USER'S MANUAL
MITSUBISHI HEAVY INDUSTRIES
Air to Water Heat Pump using R32 refrigerant
Hydrolution (HM)
HSB60-W
FDCW60VNX-W
PT300/RC-HY20-W/RC-HY40-W
This heat pump complies with EMC Directive 2014/30/EU,
LV Directive 2014/35/EU.
CE marking is applicable to the area of 50 Hz power supply.
English：Original instruction
PSA012B842
