ETI RCU-3 Installation Manual

®
We Manage Heat
®

Unpacking

Inspect the shipping container and packing material for damage. Save the shipping container and related materials until
normal operation has been established. If the unit must be returned, take care to ensure that it is packed as it was received.

Packing List

RCU–3
21357 RCU–3 Remote Control Unit (Qty 1)
18581 Wall plate screws (Qty 2)
21385 25' unshielded 22 gauge 2-wire jacketed cable
21370 RCU–3/RCU–4 Installation Manual
RCU–3 Remote Control
ETI P/N 21357
RCU–4 Remote Control
ETI P/N 21358
22 21 20 19 18 17 16 15 14 13 12
Fig 1: RCU–3 and RCU–4 remote connections to "C" Series
panels.
