • HM-T-193 ・Locations with heavy snow. (If installed, be sure to provide base flame and snow hood mentioned in the manual) ・Locations where the unit is exposed to chimney smoke. ・Locations at high altitude. (more than 1000m high) ・Locations with ammonic atmospheres. ・Locations where heat radiation from other heat source can affect the unit. ・Locations without good air circulation. ・Locations with any obstacles which can prevent inlet and outlet air of the unit. ・Locations where short circuit of air can occur. (in case of multiple units installation) ・Locations where strong air blows against the air outlet of outdoor unit. It can cause remarkable decrease in performance, corrosion and damage of components, malfunction and fire. l Do not install the outdoor unit in the locations listed below. ・Locations where discharged hot air or operating sound of the outdoor unit can bother neighborhood. ・Locations where outlet air of the outdoor unit blows directly to plants. ・Locations where vibration can be amplified and transmitted due to insufficient strength of structure. ・Locations where vibration and operation sound generated by the outdoor unit can affect seriously. (on the wall or at the place near bed room) ・Locations where an equipment affected by high harmonics is placed. (TV set or radio receiver is placed within 5m) ・Locations where drainage cannot run off safely. It can affect surrounding environment and cause a claim. l Do not install the remote control at the direct sunlight. It can cause malfunction or deformation of the remote control. l Do not use the unit for special purposes such as storing foods, cooling precision instruments and preservation of animals, plants or art. It can cause the damage of the items. l Take care when carrying the unit by hand. If the unit weights more than 20kg, it must be carried by two or more persons. Do not carry by the plastic straps, always use the carry handle when carrying the unit by hand. Use gloves to minimize the risk of cuts by the aluminum fins. l Dispose of any packing materials correctly. Any remaining packing materials can cause personal injury as it contains nails and wood. And to avoid danger of suffocation, be sure to keep the plastic wrapper away from children and to dispose after tear it up. l Pay attention not to damage the drain pan by weld spatter when welding work is done near the indoor unit. If weld spatter entered into the indoor unit during welding work, it can cause pin-hole in drain pan and result in water leakage. To prevent such damage, keep the indoor unit in its packing or cover it. l Be sure to insulate the refrigerant pipes so as not to condense the ambient air moisture on them. Insufficient insulation can cause condensation, which can lead to moisture damage on the ceiling, floor, furniture and any other valuables. l Be sure to perform air tightness test by pressurizing with nitrogen gas after completed refrigerant piping work. If the density of refrigerant exceeds the limit in the event of refrigerant leakage in the small room, lack of oxygen can occur, which can cause serious accidents.
Page 7: Technical Data
'13 • HM-T-193 Technical data Technical data - -...
Page 8: Technical Specifications
'13 • HM-T-193 Technical data Specifications Technical specifications Specifications HMA100V1 HMA100V1 HMS140VA1 HMS140V1 Indoor model HMA100VM1 HMA100VM1 HMA100V2 HMA100V2 HMS140VA2 HMS140V2 Outdoor model FDCW1VNX-A FDCW100VNX-A FDCW140VNX-A 1 phase 230V 50Hz/ 1 phase 230V 50Hz/ 1 phase 230V 50Hz/ Power source...
Page 9: Specifications
'13 • HM-T-193 Technical data Specifications HMA100V1 HMA100V1 HMS140VA1 HMS140V1 Indoor model HMA100VM1 HMA100VM1 HMA100V2 HMA100V2 HMS140VA2 HMS140V2 Outdoor model FDCW1VNX-A FDCW100VNX-A FDCW140VNX-A Height 1300 Width (+88 with valve cover) Depth (+80 with foot rail) (+80 with foot rail) Weight...
Page 10 Use an overf low valve if system flow cannot be guaranteed. Number in the end of model name in indoor unit (e.g. HMA100V1 or HMA100V2) shows available languages in the software. 1: English, French, Italian*, German, Czech, Swedish, Danish, Norwegian, Finnish, Dutch 2: English, Latvian, Estonian, Lithuanian, Polish, Spanish*, Portuguese, Turkish, Hungarian, Slovenian *According to the indoor unit software version, Italian and Spanish may be opposite.
Page 11: OperatingTemperatureRange
'13 • HM-T-193 Technical data Operating temperature range Operating temperature range Heating (All models) with immersion heater Outdoor air temperature (°C) NOTE 1. Avoid installing outdoor unit where wind blows stronger than 5m/s. In strong wind enviroment, operable temperature range is drastically narrowed i f wind protection is not used.
Page 12 '13 • HM-T-193 Technical data Capacity diagram Capacity diagram HMA100V—FDCW71VNX HMA100VM—FDCW71VNX Heating Maximum (Nominal capacity) Minimum Outdoor air temperature (°C) Condition Supply water temperature : 45ºC Water flow rate : 1376 ℓ /h Cooling 10.0 Maximum (Nominal capacity) Minimum Outdoor air temperature (°C) Condition Supply water temperature : 7ºC Water flow rate : 1221 ℓ...
Page 13 '13 • HM-T-193 Technical data Capacity diagram HMA100V—FDCW100VNX HMA100VM—FDCW100VNX Heating Maximum (Nominal capacity) Minimum Outdoor air temperature (°C) Condition Supply water temperature : 45ºC Water flow rate : 1548 ℓ /h Cooling 12.0 Maximum 10.0 (Nominal capacity) Minimum Outdoor air temperature (°C) Condition Supply water temperature : 7ºC Water flow rate : 1376 ℓ...
Page 14 '13 • HM-T-193 Technical data Capacity diagram HMS140VA—FDCW140VNX HMS140V—FDCW140VNX Heating Maximum (Nominal capacity) Minimum Outdoor air temperature (°C) Condition Supply water temperature : 45ºC Water flow rate : 2838 /h Cooling 16.0 Maximum 12.0 (Nominal capacity) Minimum Outdoor air temperature (°C) Condition Supply water temperature : 7ºC Water flow rate : 2030 /h...
Page 15 '13 • HM-T-193 Technical data Capacity diagram Capacity correction factor according to piping length and outlet water temperature in cooling HMA100V — FDCW71VNX Outlet water temp. Outlet water temp. 18℃ 18℃ 15℃ 15℃ 12℃ 10℃ 12℃ 9℃ 10℃ 8℃ 9℃ 8℃...
Page 16 '13 • HM-T-193 Technical data Capacity diagram HMS140VA — FDCW140VNX Outlet water temp. 18℃ 15℃ 12℃ 10℃ 9℃ 8℃ 7℃ Piping length(m) How to calculate estimated capacity according to ambient temp, water outlet temp and piping length (1) Read the cooling capacity at 7degC outlet and required ambient temperature. (2) Read the capacity correction factor at required water outlet temperature and piping length.
Page 17 '13 • HM-T-193 Technical data Dimensions Dimensions Indoor unit HMA100V HMA100VM Back (42) 32 32 95 65 52 Symbol Contents Climate system supply 22 mm Climate system return 22 mm Cold water 22 mm Hot water 22 mm External heat source in XL13 XL14 External heat source out...
Page 18 '13 • HM-T-193 Technical data Dimensions HMS140VA HMS140V Front Symbol Contents XL1 ( ) Climate system supply 28 mm XL2 ( ) Climate system return 28 mm XL13 Liquid line refrigerant 3 / 8˝ XL14 Gas line refrigerant 5 / 8˝ XL21 (A) Tank circuit supply (outlet) 28 mm XL22 (B)
Page 19 '13 • HM-T-193 Technical data Dimensions HT30 XL24 XL23 Symbol Contents XL23 (B) Circulation supply (outlet) G1B (1") XL24 (A) Circulation return (inlet) G1B (1") - 18 -...
Page 20 '13 • HM-T-193 Technical data Dimensions MT300 Front 505050 Symbol Contents XL3 ( Cold water G1B (1'') XL4 ( Hot water G1B (1'') External heat source in Rc1 (1'') External heat source out Rc1 (1'') XL23 XL23 (B) Circulation supply (outlet) G1B (1'') XL24 (A) Circulation return (inlet) G1B (1'')
Page 21 '13 • HM-T-193 Technical data Dimensions MT500 Back φ760 Front XL24 XL23 φ668 Symbol Contents G1B （ 1˝ ） XL3 ( ) Cold water G1B （ 1˝ ） XL4 ( ) Hot water G1 （ 1˝ ） External heat source in G1 （...
Page 22 '13 • HM-T-193 Technical data Dimensions Outdoor unit FDCW71VNX-A - 21 -...
Page 23 '13 • HM-T-193 Technical data Dimensions FDCW100VNX-A Cable gland - 22 -...
Page 24 '13 • HM-T-193 Technical data Dimensions FDCW140VNX-A - 23 -...
Page 25 '13 • HM-T-193 Technical data Electrical circuit diagram HMA100V ① Electrical circuit diagram Indoor unit HMA100V - 24 -...
Page 26 '13 • HM-T-193 Technical data Electrical circuit diagram HMA100V ② - 25 -...
Page 27 '13 • HM-T-193 Technical data Electrical circuit diagram HMA100V ③ - 26 -...
Page 28 '13 • HM-T-193 Technical data Electrical circuit diagram HMA100V ④ - 27 -...
Page 29 '13 • HM-T-193 Technical data Electrical circuit diagram HMA100V ⑤ - 28 -...
Page 30 '13 • HM-T-193 Technical data Electrical circuit diagram HMA100VM ① HMA100VM - 29 -...
Page 31 '13 • HM-T-193 Technical data Electrical circuit diagram HMA100VM ② - 30 -...
Page 32 '13 • HM-T-193 Technical data Electrical circuit diagram HMA100VM ③ - 31 -...
Page 33 '13 • HM-T-193 Technical data Electrical circuit diagram HMA100VM ④ - 32 -...
Page 34 '13 • HM-T-193 Technical data Electrical circuit diagram HMA100VM ⑤ - 33 -...
Page 35 '13 • HM-T-193 Technical data Electrical circuit diagram HMS140V ① HMS140VA（HT30，MT300，MT500） HMS140V - 34 -...
Page 36 '13 • HM-T-193 Technical data Electrical circuit diagram HMS140V ② - 35 -...
Page 37 '13 • HM-T-193 Technical data Electrical circuit diagram HMS140V ③ - 36 -...
Page 38 '13 • HM-T-193 Technical data Electrical circuit diagram HMS140V ④ - 37 -...
Page 39 '13 • HM-T-193 Technical data Electrical circuit diagram HMS140V ⑤ - 38 -...
Page 40 '13 • HM-T-193 Technical data Electrical circuit diagram HMS140V ⑥ - 39 -...
Page 41 '13 • HM-T-193 Technical data Electrical circuit diagram Outdoor unit FDCW 71VNX-A POWER SOURCE 230V 50Hz TO INDOOR UNIT F(20A) T2 T1 Y/GN F6 (5A) PWB3 FM01 CNO2 (WH) (4A) 6 5 4 3 2 1 4 3 2 1 7 6 5 4 1 CNO1 CNW2...
Page 42 '13 • HM-T-193 Technical data Electrical circuit diagram FDCW 100VNX-A, 140VNX-A POWER SOURCE 1∼ 230V Y/GN TO INDOOR UNIT F (30A) F (8A) NOISE FILTER PWB3 F (4A) FM01 FM02 Note Do not connect any wires on the port1 on the outdoor unit. ＋...
Page 43: For Home Owners
'13 • HM-T-193 For Home Owners For Home Owners - 42 -...
Page 44 '13 • HM-T-193 For Home Owners Information about the installation Information about the installation Principle of operation Hydrolution Product information Hydrolution is a complete modern heat pump system that offers effective technical energy saving and reduced carbon dioxide emissions. Heat production is safe and economical with integrated hot water heater, immersion heater, circulation pump and climate system in the indoor unit.
Page 45: General
'13 • HM-T-193 For Home Owners Front panel, indoor module Front panel, indoor unit Hot water symbol Addition. heat symbol If the electrical addition is connected Hot water charging in progress. “I” Electrical step 1 Temporary Extra hot water operation in “A”...
Page 46: Quick Movement
'13 • HM-T-193 For Home Owners Front panel, indoor module How to use front panel All the most common settings are made from panel such as comfort etc. that you require the heat pump system to fulfil. In order to make full use of it, certain basic settings must have been made (see page 47) and installation should be carried out according to the instructions. Menu 1.0 (the temperature in the water heater) is normally shown on the display.
Page 47: General
'13 • HM-T-193 For Home Owners Comfort setting heating Comfort setting heating General 1. “Auto” The indoor temperature depends on several factors. I ndoor unit automatically selects the operating mode by ■ S unlight and heat emissions from people and household taking the outdoor temperature into account. This means machines are normally sufficient to keep the house warm that the operating mode switches between “Heating”...
Page 48: Default Heating Curve Setting
'13 • HM-T-193 For Home Owners Comfort setting heating Default Heating curve setting Setting with diagrams The diagram shows the relation between the outdoor air The basic heating is set using Menu 2.1.2 and with the temperature in the area and the target supply water temperature “Heating curve offset” knob.
Page 49: Readjusting The Default Settings
'13 • HM-T-193 For Home Owners Comfort setting heating Readjusting the default settings Comfort setting with room sensor If the required room temperature is not obtained, readjustment If MH-RG10 is installed, operation mode is chosen not only by may be necessary. outdoor air temperature but also by room air temperature. Cold weather conditions Upper limit of the outdoor air temperature to operate in Heating mode can be set in Menu 8.2.3 Stop temp Heating. ■ W hen the room temperature is too low, the “Heating curve” value is increased in Menu 2.1.2 by one increment.
Page 50: General
'13 • HM-T-193 For Home Owners Comfort setting cooling Comfort setting cooling General In the default setting, cooling operation is not allowed. In order to activate, change the setting on the Menu 9.3.3 Cooling system to “On”. NOTE The climate system must manage cooling operation. Setting must be made by installer when commissioning the system.
Page 51 '13 • HM-T-193 For Home Owners Comfort setting hot water Hot water volume 8ℓ/min Comfort setting hot water MT500 Hot water volume The integrated water heater is a coil model and is heated by 1600 10 ℓ /min circulating water, which is heated by the heat pump. 1400 During “normal” consumption it is enough to run the heat 12ℓ/min...
Page 52 '13 • HM-T-193 For Home Owners Maintenance “Extra hot water” can be activated in three different ways: Maintenance 1. Periodic time based extra hot water Indoor unit and outdoor unit require minimal maintenance after commissioning. Interval between extra hot water operation is selected in Menu 1.7. Menu 1.8 shows when the next extra hot Hydrolution contains many components and is why monitoring water operation is due.
Page 53 '13 • HM-T-193 For Home Owners Maintenance Emptying the vessel MT500 Contact your installer if the vessel in indoor unit needs emptying. Maintenance of outdoor unit Outdoor unit is equipped with control and monitoring equipment, however some exterior maintenance is still necessary. Make regular checks throughout the year that the inlet grille is not clogged by leaves, snow or anything else. During the cold months of the year, check to make sure that there isn’t a build up...
Page 54 '13 • HM-T-193 For Home Owners Dealing with comfort disruption Dealing with comfort disruption Use the following list to find and remedy any heating or hot water problems. Symptom Cause Action Low hot water temperature or a lack of hot Circuit or main MCB tripped. Check and replace blown fuses. water Heat pump and immersion heater do not heat.
Page 55: Emergency Mode
'13 • HM-T-193 For Home Owners Dealing with comfort disruption The phenomena mentioned below are not malfunction. The air conditioning system Sounds of rustling or gurgling may be heard when the operation is started, when the compressor is sounds as if water is activated/deactivated during operation, or when the operation is stopped. These are the sounds of the draining from it.
Page 56 '13 • HM-T-193 For Home Owners Alarm indications Alarm indications Different types of alarms There are many monitoring functions integrated in Hydrolution To alert you to any malfunctions, the control computer transmits ■ A larms with automatic reset (do not need to be alarm signals that can be read from the front panel display. acknowledged when the cause has disappeared).
Page 57: Installation
'13 • HM-T-193 Installation Installation - 56 -...
Page 58: General
'13 • HM-T-193 Installation Outdoor unit installation Outdoor unit installation PSB012D955G ◎This installation manual deals with outdoor units and general installation specifications only. For indoor units, refer to the respective installation manuals supplied with the units. ● ◎Read this manual carefully before you set to installation work and carry it out according to the instructions contained in this manual. ●...
Page 59 6) Installation ① Anchor bolt ﬁxed position ② Notabilia for installation 71VNX 100VNX, 140VNX ● In installing the unit, ﬁx the unit’s legs with bolts speciﬁed on the left. ● The protrusion of an anchor bolt on the front side must be kept within 15 mm. Intake '13 •...
Page 60: General
℃ '13 • HM-T-193 ② Installation Outdoor unit installation ＜＞ ○ ○ φ 0.06 ● ● ● ● ● ● ● ℃ 3. DRAIN PIPING WORK ● ● Execute drain piping by using a drain elbow and drain grommets supplied separately as optional parts, where Do not use drain elbow and grommet made of plastic for drain piping when base heater for outdoor unit is used.
Page 61 '13 • HM-T-193 Installation Outdoor unit installation Connection between indoor unit and outdoor unit FDCW71VNX FDCW100VNX FDCW140VNX - 60 -...
Page 62 ● '13 • HM-T-193 Installation Outdoor unit installation （X ）（X ） ● ● − ℃ ● ● ● ● ● ● ● ● ・・・ ℃ ・ ※ ● - 61 -...
Page 63: General
'13 • HM-T-193 Installation Indoor unit installation ■ F or HMA100V and HMA100VM, be sure that sufficinet Indoor unit installation service space is provided as shown in following page. General information ■ F or HMS140VA and HMS140V, be sure to connect a tank Transport and storage on HW port even if HW application is not used. Indoor unit can be transported vertically and must be stored ■ F or HMS140VA and HMS140V, install tank unit and its vertically and in dry conditions.
Page 64 '13 • HM-T-193 Installation Indoor unit installation Hanging indoor unit/tank on a wall HMS140V MT300 1. Ensure the final product position keeps the required <Front> clearance for installation and servicing. 2. Place the bracket attached onto the wall so that the hydrobox is not tilted and f ix it with 3 deck screws on the wall.
Page 65 '13 • HM-T-193 Installation Outdoor unit installation Indoor unit installation Dimensioning expansion vessel Emptying the vessel Internal volume in HMA100V and HMA100VM for calculating The vessel in indoor unit is emptied by opening the valve expansion vessel is 270 ℓ . The expansion vessel’s volume must (QM1) and safety valve (FL2).
Page 66 '13 • HM-T-193 Installation Indoor unit installation Manual shunting When indoor unit is set to emergency mode on the main switch SF1, the heating control system is not in operation, and is why manual shunt operation is required. 1.To change a position of valve, depress a button hook and lock it by pressing a hook shown in the photo.
Page 67: General
'13 • HM-T-193 Installation Indoor unit installation Recommended installation order Pipe installation 1 For wall mount type hang indoor unit on appropriate position General and connect indoor unit and tank unit. Pipe installation must be carried out in accordance with current 2. C onnect indoor unit to the climate system, cold and hot norms and directives.
Page 68: Dimensions And Pipe Connections
'13 • HM-T-193 Installation Iutdoor unit installation Dimensions and pipe connections <HT30> <HMA100V, HMA100VM> XL23 XL24 32 32 (42) XL13 XL15 XL14 <MT300> <HMS140VA, HMS140V> XL23 XL24 <MT500> XL14 XL22 XL21 XL13 HMA100 HMS140 Climate system supply ( ) 22 mm 28 mm XL24 Climate system return (...
Page 69 '13 • HM-T-193 Installation Indoor unit installation ■ T he end of overflow pipe from the safety valves must be Pump capacity diagram left open to the atmosphere. The water may drip from the <HMA100V, HMA100VM> pipe. ■ H T30 doesn't have a port for FL2. Safety valve should be dp [kPa] installed on site. ■ H MS140VA and HMS140V need to connect a buffer vessel on the hot water tank even if hot water supply is not necessary.
Page 70 '13 • HM-T-193 Installation Iutdoor unit installation Connecting the climate system <MT300> ■ S trainer and shut off valve are supplied together with the indoor unit. Install them horizontally on XL2 as shown in the following drawing. Strainer should be put as close as possible to XL2 in order to prevent contamination from entering the indoor unit.
Page 71 '13 • HM-T-193 Installation Outdoor unit installation Outdoor unit installation Indoor unit installation Connecting hot water coil to water main <HMA100V, HMA100VM> The water heater in the indoor unit must be supplied with necessary set of valves. Connect marked pipe to HW supply and marked pipe to (Parallel screw, G1) cold water main.
Page 72 '13 • HM-T-193 Installation Iutdoor unit installation Indoor unit has a drain port on the bottom. Connect a drain MT500 hose to drain condensed water when cooling application is used. <HMS140VA, HMS140V> BT19 Drain port BT24 (Parallel screw, G1) (Parallel screw, G1) Connecting refrigerant pipes See Installation manual for outdoor unit.
Page 73 '13 • HM-T-193 Installation Iutdoor unit installation Dockings Hydrolution with climate system and any external heat source MH-RG10 Distributionssystem Climate system Required safety Erf. säker- equipment hetsutr. BT 1 Tillsats External heat source Indoor unit Outdoor unit Symbol key NOTE Symbol Description Venting valve...
Page 74: External Heat Source
'13 • HM-T-193 Installation Indoor unit installation Climate system Radiator system Under floor heating systems Fan convector system GP10 GP10 GP10 Extra Extra Extra system system system volym volym volym Ö ö r l i t Ö ö r l i t Ö...
Page 75: General
'13 • HM-T-193 Installation Iutdoor unit installation Electrical installation Principle diagram, electrical installation General Electrical distribution Indoor unit must be installed via an isolator switch in unit Incoming supply accordance with the local codes and regulations. Power and Isolator switch communication cable Other electrical equipment, except the outdoor sensors, current Current sensor*...
Page 76 '13 • HM-T-193 Installation Indoor unit installation <HMS140VA, HMS140V> <MT300> BT30-FD1 X101 X100 <MT500> AA22 BT30-FD1 S1 109 X101 -X101 -X100 X100 Explanation Symbol Type Scale length of <HT30> conductor (mm) HMA100 HMS140 X100 AA22 X101 Cable gland Cable gland BT30-FD1 Terminal block, incoming mains supply...
Page 77 '13 • HM-T-193 Installation Iutdoor unit installation Connecting the supply Miniature circuit-breaker (FA1, FA2, FA3) Incoming supply is connected on terminal block (X1) via cable The automatic heating control system, circulation pumps and gland (UB1). The cable must be dimensioned according to the their wiring in indoor unit, are internally fuse protected with a applicable norms. miniature circuit breaker (FA1). Indoor unit can be connected with either 400 V 3NAC or 230 Outdoor unit and equipment are internally fuse protected in V 1AC.
Page 78 '13 • HM-T-193 Installation Iutdoor unit installation <FDCW71VNX> Main circuit breaker size setting (R24 on AA22) (Applicable only in case of 3 phase power supply) Outdoor unit The size of the property’s main circuit breaker is set using the 1 2 3 knob (R24) on the circuit limiter PCB, (AA22). The setting can be read in Menu 8.3.4.
Page 79 '13 • HM-T-193 Installation Iutdoor unit installation A current sensor should be installed on each incoming phase PCB, terminal and wiring diagram conductor in to the distribution box to measure the current. The The following connections are made on the PCB (AA22). distribution box is an appropriate installation point. See wiring diagram for complete wiring diagram of the PCB.
Page 80 '13 • HM-T-193 Installation Indoor unit installation Contact for changing the room temperature External mixing valve (EP21-QN11, accessory) An external contact such as a room thermostat or a timer can Connection and function are described in the Installation be connected to indoor unit to change the flow temperature and instructions for accessory ESV 22/28. consequently the room temperature.
Page 81 '13 • HM-T-193 Installation Iutdoor unit installation Summary of the function of Current External sensor External thermostat (3phase thermostat the terminals on PCB AA22 only) on timer on timer system 1 system 2 Tariff A Tariff B L1 L2 L3 Outdoor sensor Optional other than...
Page 82 '13 • HM-T-193 Installation BT30 Indoor unit installation How to connect external circulation pump and heat source on X3 <HMA100V, HMA100VM> Open 3 4a 4b 5a 5b <HMS140VA, HMS140V> How to connect external circulation pump How to connect external heat source 1 2 3 4a 4b 5a 5b 1 2 3 4a 4b 5a 5b 3 4a 4b 5a 5b...
Page 83 '13 • HM-T-193 Installation Start-up and inspection Start-up and inspection MT300 Preparations Connect outdoor and indoor unit (refrigerant pipe and wiring) and connect indoor unit to the climate system. Filling the climate system 1. Ensure that the pressure gauge (BP5) is visible. 2. Ensure the valve to expansion vessel is closed (HMS140VA and HMS140V only).
Page 84: Comfort Setting Cooling
'13 • HM-T-193 Installation Start-up and inspection 4. Check the supply and return line temperatures in Menu 2.5. Commissioning Adjust the circulation pump speed in Menu 2.1.5 so that the Outdoor unit difference between these temperatures is according to the diagram below.
Page 85: Inspection Of The Installation
'13 • HM-T-193 Installation Start-up and inspection Commissioning Hydrolution without outdoor Inspection of the installation unit connected Current regulations require the heating installation to be inspected before it is commissioned. The inspection must be 1. Check that the temperature limiter (FD1) has not tripped. carried out by a suitably qualified person and should be 2.
Page 86 '13 • HM-T-193 Installation Start-up and inspection Basic Menu settings to be checked 1. Single heating application with a room sensor (MH-RG10) Overflow valve Extra system volume MH-RG10 BT 1 Fill in the altered set value on the blank cell of “Set value”. As for the set value which is already written in the cell, check if the setting is properly changed.
Page 87 '13 • HM-T-193 Installation Start-up and inspection 2. Dual heating application with a room sensor (MH-RG10) EP21-GP10 EP21 EP21-QN11 -BT2 EP21-BT3 GP10 MH-RG10 Överströmnings ventil Overflow valve BT 1 1. Initial settings Function Menu No. Default value Set value Check Remarks Language 8.1.2...
Page 88 '13 • HM-T-193 Installation Start-up and inspection Solar panels Solfång Solar panels 3. Single heating application with external heat source Ackumulator Accumulator Overflow valve Extra system volume MH-RG10 External heat source Oil/pellet b ALT 2 ALT. 2 GAS V. ALT. 1 ALT 1 boiler.
Page 89 '13 • HM-T-193 Control Start-up and inspection Checklist: Checks before commissioning Hot water Notes Checked Non-return valve Is it installed in right direction ? Safety valve Is it installed in cold water line ? Mixer valve Is it installed in right direction ? Heating Notes Checked...
Page 90: Control
'13 • HM-T-193 Control Control - 89 -...
Page 91: Menu Management
'13 • HM-T-193 Control Control Control Display Changing parameters Operating symbols Value of the current parameter In order to change a parameter (value): 1. Access the required menu. I II III I II 2. Press button, the numerical value starts to flash. 5 0 .
Page 92: Menu Tree
'13 • HM-T-193 Control Control Menu tree 1.0 [N] Hot water temp. 1.1 [N] Max HW/Peroid time 1.2 [N] Start temperature HW 1.3 [N] Stop temperature HW 1.4 [U] Stop temperature XHW 1.5 [U] Heat pump stop XHW 1.6 [U] Max heat p. time XHW 1.7 [U] Interval XHW 1.8 [U] Next XHW action 1.9 [U] HW run time...
Page 93 '13 • HM-T-193 Control Control 2.0 [N] Supply temp. 2.1.0 [N] Heating settings 2.1.1 [N] Offset heating/Total 2.1.2 [N] Heating curve 2.1.3.0 [U] Own heating curve 2.1.3.1 [U] Supply temp.at +20 2.1.3.2 [U] Supply temp.at -20 2.1.3.3 [U] Buckling temperature 2.1.3.4 [U] Supply t.
Page 94 '13 • HM-T-193 Control Control 3.0 [N] Supply temp. 2 4.0 [N] Outdoor temp. 3.1 [N] Offset heating/Tot 2 4.1 [N] Outdoor avg. temp. 3.2 [N] Heating curve 2 4.2 [U] Outdoor filter time 3.3 [U] Min supply temp. 2 4.3 [U] Outdoor avg.
Page 95 '13 • HM-T-193 Control Control 7.0 [N] Clock 8.0 [N] Other adjustments 7.1 [N] Date 8.1.0 [N] Display settings 8.1.1 [N] Menu type 7.2 [N] Time 8.1.2 [N] Language 7.3.0 [U] Temp set back 7.3.1 [U] Set back time 8.1.3 [N] Display contrast 7.3.2 [U] Set back temp +/- 8.1.4 [N] Light intensity 7.3.3 [U] Heating system...
Page 96 '13 • HM-T-193 Control Control 9.0 [S] Service menus 9.1.0 [S] Heat pump settings 9.1.1 [S] DM start heating 9.1.2 [S] DM start cooling 9.1.3 [S] Stop Temp. heat low 9.1.4 [S] Stop Temp. heat high 9.1.5 [S] Stop Temp. cool low 9.1.6 [S] Stop Temp.
Page 97 '13 • HM-T-193 Control Control 9.0 [S] Service menus 9.3.10.0 [S] Floor drying setting 9.3.10.1 [S] Floor drying 9.3.10.2 [S] Period time 1 9.3.10.3 [S] Temp. period 1 9.3.10.4 [S] Period time 2 9.3.10.5 [S] Temp. period 2 9.3.10.6 [S] Return 9.3.11 [S] Supply pump exer.
Page 98 '13 • HM-T-193 Control Control 9.0 [S] Service menus 9.8.x.6 [S] Run time compressor 9.8.x.7 [S] Outdoor avg. 1min. 9.8.x.8 [S] Outdoor temp Tho-A 9.8.x.9 [S] Supply/Return temp 9.8.x.10 [S] Condensor out 9.8.x.11 [S] Hot water temp. 9.8.x.12 [S] CompFreq act/set 9.8.x.13 [S] Heat Ex Tho-R1 9.8.x.14 [S] Heat Ex Tho-R2 9.8.x.15 [S] Suction temp.
Page 99: Main Menus
'13 • HM-T-193 Control Control Main menus Menu 1.0 [N] Hot water temp. Menu 9.0 [S] Service menus The current hot water temperature in the vessel is shown here. This menu and its sub-menus are only shown on the display screen when access has been selected in Menu 8.1.1.
Page 100 '13 • HM-T-193 Control Control 1.0 [N] Hot water temp. Menu 1.1 [N] Max HW/Period time Menu 1.10.0 [S] HW charge act/set The time of the hot water period and the time for the whole Shows the actual and target values for the hot water charging temperature.
Page 101 '13 • HM-T-193 Control Control 2.0 [N] Supply temp. Menu 1.10.9 [S] HW reg value for xP Menu 2.1.0 [N] Heating settings Here you select the breaking point when the flow is no longer Heating settings are made in the sub-menus for this menu. linear to the control signal in the heating medium pump.
Page 102 '13 • HM-T-193 Control Control Control Menu 2.1.4 [U] Min supply heating Menu 2.2.4 [N] Min supply cooling The set minimum level for the supply temperature to the The set minimum level for the supply temperature to the cooling system is shown here. heating system is shown here.
Page 103 '13 • HM-T-193 Control Control 3.0 [N] Supply temp. 2 Menu 3.1 [N] Offset heating/Tot 2 Menu 3.6.1 [U] Supply temp.at +20 The heating curve offset 2 is selected here. The supply temperature at an outdoor air temperature of +20 °C is selected here. The total offset of heat curve 2 is also shown here.
Page 104 '13 • HM-T-193 Control Control 4.0 [N] Outdoor temp. 5.0 [N] Heat pump Menu 4.1 [N] Outdoor avg. temp. Menu 5.1 [N] Number of starts The accumulated number of starts with the compressor in This menu shows the average outdoor temperature according outdoor unit is shown here.
Page 105 '13 • HM-T-193 Control Control 6.0 [N] Room temperature* Requires accessory and activation in Menu 9.3.6. Menu 5.15.0 [S] OU communication Readings regarding any communication errors can be made in Menu 6.1 [U] Room compensation the sub-menus to this menu. A factor is selected here that determines how much the Menu 5.15.1 [S] Com.
Page 106 '13 • HM-T-193 Control Control 7.0 [N] Clock Menu 7.5.0 [U] Vacation set back Menu 7.1 [N] Date Holiday settings are made in the sub-menus to this menu. The current date is set here. When the holiday function is active, the calculated supply line Menu 7.2 [N] Time temperature is reduced according to the setting and hot water charging can be switched off.
Page 107 '13 • HM-T-193 Control Control 8.0 [N] Other adjustments Menu 7.6.0 [N] Silent mode Menu 8.1.0 [N] Display settings Settings concerning language and menu type are set in the sub- Setting is made in the sub-menu of this menu if Silent mode is menus to this menu.
Page 108 '13 • HM-T-193 Control Control Menu 8.2.3 [U] Stop temp. heating Menu 8.3.7 [U] Return The average outdoor air temperature at which the heat pump (in Return to Menu 8.3.0. auto mode) is to stop heat production. Menu 8.5.0 [U] Period settings When the average outdoor air temperature falls below Stop temp.
Page 109: S]ServiceMenus
'13 • HM-T-193 Control Control 9.0 [S] Service menus Menu 9.1.0 [S] Heat pump settings Menu 9.1.8 [S] Min CompFreq act/set Select the min compressor frequency here. Both actual and set Settings for outdoor unit are made in the sub-menus to this values are shown.
Page 110 '13 • HM-T-193 Control Control Menu 9.2.4 [S] Reg. amplification Menu 9.3.4 [S] Heating system 2 Usage of heating system 2 is defined in this menu. If “Off” is P section for additional heat control. selected in Menu 9.3.3 only “Off” or “Heat” can be selected Setting range: 0 –...
Page 111 '13 • HM-T-193 Control Control Menu 9.3.9 [S] Operating state Menu 9.3.11 [S] Supply pump exer. Describes the operating status of Hydrolution. Pump operation can be deactivated here. Pump is in operation for 2 minutes 12 hours after last operation. Shutdown: Additional heater and heat pump are shutdown due to an alarm.
Page 112 '13 • HM-T-193 Control Control Menu 9.3.16 [S] Type of HW sensor Menu 9.5.7 [S] Program version Here you can select whether to use hot water sensors that The current program software version in indoor unit is shown manage higher temperatures (above 90 °C) or not. here.
Page 113 '13 • HM-T-193 Control Control Default value: Off Menu 9.8.x.1 [S] Time Menu 9.6.3 [S] Max deltaF Menu 9.8.x.2 [S] Alarm type The parameter for the heat regulator’s max change of the target Error code is displayed. For details see page 152. compressor frequency is selected here.
Page 114 '13 • HM-T-193 Control Control Menu 9.8.x.3 [S] Run status Menu 9.8.x.4 [S] Run status last Menu 9.8.x.5 [S] Run status time Menu 9.8.x.6 [S] Run time compressor Menu 9.8.x.7 [S] Outdoor avg. 1min. Menu 9.8.x.8 [S] Outdoor temp Tho-A Menu 9.8.x.9 [S] Supply/Return temp Menu 9.8.x.10 [S] Condensor out Menu 9.8.x.11 [S] Hot water temp.
Page 115: System Description
'13 • HM-T-193 System description Principle of operation System description - 114 -...
Page 116 '13 • HM-T-193 System description Principle of operation Principle of operation Hydrolution Function Hydrolution is a system that can produce heating, hot water and cooling. The principle during heating can be simplified as follows: ① The refrigerant in outdoor unit retrieves heat from the outdoor air then compresses it, which increases the temperature further.
Page 117 '13 • HM-T-193 System description Principle of operation Principle of operation Heating operation mode [Alternating mode] (When the heat load can be covered by the capacity of outdoor unit) 100% of hot water from water heat exchanger goes to radiator. Hot water in the tank is not used.
Page 118 '13 • HM-T-193 System description Hot water operation mode (When the water temperature in tank is decreased below setting temperature) 100% of hot water from water heat exchanger goes to tank. QM31:closed (Take note that water flow going in/out tank is different from combined mode).
Page 119: General
'13 • HM-T-193 System description General General Outdoor unit Tho-A Temperature sensor, outdoor air Explanation Tho-D Temperature sensor, hot gas Tho-R1 Temperature sensor, heat exchanger out External QN11 Mixing valve Tho-R2 Temperature sensor, heat exchanger, in QN12 Shuttle valve for heating/cooling Tho-S Temperature sensor, suction gas Non-return valve...
Page 120: Radiators - Only Heating
'13 • HM-T-193 System description Radiators - only heating Radiators - only heating HMA100V - FDCW100VNX (71VNX) 4-way valve 63H1 High pressure switch Compressor motor Current sensor EEV-C Expansion valve, cooling EEV-H Expansion valve, heating FMo1 Fan motor Low pressure sensor Tho-A Temperature sensor, outdoor air Tho-D...
Page 121: Hms140V(Mt300)-Fdcw140Vnx
'13 • HM-T-193 System description Principle of operation HMS140V (MT300)-FDCW140VNX Function Installation requirements The heat pump prioritises hot water charging. The compressor See page 9. output is adjusted according to the outdoor temperature. The circulation pump varies the flow to maintain a high charge temperature.
Page 122: Underfloor Heating And Cooling
'13 • HM-T-193 System description Underfloor heating and cooling Underfloor heating and cooling 4-way valve 63H1 High pressure switch Compressor motor Current sensor EEV-C Expansion valve, cooling EEV-H Expansion valve, heating FMo1 Fan motor Low pressure sensor Tho-A Temperature sensor, outdoor air Tho-D Temperature sensor, hot gas Tho-R1...
Page 123: Fan Convectors - Heating And Cooling
'13 • HM-T-193 System description Fan convectors - heating and cooling Fan convectors - heating and cooling 4-way valve 63H1 High pressure switch Compressor motor Current sensor EEV-C Expansion valve, cooling EEV-H Expansion valve, heating FMo1 Fan motor Low pressure sensor Tho-A Temperature sensor, outdoor air Tho-D...
Page 124: Dual System - Heating And Cooling
'13 • HM-T-193 System description Dual system - heating and cooling Dual system - heating and cooling 4-way valve 63H1 High pressure switch Compressor motor Current sensor EEV-C Expansion valve, cooling EEV-H Expansion valve, heating EP21-BT2 Temperature sensor, supply 2 FMo1 Fan motor EP21-BT3...
Page 125: Cooling
'13 • HM-T-193 System description Underfloor heating and fan convectors- heating and cooling Underfloor heating and fan convectors- heating and cooling 4-way valve 63H1 High pressure switch Compressor motor Current sensor EEV-C Expansion valve, cooling EEV-H Expansion valve, heating FMo1 Fan motor Low pressure sensor Tho-A...
Page 126: External Heat Source
'13 • HM-T-193 System description External heat source External heat source Function By connecting a solar heat collector via intermediate heat exchanger to indoor unit or tank, the solar heat can produce hot water and heating for the house. If the solar panel does not produce necessary heat, the outdoor unit and the imnersion heater generate heat.
Page 127 '13 • HM-T-193 System description External heat source ↑ Connected to X3:2 and X3:4 with the jumper wire on X3:2-3 removed. For details, see page 81. Function Hydrolution engages additional heat source when the compressor output is not sufficient for the house demand. When the additional heat source is connected, valves QM 30 and QM31 shift to the heating system.
Page 128 '13 • HM-T-193 System description External heat source ↑ Connected to X3:2 and X3:4 with the jumper wire on X3:2-3 removed. For details, see page 81. Function Hydrolution engages additional heat source when the compressor output is not sufficient for the house demand. When the additional heat source is connected, valves QM 30 and QM31 shift to the heating system.
Page 129: Wood
'13 • HM-T-193 System description External heat source Wood Function By connecting a wood-fired boiler via accumulator tank to indoor unit or tank, hot water and heat to the house can be produced by If there is no heat in the accumulator tank, heat and hot water are produced by the heat pump or by internal electric heater according to the selected operating mode.
Page 130: Service
'13 • HM-T-193 Service Service - 129 -...
Page 131: Operation Control Function By The Indoor Unit Control
'13 • HM-T-193 Service Operation control function by the indoor unit control Operation control function by the indoor unit control Operation mode General The modes mentioned below can be chosen from the control panel. Hot water operation always has the first priority over heating/cooling. Mode Function (1) Auto...
Page 132 '13 • HM-T-193 Service Operation control function by the indoor unit control - 131 -...
Page 133 '13 • HM-T-193 Service Operation control function by the indoor unit control Mode transition in Auto/AutoC mode Change-over of Heating/Cooling/Hot water operation is controlled by detection with outdoor air temperature sensor (BT1) of the indoor unit. Threshold value depends on setting on Menu 8.2.3 – 8.2.5. Menu 8.2.3 Stop temp.
Page 134 '13 • HM-T-193 Service Operation control function by the indoor unit control Exceptional case of mode transition In order to prevent water pipes on the system from freezing, there is some exception of mode transition when the outdoor air temperature (BT1) drops below 0°C. 1) In (4) Cooling or (5) Hot water mode;...
Page 135 '13 • HM-T-193 Service Operation control function by the indoor unit control Supply water temperature control in heating Target supply water temperature can be seen in Menu 2.0 (for heating system 1) and 3.0 (for heating system 2). For dual system, the target temperature for downstream heating system must be lower than that for upstream heating system. Heating curve Heating curve is the basic principle to decide the target supply water temperature for heating.
Page 136 '13 • HM-T-193 Service Operation control function by the indoor unit control Heating curve offset It is possible to offset the heating curve chosen in the menu above in order to obtain higher target supply water temperature. The offset for heating system 1 can be set using the knob on the controller. The set value can be seen in Menu 2.1.1. The figure below shows the case that heating curve 9 is chosen with heating curve offset +2.
Page 137 '13 • HM-T-193 Service Operation control function by the indoor unit control Information about the installation Upper / Lower limit of the supply water temperature Regardless of the heating curve setting and the outdoor air temperature, target water temperature cannot exceed the min/max supply water temperature set in Menu 2.1.4 and 2.3 for heating system 1 or in Menu 3.3 and 3.4 for heating system 2.
Page 138 '13 • HM-T-193 Service Operation control function by the indoor unit control Heating thermo-ON / OFF control The control by DM value is the basic principle to operate/stop the outdoor unit operation. DM (Degree-Minutes) value DM value is integrated value of the gap between the target and actual supply water temperature. Compressor required speed and electric heater ON/OFF are controlled by the DM value.
Page 139 '13 • HM-T-193 Service Operation control function by the indoor unit control Exceptional processing of DM value In case the actual supply water temperature BT2 deviates from the target temperature drastically, DM value is sometimes forcibly overwritten to make the water temperature close to the target quickly. Forced outdoor unit operation In case the actual supply water temperature is lower than the target temperature and the gap is bigger than the value set in Menu 9.3.12 (Supply temp diff) when the outdoor unit is not operating, the DM value is overwritten to smaller value than in Menu 9.1.1 by 1,...
Page 140 '13 • HM-T-193 Service Operation control function by the indoor unit control Supply water temperature control in coonling Principle such as cooling curve, cooling curve offset and upper/lower limit is the same as heating operation. Target supply water temperaure can be checked inMenu 2.0. Cooling curve can be chosen in Menu 2.2.2 Cooling curve Cooling curve is the basic principle to decide the target supply water temperature for cooling.
Page 141 '13 • HM-T-193 Service Operation control function by the indoor unit control Cooling thermo-ON / OFF control Principle of the control such as DM value is the same as heating operation. DM (Degree-Minutes) value DM value is limited from -100 to +400 and does not exceed the limit. Operation state transition according to DM value According to the DM value, operating state is changed.
Page 142 '13 • HM-T-193 Service Operation control function by the indoor unit control Hot water operation control Hot water operation is prioritized over heating and cooling. ON/OFF control Regardless of the DM value, hot water operation when tank water temperature (BT6) lowers below Start temp HW in Menu 1.2. It ﬁnishes when the tank water temperature reaches Stop temp HW in Menu 1.3.
Page 143 '13 • HM-T-193 Service Operation control function by the indoor unit control Timing chart of DM value and supply water temperature Water temperature During this period, target water temperature is (Menu 9.6.7)-1.5°C Overshoot upper limit (Menu 9.6.7) Target water temperature by heating curve During Combined mode, target supply water temperature is set at 1K lower than the actual Actual supply water temp.
Page 144: Protection Control
'13 • HM-T-193 Service Operation control function by the indoor unit control Protection control Current protection 1) Maximum current limit control for the outdoor unit (by indoor unit control) When the operation current of the outdoor unit comes close to the limit, request compressor speed is retained in order to keep the current.
Page 145: Operation Control Function By The Outdoor Unit Control
'13 • HM-T-193 Service Operation control function by the outdoor unit control Operation control function by the outdoor unit control Determination of compressor speed (frequency) Maximum and minimum frequency under normal operating conditions (rps) Model FDCW71VNX FDCW100VNX FDCW140VNX Operation mode Cooling Heating Cooling...
Page 146: Fdcw71Vnx
'13 • HM-T-193 Service Operation control function by the outdoor unit control Minimum required frequency adjustment under outdoor air temperature (Tho-A) condition According to the outdoor air temperature, minimum required frequency is offset by as per below table. Model FDCW71VNX FDCW100VNX FDCW140VNX Cooling mode...
Page 147: Fdcw100Vnx − Fdcw140Vnx
'13 • HM-T-193 Service Operation control function by the outdoor unit control Model Operation Mode A rps B min FDCW71VNX Cooling FDCW100VNX Cooling FDCW140VNX Cooling Compressor protection start III [Control condition] In case all of the following conditions are fulfilled a) Restarting the compressor in heating mode after 2 hours or longer stop of compressor.
Page 148 '13 • HM-T-193 Service Operation control function by the outdoor unit control b) Lower limit Model Operation Mode Min.rpm Cooling FDCW71VNX Heating Cooling FDCW100VNX Heating Cooling FDCW140VNX Heating Fan speed control during cooling operation Fan speed is controlled every 15 seconds according to the outdoor heat exchanger temperature (Tho-R1,-R2), whichever the higher.
Page 149 '13 • HM-T-193 Service Operation control function by the outdoor unit control Defrosting Model 71-140 Defrosting start conditions If all of the following defrosting condition A or condition B are met, the defrosting operation starts. For model 140, SV1 is open when 4 way valve switches, and closed when low pressure keeps 0.55MPa or higher for 5 seconds or longer.
Page 150 '13 • HM-T-193 Service Operation control function by the outdoor unit control Protective control/ anomalous stop control by compressor speed (frequency) Compressor discharge pipe temperature protection Protective control If the discharge pipe temperature (detected with Tho-D) exceed the setting value, the compressor speed (frequency) is controlled in order to suppress the rise of discharge pipe temperature.
Page 151 '13 • HM-T-193 Service Operation control function by the outdoor unit control Heating high pressure protection Protective control i) If the liquid line temperature of water heat exchanger (BT15=Thi-L) or the condensing saturated temperature (CST), whichever the higher, exceeds the setting value, the compressor speed (frequency) is controlled to suppress the rise of high pressure.
Page 152: Fdcw100Vnx
'13 • HM-T-193 Service Operation control function by the outdoor unit control Overcurrent protection Current safe control I When the inverter primary current (CT current) reaches following value, the compressor speed is reduced until it gets to the cancellation value. Model Operation Mode Current (A)
Page 153 '13 • HM-T-193 Service Operation control function by the outdoor unit control 10) Anti-freeze control by the compressor frequency control It depends on the command from indoor unit 11) Refrigerant amount shortage protection Under the control of compressor protection start Ⅲ during cooling operation, the following control is performed by detecting the liquid line temperature of indoor unit (BT15=Thi-L) and inlet water temperature (BT3=Twin).
Page 154 '13 • HM-T-193 Service Operation control function by the outdoor unit control Pump-down control It is possible to recover the refrigerant on the piping into the outdoor unit by this function. Pump-down operation starts when the following conditions are fulfilled. Within ten minutes since the operation mode is changed to Add heat.
Page 155 '13 • HM-T-193 Service Alarm list Alarm list Alarm with automatic reset Alarm Alarm text on the Triggers alarm Resets alarm display When condenser supply (BT12) is less than 5°C. When condenser supply is greater than 14°C. Low condenser out High KF When condenser supply is greater than 60°C and When condenser supply is lower than 51°C.
Page 156 '13 • HM-T-193 Service Alarm list Alarm Alarm text on the Description May be due to display Aborted defrost - Insufficient water flow Occurs if alarm 78 occurs 10 times continuously during defrost operation. Also see the troubleshooting guide on page 166. S.
Page 157 '13 • HM-T-193 Service Alarm list Alarm Alarm text on the May be due to Description display S. fault Tho-D Sensor fault, hot gas in outdoor unit (Tho-D). - Open-circuit or short-circuit on sensor input - Sensor does not work (see “Temperature sensor” section) - Defective control PCB in outdoor unit Also see the troubleshooting guide on page 173.
Page 158 '13 • HM-T-193 Service Alarm list Alarm Alarm text on the Description May be due to display S. fault Tho-S Sensor fault, suction gas in outdoor unit (Tho-S). - Open-circuit or short-circuit on sensor input - Sensor does not work (see “Temperature sensor” section) - Defective control PCB in outdoor unit Also see the troubleshooting guide on page 182.
Page 159: HotWaterAlarm
'13 • HM-T-193 Service Alarm list Hot water alarm The following alarms block hot water production via outdoor unit. The additional heat source is blocked completely. Alarm Alarm text on the Description May be due to display High HW temp. Too high temperature (>90°C) on hot water sensor - Contactor to internal electric heater defective (BT6).
Page 160 '13 • HM-T-193 Service Troubleshooting guide Troubleshooting guide 3 - Thermal cutout Measure the voltage through the temperature limiter (FD1). Can it be reset mechanically when Replace temperature Has the temperature limiter been the temperature is < 80°C? limiter. mechanically tripped? Was the hot water temperature Check the characteristics of the immersion heater...
Page 161 '13 • HM-T-193 Service Troubleshooting guide 4 - OU power failure Is the voltage supply OK? Check supply power voltage. Has miniature circuit breaker FA2 Turn on the breaker. tripped? Check contactor QA10 and wiring to the outdoor unit. - 160 -...
Page 162: LowCondenserOut
'13 • HM-T-193 Service Troubleshooting guide 5 - Low condenser out Are the characteristics of the condenser Replace the sensor. out sensor (BT12) OK? Is the service valve on the Open it. water line open? Is the valve(s) (QM31 or QN11) Is the operation signal of the Replace the indoor relay board AA6.
Page 163 '13 • HM-T-193 Service Troubleshooting guide 6 - High condenser out Are the characteristics of the condenser out Replace the sensor. sensor (BT12) OK? Check the flow over heat exchanger EP2 and settings for heating and hot water. - 162 -...
Page 164: AntiFreezeHx
'13 • HM-T-193 Service Troubleshooting guide 7 - Anti freeze HX Is the low pressure sensor Does the low pressure saturated temperature on the outdoor unit corrected Plug in the connector surely. correspond to the liquid line temperature (BT15)? properly? If the phenomena persists, Is the valve of the refrigeration Open it.
Page 165: HighHwTemp.,9HighAhTemp
'13 • HM-T-193 Service Troubleshooting guide 8 - High HW temp., 9 High AH temp. Is the characteristics of the sensor Peplace the sensor(s) (BT6, BT19) correct? Is there an external heat source? Is the heat source correctly set? Check the heart source. Check the contactors QA1, QA2, QA3 and replace if necessary.
Page 166: HighSupplyTemp.1,11HighSupplyTemp.2
'13 • HM-T-193 Service Troubleshooting guide 10 - High Supply temp. 1, 11 High Supply temp. 2 Is the supply water temperature sensor for the relevant system correctly Connect it correctly. connected? Are the characteristics for the sensor OK? (See “Temperature Defective sensor - replace.
Page 167: AbortedDefrost
'13 • HM-T-193 Service Troubleshooting guide 14, 16 - Aborted defrost Is the water flow rate bigger than Is the water flow setting done Set on correct value. minimum flow rate? correctly? *Go to “No” for alarm 16. It occurs in case water flow is insufficient during defrost.
Page 168: S.FaultHp
'13 • HM-T-193 Service Troubleshooting guide 31 - S. fault HP Is the pressure sensor (BP4) Connect it correctly correctly connected? Is the saturated temperature of Does the pressure (external meter) balanced pressure same or similar Replace the refrigerant. correspond with the value to the outdoor air temperature displayed in the indoor unit? when the outdoor unit is stopping.
Page 169: LiquidLine,34-S.FaultHw,35-S.FaultAh,36-S.Fault Supply1,37-S.FaultSupply2
'13 • HM-T-193 Service Troubleshooting guide 30 - S. fault Outdoor, 32 - S. fault Cond out, 33 - S. fault Liquid line, 34 - S. fault HW, 35 - S. fault AH, 36 - S. fault supply 1, 37 - S. fault supply 2 Is the actual sensor correctly Connect it correctly.
Page 170: E35-HighHxTemp
'13 • HM-T-193 Service Troubleshooting guide E35 - High HX temp Are the characteristics of the heat exchanger sensor (Tho-R1, R2) Replace defective sensor. - Is the air circulation at the outdoor Is the air circulation around the unit obstructed? outdoor unit done properly? - Is the installation space sufficient? - Is the heat exchanger clogged?
Page 171 '13 • HM-T-193 Service Troubleshooting guide E36 - Permanent Hotgas Are the characteristics of the Replace defective sensor. hot gas sensor (Tho-D) OK? Does the fault also occur during Insufficient amount of refrigerant. cooling? Recharge it. Check the operation data with Does the discharge pipe temperature logging tool.
Page 172 '13 • HM-T-193 Service Troubleshooting guide E37 - S. fault Tho-R Is the heat exchanger’s temperature sensor (Tho-R1, R2) correctly Connect it correctly. connected? Are the characteristics of the heat Defective sensor - replace. exchanger’s temperature sensor (Tho-R1, R2) OK? Replace the control PCB.
Page 173 '13 • HM-T-193 Service Troubleshooting guide E38 - S. fault Tho-A Is the outdoor sensor (Tho-A) Connect it correctly. correctly connected? Are the characteristics of the Defective sensor - replace. outdoor sensor (Tho-A) OK? Replace the control PCB. - 172 -...
Page 174 '13 • HM-T-193 Service Troubleshooting guide E39 - S. fault Tho-D Is the hot gas sensor (Tho-D) Connect it correctly. correctly connected? Are the characteristics of the hot Defective sensor - replace. gas sensor (Tho-D) OK? Replace the control PCB. - 173 -...
Page 175 '13 • HM-T-193 Service Troubleshooting guide E40 - HP alarm If the voltage supply to the outdoor unit is switched off and on too quickly, E40 may be displayed. This is normal. Are the service valves fully open? Open the service valves. Is the high pressure switch Has the high pressure switch Connect the switch correctly.
Page 176: E42-CurrentCut
'13 • HM-T-193 Service Troubleshooting guide E42 - Current cut Is the voltage supply OK? Check supply power voltage. Open the service valves. Are the service valves open? Is the high pressure during Check the amount of refrigerant. operation OK? Check the refrigerant circuit.
Page 177: E45-InverterCommunicationError
'13 • HM-T-193 Service Troubleshooting guide E45 - Inverter communication error Is the communication between Correct the connection the control PCB and the inverter PCB OK? Are JSW10, 11 on the inverter Set JSW10, 11 correctly PCB all set correctly ? Note (1): See page 180 &...
Page 178 '13 • HM-T-193 Service Troubleshooting guide E47 - Inverter A/F module over current Does the phenomenon persist after resetting power supply? Is the IC2 crocked or burn? Does the compressor operate? Is the vottage within DC380-390V Detween T26 and T27? Normal.
Page 179 '13 • HM-T-193 Service Troubleshooting guide E48 - Fan alarm Is there any foreign material Remove foreign material. obstructing the fan propeller? Replace the fan motor. If the Does the fan rotate freely when it is resistance between turned by hand? (Vm):red-(GND):blue is 1 kΩ...
Page 180: E49-LpAlarm
'13 • HM-T-193 Service Troubleshooting guide E49 - LP alarm Is the low pressure sensor Correct it. correctly connected? Check the value on the low pressure sensor, via indoor unit, in: (1) stationary compressor, (2) compressor operation. Is the value around 0 MPa, without significant change, both in states (1) and (2)? Check the insulation resistance on...
Page 181 '13 • HM-T-193 Service Troubleshooting guide From previous page Are the service valves fully open? Open the service valves. Are the connections to the low pressure sensor and sensor for Connect it. suction gas temperature OK? Are the characteristics of the low Defective low pressure sensor or sensor for suction gas pressure sensor and sensor for...
Page 182: E51(E41)-InverterAndFanMotorError
'13 • HM-T-193 Service Troubleshooting guide E51(E41) - Inverter and fan motor error (1) (2) Replace Inverter PCB Is the voltage 15VDC detected If not solved yet, replace between ② and ③ of CNI3 on noise filter PCB as well the control PCB side? Note (1): Under anomalous conditions, Note (2): How to check voltage...
Page 183 '13 • HM-T-193 Service Troubleshooting guide E53 - S. fault Tho-S Is the sensor for the suction gas temperature (Tho-S) correctly Connect it. connected? Are the characteristics for the Replace the sensor. suction gas sensor OK? Replace the control PCB. - 182 -...
Page 184 '13 • HM-T-193 Service Troubleshooting guide E54 - S. fault LPT Is the low pressure sensor Connect it. correctly connected? Does the pressure (external meter) Check the amount of refrigerant. correspond with the value Check the refrigerant circuit. displayed in the indoor unit? Replace the low pressure sensor.
Page 185: E57-LowRefrigerant
'13 • HM-T-193 Service Troubleshooting guide E57 - Low refrigerant Are the service valves fully open? Open the service valves. Is the connecton of the sensor for indoor heat exchanger Correct it. temperature (BT15) or for inlet water temperature (BT3) OK? Defective the sensors for Are the characteristics of the indoor heat exchanger...
Page 186 '13 • HM-T-193 Service Troubleshooting guide E59 - Inverter error Is power supply voltage OK? Check power supply (1) (2) Replace Inverter PCB Is the voltage 15VDC detected between of CNI3 on If not solved yet, replace noise filter PCB as well the control PCB side? Note (1): Under anomalous conditions, Note (2): How to check voltage at...
Page 187 '13 • HM-T-193 Service Function check, components Function check, components Indoor unit Relay test - forced control Control conditions Forced control of the relays can be carried out in Menu 9.3.7.0. Menu 9.3.7.1 must be selected to “On” in order for the function to be activated.
Page 188 '13 • HM-T-193 Service Function check, components Relay functions Relay Component Name Status Function Connection Circulation pump, climate system -GP1 X1:2 K2, K3 Shuttle valve for Cooling/heating -QN12 K2-0, K3-0 K2-0, K3-1 X1:4 -QN11 Open Mixing valve X1:13 -QN11 Close X1:14 Mixing valve Reversing valve, climate system...
Page 189: Dip Switch Setting
'13 • HM-T-193 Service DIP switches, FDCW71VNX Dip switch setting FDCW71VNX (1) Control PCB Control PCB Factory setting Remarks Switches Parts No. CNTH SW3-1* * See below table CNI1 * See below table SW3-2* CNW2 Keep OFF SW3-3 Keep ON CNIP SW3-4 Keep ON...
Page 190: Fdcw100Vnx,140Vnx
'13 • HM-T-193 Service DIP switches, FDCW100VNX, FDCW140VNX FDCW100VNX, 140VNX (1) Control PCB Control PCB Factory setting Switches Remarks 100VNX 140VNX Keep as factory setting JSW1-1 CNA2 Keep as factory setting JSW1-2 Keep as factory setting JSW1-3 Keep as factory setting JSW1-4 Keep as factory setting SW4-1...
Page 191: Component Replacement
'13 • HM-T-193 Service Component replacement Component replacement Indoor unit HMA100V, HMA100VM HMS140VA, HMS140V - 190 -...
Page 192: OutdoorUnit
'13 • HM-T-193 Service Component replacement Component replacement Outdoor unit FDCW71VNX FDCW71VNX FDCW100VNX FDCW100VNX FDCW140VNX - 191 -...
Page 193 '13 • HM-T-193 Service Component replacement FDCW71VNX Fan and fan motor (FMo1) 1. Loosen the screws and Top panel (5 screws) remove the top panel and service panel first. 2. Loosen 5 screws and remove the front panel including fan grille. Front panel Service panel (5 screws)
Page 194: Hm-T-
'13 • HM-T-193 Service Component replacement FDCW71VNX Fan and fan motor (FMo1) 6. Remove tapes and fan cable Control box Tapes Fan cable 7. Release 2 metal clamps 8. Loosen 4 screws and remove fan motor 2 metal clamps 4 screws Compressor (CM) 1.
Page 195 '13 • HM-T-193 Service Component replacement FDCW71VNX Compressor (CM) 2. Remove the top and inner insulations. 3 Cut off the strap and pull out the sensor (Tho-D) Tho-D Top insulation Inner insulation 4. Remove the terminal cover 5. Disconnect the fasten terminal connectors from compressor.
Page 196 '13 • HM-T-193 Service Component replacement FDCW71VNX Control PCB (PWB1) 1. Open the top panel 2. Open the control box cover. Control box Note: Be sure to do this work after elapsing 3 minutes from power OFF. 3. Loosen 4 screws Control PCB 4.
Page 197 '13 • HM-T-193 Service Component replacement FDCW71VNX Inverter PCB (PWB2) 1. Remove control PCB first Note: Be sure to do this work after elapsing 3 minutes from power OFF. 2. Disconnect the connectors 3. Pinch the head of locking support and remove inverter Inveter PCB CNG2 CN12...
Page 198 '13 • HM-T-193 Service Component replacement FDCW71VNX Noise filter PCB (PWB3) 1. Remove control PCB first Note: Be sure to do this work aftter elapsing 3 minutes from power OFF. 3. Cut straps CNW2 4. Disconect the connectors Noise filter PCB CNA2 and CNO2 on the noise filter PCB 5.
Page 199 '13 • HM-T-193 Service Component replacement FDCW100VNX Fan and fan motor (FMo1) 1. Loosen 4 screws and remove the fan grille 4 screws 2. Loosen the nut and remove the fan propeller 1 nut 3. Detach the clamps and cut Clamps off the straps 4.
Page 200 '13 • HM-T-193 Service Component replacement FDCW100VNX Fan and fan motor (FMo1) 5. Loose 4 screws 6. Remove the fan motor 4 screws Compressor (CM) 1. Loosen screws and remove the service panel and top 4 screws (short) panel. 2. Loosen 4 short screws and 4 long screws and then remove the bar for easy access to the compressor.
Page 201 '13 • HM-T-193 Service Component replacement FDCW100VNX Compressor (CM) 4. Remove the top insulation 5. Remove the terminal cover 6. Disconnect the fasten terminal connectors from compressor. U: Red cable V: White cable W: Blue cable Terminal cove r Top Insulation Tho-D 7.
Page 202 '13 • HM-T-193 Service Component replacement FDCW100VNX Compressor (CM) 9. Untie the strings and remove the insulations 10. Unscrew and disconnect the grounding cable 11. Loosen 3 nuts of Upper insulation compressor fixing bolts 3 nuts of compressor Lower insulation Screw for 3 nuts of compressor grounding...
Page 203 '13 • HM-T-193 Service Component replacement FDCW100VNX Control PCB (PWB1) 3. Disconnect all connectors Control PCB CNA2 CNW2 CNA1 CNT3 CNFAN1 CNT1 CNEEV2 CNEEV1 CNTH CNIP CNPS 4. Pinch the head of locking supports and remove the control PCB. 6 locking supports.
Page 204 '13 • HM-T-193 Service Component replacement FDCW100VNX Inverter PCB (PWB2) 1. Loosen 7 screws and remove the control PCB layer. 1 screw Note: Be sure to do this work after elapsing 3 minutes from power OFF. 6 screws 2. Disconnect the connectors Control PCB layer 9 screws of CNI2, CNI4 and CNACT1...
Page 205 '13 • HM-T-193 Service Component replacement FDCW100VNX Noise filter PCB (PWB3) 1. Loosen 6 screws and disconnect the cables 2. Disconnect the connector Note: Be sure to do this work after elapsing 3 minutes from power OFF. Noise filter PCB Control PCB layer 6 screws Connector...
Page 206 '13 • HM-T-193 Service Component replacement FDCW140VNX Fan and fan motor (FMo1& FMo2) 1. Loosen the screws and remove the fan grille for upper fan (FMo1) and/or lower fan (FMo2). 4 screws each 2. Loosen the nut and remove the fan propeller for upper fan (FMo1) and/or lower fan (FMo2) 1 nut...
Page 207 '13 • HM-T-193 Service Component replacement FDCW140VNX Fan and fan motor (FMo1& FMo2) 4. Detach the clamps and cut Clamps off the straps Straps 5. Loosen 4 screws 6. Remove the fan motor (FMo1 and/or FMo2) 4 screws Compressor (CM) 1.
Page 208 '13 • HM-T-193 Service Component replacement FDCW140VNX Compressor (CM) 2. Untie the strings and remove the top and side insulations Tho-D 3 Cut off the strap and pull out the sensor (Tho-D) Insulation (top section) Outer insulations (side section) Inner insulations (side section) 4.
Page 209 '13 • HM-T-193 Service Component replacement FDCW140VNX Control PCB (PWB1) 1. Unscrew and disconnect the cable 2. Cut the strap and take the cable out from CT hole as shown in the photo Note: Be sure to do this work after elapsing 3 minutes from power OFF.
Page 210 '13 • HM-T-193 Service Component replacement FDCW140VNX Inverter PCB (PWB2) 1. Loosen 2 screws on the bar 2. Loosen 7 screws and remove side pannel 2 screws (small) 6 screws (short) 1 screws (long) 3. Loosen 4 screws and remove the bar for easy access to the inverter PCB layer Note: Be sure to do this...
Page 211 '13 • HM-T-193 Service Component replacement FDCW140VNX Inverter PCB (PWB2) 4. Loosen a screw on the capacitor and disconnect the red and blue cables which are connected to the control 5. Disconnect the fasten terminals of red and white cables which are connected to the control PCB.
Page 212 '13 • HM-T-193 Service Component replacement FDCW140VNX Noise filter PCB (PWB3) 1. Loosen 6 screws and disconnect the cables 2. Disconnect the connector Note: Be sure to do this work after elapsing 3 minutes from power OFF. Noise filter PCB Control PCB layer 6 screws Connector...
Page 213: Components
'13 • HM-T-193 Components Components - 212 -...
Page 214: Indoor Unit
'13 • HM-T-193 Components Indoor unit Indoor unit Circulation pump (GP10) Dimensions <All models> General NOTE The pump must not be operated dry, as this damages the bearings extremely quickly. Electrical connections When the electrical connection is correct, the indicator lamp illuminates green continuously.
Page 215: Troubleshooting
'13 • HM-T-193 Components Indoor unit Troubleshooting Indicator lamp Cause Action The pump is not connected or is incorrectly - Check the connection. connected. - Power failure. Check power supply and fuses. 1 × short + 1 × long Low voltage. - Check supply voltage.
Page 216 '13 • HM-T-193 Components Indoor unit Shuttle valves ＜HMA100V, HMA100VM＞＜HMS140VA, HMS140V＞ - 215 -...
Page 217 '13 • HM-T-193 Components Indoor unit Technical data 2 way valve Technical specifications actuator V415B LR230A-002 LI Connection G1˝ ext Voltage AC 100-240 V Length 74 mm Frequency 50/60 Hz KVS value Output 1.5 W Electrical connections 3 × 0.75 mm Run time 35 s / 90 °...
Page 218 '13 • HM-T-193 Components Indoor unit Particle ﬁlter (HQ1) ＜HMA100V, HMA100VM＞＜HMS140VA, HMA140V＞ Mesh size 0.6 mm Mesh size 0.25 mm Connection G1˝ ext Connection Rp1 1/2˝ int Length 118 mm Length 102 mm KVS value KVS value Safety valve (FL2) Connection inlet G1/2˝...
Page 219: Expansion Valve
'13 • HM-T-193 Components Outdoor unit Outdoor unit Compressor Expansion valve Discharge gas Suction gas Coil (stator) Terminal block Permanent magnet (rotor) Rotor (motor) Needle valve Stator (motor) Refrigerant Crankshaft Cylinder Accumulator Rotor Refrigerant Low pressure sensor 4-way valve From discharge Electric signal Valve Pressure sensitive...
Page 220 '13 • HM-T-193 Components Temperature sensor Temperature sensor Sensor placement Data for sensor in outdoor unit Tho-D BT 1 (kΩ) BT12 BT15 120 140 160 (ºC) Temperature Tho-S, Tho-R1, Tho-R2 Tho-A Tho-S Tho-D (kΩ) Tho- BT19 Tho-R2 AMS 10 ACVM 270 Temperature sensor, outdoor air (external) Temperature sensor, supply 100 (ºC)
Page 221 '13 • HM-T-193 Components Indoor unit Data for sensor in indoor unit and tank unit Resistance (k ) Voltage (V) Temperature (°C) 4.78 73.5 4.70 53.4 4.60 39.3 4.47 29.2 4.31 21.9 4.12 16.6 3.90 12.7 3.65 9.81 3.38 7.62 3.09 5.97 2.80...
Page 222 '13 • HM-T-193 Components Component positions Component positions Indoor unit Component image HMA100V, HMA100VM XL15 XL13 XL14 QM20 QM30 QM31 QN11 QA10 AA22-R26 AA22-R25 AA22-R24 AA22 BT30 AA21 AA23 BT24 BT19 - 221 -...
Page 223 '13 • HM-T-193 Components Component positions HMS140VA, HMS140V BT15 BT12 QN11 QM30 QM31 XL14 XL13 XL21 XL22 QM20 AA23 AA22-R26 FD1-QA41 AA22-R25 AA22-R24 AA22 AA21 - 222 -...
Page 224 '13 • HM-T-193 Components Component positions HT30 X100 X101 XL24 SENSOR BT19 XL23 FD1-BT30 IMMERSION HEATER 9kW MT500 XL24 FD1-BT30 BT19 X101 BT24 X100 XL23 - 223 -...
Page 225 '13 • HM-T-193 Components Component positions MT300 FD1-BT30 BT19 X101 X100 BT24 - 224 -...
Page 226 '13 • HM-T-193 Components Component positions List of components Sensor, thermostats Temperature sensor, tank water Pipe connections BT19 Temperature sensor, immersion heater Climate system supply Temperature sensor, external heat source BT24 Climate system return BT30 Thermostat, standby mode Cold water Temperature limiter Hot water Docking in...
Page 227: List Of Components
'13 • HM-T-193 Components Component positions Outdoor unit FDCW140VNX Component image PWB3 PWB1 FDCW71VNX PWB2 PWB2 PWB1 FMo1 63H1 PWB3 63H1 EEV-C FMo1 QM35 EEV-H QM36 EEV-C QM35 FMo2 QM36 EEV-H List of components FDCW100VNX Solenoid for 4-way valve 63H1 High pressure switch Compressor motor PWB3...
Page 228: Accessories　 Accessories
'13 • HM-T-193 Components Accessories Accessories Accessories ESV 22 / ESV28 MH-RG 10 VCC22 / VCC28 Extra mixing valve group. Reversing valve, cooling Room sensor. 22 is for HMA100 and 28 is for HMS140 22 is for HMA100 and 28 is for HMS140 Part No.
Page 229 '13 • HM-T-193 Components Accessories Wind protection (prepared on site) At the site where the following conditions meet, wind protection for outdoor unit is required to avoid capactity drop or abnormal stop for protection. ● Natural wind directly blows into outdoor unit. ●...
Page 230 '13 • HM-T-193 Components Accessories Rear wind guard φ8 5−φ6 30゜ Side wind guard 212.5 45゜ 4−φ6 258.5 - 229 -...
Page 231 '13 • HM-T-193 Components Accessories < For FDCW100VNX-A> Front wind guard (screw position) 2−φ3 4−φ6 Attachment Attachment (detail) 2−φ8 4−φ3 -0.1 17.5 Prepare a pair of symmetrical attachment. - 230 -...
Page 232 '13 • HM-T-193 Components Accessories Rear wind guard 4−φ6 Use M5×13 self-drilling screw to attach it where screw hole is not available. 15゜ Side wind guard 4−φ6 Use M5×13 self-drilling screw to attach it where screw hole is not available. 30゜...
Page 233 '13 • HM-T-193 Components Accessories < For FDCW140VNX-A> Front wind guard Appearance is as same as FDCW100VNX-A but two pieces are required. Rear wind guard 13−φ6 (A mark) Use M5×13 self-drilling screw to attach it where screw hole is not available. B mark (3 places) Side wind guard Use M5×13 self-drilling screw to attach it...
Page 234: Installation Manual
'13 • HM-T-193 Components Accessories Installation manual VCC22 General Contents This accessory is used when HMA100V is installed in houses Copper pipe, collared with cooling and heating systems, for example, in cases Flat gasket where the house has a radiator system and fan con-vectors. Swivel nut 1"...
Page 235 '13 • HM-T-193 Components Accessories Pipe connections Heating Install as follows: ■ First drain the boiler water reservoir/heating system if filled with water. ■ The shunt valve (EP22-QN12) is located on the flow line after indoor unit, before the first radiator in the heating indoor unit system 1, see image.
Page 236 '13 • HM-T-193 Components Accessories Outline diagram with VCC 22 - reversing valve, cooling EP22-QN12 Cooling Kyla GP10 Non-return valve Overflow valve RG10 Erf. säker- Required safety equipment hetsutr. BT 1 Explanation Temperature sensor, outdoor GP10 Circulation pump Buffer vessel EP22-QN12 Shuttle valve Expansion vessel EP22...
Page 237 '13 • HM-T-193 Components Accessories Electrical connection Program settings ■ Select “Service” in menu 8.1.1 to gain access to menus 9.0 NOTE and the sub-menus. All electrical connections must be carried out by an ■ Select “On” in menu 9.3.3, “Cooling system”. authorised electrician.
Page 238 '13 • HM-T-193 Components Accessories VCC28 Contents Copper pipe, collared General Flat gasket This accessory is used when the indoor module is installed in Swivel nut 1 1/4" houses with cooling and heating systems, for example, in cases 3-way valve where the house has a radiator system and fan convectors.
Page 239 '13 • HM-T-193 Components Accessories Pipe connections Heating Install as follows: ■ First drain the boiler water reservoir/heating system if filled with water. ■ The shunt valve (EP22-QN12) is located on the flow line after the indoor unit, before the first radiator in the heating Indoor unit system 1, see image.
Page 240 '13 • HM-T-193 Components Accessories Outline diagram indoor unit with VCC 28 - reversing valve, cooling EP22-QN12 Cooling Kyla Bypass Överströmnings- ventil valve RG10/ RE10 Required safety Erf. säker- equipment hetsutr. BT 1 Explanation Temperature sensor, outdoor EP22 Cooling/heating Buffer vessel EP22-QN12 Shuttle valve - 239 -...
Page 241 '13 • HM-T-193 Components Accessories - White cable (230 V signal) to spring terminal X6:1a Electrical connection - Blue cable (zero) to spring terminal X6:6a NOTE All electrical connections must be carried out by an authorised electrician. Program settings Electrical installation and wiring must be carried out ■...
Page 242 '13 • HM-T-193 Components Accessories ESV 22 General Contents This accessory is used when HMA 100V or HMS 140V is 3 wire circulation pump installed in houses with two different heating systems that Cable ties require different flow line temperatures, for example, in cases Heating pipe paste where the house has both a radiator system and an under floor Insulation tape...
Page 243 '13 • HM-T-193 Components Accessories Pipe connections CIRK.PUMP Install as follows: ■ First drain the boiler water reservoir/heating system if filled with water. ■ The extra heating medium pump(EP21-GP20) is placed in a suitable location between the shunt valve (EP21-QN25) Heating medium pump, (EP21-GP20) and heating system 2 in the direction of flow.
Page 244 '13 • HM-T-193 Components Accessories Outline diagram indoor unit with ESV 22 - extra shunt HMA 100V with ESV 22 EP21-GP20 EP21-BT2 EP21-QN25 EP21-BT3 UKV40 AA25 AA25 Required safety equipment BT 1 Explanation Temperature sensor, outdoor Buffer vessel EP21-BT2 Temperature sensor, supply line 2 EP21-GP20 Extra circulation pump EP21-BT3 Temperature sensor, return 2...
Page 245 '13 • HM-T-193 Components Accessories HMS 140V with ESV 22 EP21-GP20 EP21-QN25 EP21-BT2 EP21-BT3 Överströmnings- Bypass ventil valve AA25 Erf. säker- Required safety equipment hetsutr. BT 1 Explanation AA25 Equipment box (MH-RG10) Buffer vessel Temperature sensor, outdoor EP21-GP20 Extra circulation pump EP21-BT2 Temperature sensor, supply line 2 EP21-QN25 Shunt valve...
Page 246 '13 • HM-T-193 Components Accessories - The sensor used as flow sensor (EP21-BT2) is con- Electrical connection nected to terminal AA22:X4:7 and AA22:X4:8 in the NOTE load monitor card's lower terminal block. - The return line sensor (EP21-BT3) is connected to All electrical connections must be carried out by an terminal AA22:X4:5 and AA22:X4:6 on the same authorised electrician.
Page 247 '13 • HM-T-193 Components Accessories Connect valve actuator (EP21-QN25) as follows: Electrical connection HMS 140V - White cable (230 V signal) to spring terminal X6:8a The electrical circuit diagram is at the end of these installation - Brown cable (230 V signal) to spring terminal X6:7b instructions.
Page 248 '13 • HM-T-193 Components Accessories Temperature sensor installation Install the temperature sensor with cable ties with the heat conducting paste and aluminium tape. Then insulate with supplied insulation tape. NOTE Sensor and communication cables must not be placed near power cables. Program settings ■...
Page 249 '13 • HM-T-193 Components Accessories ESV 28 General Contents This accessory is used when HMS 140V is installed in houses Copper pipe, collared with two different heating systems that require different flow 3 wire circulation pump line temperatures, for example, in cases where the house has Cable ties both a radiator system and an under floor heating system.
Page 250 '13 • HM-T-193 Components Accessories Pipe connections CIRK.PUMP Install as follows: ■ First drain the boiler water reservoir/heating system if filled with water. ■ The extra heating medium pump(EP21-GP20) is placed in a suitable location between the shunt valve (EP21- QN25) Heating medium pump, (EP21-GP20) and heating system 2 in the direction of flow.
Page 251 '13 • HM-T-193 Components Accessories Outline diagram indoor unit with ESV 28 - extra shunt HMS 140V with ESV 28 EP21-GP20 EP21-QN25 EP21-BT2 EP21-BT3 Överströmnings- Bypass ventil valve AA25 Erf. säker- Required safety equipment hetsutr. BT 1 Explanation AA25 Equipment box (MH-RG10) Buffer vessel Temperature sensor, outdoor EP21-GP20...
Page 252 '13 • HM-T-193 Components Accessories Connect valve actuator (EP21-QN25) as follows: Electrical connection HMS 140V - White cable (230 V signal) to spring terminal X6:8a NOTE - Brown cable (230 V signal) to spring terminal X6:7b All electrical connections must be carried out by an - Blue cable (zero) to spring terminal X6:6b authorised electrician.
Page 253 '13 • HM-T-193 Components Accessories Temperature sensor installation Install the temperature sensor with cable ties with the heat conducting paste and aluminium tape. Then insulate with supplied insulation tape. NOTE Sensor and communication cables must not be placed near power cables. Program settings ■...
Page 254 '13 • HM-T-193 Components Accessories ACK 22 General Contents This accessory is used to connect accessories ESV 22 and VCC Cable set 22 to the indoor unit HMA100V. Torx head screw, M5 self-tapping Cable ties Relay card with wiring (AA7) Label Terminal block 2x1-pole (X6) Terminal block 2x1-pole PE (X6)
Page 255 '13 • HM-T-193 Components Accessories 4. Mount the terminal blocks, label and strain relief on the Electrical connection mounting plate. Screw the plate into place with two NOTE accompanying M5 self-tapping torx screws, see image below. All electrical connections must be carried out by an authorised electrician.
Page 256 '13 • HM-T-193 Components Accessories 5. Press the 7-pole edge connector with zero number 0108 to 0112 on the relay card AA6 according to the image below (NOTE! Be careful to match up the guide pin in the edge connector with its hole in the card edge). Then connect the loose wire ends as follows: - Blue cable with zero number 0108 to spring terminal X6:6a.
Page 257 '13 • HM-T-193 Components Accessories ACK 28 General Contents This accessory is used to connect accessories ESV 28 and VCC Cable set 28 to the indoor unit. Torx head screw, M5 self-tapping 10 x Cable ties Relay card with wiring (AA7) Label Terminal block 2x1-pole (X6) Terminal block 2x1-pole PE (X6)
Page 258 '13 • HM-T-193 Components Accessories 5. Mount the terminal blocks, label and strain relief on the Electrical connection mounting plate. Screw the plate into place with two NOTE accompanying M5 self-tapping torx screws, see image M5, self-tapping torx below. screws All electrical connections must be carried out by an M5, self-tapping torx Electrical connection, X6...
Page 259 '13 • HM-T-193 Components Accessories 6. Press the 7-pole edge connector with zero number 0108 to 7. Connect the other individual wires as follows: 0112 on the relay card AA6 according to the image below - Brown cable with zero number 0101 to spring terminal (NOTE! Be careful to match up the guide pin in the edge X6:3b.
Page 260 '13 • HM-T-193 Components Accessories MH-RG10 General Setting ROOM SENSOR MH-RG 10 is used together with MHI air to This room sensor measures the temperature in homes and water heat pump system. regulates the heat/cool to the climate system. The room sensor can correct the temperature to radiators or If there are thermostat valves on the radiators in the same room floor loops depending on the increased indoor temperature in as the room sensor these should be fully open in order for the...
Page 261 '13 • HM-T-193 Components Accessories Connecting Adjustment during installation Positions on MH-RG 10: The room sensor is primarily intended to correct decreases in room temperature due to causes other than changes in the F : 6 Signalground outdoor temperature, for example, centralised load control. G : 1 Setting (set point value) The room sensor corrects the curve slope so that the flow H : 2 Room temp (actual value)
Page 262 AIR TO WATER HEAT PUMP Air-Conditioning & Refrigeration Systems Headquarters 16-5, Konan 2-chome, Minato-ku, Tokyo,108-8215 Japan http://www.mhi.co.jp Because of our policy of continuous improvement, we reserve the right to make changes in all specifications without notice. © Copyright MITSUBISHI HEAVY INDUSTRIES, LTD.
