USER'S MANUAL

W I R E L E S S T O U C H

C O N T R O L U N I T

Table of Contents

Need help?

Do you have a question about the BU-SU and is the answer not in the manual?

Questions and answers

Summary of Contents for ETI BU-SU

Page 1 USER'S MANUAL W I R E L E S S T O U C H C O N T R O L U N I T...
Page 2 We want to thank you for your purchase of the BU-TS control unit, which is an element of wireless RF Control system. BU-TS allows: you to control many devices trough touch screen ETI device name ELKO device name - heating control...
Page 3: Table Of Contents
BU-TS user manual Contents: Before you start ....... Settings Control - Default setting ......- Temperature regulation ..Overview of wireless devices ... - Menu(creating and naming) ... - Switching ......... Characteristics of BU-TS ..- Programming ......- Dimming ........Technical specifications ...
Page 4: Overview Of Wireless Devices
Overview of wireless RF Control devices RF Control system CENTRAL WIRELESS UNIT CONTROLLER All actuators of the RF Control BU-TS-W BU-TS-B BU Pilot with System can be controlled by for surface mounting for mounting wireless central unit and all 100 - 230V AC or in the installation remote controller, adapter (external)
Page 5 Overview of wireless RF Control devices SWITCHING ACTUATORS BU-SU Multi BU-SU single channel single channel multifunction single function switching actuator switching actuator 1 x switching 1 x switching contact 16A contact 16 A 230V AC 230V AC DIMMING ACTUATORS BU-DEU...
Page 6: Characteristics Of Bu-Ts
Characteristics of BU-TS Control Unit of the wireless system RF Control - BU-TS provides intelligent control of the BU units. It can be used for: Central control of all units from one place Complete overview (visualization) of the current status of units (appliances / equipment) Features: sends command to temperature, switching, dimming and shutter actuators accepts commands from the transmitters, actuators, temperature sensors and detectors...
Page 7: Technical Specifications
Technical specifications Technical parameters BU-TSD BU-TSW Technical parameters BU-TSD BU-TSW Display Connection screwless terminal push-in or jack Type: color TFT LCD push-in 2.1 mm Resolution: 320 x 240 pixels / 262,144 colors Max. cross section of wires: max. 2.5 mm / 1.5 mm with socket Aspect ratio:...
Page 8 BU-TSW POWER SUPPLY OVER TERMINALS POWER SUPPLY OVER ADAPTER 100 - 230V AC FITTING ON THE SURFACE adapter included with BU-TSW...
Page 9 BU-TSD POWER SUPPLY OVER TERMINALS FITTING TO THE INSTALLATION BOX AC 230V...
Page 10: Description Of Control Icons
Description of Control Icons Basic Main menu Heating Dimming BU-TS version Information Temperature regulation temperature switch ON and number of assigned units settings Switching switch OFF Switching back to the home screen Dimming switch ON dimming step back Blinds switch OFF light inclination Detectors impuls...
Page 11: Basic Steps
ON building construction, materials and placing of all - the names of units (for the correct classification of the units. group, for example: BU-SU Multi)- addresses of units (to identify the actuator, for example: 577515) Transmission of radio-frequency signals through various materials.
Page 12: Initial Setup
SETUP fig. 1 Initial setup When the BU-TS is switched on for the first time, you will be automatically redirected to the display calibration screen. Touch screen can be controlled by the light touch (of about0.5-1s) in the desired location. On the screen (Fig.
Page 13: Switching
SETUP Menu (create name) Menu (create name) is used to add, edit or remove the names of the controlled device. In this menu (Figure 1) you need to first create your own device names for the sections you want to control. Creating names is important for successful programming of the BU-TS.
Page 14 SETUP Menu (create name) / Edit Menu (create name) / Remove Edit button is used to change or modify the name in the crea- Remove button can delete unit name. ted menu. Press the Remove icon (Fig. 5) following menu appears, se- Press the Edit icon (Fig.1), a menu appears, select the se- lect the section from which you want to remove the name (Fig.
Page 15: Dimming
- see table (eg programming actuator BU-TCU - find it in the Temperature regulation section). RF Control actuators divisions Temperature Switching Dimming Blinds Detectors regulation BU-TCU/G BU-SU BU-DU BU-SHUV JA-81M / 82M BU-DAU BU-DU Multi JA-80P BU-DAU BU-DEU fig. 1 fig. 3 internal sensor external sensor * BU-SU Multi...
Page 16 SETUP Programming / Assign new It is used to assign a name to the actuator in the menu. In the required section (heating, dimming ...) select Assign new (Fig. 1). A list of selected sections actuators will be shown. (Fig. 2). Select the name of the actuator which you want to associate with the BU-TS.
Page 17 SETUP Programming / Associated Receivers fig. 7 It serves to control or remove the actuator from the name of the menu you created. In the selected section (Figure 1 - Temperature regulation, dimming ...) select Assigned receivers BU-TCU (Fig. 2) a list of names specified in this section will be shown(Fig. 3). Touching on the name you will assign it to the actuator (Fig.
Page 18 fig. 1 fig. 2 fig. 3 fig. 5 fig. 8 fig. 6 fig. 4 fig. 7 fig. 9...
Page 19 fig. 1 Note: Two state JA-81M and JA-82M can be used in two ways: information about the status (open / close) - eg window is open(without pairing with a switching actuator) pairing with the multifunction switching actuator, which responds to the detector status (open / close) - eg light is switched on when you open the door.
Page 20 Programming / Quick Control Quick control is used for creating a group command, where one-touch control multiple actuators. For each name of group command you can assign a combination of up to 20 different actors. Note: Quick control can be set only when all actuators are programmed in different sections of switching, dimming and blind control. In the Quick Menu control(Fig.
Page 21: Setup / Display
Setup / Display fig. 1 (fig. 1-2) Background: select the type of screen background color (black, blue, green, purple). fig. 2 Screensaver: the desired brightness (25%, 50%, 75%, 100%) will be activated after preset time since the last touch (15s, 30s, 1min, 3min). Sleep mode: set the time after which BU-TS screen unit goes to sleep - the screen goes dark (0min, 10min, 15min, 20min).
Page 22 fig. 1 fig. 9 fig. 2 fig. 4 fig. 7 fig. 5 fig. 3 fig. 6 fig. 8 fig. 10...
Page 23 fig. 1 Control / Temperature regulation Temperature regulation Menu (Fig.1) is designed for setting controls over heating equipment. Touch the heating you enter the menu of additional circuits (image 2). Standard mode Economic mode Party mode Anti-freezing mode These modes offer a preset temperature, which you can adjust as you need for individual fig.
Page 24 fig. 1 fig. 4 fig. 7 fig. 2 fig. 5 fig. 8 fig. 3 fig. 6...
Page 25 Temperature regulation / holiday mode Holiday mode is used for temporary interruption of the heating program. Touch holiday mode (Fig. 1) to open Switch ON screen where you set the date, month and year when your holiday mode should start. Confirm with (Fig.
Page 26: Control / Switching
Switching / Function Press the Next functions button (Fig. 3) will show a selection of switching functions (Fig. 4). Other functions can be used only in combination with multifunction switch actuators - BU-SU Multi Impulse –first touch switch on, second one to switch off.
Page 27 CONTROL / SWITCHING Main menu / Switch on / BU-DAU Upon selecting the Switching on menu to which the BU-DAU actuator is assigned, the basic function are displayed: Switch on Switch off . Press shortly the arrows at the Regulation icon 0-10V to set the desired value (Fig.
Page 28 CONTROL / SWITCHING Switching / Weekly Program Weekly program provides weekly settings for the automatic mode switching. Touch Weekly program icon (Fig. 1), setup menu will appear. Touch-hour time interval (or minutes) to mark information you want to will set the time of switch On and switch Off. change.
Page 29 CONTROL / DIMMING Main menu / Dimming Dimming Menu is for all the lights where you want to control the brightness (load R L, C - 250V). Touch-Dimming (Fig. 1)to display a selection of names you created in menu (Fig. 2). Red / Green LED indicates contact status: green- On red -Off.
Page 30 CONTROL / BLINDS Main Menu / Blinds Blinds Menu is designed to control all shutters, blinds, awnings, gates and garage doors that have a built-end switch. Touch the Louvre (Fig. 1)to display selection of names you created in menu (Fig. 2). Red / Green LED indicates device status: green- closed blinds red –...
Page 31 CONTROL / BLINDS Blinds / Weekly program Weekly program can adjust automatic weekly mode. Touch Weekly program icon (Fig. 1), setup menu will appear. Touch-hour time interval (or minutes) to mark information you want to change. Arrows will set the time of switch On and switch Off Note: longer press of arrow is accelerate shift of figures.
Page 32 Main Menu / Detectors fig. 1 fig. 2 The menu Detectors is used for the visualisation and switching of devices using detectors. By touching the option Detectors (Fig. 1) you will display the list of names on the detector menu that you have created (Fig. 2). Double State Detectors Double state detectors (JA-81M - doors;...
Page 33 CONTROL / QUICK CONTROL fig. 1 fig. 2 fig. 3...
Page 34 BU-TS Unit Warnings Warning is displayed in case of incorrect or incomplete entry. Warning Procedure Up to 40 rooms may be defined. no more than 40 device names may be entered Saving failed. repeat entry Delete failed. repeat entry No unit allocated. allocate the requested actuator Two time programmes overlap within a single day.
Page 35 What to do when ... BU-TS Unit Warnings Warning Procedure No unit allocated to the room. allocate actuator This group has already been allocated. enter new settings Display incomplete - control impossible. calibrate the device (disconnect the power supply, after reconnecting hold the logo BU-TS, finish the calibration by touching twice the cross signs that appear in each corner of the screen) EPROM memory error!
Page 36: Installation Form
Installation Form Description / Serial no.: Actuator name Actuator address Name of the controlled device...
Page 37 Installation Form Description / Serial no.: Actuator name Actuator address Name of the controlled device...
Page 38 ETI Elektroelement d.d., Obrezija 5, SI-1411 Izlake Slovenija Tel.: +386 (0)3 56 57 570, Fax: +386 (0)3 56 74 077 e-mail: eti@eti.si Web: www.eti.si rev.0...
