USER MANUAL
KOOLMORE RESERVE
Residential Panel Ready Ice Maker
57 lbs/24hr 15"x34"
Model: KM-BIM57-PR
PANEL READY
Before using, please read the operating instructions carefully to
ensure proper application and achieve satisfactory results.
Advertisement
Table of Contents
Related Manuals for KoolMore RESERVE KM-BIM57-PR
Summary of Contents for KoolMore RESERVE KM-BIM57-PR
- Page 1 USER MANUAL KOOLMORE RESERVE Residential Panel Ready Ice Maker 57 lbs/24hr 15"x34" Model: KM-BIM57-PR PANEL READY For any service related issues, please contact us: 718-576-6342 Before using, please read the operating instructions carefully to support@koolmore.com ensure proper application and achieve satisfactory results.
- Page 2 Stay informed with the latest information for your KoolMore Reserve Appliance. If you need any assistance or have questions, our customer support team is here to help.
-
Page 3: Safety Instructions
INSTALLER: Leave these instructions with the appliance. CUSTOMER: Read this manual carefully before using and starting up, and save it for future use. If you pass on the product to another person, hand over this instruction manual along with it. Retain your sales receipt or cancelled check. - Page 4 SAFETY DANGER IMPORTANT - Risk of child entrapment! Child entrapment and suffocation are not problems of the past. Junked or abandoned appliances are still dangerous, even if they will "just sit in the garage a few days". Before discarding your old refrigerator: •...
- Page 5 • To prevent personal injury, property damage or damage to the unit, this appliance should only be unpacked and set up by two people according to the installation section. • Refrigeration equipment must be properly disposed of in a professional and appropriate way, in accordance with the current local regulations and laws which protects the environment.
- Page 6 and cabinet are necessarily small. Be careful closing doors when children are in the area. • Do not cover shelves with aluminum foil or any other shelf material which may prevent air circula- tion. • WARNING: Connect to potable water supply only. •...
-
Page 7: Product Features
PRODUCT FEATURES • Built-in or Free-standing installation Ice Machine. • Self-contained and air-cooled. • Electronic control with digital display and touchpad input. • ON/OFF Power Switch. • Select/Harvest, Cleaning and Delay Start functions. • Idle mode (Delay Start) – 10-Hour temporary shut down. •... -
Page 8: Before Using Your Appliance
INSTALLATION BEFORE USING YOUR APPLIANCE Remove all exterior and interior packing. Clean the interior surface with lukewarm water using a soft cloth. The unit may have residual odors at first, they will disappear as the unit cools. IMPORTANT: Before connecting the icemachine to the power source, let it stand upright for approximately 24 hours. -
Page 9: Electrical Connection
NOTE: Make sure that the socket and ON/OFF switch are easily accessible after the appliance has been installed. BUILT-UNDER INSTRUCTIONS Make sure your installation does not block the front ventilation grill. If the unit is fully integrated to be installed for fitting kitchen, make sure that the ventilation gaps in the plinth are at least 300 square centimeters and remove the ventilation grilles, so that warm air can disperse unhindered. -
Page 10: Installing The Handle
use an extension cord with this appliance. However, if you must use an extension cord it is absolutely necessary that it be a UL/CUL-listed, 3-wire grounding type appliance extension cord having a grounding type plug and outlet and that the electrical rating of the cord be 115 volts and at least 10 amperes. INSTALLING THE HANDLE IMPORTANT: Do not overtighten the screws &... - Page 11 DESIGN 2 – For articulated hinge models Pull the top decoration cover (3) upward and remove it. Remove the cover caps (2) and then remove the door by unscrewing the four screws (1). Be careful to hold the door firmly after removing the screws and place it on a padded surface to avoid the risk of damage.
-
Page 12: Water Supply And Drain Line Sizing/Connections
Door Panel Installation Attach the wood overlay panel (1) on the door (2) by using the four wood screws ST4x15 Type AB Philips (3). WATER SUPPLY AND DRAIN REQUIREMENTS Prepare water supply line and drain before installation of your ice machine. Installation requires a 1/4" ID copper cold water line and compression fitting (not supplied). -
Page 13: Installation Procedure
INSTALLATION PROCEDURE Prepare the site by following the instructions under Electrical Connection and Water Supply and Drain Requirements. Remove ice machine from carton. Inspect for damage. Remove literature packet and drain hose from inside the ice machine. Adjust leg levelers. Reverse door if desired. -
Page 14: Operation
OPERATION ▪ The ice machine is factory-operated and adjusted before shipment. Normally, new installation does not require any adjustment. ▪ Turn on the water tap, then plug the machine or touch the POWER key to turn on. The ice machine will start working automatically. -
Page 15: Delay Start
Touching the MODE key once will initiate an ice making cycle. The display will show . Touching the MODE key again will initiate a harvest cycle. The display will show DELAY START Touching the DELAY START key will initiate a delay cycle. The ice machine will not run until the delay time expires. -
Page 16: Temperature Memory Function
When the Medium size is selected, the indicator will be on. When the Small size is selected, the indicator will be ON. When the Large size is selected, the indicator will be ON. TEMPERATURE MEMORY FUNCTION In the event of a power interruption (power surge, breaker switch, etc.), the unit can remember the previous temperature settings, and when the power is recovery, the ice machine will go back the same setting as power off. -
Page 17: Maintenance
MAINTENANCE WARNING ▪ To avoid possible injury due to electric shock, disconnect the power cord or turn off power at the circuit breaker panel or fuse box and shut off the water line before cleaning the appliance. Clean only the parts of the appliance listed in this manual. Clean them only in the manner ▪... - Page 18 is used first time and reused after prolonged shutdown. It is usually convenient to sanitize the trough after the ice making system has been cleaned, and the ice storage bin is empty. Disconnect the power to the unit. Open the door. With a clean cloth, wipe down the interior of the unit with a sanitizing solution made of 1 ounce of household bleach or chlorine and 2 gallons of hot water (95°F –...
-
Page 19: Removal Of Parts For Cleaning/Sanitizing
clean all components. The cleaner solution will foam when it contacts lime scale and mineral deposits. Once the foaming stops, use a soft-bristle nylon brush, sponge or cloth (NOT a wire brush) to carefully clean the parts. Disassemble the spray bar (remove the left and right silicone plugs), remove nozzles and soak for 5 minutes. -
Page 20: Power Failure
Disconnect the water hose (3) from the spray bar assembly (2). Grasp two ends of the spray bar, lift up and remove from seat formed in water trough. Gently pull out the two silicone plugs (1) and then you can clean nozzle frame and the gap of nozzle. Nozzles are not suggested to be removed for cleaning. -
Page 21: Moving Your Appliance
Use a spray bottle and a solution of sanitizer/water (0.50 oz/1 gal) and spray all interior surfaces. Do not rinse, allow to air dry. Leave the door partially open to allow for circulation and prevent mold or mildew growth. MOVING YOUR APPLIANCE Unplug the power plug from the electrical outlet. -
Page 22: Troubleshooting
TROUBLESHOOTING PROBLEMS WITH YOUR APPLIANCE You can solve many common problems easily, saving you the cost of a possible service call. Try the suggestions below to see if you can solve the problem before calling customer service. PROBLEM POSSIBLE CAUSE REMEDY The appliance is not connected to a power Switch on the appliance. -
Page 23: Limited Warranty
At its sole discretion, Koolmore Supply Inc. may decide to replace the product. In such an event, your replace- ment appliance will carry the warranty for the remaining term of the original unit's warranty period.
