Agilent InfinityLab LC Series

Multicolumn Thermostats

User Manual

Table of Contents

Chapters

Troubleshooting

Need help?

Do you have a question about the InfinityLab LC Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Agilent Technologies InfinityLab LC Series

Page 1 Agilent InfinityLab LC Series Multicolumn Thermostats User Manual...
Page 2: Warranty
Copyright adhered to, could result in damage manual and any information contained herein, including but not limited to the © Agilent Technologies, Inc. to the product or loss of important implied warranties of merchantability 2017-2024 data. Do not proceed beyond a and fitness for a particular purpose.
Page 3: Table Of Contents
Contents In This Book 6 Introduction 7 Product Description of the 1290 Infinity III Multicolumn Thermostat (G7116B) 8 Features of the 1290 Infinity III Multicolumn Thermostat (G7116B) 9 Product Description of the 1260 Infinity III Multicolumn Thermostat (G7116A) 10 Features of the 1260 Infinity III Multicolumn Thermostat (G7116A) 11 Operating Principle 12 Column Switching Valve 14 Typical Applications 17...
Page 4 Troubleshooting and Diagnostics 110 Diagnostic Features 111 Maintenance and Troubleshooting Tools of the Module 112 Agilent Lab Advisor Software 115 Error information 116 What Are Error Messages 118 General Error Messages 119 MCT Error Messages 129 Maintenance 147 Introduction to Maintenance 148 Safety Information Related to Maintenance 150 Overview of Maintenance 152 Cleaning the Module 153 Correcting Leaks 154 Replace Parts of Quick Change Valve Head 155...
Page 5 Hardware Information 202 General Hardware Information 203 Module-Specific Hardware Information 214 Appendix 215 General Safety Information 216 Material Information 223 At-a-Glance Details About Agilent Capillaries 229 Waste Electrical and Electronic Equipment (WEEE) Directive 233 Radio Interference 234 RFID Statement 235 Sound Emission 237 Agilent Technologies on Internet 238 Multicolumn Thermostats User Manual...
Page 6: In This Book
9007204967054731 ag-textnode-base-id: 5712313739 In This Book This manual covers the following Agilent InfinityLab LC Series modules: • Agilent 1290 Infinity III Multicolumn Thermostat (G7116B) • Agilent 1260 Infinity III Multicolumn Thermostat (G7116A) Multicolumn Thermostats User Manual...
Page 7: Introduction
ag-textnode-version-id: 18014402491307019 ag-textnode-base-id: 3981825035 Introduction This chapter gives an introduction to the module and instrument overview. Product Description of the 1290 Infinity III Multicolumn Thermostat (G7116B) 8 Features of the 1290 Infinity III Multicolumn Thermostat (G7116B) 9 Product Description of the 1260 Infinity III Multicolumn Thermostat (G7116A) 10 Features of the 1260 Infinity III Multicolumn Thermostat (G7116A) 11 Operating Principle 12...
Page 8: Product Description Of The 1290 Infinity Iii Multicolumn Thermostat (G7116B)
MCT, sample preparation for analyte enrichment or matrix removal, alternating column regeneration – and many more. The MCT matches perfectly with all InfinityLab LC Series systems and can also be combined with previous 1260 and 1290 Infinity Series modules. Status indicator...
Page 9: Features Of The 1290 Infinity Iii Multicolumn Thermostat (G7116B)
Introduction Features of the 1290 Infinity III Multicolumn Thermostat (G7116B) ag-textnode-version-id: 9007202257072139 ag-textnode-base-id: 3002331147 Features of the 1290 Infinity III Multicolumn Thermostat (G7116B) • Superior usability with flexible flap positions: open door to 90° (desk function), or to 180°, or even removal of the front door for maximum accessibility. •...
Page 10: Product Description Of The 1260 Infinity Iii Multicolumn Thermostat (G7116A)
The MCT matches perfectly with all InfinityLab LC Series systems and can also be combined with 1290 Infinity III Series modules as well as with previous 1260 and 1290 Series modules.
Page 11: Features Of The 1260 Infinity Iii Multicolumn Thermostat (G7116A)
Introduction Features of the 1260 Infinity III Multicolumn Thermostat (G7116A) ag-textnode-version-id: 9007202257081611 ag-textnode-base-id: 3002340619 Features of the 1260 Infinity III Multicolumn Thermostat (G7116A) • Superior usability with flexible flap positions: open door to 90° (desk function), or to 180°, or even removal of the front door for maximum accessibility. •...
Page 12: Operating Principle
Introduction Operating Principle ag-textnode-version-id: 3002304523 ag-textnode-base-id: 3002304523 Operating Principle Detector Valve Column Heat exchanger Multisampler Figure 3: Hydraulic path The Concept of Heating and Cooling The design of the Multicolumn Thermostat (MCT) uses Quick Connect Heat Exchangers that are mounted on to the heating and cooling devices with Peltier elements.
Page 13 Introduction Operating Principle phase). In a flowthrough temperature regulation system, there are necessarily slightly different temperatures at different positions. The actual temperature displayed on the user interface is always the temperature measured at the heating and cooling device. The equilibration of the column may take a while. Stability of the pressure signal is a good indication for temperature equilibrium of the column.
Page 14: Column Switching Valve
Introduction Column Switching Valve ag-textnode-version-id: 9007203236574219 ag-textnode-base-id: 3981833227 Column Switching Valve InfinityLab Quick Change Valves for column switching are an orderable add-on option for the InfinityLab Multicolumn Thermostat. ag-textnode-version-id: 9007202257020939 ag-textnode-base-id: 3002279947 Multicolumn Selection (G7116B with G4239C) Advantages • Increase productivity •...
Page 15: Multicolumn Selection (G7116A With G4237A)
Introduction Column Switching Valve ag-textnode-version-id: 3002288907 ag-textnode-base-id: 3002288907 Multicolumn Selection (G7116A with G4237A) Advantages • Increase productivity • Higher instrument up-time The valve facilitating quick changes allows the selection between up to four different stationary phases for a variety of applications, or the usage of identical stationary phases in columns with different dimensions for either faster run- times (short columns) or higher resolution (long columns) or for loading studies with different internal diameters.
Page 16 Introduction Column Switching Valve Figure 6: Different chromatographic results obtained for the same sample on five different stationary phases Multicolumn Thermostats User Manual...
Page 17: Typical Applications
Introduction Typical Applications ag-textnode-version-id: 9007203236583051 ag-textnode-base-id: 3981842059 Typical Applications The interconnection of ports at particular valve position strongly depends on the NOTE combination of valve and module. The software user interface always displays the correct situation. A method modification or re-plumbing of the connections is typically required if transferring methods from G1316A/B/C to G7116A/B, G1170A or G4227A.
Page 18: Sample Enrichment And Sample Cleanup (2-Position/6-Port Or 2-Position/10-Port Valves)
Introduction Typical Applications To detector To detector Column 2 Column 2 Column 1 Column 1 From pump From pump Position 1-6 Position 1-2 The valve can select either column 1 or column 2, allowing quick changes between two different stationary phases for separation selectivity, or immediate availability of a second and identical stationary phase in case the first column loses efficiency, when dealing with complex matrices for instance.
Page 19 Introduction Typical Applications Sample Cleanup Pump A / autosampler Pump A / autosampler Precolumn Precolumn Analytical Analytical column column Detector Detector Waste Waste Pump B Pump B Position 1-6 Position 1-2 Advantages: • Easy automation of sample preparation • Higher reproducibility •...
Page 20: Alternating Column Regeneration (2-Position/10-Port Valves Only)
Introduction Typical Applications extra pump backflushes the matrix components out of the precolumn to waste, while the analytes are separated on the main column. Backflushing prepares the precolumn for the next injection. ag-textnode-version-id: 3002322187 ag-textnode-base-id: 3002322187 Alternating Column Regeneration (2-Position/10-Port Valves Only) Advantages: •...
Page 21: Site Requirements And Specifications
ag-textnode-version-id: 18014402492295435 ag-textnode-base-id: 3982813451 Site Requirements and Specifications This chapter provides information on environmental requirements, physical and performance specifications. Site Requirements 22 Power Considerations 22 Power Cords 23 Bench Space 24 Condensation 24 Specifications of the 1290 Infinity III Multicolumn Thermostat 25 Specifications of the 1260 Infinity III Multicolumn Thermostat 28 Valve Specifications 31 Extended Specifications 34 Multicolumn Thermostats User Manual...
Page 22: Site Requirements
Site Requirements and Specifications Site Requirements ag-textnode-version-id: 3000924939 ag-textnode-base-id: 3000924939 Site Requirements A suitable environment is important to ensure optimal performance of the instrument. ag-textnode-version-id: 3017155083 ag-textnode-base-id: 3017155083 Power Considerations The module power supply has wide ranging capability. It accepts any line voltage in the range described in Specifications of the 1290 Infinity III Multicolumn Thermostat...
Page 23: Power Cords
— Never use the power cords that Agilent Technologies supplies with this instrument for any other equipment. — Never use cables other than the ones supplied by Agilent Technologies to ensure proper functionality and compliance with safety or EMC regulations.
Page 24: Bench Space
Site Requirements and Specifications Site Requirements Electrical shock hazard WARNING ag-struc-frag-safety-version-id: 3003281291 ag-struc-frag-safety-base-id: 3003281291 Solvents may damage electrical cables. — Prevent electrical cables from getting in contact with solvents. — Exchange electrical cables after contact with solvents. ag-textnode-version-id: 3017139339 ag-textnode-base-id: 3017139339 Bench Space The module dimensions and weight (see Specifications of the 1290 Infinity III...
Page 25: Specifications Of The 1290 Infinity Iii Multicolumn Thermostat
Site Requirements and Specifications Specifications of the 1290 Infinity III Multicolumn Thermostat ag-textnode-version-id: 18014402492353675 ag-textnode-base-id: 3982871691 Specifications of the 1290 Infinity III Multicolumn Thermostat Table 1: Physical specifications of the 1290 Infinity III Multicolumn Thermostat (G7116B) Type Specification Comments Weight 12.5 kg (27.6 lbs) Dimensions (height × width × 160 x 435 x 436 mm G7116B may have a depth)
Page 26 Site Requirements and Specifications Specifications of the 1290 Infinity III Multicolumn Thermostat Table 2: Performance specifications of the 1290 Infinity III Multicolumn Thermostat (G7116B) Feature Specification Comment Operating Thermostatted column compartment with dual, principle independent Peltier element. Solvent pre-heating and still-air operation for reduction of chromatographic band broadening under UHPLC-conditions.
Page 27 Site Requirements and Specifications Specifications of the 1290 Infinity III Multicolumn Thermostat Feature Specification Comment Heat-up/cool- 5 min from ambient to 40 °C down time 10 min from 40 °C to 20 °C <30 min from 25 °C to 100 °C Solvent heat Individually quick-installable for every column. exchangers Available at 1 µL internal volume, 0.075 mm i.d.
Page 28: Specifications Of The 1260 Infinity Iii Multicolumn Thermostat
Site Requirements and Specifications Specifications of the 1260 Infinity III Multicolumn Thermostat ag-textnode-version-id: 18014402492349963 ag-textnode-base-id: 3982867979 Specifications of the 1260 Infinity III Multicolumn Thermostat Table 3: Physical specifications of the 1260 Infinity III Multicolumn Thermostat (G7116A) Type Specification Comments Weight 12.5 kg (27.6 lbs) Dimensions (height × width × 160 x 435 x 436 mm G7116A only has a depth)
Page 29 Site Requirements and Specifications Specifications of the 1260 Infinity III Multicolumn Thermostat Type Specification Comments Temperature 10 °C below ambient (minimum 4 °C) to 85 °C range Temperature Settable in steps of 0.1 °C range increment Temperature ± 0.1 °C stability Temperature ± 0.5 °C (with calibration at 40 °C) accuracy Temperature 0.05 °C...
Page 30 Site Requirements and Specifications Specifications of the 1260 Infinity III Multicolumn Thermostat Type Specification Comments Column Optionally, column identification kit to track history of identification up to four columns. Mounted on the left hand-side of module. Instrument LC and CE Drivers A.02.14 or above. For details about control Instrument Control Framework (ICF) A.02.04 or...
Page 31: Valve Specifications
Site Requirements and Specifications Valve Specifications ag-textnode-version-id: 3001807755 ag-textnode-base-id: 3001807755 Valve Specifications Table 5: G4239C (5067-4233), 8-position/18-port valve 1300 bar Type Specification Maximum pressure 1300 bar Typical application 8 column selection Port size Accepts M4 male threaded fittings Liquid contacts PEEK, Stainless steel pH range 0 –...
Page 32 Site Requirements and Specifications Valve Specifications Table 8: G4231A (5067-4282), 2-position/6-port valve 800 bar Type Specification Maximum pressure 800 bar Typical application Any two-way switching, e.g. between two detectors, between waste and detector, between two columns Port size Accepts 10-32 male threaded fittings Liquid contacts PEEK, Stainless steel pH range 0 –...
Page 33 Site Requirements and Specifications Valve Specifications Table 11: G4234C (5067-4273), 6-position/14-port valve 1300 bar Type Specification Maximum pressure 1300 bar Typical application 6 column selection Port size Accepts M4 male threaded fittings Liquid contacts PEEK, Stainless steel pH range 0 – 14 Table 12: G4234A (5067-4284), 6-position/14-Port valve 800 bar Type Specification Maximum pressure...
Page 34: Extended Specifications
Site Requirements and Specifications Extended Specifications ag-textnode-version-id: 3001812235 ag-textnode-base-id: 3001812235 Extended Specifications The G7116A MCT is delivered with Large ID Quick Connect Heat Exchanger (0.17 mm with 3 µL internal volume) that is suitable for standard applications. The G7116B MCT is delivered with Low Dispersion Quick Connect Heat Exchanger (0.12 mm with 1.6 µL internal volume) that is suitable for standard applications.
Page 35: Installation
ag-textnode-version-id: 9007203439778187 ag-textnode-base-id: 4185037195 Installation The installation of the module will be done by an Agilent service representative. In this chapter, only installation of user-installable options and accessories are described. Installation of User-Installable Options and Accessories 36 Open the Front Door 36 Install Heat Exchanger 36 Exchange a Column 40 Installing Valve Heads 45...
Page 36: Installation Of User-Installable Options And Accessories
Installation Installation of User-Installable Options and Accessories ag-textnode-version-id: 18014401510563211 ag-textnode-base-id: 3001081227 Installation of User-Installable Options and Accessories ag-textnode-version-id: 3001854347 ag-textnode-base-id: 3001854347 Open the Front Door The front door opens in two angles: 90° and 180°. In the 90° position, it can be used as a tray.
Page 37: Install Heat Exchanger
Installation Installation of User-Installable Options and Accessories ag-textnode-version-id: 9007202256558219 ag-textnode-base-id: 3001817227 Install Heat Exchanger For bio-inert modules use bio-inert parts only! Do not mix with bio / biocompatible parts. For biocompatible modules use bio / biocompatible parts only! Do not mix with bio-inert parts. Modified design of Quick Connect Heat Exchangers allows simplified installation of the heat exchanger in the Multicolumn Thermostat (MCT).
Page 38 Installation Installation of User-Installable Options and Accessories Tools required Qty. Description 5043-0915 Fitting mounting tool 5023-2502 Hex driver SW-6.35, slitted 8710-0510 Open-end wrench 1/4-5/16 inch Parts required Qty. Description (For 1290) G7116-60015 Quick Connect Heat Exchanger Standard G7116-60021 Quick Connect Heat Exchanger Ultra Low Dispersion G7116-60031 Quick Connect Heat Exchanger High Flow...
Page 39 Installation Installation of User-Installable Options and Accessories Parts required Qty. Description (Bio-compatible G7116-60071 Quick Connect Bio Heat Exchanger Standard Flow option) G7116-60081 Quick Connect Bio Heat Exchanger High Flow G7116-68003 Column Holder Lamella, 2/pk 5500-1596 Quick Turn Capillary MP35N 0.12 mm x 280 mm 5067-5966 InfinityLab Quick Turn Fitting...
Page 40 Installation Installation of User-Installable Options and Accessories 3 Connect the column connection capillary to the outlet of the Quick Connect Heat Exchanger. Max. 2.5 Nm 4 Position the heat exchanger in the groove of the MCT heater block and prepare column holders to fix the heat exchanger. 5 Turn column holders to fix the Quick Connect Heat Exchanger in the MCT.
Page 41: Exchange A Column
Installation Installation of User-Installable Options and Accessories ag-textnode-version-id: 9007202256561931 ag-textnode-base-id: 3001820939 Exchange a Column This procedure describes the exchange of a column for a different one. Tools required Qty. Description 5043-0915 Fitting mounting tool, OR 8710-0510 Open-end wrench 1/4-5/16 inch Parts required Qty.
Page 42 Installation Installation of User-Installable Options and Accessories Preparations • Heat exchanger(s) installed in MCT • Column holder clip(s) installed in the heater block on top of heat exchanger(s) • Column inlet capillary connected to heat exchanger outlet • Ensure the Heat Exchanger(s) and column holder clip(s) are installed. Remove a Column 1 Remove the column from the column holder.
Page 43: Install A Column
Installation Installation of User-Installable Options and Accessories 3 Open the lever of the Quick Connect Fitting. 4 Unscrew and remove the Quick Connect Fitting from the column inlet. Install a Column 1 Connect the column inlet capillary to the column inlet using the Quick Connect Fitting.
Page 44 Installation Installation of User-Installable Options and Accessories 2 Turn the column onto the Quick Connect Fitting until it is finger-tight. 3 Close the lever to make a leak-tight connection. 4 Connect the capillary to detector to the column outlet. When using the Quick Turn Fitting, tighten the fitting until it is finger-tight.
Page 45: Installing Valve Heads
Installation Installation of User-Installable Options and Accessories 5 Use a wrench to counter the column while tightening the capillary fitting. 6 Position the column into the column holder clip(s). 7 Configure the column. For further information see Agilent Information Center or the online help of your CDS.
Page 46 Installation Installation of User-Installable Options and Accessories The valves are mounted on pull-out rails to allow easy installation of capillaries. NOTE Push the valve gently into its housing until it snaps into the inner position, push it again and it slides out. When all capillaries are installed, push the valve back into its housing, see Install the Valve Head and Connect Capillaries...
Page 47: Remove The Transportation Lock And The Valve Dummy
Installation Installation of User-Installable Options and Accessories ag-textnode-version-id: 3001835787 ag-textnode-base-id: 3001835787 Remove the Transportation Lock and the Valve Dummy The following procedure demonstrates the necessary steps for installing the valve head to the valve drive of a Multicolumn Thermostat (MCT). For the installation of a valve head to a G1170A Valve Drive you can ignore the steps that describe the MCT features of the transportation lock and spring loaded valve drive.
Page 48 Installation Installation of User-Installable Options and Accessories 4 Unscrew the valve dummy. 5 Remove the valve dummy from the valve drive. Multicolumn Thermostats User Manual...
Page 49: Install The Valve Head And Connect Capillaries
Installation Installation of User-Installable Options and Accessories ag-textnode-version-id: 9007202256580491 ag-textnode-base-id: 3001839499 Install the Valve Head and Connect Capillaries For bio-inert modules use bio-inert parts only! Do not mix with bio / biocompatible parts. For biocompatible modules use bio / biocompatible parts only! Do not mix with bio-inert parts.
Page 50 Installation Installation of User-Installable Options and Accessories For a correct installation of the valve head, the outside pin (red) must completely NOTE fit into the outside groove on the valve drive’s shaft (red). A correct installation is only possible if the two pins (green and blue) on the valve head fit into their corresponding grooves on the valve drive’s actuator axis.
Page 51 Installation Installation of User-Installable Options and Accessories If the outside pin does not fit into the outside groove, you have to turn the valve head until you feel that the two pins snap into the grooves. Now you should feel additional resistance from the valve drive while continuously turning the valve head until the pin fits into the groove.
Page 52 Installation Installation of User-Installable Options and Accessories 3 Install all required capillary connections to the valve. 4 Push the valve head until it snaps in and stays in the rear position. 5 Power on or power-cycle your module, so the valve head gets recognized during module initialization.
Page 53: Installing The Capillaries
Installation Installation of User-Installable Options and Accessories ag-textnode-version-id: 3001824651 ag-textnode-base-id: 3001824651 Installing the Capillaries The 2-position/10-port valve can be used here in the same way as a 2-position/6- port valve, just follow the rerouting diagram below. Map the ports from the 2-position/6-port valve to the corresponding ports of the 2-position/10-port valve according to the red arrows.
Page 54 Installation Installation of User-Installable Options and Accessories 7 Fasten all fittings on attached modules (autosampler, detector, additional pumps). Fit all unused valve ports with blank nuts. 8 Push the valve into the rear position. 9 Place the capillaries that go to another module or waste into the capillary guides to prevent squeezing them when closing the front cover.
Page 55: Install The Divider Assembly
Installation Installation of User-Installable Options and Accessories ag-textnode-version-id: 3001828363 ag-textnode-base-id: 3001828363 Install the Divider Assembly Parts required Qty. Description G7116-60006 Divider Assembly MCT The Divider Assembly must be installed if different temperatures are used on the NOTE right and the left heater element to separate these two temperature zones. 1 Push the rear part of the Divider Assembly into position (1.) and fix it with the screw (2.).
Page 56 Installation Installation of User-Installable Options and Accessories 4 Install the front part of the Divider Assembly by putting it on top. 5 The front plate should be flush with the top and the bottom edge of the MCT housing. Multicolumn Thermostats User Manual...
Page 57: Installation Of The Infinitylab Thermal Equilibration Device
Hex driver SW-6.35, slitted Preparations • Install Quick Change Valve Head and columns according to the instructions Agilent InfinityLab LC Series Multicolumn Thermostats User Manual (G7116- MCT-UseMa-en-SD-29000232.pdf, SD-29000232) Divider assembly cannot be installed in the MCT together with the Thermal NOTE Equilibration Device at the same time.
Page 58 Installation Installation of User-Installable Options and Accessories 2 Place the InfinityLab Thermal Equilibration Device covering one or more installed columns in the way that the twist-lock clips are located at the top of the device. 3 Guide capillaries (and column ID tag cords, if installed) through silicone side covers.
Page 59: Install The Column Identification Option
Installation Installation of User-Installable Options and Accessories ag-textnode-version-id: 9007202256602763 ag-textnode-base-id: 3001861771 Install the Column Identification Option Parts required Qty. Description 5067-5915 Column ID Kit Left 5067-5916 Column ID Kit Right 5067-5917 InfinityLab Column Identification Tag Preparations • Power off the instrument. Electronic boards and components are sensitive to electrostatic discharge CAUTION (ESD).
Page 60 Installation Installation of User-Installable Options and Accessories 3 Identify the left and right (G7116B only) column ID module. The ID sockets 1 to 4 are numbered from top to bottom. 4 Take the end of the preinstalled flex-board connector out of the holder. 5 Connect the flex cable to the column ID module.
Page 61 Installation Installation of User-Installable Options and Accessories b Push in the cable with the contacts facing to the rear. c Close the locking mechanism. d Verify that the cable is properly attached to the connector without visible offset. 6 Attach the column ID module to the MCT cover. Multicolumn Thermostats User Manual...
Page 62 Installation Installation of User-Installable Options and Accessories 7 Repeat steps 4 to 9 for the column ID module on the other side (for G7116B, on the right). 8 Install the waste tube clip holder (example shows a G7116B). Multicolumn Thermostats User Manual...
Page 63: Connecting The Column Id Tags
Installation Installation of User-Installable Options and Accessories ag-textnode-version-id: 3001858059 ag-textnode-base-id: 3001858059 Connecting the Column ID Tags 1 If the column has no Column ID Tag, fit a tag by slipping the loop over one end of the column and pulling it tight through the plastic holder. Once the loop has been pulled tight, the tag can no longer be removed from the NOTE column.
Page 64: Installing Capillaries
Installation Installing Capillaries ag-textnode-version-id: 45036000351652875 ag-textnode-base-id: 4077947915 Installing Capillaries This section provides information on how to install capillaries and fittings. Multicolumn Thermostats User Manual...
Page 65: Install Capillaries
Installation Installing Capillaries ag-textnode-version-id: 9007202257747211 ag-textnode-base-id: 3003006219 Install Capillaries Capillaries and connections depend on which system is installed. As you move to smaller-volume, high-efficiency columns, you will want to use NOTE narrow id tubing, as opposed to the wider id tubing used for conventional HPLC instruments.
Page 66 Installation Installing Capillaries From 5500-1217 (Capillary, ST, 0.17 mm x 900 mm SI/SX) Pump Vialsampler with ICC 5500-1157 (Capillary ST 0.12 mm x 500 mm SL/S) Multisampler MCT Valve/Heat Exchanger 5500-1251 (Capillary ST 0.12 mm x 400 mm SL/SL) Vialsampler MCT Valve/Heat Exchanger 5500-1238 (Capillary ST 0.12 mm x 105 mm SL/SL) Vialsampler ICC Heat Exchanger 5500-1249 (Capillary ST 0.12 mm x 120 mm SL/SL, long...
Page 67 Installation Installing Capillaries From 5500-1419 (Capillary MP35N 0.17 mm x 500 mm, SI/SI) Pump Multisampler 5500-1279 (Capillary MP35N 0.12 mm x 500 mm SI/SI) Multisampler 5500-1578 (Quick Connect Capillary MP35N 0.12 mm x MCT Heat Exchanger Column 105 mm) 5500-1596 (Quick Turn Capillary MP35N 0.12 mm x 280 mm) Column/MCT Valve Detector (DAD) 5500-1598 (Quick Turn Capillary MP35N 0.12 mm x 500 mm) Column/MCT Valve Detector (VWD)
Page 68 Installation Installing Capillaries 3 Carefully slide the ferrule components on after the nut and then finger-tighten the assembly while ensuring that the tubing is completely seated in the bottom of the end fitting. 4 Use a stable port installed to the module to gently tighten the fitting facing to the module.
Page 69: Install Uhp-Ff Fittings
Installation Installing Capillaries ag-textnode-version-id: 9007202613096587 ag-textnode-base-id: 3358355595 Install UHP-FF Fittings Tools required Qty. Description 5043-0915 Fitting mounting tool For details on necessary capillaries and fittings, see the part section of the manual. 1 Slide the fitting on the capillary. Let the capillary jut out 5 mm. Capillary Fitting 5 mm...
Page 70 Installation Installing Capillaries 3 Finger tighten the nut into the port until snug. 4 Use 5043-0915 (Fitting mounting tool) or a 5 mm hex wrench for fixing the fitting (maximum torque 0.8 Nm). Multicolumn Thermostats User Manual...
Page 71 Installation Installing Capillaries Potential damage of capillaries CAUTION — Do not remove fittings from used capillaries. 5 When using UHP-FF fittings with bio-inert capillaries, do not try to remove fittings from these capillaries. Bio-inert capillaries are using a PEEK front end, which may expand under pressure especially when being in contact with some organic solvents.
Page 72: Handling Leak And Waste
36028800545451531 ag-textnode-base-id: 3526487563 Handling Leak and Waste The Agilent InfinityLab LC Series has been designed for safe leak and waste handling. It is important that all security concepts are understood and instructions are carefully followed. The solvent cabinet is designed to store a maximum volume of 8 L solvent. The maximum volume for an individual bottle stored in the solvent cabinet should not exceed 2 L.
Page 73 Installation Handling Leak and Waste Figure 10: Infinity III Leak Waste Concept (Flex Bench installation) Multicolumn Thermostats User Manual...
Page 74 Installation Handling Leak and Waste Figure 11: Infinity III Single Stack Leak Waste Concept (bench installation) Multicolumn Thermostats User Manual...
Page 75 Installation Handling Leak and Waste Figure 12: Infinity III Two Stack Leak Waste Concept (bench installation) The waste tube connected to the leak plane outlet on each of the bottom instruments guides the solvent to a suitable waste container. Multicolumn Thermostats User Manual...
Page 76: Drain Connectors Installation
Installation Handling Leak and Waste ag-textnode-version-id: 9007209510841867 ag-textnode-base-id: 10256100875 Drain Connectors Installation Drain Connectors have been developed to improve leak drainage for low flow leaks of high viscosity solvents (for example, isopropanol) in Agilent InfinityLab LC Series Systems. Install these parts to modules where they are missing (usually preinstalled).
Page 77 Installation Handling Leak and Waste Table 18: Compatibility of drain connectors and modules Drain Connector Type Compatible Module Compatible Module Type Double G7116A/B Column Compartment Single G7114A/B Detector G7115A G7117A/B/C G7121A/B G7162A/B G7165A G7129A/B/C Sampler G7167A/B/C G5668A G7137A G7157A G4767A G7122A Degasser G7104A/C Pump...
Page 78 Installation Handling Leak and Waste In case of incorrect installation, drain connectors cannot fully perform the NOTE intended function. It is not required to power off the HPLC stack to install Single and Double Drain NOTE Connectors. The installation of the connectors does not affect the analysis performed during the installation.
Page 79 Installation Handling Leak and Waste 1 Align the ring with the leak drain outlet of the module, press slightly with the fingers, and slide the connector along the leak drain outlet until it is aligned with the front of the leak drain. Make sure that the following requirements are covered: •...
Page 80: Waste Concept
Installation Handling Leak and Waste ag-textnode-version-id: 9007202332686987 ag-textnode-base-id: 3077945995 Waste Concept Agilent recommends using the 5043-1221 (6 L waste can with 1 Stay Safe cap GL45 with 4 ports) for optimal and safe waste disposal. If you decide to use your own waste solution, make sure that the tubes don't immerse in the liquid. ag-textnode-version-id: 3596422027 ag-textnode-base-id: 3596422027 Waste Guidance...
Page 81: Leak Sensor
Installation Handling Leak and Waste The waste drainage must go straight into the waste containers. The waste flow NOTE must not be restricted at bends or joints. ag-textnode-version-id: 3002300811 ag-textnode-base-id: 3002300811 Leak Sensor Solvent incompatibility CAUTION ag-struc-frag-safety-version-id: 3004406283 ag-struc-frag-safety-base-id: 3004406283 The solvent DMF (dimethylformamide) leads to corrosion of the leak sensor.
Page 82: Connecting Modules And Control Software
WARNING ag-struc-frag-safety-version-id: 3822076043-1 ag-struc-frag-safety-base-id: 3822076043 Using cables not supplied by Agilent Technologies can lead to damage of the electronic components or personal injury. — Never use cables other than the ones supplied by Agilent Technologies to ensure proper functionality and compliance with safety or EMC regulations.
Page 83: Using The Module
ag-textnode-version-id: 18014402694527627 ag-textnode-base-id: 4185045643 Using the Module This chapter provides information on how to use the module. General Information 84 Turn On/Off 84 Status Indicators 86 Preparation of the System 88 Prepare a Run 88 Prime and Purge the System 95 Preparing the Module 97 Using Column ID Tags 97 Availability of Column Information 105 Multicolumn Thermostats User Manual...
Page 84: General Information
Using the Module General Information ag-textnode-version-id: 36028801094302731 ag-textnode-base-id: 4075338763 General Information ag-textnode-version-id: 18014401511325195 ag-textnode-base-id: 3001843211 Turn On/Off This procedure exemplarily shows an arbitrary LC stack configuration. Multicolumn Thermostats User Manual...
Page 85 Using the Module General Information 2 On/Off switch: On 3 Turn instrument On/Off with the control software. Multicolumn Thermostats User Manual...
Page 86: Status Indicators
Using the Module General Information 4 On/Off switch: Off ag-textnode-version-id: 36028800065377547 ag-textnode-base-id: 3046413579 Status Indicators The module status indicator indicates one of six possible module conditions. Multicolumn Thermostats User Manual...
Page 87 Using the Module General Information Figure 14: Arbitrary LC stack configuration (example) Idle Run mode Not-ready. Waiting for a specific pre-run condition to be reached or completed. Error mode - interrupts the analysis and requires attention (for example, a leak or defective internal components).
Page 88: Preparation Of The System
Using the Module Preparation of the System ag-textnode-version-id: 63050398769392779 ag-textnode-base-id: 3986205835 Preparation of the System ag-textnode-version-id: 18014403027169547 ag-textnode-base-id: 4517687563 Prepare a Run This procedure exemplarily shows how to prepare a run. Parameters as shown in the screenshots may vary, depending on the system installed. Toxic, flammable and hazardous solvents, samples and reagents WARNING ag-struc-frag-safety-version-id: 3004430475-1...
Page 89 Using the Module Preparation of the System 1 Switch on the detector. 2 Fill the solvent bottles with adequate solvents for your application. 3 Place solvent tubings with bottle head assemblies into the solvent bottles. 4 Place solvent bottles into the solvent cabinet. Multicolumn Thermostats User Manual...
Page 90 Using the Module Preparation of the System 5 Solvent bottle filling dialog (in the software). Multicolumn Thermostats User Manual...
Page 91 Using the Module Preparation of the System 6 Purge the pump. For details on priming and purging, refer to the technical note Best Practices for NOTE Using an Agilent LC System Technical Note (InfinityLab-BestPractice-en- SD-29000194.pdf, SD-29000194). 7 Change solvent type if necessary. Multicolumn Thermostats User Manual...
Page 92 Using the Module Preparation of the System 8 Choose the tray format of the sampler. Multicolumn Thermostats User Manual...
Page 93 Using the Module Preparation of the System 9 Add a new column. 10 Enter the column information. Multicolumn Thermostats User Manual...
Page 94 Using the Module Preparation of the System 11 Select the column in the Method settings of the column compartment. 12 Set the detector parameters according to the needs of your method. Multicolumn Thermostats User Manual...
Page 95 Using the Module Preparation of the System Multicolumn Thermostats User Manual...
Page 96: Prime And Purge The System
Using the Module Preparation of the System ag-textnode-version-id: 9007202538343307 ag-textnode-base-id: 3283602315 Prime and Purge the System When the solvents have been exchanged or the pumping system has been turned off for a certain time (for example, overnight) oxygen will re-diffuse into the solvent channel between the solvent reservoir, vacuum degasser (when available in the system) and the pump.
Page 97: Preparing The Module
Using the Module Preparing the Module ag-textnode-version-id: 18014402494784651 ag-textnode-base-id: 3985302667 Preparing the Module ag-textnode-version-id: 9007203240195467 ag-textnode-base-id: 3985454475 Using Column ID Tags The Agilent InfinityLab Column Identification Tag is designed to enable the automatical detection of the columns installed in the column thermostat and help the user to track the usage of the columns in the laboratory.
Page 98 Using the Module Preparing the Module There are two ways to edit the content of custom column identification tags: • One way is to type in all the necessary information manually, using the Column Assignment tab of the control interface. •...
Page 99 Using the Module Preparing the Module ag-textnode-version-id: 3001869195 ag-textnode-base-id: 3001869195 Using Column ID Tags with ChemStation 1 In the Method and Run Control view of the Agilent OpenLAB CDS ChemStation Edition, select Columns from the Instrument menu. The Edit Columns dialog box is displayed. If the Edit Columns table is empty, go straight to Step 3.
Page 100 Using the Module Preparing the Module The Column Assignment dialog box is displayed. Figure 16: Column Assignment dialog box The Column Assignment dialog box allows you to specify and review detailed information about the columns attached to each position in the column compartment.
Page 101 Using the Module Preparing the Module The list of columns from the ChemStation's Edit Columns table is displayed. Figure 17: The list of columns from the ChemStation's Edit Columns table To reduce the list to only those columns that are marked as Installed, mark the Only show installed Columns check box.
Page 102 Using the Module Preparing the Module The information in the ChemStation's Edit Columns table is also updated. 12 You can edit the information on the column ID tag using the ChemStation Edit Columns table. When you have finished editing the information, repeat steps 7 to 9 to update the information in the tag.
Page 103 Using the Module Preparing the Module The Plumbing button of the ChemStation Edit Columns table displays the Column Assignment dialog box. It can also be displayed by selecting Column Assignment from the context menu of the column compartment Dashboard panel in the ChemStation's Method and Control view. Figure 19: Column Assignment dialog box overview The Column Assignment dialog box has three sections that give you information about the column:...
Page 104 Using the Module Preparing the Module • Place the mouse cursor over a column to display a tooltip of the column information from the column ID tag. • Click a column to highlight the column information in the Column Tag Information table. •...
Page 105: Availability Of Column Information
Using the Module Preparing the Module ag-textnode-version-id: 9007203240199435 ag-textnode-base-id: 3985458443 Availability of Column Information ag-textnode-version-id: 3001882379 ag-textnode-base-id: 3001882379 The ChemStation Columns Table The Edit Columns dialog box, which you access using the Columns command of the Instrument menu in Method and Run Control view, shows the detailed information about the columns attached to each position in the device.
Page 106 : A column with a sealed column ID tag is installed at this position. • : A column with a prelabeled column ID tag supplied by Agilent Technologies is installed at this position. Location Shows the location in the device to which the plumbing of the valve position leads.
Page 107 Using the Module Preparing the Module ag-textnode-version-id: 9007202256613899 ag-textnode-base-id: 3001872907 Column Tag Information The column ID tag contains the following information: Field Description Type Read/Write permission pre-labeled custom tag Description A description of the column. Static Read Write Length The length of the column in mm. Static Read Write...
Page 108: Optimizing The Performance Of The Module
ag-textnode-version-id: 18014402569549195 ag-textnode-base-id: 4060067211 Optimizing the Performance of the Module This chapter provides information on how to optimize the module. Optimizing the Column Compartment 109 Multicolumn Thermostats User Manual...
Page 109: Optimizing The Column Compartment
Optimizing the Performance of the Module Optimizing the Column Compartment ag-textnode-version-id: 3002345611 ag-textnode-base-id: 3002345611 Optimizing the Column Compartment For best performance results of the multicolumn compartment: • Use short connection capillaries and place them close to the heat exchanger. This reduces heat dissipation and excessive band broadening. •...
Page 110: Troubleshooting And Diagnostics
ag-textnode-version-id: 18014402702609803 ag-textnode-base-id: 4193127819 Troubleshooting and Diagnostics This chapter gives an overview of the maintenance, troubleshooting, and diagnostic features available. Diagnostic Features 111 User Interfaces 111 Troubleshooting With HPLC Advisor 111 Maintenance and Troubleshooting Tools of the Module 112 Available Tests vs User Interfaces 112 Thermostat Test 112 System Pressure Test 113 Sensors Offset Calibration 114...
Page 111: Diagnostic Features
Troubleshooting and Diagnostics Diagnostic Features ag-textnode-version-id: 27021601745768715 ag-textnode-base-id: 3981545739 Diagnostic Features This section gives an overview of the diagnostic features available. ag-textnode-version-id: 18014402312290571 ag-textnode-base-id: 3802808587 User Interfaces InfinityLab Assist InfinityLab Assist provides you with assisted troubleshooting and maintenance at your instrument. If the system in use supports the InfinityLab Assist, follow the instructions provided.
Page 112: Maintenance And Troubleshooting Tools Of The Module
Troubleshooting and Diagnostics Maintenance and Troubleshooting Tools of the Module ag-textnode-version-id: 18014402573864459 ag-textnode-base-id: 4064382475 Maintenance and Troubleshooting Tools of the Module This chapter describes the module's built-in test functions. ag-textnode-version-id: 3002984843 ag-textnode-base-id: 3002984843 Available Tests vs User Interfaces • Depending on the user interface, the available tests and the screens/reports may vary (see Test Functions and Calibrations).
Page 113: System Pressure Test
Troubleshooting and Diagnostics Maintenance and Troubleshooting Tools of the Module ag-textnode-version-id: 3002946827 ag-textnode-base-id: 3002946827 System Pressure Test For running a System Pressure Test, please refer to the corresponding pump manual. The System Pressure Test may be used for testing the tightness of a valve installed in the MCT.
Page 114: Sensors Offset Calibration
Troubleshooting and Diagnostics Maintenance and Troubleshooting Tools of the Module Use appropriate blank nuts to plug ports on the column selection valves: NOTE — 5067-6127 (Blank nut SL) for standard ports on stainless steel valves, — 5067-6141 (M4 Blank nut) for M4 ports on stainless steel valves, —...
Page 115: Agilent Lab Advisor Software
Lab Advisor Advanced Lab Advisor Basic is included with every Agilent 1200 Infinity Series and Agilent InfinityLab LC Series instrument. The Lab Advisor Advanced features can be unlocked by purchasing a license key, and include real-time monitoring of instrument actuals, all various instrument signals, and state machines.
Page 116: Error Information
ag-textnode-version-id: 18014402702633739 ag-textnode-base-id: 4193151755 Error information This chapter describes the meaning of error messages, and provides information on probable causes and suggested actions how to recover from error conditions. What Are Error Messages 118 General Error Messages 119 Timeout 119 Shutdown 119 Remote Timeout 120 Lost CAN Partner 121 Leak 122 Leak Sensor Open 123...
Page 117 Error information PELTIER ERROR (left) 142 PELTIER ERROR (right) 143 PELTIER OVERCURRENT (left) 144 PELTIER OVERCURRENT (right) 145 Multicolumn Thermostats User Manual...
Page 118: What Are Error Messages
Error information What Are Error Messages ag-textnode-version-id: 18014401511832075 ag-textnode-base-id: 3002350091 What Are Error Messages Error messages are displayed in the user interface when an electronic, mechanical, or hydraulic (flow path) failure occurs that requires attention before the analysis can be continued (for example, repair, or exchange of consumables is necessary).
Page 119: General Error Messages
Error information General Error Messages ag-textnode-version-id: 72057597564456331 ag-textnode-base-id: 3526528395 General Error Messages General error messages are generic to all Agilent series HPLC modules and may show up on other modules as well. ag-textnode-version-id: 9007202257100299 ag-textnode-base-id: 3002359307 Timeout Error ID: 62 The timeout threshold was exceeded.
Page 120: Shutdown
Error information General Error Messages ag-textnode-version-id: 27021600766713739 ag-textnode-base-id: 3002490763 Shutdown Error ID: 63 An external instrument has generated a shutdown signal on the remote line. The module continually monitors the remote input connectors for status signals. A LOW signal input on pin 4 of the remote connector generates the error message.
Page 121: Remote Timeout
Error information General Error Messages ag-textnode-version-id: 9007202257270027 ag-textnode-base-id: 3002529035 Remote Timeout Error ID: 70 A not-ready condition is still present on the remote input. When an analysis is started, the system expects all not-ready conditions (for example, a not-ready condition during detector balance) to switch to run conditions within one minute of starting the analysis.
Page 122: Lost Can Partner
Error information General Error Messages ag-textnode-version-id: 9007202257121675 ag-textnode-base-id: 3002380683 Lost CAN Partner Error ID: 71 During an analysis, the internal synchronization or communication between one or more of the modules in the system has failed. The system processors continually monitor the system configuration. If one or more of the modules is no longer recognized as being connected to the system, the error message is generated.
Page 123: Leak
Error information General Error Messages ag-textnode-version-id: 27021600766637707 ag-textnode-base-id: 3002414731 Leak Error ID: 64 A leak was detected in the module. The signals from the two temperature sensors (leak sensor and board-mounted temperature-compensation sensor) are used by the leak algorithm to determine whether a leak is present.
Page 124: Leak Sensor Open
Error information General Error Messages ag-textnode-version-id: 27021600766781835 ag-textnode-base-id: 3002558859 Leak Sensor Open Error ID: 83 The leak sensor in the module has failed (open circuit). The current through the leak sensor is dependent on temperature. A leak is detected when solvent cools the leak sensor, causing the leak sensor current to change within defined limits.
Page 125: Leak Sensor Short
Error information General Error Messages ag-textnode-version-id: 27021600766675979 ag-textnode-base-id: 3002453003 Leak Sensor Short Error ID: 82 The leak sensor in the module has failed (short circuit). The current through the leak sensor is dependent on temperature. A leak is detected when solvent cools the leak sensor, causing the leak sensor current to change within defined limits.
Page 126: Compensation Sensor Open
Error information General Error Messages ag-textnode-version-id: 54043198531068427 ag-textnode-base-id: 3002622475 Compensation Sensor Open Error ID: 81 The ambient-compensation sensor (NTC) on the power switch board in the module has failed (open circuit). The resistance across the temperature compensation sensor (NTC) on the power switch board is dependent on ambient temperature.
Page 127: Compensation Sensor Short
Error information General Error Messages ag-textnode-version-id: 54043198531110923 ag-textnode-base-id: 3002664971 Compensation Sensor Short Error ID: 80 The ambient-compensation sensor (NTC) on the power switch board in the module has failed (open circuit). The resistance across the temperature compensation sensor (NTC) on the power switch board is dependent on ambient temperature.
Page 128: Fan Failed
Error information General Error Messages ag-textnode-version-id: 36028800302691851 ag-textnode-base-id: 3283727883 Fan Failed Error ID: 68 The rotational speed is below acceptable limit. Depending on the module, assemblies (e.g. the lamp in the detector) are turned off to assure that the module does not overheat inside. Probable cause Suggested actions Fan cable disconnected.
Page 129: Mct Error Messages
Error information MCT Error Messages ag-textnode-version-id: 9007204939465227 ag-textnode-base-id: 5684724235 MCT Error Messages These errors are module specific. ag-textnode-version-id: 9007202257414667 ag-textnode-base-id: 3002673675 VALVE INIT FAILED Error ID: 32030 During initialization, the valve actuator turns until the encoder reads the reference index position. An error is generated, if the reference index cannot be found within a given time.
Page 130 Error information MCT Error Messages ag-textnode-version-id: 9007202257461387 ag-textnode-base-id: 3002720395 VALVE FAILED Error ID: 32031 Switching of the valve failed. Probable cause Suggested actions Mechanical problems. • Check valve head for correct installation. Friction too high or • Try to identify the source of trouble (valve head or drive) blockages on the valve by installing a different valve head if possible.
Page 131: Valve Tag Violation
Error information MCT Error Messages ag-textnode-version-id: 9007202257512331 ag-textnode-base-id: 3002771339 VALVE TAG VIOLATION Error ID: 32032 Reading the valve tag failed. Probable cause Suggested actions A valve head has been • For changing the valve head follow the instructions exchanged (hot-plugged) “Replace Valve Heads.”...
Page 132 Error information MCT Error Messages ag-textnode-version-id: 9007202257658251 ag-textnode-base-id: 3002917259 WRONG VALVE Error ID: 32130 Valve not supported in this module. For G7116B: NOTE G4232D (5067-4240: 2-position/10-port Valve 1300 bar) G4231C (5067-4241: 2-position/6-port Valve 1300 bar) G4234A (5067-4284: 6-position/14-port Valve 800 bar) G4234C (5067-4273: 6-position/14-port Valve 1300 bar) G4239C (5067-4233: 8-position/18-port Valve 1300 bar) 5067-4237: 8-position/9-port Valve 1300 bar For G7116B Bio:...
Page 133 Error information MCT Error Messages ag-textnode-version-id: 9007202257529483 ag-textnode-base-id: 3002788491 WAIT TIMEOUT (left) Error ID: 32044 Wait operation for left temperature timed out. Probable cause Suggested actions Defective heater. • Please contact your Agilent service representative. Defective mainboard. • Please contact your Agilent service representative. Multicolumn Thermostats User Manual...
Page 134 Error information MCT Error Messages ag-textnode-version-id: 9007202330616075 ag-textnode-base-id: 3075875083 WAIT TIMEOUT (right) Error ID: 32045 Wait operation for right temperature timed out. Probable cause Suggested actions Defective heater. • Please contact your Agilent service representative. Defective mainboard. • Please contact your Agilent service representative. Multicolumn Thermostats User Manual...
Page 135 Error information MCT Error Messages ag-textnode-version-id: 9007202257563531 ag-textnode-base-id: 3002822539 HEATEX OVERTEMP (left) Error ID: 32080 The temperature of the left Peltier heat sink has exceeded the maximum limit. Probable cause Suggested actions Defective heater assembly. • Please contact your Agilent service representative. Defective mainboard.
Page 136 Error information MCT Error Messages ag-textnode-version-id: 9007202330882827 ag-textnode-base-id: 3076141835 HEATEX OVERTEMP (right) Error ID: 32081 The temperature of the right Peltier heat sink has exceeded the maximum limit. Probable cause Suggested actions Defective heater assembly. • Please contact your Agilent service representative. Defective mainboard.
Page 137 Error information MCT Error Messages ag-textnode-version-id: 9007202257593355 ag-textnode-base-id: 3002852363 UHX SENSOR ERROR Error ID: 32090 Upper heat exchanger sensor has an error. Probable cause Suggested actions Defective sensor. • Please contact your Agilent service representative. Defective cable. • Please contact your Agilent service representative. Defective mainboard.
Page 138 Error information MCT Error Messages ag-textnode-version-id: 9007202330893579 ag-textnode-base-id: 3076152587 UHX SENSOR ERROR (right) Error ID: 32091 Upper right heat exchanger sensor has an error. Probable cause Suggested actions Defective sensor. • Please contact your Agilent service representative. Defective cable. • Please contact your Agilent service representative. Defective mainboard.
Page 139 Error information MCT Error Messages ag-textnode-version-id: 9007202257623179 ag-textnode-base-id: 3002882187 LHX SENSOR ERROR (left) Error ID: 32092 Lower left heat exchanger sensor has an error. Probable cause Suggested actions Defective sensor. • Please contact your Agilent service representative. Defective cable. • Please contact your Agilent service representative. Defective mainboard.
Page 140 Error information MCT Error Messages ag-textnode-version-id: 9007202330904971 ag-textnode-base-id: 3076163979 LHX SENSOR ERROR (right) Error ID: 32093 Lower right heat exchanger sensor has an error. Probable cause Suggested actions Defective sensor. • Please contact your Agilent service representative. Defective cable. • Please contact your Agilent service representative. Defective mainboard.
Page 141 Error information MCT Error Messages ag-textnode-version-id: 9007202257627659 ag-textnode-base-id: 3002886667 LHS SENSOR ERROR (left) Error ID: 32094 Left heat sink sensor has an error. Probable cause Suggested actions Defective sensor. • Please contact your Agilent service representative. Defective cable. • Please contact your Agilent service representative. Defective mainboard.
Page 142 Error information MCT Error Messages ag-textnode-version-id: 9007202330929163 ag-textnode-base-id: 3076188171 LHS SENSOR ERROR (right) Error ID: 32095 Right heat sink sensor has an error. Probable cause Suggested actions Defective sensor. • Please contact your Agilent service representative. Defective cable. • Please contact your Agilent service representative. Defective mainboard.
Page 143 Error information MCT Error Messages ag-textnode-version-id: 9007202257636619 ag-textnode-base-id: 3002895627 PELTIER ERROR (left) Error ID: 32096 Left Peltier hardware is not operational. Probable cause Suggested actions Defect heater element. • Please contact your Agilent service representative. Defective mainboard. • Please contact your Agilent service representative. Multicolumn Thermostats User Manual...
Page 144 Error information MCT Error Messages ag-textnode-version-id: 9007202257653771 ag-textnode-base-id: 3002912779 PELTIER ERROR (right) Error ID: 32097 Right Peltier hardware is not operational. Probable cause Suggested actions Defect heater element. • Please contact your Agilent service representative. Defective mainboard. • Please contact your Agilent service representative. Multicolumn Thermostats User Manual...
Page 145 Error information MCT Error Messages ag-textnode-version-id: 9007202257632139 ag-textnode-base-id: 3002891147 PELTIER OVERCURRENT (left) Error ID: 32098 Probable cause Suggested actions Defective sensor. • Please contact your Agilent service representative. Defective cable. • Please contact your Agilent service representative. Defective mainboard. • Please contact your Agilent service representative. Multicolumn Thermostats User Manual...
Page 146 Error information MCT Error Messages ag-textnode-version-id: 9007202330573451 ag-textnode-base-id: 3075832459 PELTIER OVERCURRENT (right) Error ID: 32099 Probable cause Suggested actions Defective sensor. • Please contact your Agilent service representative. Defective cable. • Please contact your Agilent service representative. Defective mainboard. • Please contact your Agilent service representative. Multicolumn Thermostats User Manual...
Page 147: Maintenance
ag-textnode-version-id: 27021601828562443 ag-textnode-base-id: 4064339467 Maintenance This chapter describes the maintenance of the MCT. Introduction to Maintenance 148 Safety Information Related to Maintenance 150 Overview of Maintenance 152 Cleaning the Module 153 Correcting Leaks 154 Replace Parts of Quick Change Valve Head 155 Replace Valve Heads 158 InfinityLab LC Method Development Solutions User Guide 000 Prepare the MCT for Transportation 163 Replace the Module Firmware 164 Multicolumn Thermostats User Manual...
Page 148: Introduction To Maintenance
Maintenance Introduction to Maintenance ag-textnode-version-id: 3002006923 ag-textnode-base-id: 3002006923 Introduction to Maintenance The module is designed for easy maintenance. The most frequent maintenance such as maintaining valve heads (if optional valve drive is installed) or replacing heat exchangers can be done from the front with the module in place in the system stack.
Page 149 Maintenance Introduction to Maintenance Valve Door Figure 22: Overview of maintenance parts (G7116A) There are no serviceable parts inside. NOTE Do not open the module. Multicolumn Thermostats User Manual...
Page 150: Safety Information Related To Maintenance
Maintenance Safety Information Related to Maintenance ag-textnode-version-id: 18014402382780683 ag-textnode-base-id: 3873298699 Safety Information Related to Maintenance Fire and damage to the module WARNING ag-struc-frag-safety-version-id: 4345405195 ag-struc-frag-safety-base-id: 4345405195 Wrong fuses — Make sure that only fuses with the required rated current and of the specified type (super-fast, fast, time delay etc) are used for replacement.
Page 151 Maintenance Safety Information Related to Maintenance Hot heat exchangers WARNING ag-struc-frag-safety-version-id: 9007202258557707 ag-struc-frag-safety-base-id: 3003816715 The column compartment has two heat exchanger assemblies that might be hot. — Allow them to cool down before starting repairs. Toxic, flammable and hazardous solvents, samples and reagents WARNING ag-struc-frag-safety-version-id: 3003809803 ag-struc-frag-safety-base-id: 3003809803...
Page 152: Overview Of Maintenance
Maintenance Overview of Maintenance ag-textnode-version-id: 3002011403 ag-textnode-base-id: 3002011403 Overview of Maintenance The following pages describe maintenance procedures (simple repairs) that can be done without opening the main cover. Table 20: Maintenance procedures Procedure Typical Frequency Notes Cleaning the Module If necessary page 153 Install Heat Exchanger When new application requires a...
Page 153: Cleaning The Module
Maintenance Cleaning the Module ag-textnode-version-id: 3002023307 ag-textnode-base-id: 3002023307 Cleaning the Module To keep the module case clean, use a soft cloth slightly dampened with water, or a solution of water and mild detergent. Avoid using organic solvents for cleaning purposes. They can cause damage to plastic parts. Liquid dripping into the electronic compartment of your module can cause WARNING shock hazard and damage the module...
Page 154: Correcting Leaks
Maintenance Correcting Leaks ag-textnode-version-id: 9007202256786571 ag-textnode-base-id: 3002045579 Correcting Leaks When • If a leakage has occurred at the heat exchanger or at the capillary connections or at the column switching valve. Tools required Qty. Description Tissue Pipette Wrench, 1/4 – 5/16 (for capillary connections) 1 Remove the door.
Page 155: Replace Parts Of Quick Change Valve Head
Maintenance Replace Parts of Quick Change Valve Head ag-textnode-version-id: 9007202256760587 ag-textnode-base-id: 3002019595 Replace Parts of Quick Change Valve Head For bio-inert modules use bio-inert parts only! Do not mix with bio / biocompatible parts. For biocompatible modules use bio / biocompatible parts only! Do not mix with bio-inert parts.
Page 156 Maintenance Replace Parts of Quick Change Valve Head 9 Place the new (if required) stator face in place on the stator head. Reinstall the stator head. 10 Insert the stator screws in the stator head. Tighten the screws alternately two turns at a time until the stator head is secure.
Page 157 Maintenance Replace Parts of Quick Change Valve Head Figure 23: Valve Head Parts (example) Stator screws Stator head assembly Stator ring screws (not available) Stator ring (available for service only) Rotor seal Bearing ring Spanner nut (available for service only) Figure 23 on page 157 illustrates replacement parts for the valve heads, with the NOTE 6-column selector valve as an example.
Page 158: Replace Valve Heads
Maintenance Replace Valve Heads ag-textnode-version-id: 18014401511531275 ag-textnode-base-id: 3002049291 Replace Valve Heads Several optional valve heads are available, which can be installed and exchanged easily. Parts required Qty. Description Agilent Quick Change Valve Head For details, see Valve Options Overview (G7116B) on page 171 and Valve Options Overview (G7116A)
Page 159 Maintenance Replace Valve Heads Column Damage or Bias Measurement Results CAUTION ag-struc-frag-safety-version-id: 3003523723-2 ag-struc-frag-safety-base-id: 3003523723 Switching the valve to a wrong position can damage the column or bias measurement results. — Fit the lobe to the groove to make sure the valve is switched to the correct position.
Page 160 Maintenance Replace Valve Heads 2 Push the valve head to bring it to its outer position. 3 Remove all capillary connections from the valve head. 4 Unscrew the nut and remove the valve head. Multicolumn Thermostats User Manual...
Page 161 Maintenance Replace Valve Heads 5 Put the new valve head onto the valve drive such that the lobe fits to the groove (see also G7116B_Installation of the Valve Heads on page 45). 6 Fasten the valve head onto the valve drive using the union nut (see also G7116B_Installation of the Valve Heads on page 45).
Page 162 Maintenance Replace Valve Heads 8 Push the valve head until it snaps in and stays in the rear position. 9 Switch on the module. Multicolumn Thermostats User Manual...
Page 163: Prepare The Mct For Transportation
Maintenance Prepare the MCT for Transportation ag-textnode-version-id: 3002065419 ag-textnode-base-id: 3002065419 Prepare the MCT for Transportation When • If an MCT including the Valve Drive Option shall be transported The module has been shipped with transportation locks, which must be used for NOTE transportation protection.
Page 164: Replace The Module Firmware
Maintenance Replace the Module Firmware ag-textnode-version-id: 18014401511543691 ag-textnode-base-id: 3002061707 Replace the Module Firmware When Install a newer firmware • It fixes known problems of older versions, or • It introduces new features, or • It ensures keeping all systems at the same (validated) revision When Install an older firmware •...
Page 165: Parts And Materials For Maintenance
ag-textnode-version-id: 27021601842507915 ag-textnode-base-id: 4078284939 Parts and Materials for Maintenance This chapter provides information on parts for maintenance. Plastic Parts 166 Leak Parts 168 Valve Options and Parts 169 Valve Head Parts 169 Valve Options Overview (for G7116B) 171 Valve Options Overview (for G7116A) 172 Column ID Parts 174 Column ID Upgrade Kit (for G7116B) 174 Column ID Upgrade Kit (for G7116A) 174 Column ID Parts (for G7116B) 174...
Page 166: Plastic Parts
Parts and Materials for Maintenance Plastic Parts ag-textnode-version-id: 9007202256631563 ag-textnode-base-id: 3001890571 Plastic Parts Figure 24: Plastic parts Description G7116-60004 Door-Kit TCC HE G7116-60001 Door Kit Infinity II MCT (for G7116A) (obsolete) G7116-68713 Cabinet Kit MCT includes parts 2 – 7 : G7116-40100 Base Cover MCT G7116-40103 Side Cover Left Insert MCT Side Cover Left MCT...
Page 167 Parts and Materials for Maintenance Plastic Parts Description Top Cover Kit (available only as a part of the kit) Side Cover Right MCT (available only as a part of the kit) G7116-40106 Side Cover Right Insert MCT G7116-67004 MCT Hinge Base Assembly Kit (repair kit for MCT door hinge base) G7116-60003 Transportation Foam Assembly...
Page 168: Leak Parts
Parts and Materials for Maintenance Leak Parts ag-textnode-version-id: 3003026315 ag-textnode-base-id: 3003026315 Leak Parts Figure 25: Plastic parts Description G7116-40043 Leak Adapter Top MCT G7116-40013 Leak Adapter Hitch MCT Multicolumn Thermostats User Manual...
Page 169: Valve Options And Parts
Parts and Materials for Maintenance Valve Options and Parts ag-textnode-version-id: 18014402656364299 ag-textnode-base-id: 4146882315 Valve Options and Parts MCT: Description G1353D Valve drive upgrade kit for MCT External Valve Drive: Description G1170A 1290 Infinity III Valve Drive 5067-6138 Infinity II & III Valve Holder Kit Right 5067-6139 Infinity II &...
Page 170 Parts and Materials for Maintenance Valve Options and Parts Figure 26: Valve Head Parts (example) Stator screws Stator head assembly Stator ring screws (not available) Stator ring (available for service only) Rotor seal Bearing ring Spanner nut (available for service only) Multicolumn Thermostats User Manual...
Page 171: Valve Options Overview (For G7116B)
Parts and Materials for Maintenance Valve Options and Parts ag-textnode-version-id: 3000985355 ag-textnode-base-id: 3000985355 Valve Options Overview (for G7116B) Table 21: Replacement parts standard valve heads for G7116B Valve Head Rotor Seal Stator Head Stator Screws Stator Ring 5067-4233 5068-0200 (P 5068-0199 5068-0089 n.a.
Page 172: Valve Options Overview (For G7116A)
Parts and Materials for Maintenance Valve Options and Parts Valve Head Rotor Seal Stator Head Stator Screws Stator Ring 5067-4118 5068-0012 5068-0011 5068-0019 n.a. 2-Position/10-Port Valve (Vespel) 1200 bar 5067-4142 5068-0067 5068-0077 5068-0089 n.a. 6-Position/14-Port Valve (Vespel) 1200 bar ag-textnode-version-id: 3000985739 ag-textnode-base-id: 3000985739 Valve Options Overview (for G7116A) Table 23: Replacement parts standard valve heads for G7116A Valve Head...
Page 173 Parts and Materials for Maintenance Valve Options and Parts ag-textnode-version-id: 3001985291 ag-textnode-base-id: 3001985291 Obsolete Valve Heads The following 600 bar valve heads are no longer orderable: Table 24: Replacement parts obsolete valve heads for G7116A Valve Head Rotor Seal Stator Head Stator Screws Stator Ring 5067-4287 5068-0264...
Page 174: Column Id Parts
Parts and Materials for Maintenance Column ID Parts ag-textnode-version-id: 4078292363 ag-textnode-base-id: 4078292363 Column ID Parts ag-textnode-version-id: 3016883723 ag-textnode-base-id: 3016883723 Column ID Upgrade Kit (for G7116B) Description G4750B Column ID upgrade kit for G7116B ag-textnode-version-id: 3002002443 ag-textnode-base-id: 3002002443 Column ID Upgrade Kit (for G7116A) Description G4750A Column ID upgrade kit for G7116A...
Page 175 Parts and Materials for Maintenance Column ID Parts Description 5067-5915 Column ID Kit Left 5067-5917 InfinityLab Column Identification Tag Multicolumn Thermostats User Manual...
Page 176: Accessories And Consumables
Parts and Materials for Maintenance Accessories and Consumables ag-textnode-version-id: 9007203333034891 ag-textnode-base-id: 4078293899 Accessories and Consumables ag-textnode-version-id: 9007203333036427 ag-textnode-base-id: 4078295435 Accessories and Consumables (for G7116B) ag-textnode-version-id: 3016929419 ag-textnode-base-id: 3016929419 G7116-68705 Accessory Kit (for G7116B) The Accessory Kit (for G7116B) contains accessories and tools needed for the installation and maintenance.
Page 177 Parts and Materials for Maintenance Accessories and Consumables Description G7116-60071 Quick Connect Bio Heat Exchanger Standard Flow G7116-68003 Column Holder Lamella, 2/pk (delivered as a part of G7116-60071) 5043-0915 Fitting mounting tool G7116-60006 Divider Assembly MCT 5023-2625 Union MP35N Double Drain Connector 5500-1578 Quick Connect Capillary MP35N 0.12 mm x 105 mm 5067-5965...
Page 178: Accessories And Consumables (For G7116A)
Parts and Materials for Maintenance Accessories and Consumables ag-textnode-version-id: 4078296971 ag-textnode-base-id: 4078296971 Accessories and Consumables (for G7116A) ag-textnode-version-id: 3016956299 ag-textnode-base-id: 3016956299 G7116-68755 Accessory Kit (for G7116A) The Accessory Kit (for G7116A) contains accessories and tools needed for the installation and maintenance. Description 5181-1516 CAN cable, Agilent module to module, 0.5 m...
Page 179: Additional Heater Devices
Parts and Materials for Maintenance Accessories and Consumables Description 5063-6527 Tubing, Silicon Rubber, 1.2 m, ID/OD 6 mm/9 mm 5067-5403 UHP fitting 5067-4741 ZDV union (Bio-inert) ag-textnode-version-id: 3001938315 ag-textnode-base-id: 3001938315 Available Consumables (for G7116A) Description G7116-68003 Column Holder Lamella, 2/pk G7116-68004 Column Holder Clamp, 2/pk G7116-60006 Divider Assembly MCT For separating different temperature zones between left and right...
Page 180 Parts and Materials for Maintenance Accessories and Consumables Table 25: Heat Exchanger overview Flow rate 0.075 mm i.d. capillary 0.12 mm i.d. capillary 0.17 mm i.d. capillary < 2 mL/min Ultra‐low Dispersion Standard Flow Large ID G7116‐60021 G7116‐60015 G7116‐60051 (Internal volume: 1.0 µL) (Internal volume: 1.6 µL) (Internal volume: 3.0 µL) >...
Page 181 Parts and Materials for Maintenance Accessories and Consumables Table 26: InfinityLab Quick Connect Heat Exchangers Item Description Old design Quick Connect Heat Exchanger: twist lock clips of the Quick Connect Heat Exchanger are used to secure the Quick Connect Heat Exchanger in the heater block of the MCT. New design Quick Connect Heat Exchanger: column holders (lamella type G7116-68003 or clamp type G7116-68004) are used to secure the...
Page 182: Infinitylab Quick Connect And Quick Turn Fittings
Parts and Materials for Maintenance Accessories and Consumables ag-textnode-version-id: 4078298507 ag-textnode-base-id: 4078298507 InfinityLab Quick Connect and Quick Turn Fittings ag-textnode-version-id: 3001895051 ag-textnode-base-id: 3001895051 InfinityLab Quick Connect Fittings Figure 27: InfinityLab Quick Connect Fitting Description 5067-5965 InfinityLab Quick Connect LC fitting (fitting without preinstalled capillary) 5043-0924 Front Ferrule for Quick Connect/Turn Fitting 5067-5961...
Page 183 Parts and Materials for Maintenance Accessories and Consumables ag-textnode-version-id: 3001899531 ag-textnode-base-id: 3001899531 InfinityLab Quick Connect Fitting Replacement Capillaries Description 5500-1174 InfinityLab Capillary ST 0.075 mm x 105 mm 5500-1175 InfinityLab Capillary ST 0.075 mm x 150 mm 5500-1176 InfinityLab Capillary ST 0.075 mm x 220 mm 5500-1177 InfinityLab Capillary ST 0.075 mm x 250 mm 5500-1178...
Page 184 Parts and Materials for Maintenance Accessories and Consumables ag-textnode-version-id: 3001904011 ag-textnode-base-id: 3001904011 InfinityLab Quick Turn Fitting Figure 28: InfinityLab Quick Turn Fitting Description 5067-5966 InfinityLab Quick Turn Fitting 5043-0924 Front Ferrule for Quick Connect/Turn Fitting ag-textnode-version-id: 3001908491 ag-textnode-base-id: 3001908491 Capillaries for Use with the InfinityLab Quick Turn Fitting Description 5500-1198 Capillary ST 0.075 mm x 105 mm, long socket...
Page 185 Parts and Materials for Maintenance Accessories and Consumables Description 5500-1193 InfinityLab Quick Turn Capillary ST 0.17 mm x 105 mm, long socket 5500-1194 Capillary ST 0.17 mm x 150 mm, long socket 5500-1234 Capillary ST 0.17 mm x 180 mm 5500-1195 Capillary ST 0.17 mm x 200 mm, long socket 5500-1196 Capillary ST 0.17 mm x 280 mm, long socket 5500-1235...
Page 186 Parts and Materials for Maintenance Accessories and Consumables Description 5500-1581 Quick Connect Capillary MP35N 0.12 mm x 280 mm 5500-1582 Quick Connect Capillary MP35N 0.12 mm x 400 mm 5500-1583 Quick Connect Capillary MP35N 0.12 mm x 500 mm 5500-1584 Quick Connect Capillary MP35N 0.17 mm x 105 mm 5500-1585 Quick Connect Capillary MP35N 0.17 mm x 150 mm 5500-1586...
Page 187 Parts and Materials for Maintenance Accessories and Consumables Description 5500-1603 Quick Turn Capillary MP35N 0.17 mm x 400 mm 5500-1604 Quick Turn Capillary MP35N 0.17 mm x 500 mm 5500-1605 Quick Turn Capillary MP35N 0.17 mm x 700 mm Multicolumn Thermostats User Manual...
Page 188: Identifying Cables
ag-textnode-version-id: 27021601743836299 ag-textnode-base-id: 3979613323 Identifying Cables This chapter provides information on cables used with the modules. Cable Overview 189 Analog Cables 191 Remote Cables 193 BCD Cables 197 CAN/LAN Cables 199 RS-232 Cables 200 USB 201 Multicolumn Thermostats User Manual...
Page 189: Cable Overview
Identifying Cables Cable Overview ag-textnode-version-id: 9007202256869899 ag-textnode-base-id: 3002128907 Cable Overview Never use cables other than the ones supplied by Agilent Technologies to ensure NOTE proper functionality and compliance with safety or EMC regulations. Analog cables Description 35900-60750 Agilent 35900A A/D converter...
Page 190 Identifying Cables Cable Overview RS-232 cables Description RS232-61601 RS-232 cable, 2.5 m Instrument to PC, 9-to-9 pin (female). This cable has special pin-out, and is not compatible with connecting printers and plotters. It is also called "Null Modem Cable" with full handshaking where the wiring is made between pins 1-1, 2-3, 3-2, 4-6, 5-5, 6-4, 7-8, 8-7, 9-9.
Page 191: Analog Cables
Identifying Cables Analog Cables ag-textnode-version-id: 9007202256873995 ag-textnode-base-id: 3002133003 Analog Cables One end of these cables provides a BNC connector to be connected to Agilent modules. The other end depends on the instrument to which connection is being made. Agilent Module to 35900 A/D converters p/n 35900-60750 35900 Pin Agilent...
Page 192 Identifying Cables Analog Cables Agilent Module to General Purpose p/n 01046-60105 Pin Agilent Signal Name module Not connected Black Analog - Analog + Multicolumn Thermostats User Manual...
Page 193: Remote Cables
Identifying Cables Remote Cables ag-textnode-version-id: 9007202256882571 ag-textnode-base-id: 3002141579 Remote Cables ERI (Enhanced Remote Interface) • 5188-8029 ERI to general purpose (D-Sub 15 pin male - open end) • 5188-8044 ERI to ERI (D_Sub 15 pin male - male) • 5188-8059 ERI-Extension-Cable 1.2 m (D-Sub15 pin male / female) p/n 5188-8029 Color code Enhanced Remote Classic Remote...
Page 194 Identifying Cables Remote Cables • 5188-8045 ERI to APG (Connector D_Subminiature 15 pin (ERI), Connector D_Subminiature 9 pin (APG)) p/n 5188-8045 Pin (ERI) Signal Pin (APG) Active (TTL) Start Request Stop Ready High Power on High Future Shut Down Start Prepare Ground Cable Shielding Multicolumn Thermostats User Manual...
Page 195 High Ground Cable Shielding One end of these cables provides an Agilent Technologies APG (Analytical Products Group) remote connector to be connected to Agilent modules. The other end depends on the instrument to be connected to. Multicolumn Thermostats User Manual...
Page 196 Identifying Cables Remote Cables Agilent Module to Agilent 35900 A/D Converters p/n 5061-3378 Pin 35900 A/D Pin Agilent Signal Name Active module (TTL) 1 - White 1 - White Digital ground 2 - Brown 2 - Brown Prepare run 3 - Gray 3 - Gray Start 4 - Blue 4 - Blue Shut down 5 - Pink...
Page 197: Bcd Cables
Identifying Cables BCD Cables ag-textnode-version-id: 3358242315 ag-textnode-base-id: 3358242315 BCD Cables One end of these cables provides a 15-pin BCD connector to be connected to the Agilent modules. The other end depends on the instrument to be connected to Agilent Module to General Purpose p/n G1351-81600 Wire Color Pin Agilent...
Page 198 Identifying Cables BCD Cables Agilent Module to 3396 Integrators p/n 03396-60560 Pin 3396 Pin Agilent Signal Name BCD Digit module BCD 5 BCD 7 BCD 6 BCD 4 BCD0 BCD 3 BCD 2 BCD 1 Digital ground + 5 V Multicolumn Thermostats User Manual...
Page 199: Can/Lan Cables
Identifying Cables CAN/LAN Cables ag-textnode-version-id: 18014401511606795 ag-textnode-base-id: 3002124811 CAN/LAN Cables Both ends of this cable provide a modular plug to be connected to Agilent modules CAN or LAN connectors. Can Cables Description 5181-1516 CAN cable, Agilent module to module, 0.5 m 5181-1519 CAN cable, Agilent module to module, 1 m LAN Cables Description...
Page 200: Rs-232 Cables
Identifying Cables RS-232 Cables ag-textnode-version-id: 9007202256878091 ag-textnode-base-id: 3002137099 RS-232 Cables Description RS232-61601 RS-232 cable, 2.5 m Instrument to PC, 9-to-9 pin (female). This cable has special pin-out, and is not compatible with connecting printers and plotters. It is also called "Null Modem Cable" with full handshaking where the wiring is made between pins 1-1, 2-3, 3-2, 4-6, 5-5, 6-4, 7-8, 8-7, 9-9.
Page 201: Usb
Identifying Cables ag-textnode-version-id: 9007202256886667 ag-textnode-base-id: 3002145675 To connect a USB Flash Drive use a USB OTG cable with Mini-B plug and A socket. Description 5188-8050 USB A M-USB Mini B 3 m (PC-Module) 5188-8049 USB A F-USB Mini B M OTG (Module to Flash Drive) Multicolumn Thermostats User Manual...
Page 202: Hardware Information
ag-textnode-version-id: 18014404194702987 ag-textnode-base-id: 5685221003 Hardware Information General Hardware Information 203 Firmware Description 203 Electrical Connections 205 Interfaces 207 Instrument Layout 212 Early Maintenance Feedback (EMF) 213 Module-Specific Hardware Information 214 2-bit Configuration Switch 214 Multicolumn Thermostats User Manual...
Page 203: General Hardware Information
Hardware Information General Hardware Information ag-textnode-version-id: 36028801083399691 ag-textnode-base-id: 4064435723 General Hardware Information This section provides detailed hardware information on firmware that is valid for this module. ag-textnode-version-id: 3002159627 ag-textnode-base-id: 3002159627 Firmware Description The firmware of the instrument consists of two independent sections: •...
Page 204: Firmware Updates
Hardware Information General Hardware Information • or module specific functions like • internal events such as lamp control, filter movements, • raw data collection and conversion to absorbance. Firmware Updates Firmware updates can be done with the Agilent Lab Advisor software with files on the hard disk (latest version should be used).
Page 205: Electrical Connections
Hardware Information General Hardware Information Main FW update Resident System Main System Resident FW Update Figure 29: Firmware update mechanism Some modules are limited in downgrading due to their mainboard version or their NOTE initial firmware revision. For example, a G1315C DAD SL cannot be downgraded below firmware revision B.01.02 or to a A.xx.xx.
Page 206: Rear View Of The Module
— Any other instruments connected to this instrument shall be approved to a suitable safety standard and must include reinforced insulation from the mains. Never use cables other than the ones supplied by Agilent Technologies to ensure NOTE proper functionality and compliance with safety or EMC regulations.
Page 207: Serial Number Information
Alpha-numeric code 0-9, A-Z, where each combination unambiguously denotes a module (there can be more than one code for the same module) 00000 Serial number ag-textnode-version-id: 18014402069660043 ag-textnode-base-id: 3560178059 Interfaces The Agilent InfinityLab LC Series modules provide the following interfaces: Multicolumn Thermostats User Manual...
Page 208 Hardware Information General Hardware Information Table 28: Agilent InfinityLab LC Series interfaces Module RS-232 Analog APG (A) / Special (on-board) ERI (E) Pumps G7104A/C G7110B G7111A/B, G5654A G7112B G7120A, G7132A G7161A/B Samplers G7129A/B/C G7167A/B/C, G7137A, G5668A, G3167A G7157A Detectors G7114A/B G7115A...
Page 209 Hardware Information General Hardware Information Module RS-232 Analog APG (A) / Special (on-board) ERI (E) G1170A Requires a host module with on-board LAN or with additional G1369C LAN Card. G7116A/B Requires a host module with on-board LAN or with additional G1369C LAN Card.
Page 210: Overview Interfaces
Hardware Information General Hardware Information ag-textnode-version-id: 18014401511671819 ag-textnode-base-id: 3002189835 Overview Interfaces The CAN is inter-module communication interface. It is a 2-wire serial bus system supporting high speed data communication and real-time requirement. The modules have either an interface slot for a LAN card (e.g. Agilent G1369B/C LAN Interface) or they have an on-board LAN interface (e.g.
Page 211 Remote (ERI) The ERI (Enhanced Remote Interface) connector may be used in combination with other analytical instruments from Agilent Technologies if you want to use features as common shut down, prepare, and so on. It allows easy connection between single instruments or systems to ensure coordinated analysis with simple coupling requirements.
Page 212: Special Interfaces
Hardware Information General Hardware Information Signal Description SHUT DOWN (L) System has serious problem (for example, leak: stops pump). Receiver is any module capable to reduce safety risk. START (L) Request to start run / timetable. Receiver is any module performing run-time controlled activities.
Page 213: Early Maintenance Feedback (Emf)
Hardware Information General Hardware Information • the metal inner cabinet shields the internal electronics from electromagnetic interference and also helps to reduce or eliminate radio frequency emissions from the instrument itself. ag-textnode-version-id: 3002155147 ag-textnode-base-id: 3002155147 Early Maintenance Feedback (EMF) Maintenance requires the exchange of components that are subject to wear or stress.
Page 214: Module-Specific Hardware Information
Hardware Information Module-Specific Hardware Information ag-textnode-version-id: 18014402588003083 ag-textnode-base-id: 4078521099 Module-Specific Hardware Information ag-textnode-version-id: 3002203787 ag-textnode-base-id: 3002203787 2-bit Configuration Switch 2-bit configuration switch Figure 31: Location of configuration switch Table 30: Dip switches settings for G7116A/B Mode Select Default Coldstart down Boot resident down Not supported down...
Page 215: Appendix
In Case of Damage 218 Solvent Information 219 Magnets 221 Safety Symbols 221 Material Information 223 General Information About Solvent/Material Compatibility 223 At-a-Glance Details About Agilent Capillaries 229 Waste Electrical and Electronic Equipment (WEEE) Directive 233 Radio Interference 234 RFID Statement 235 Sound Emission 237 Agilent Technologies on Internet 238 Multicolumn Thermostats User Manual...
Page 216: General Safety Information
Appendix General Safety Information ag-textnode-version-id: 63050397785402635 ag-textnode-base-id: 3002215691 General Safety Information The following general safety precautions must be observed during all phases of operation, service, and repair of this instrument. Failure to comply with these precautions or with specific warnings elsewhere in this manual violates safety standards of design, manufacture, and intended use of the instrument.
Page 217: Before Applying Power
— Verify that the voltage range and frequency of your power distribution matches to the power specification of the individual instrument. — Never use cables other than the ones supplied by Agilent Technologies to ensure proper functionality and compliance with safety or EMC regulations.
Page 218: Do Not Operate In An Explosive Atmosphere
Appendix General Safety Information ag-textnode-version-id: 3002235275 ag-textnode-base-id: 3002235275 Do Not Operate in an Explosive Atmosphere Presence of flammable gases or fumes WARNING ag-struc-frag-safety-version-id: 3004420107 ag-struc-frag-safety-base-id: 3004420107 Explosion hazard — Do not operate the instrument in the presence of flammable gases or fumes.
Page 219: Solvent Information
Appendix General Safety Information ag-textnode-version-id: 18014402035996427 ag-textnode-base-id: 3526514443 Solvent Information Toxic, flammable and hazardous solvents, samples and reagents WARNING ag-struc-frag-safety-version-id: 3004430475-2 ag-struc-frag-safety-base-id: 3004430475 The handling of solvents, samples and reagents can hold health and safety risks. — When working with these substances observe appropriate safety procedures (for example by wearing goggles, safety gloves and protective clothing) as described in the material handling and safety data sheet supplied by the vendor, and follow good laboratory practice.
Page 220 Appendix General Safety Information Recommendations on the Use of Solvents Observe the following recommendations on the use of solvents. • Brown glass ware can avoid growth of algae. • Follow the recommendations for avoiding the growth of algae, see the pump manuals.
Page 221: Magnets
Appendix General Safety Information ag-textnode-version-id: 27021600810554507 ag-textnode-base-id: 3046331531 Magnets Figure 32: Magnet in the front door of the Multicolumn Thermostat ag-textnode-version-id: 27021600766477323 ag-textnode-base-id: 3002254347 Safety Symbols Table 31: Symbols The apparatus is marked with this symbol when the user shall refer to the instruction manual in order to protect risk of harm to the operator and to protect the apparatus against damage.
Page 222 Appendix General Safety Information Manufacturing date. Product Number Serial Number Power symbol indicates On/Off. The apparatus is not completely disconnected from the mains supply when the on/off switch is in the Off position Pacemaker Magnets could affect the functioning of pacemakers and implanted heart defibrillators. A pacemaker could switch into test mode and cause illness.
Page 223: Material Information
Appendix Material Information ag-textnode-version-id: 45036002195549963 ag-textnode-base-id: 5921845003 Material Information This section provides detailed information about materials used in the HPLC system and general information about solvent/material compatibility. ag-textnode-version-id: 3002994315 ag-textnode-base-id: 3002994315 General Information About Solvent/Material Compatibility Materials in the flow path are carefully selected based on Agilent’s experiences in developing highest-quality instruments for HPLC analysis over several decades.
Page 224: Polyphenylene Sulfide (Pps)
Appendix Material Information resistance to high-temperature oxidation. Due to excellent chemical resistance and toughness, the alloy is used in diverse applications: dental products, medical devices, nonmagnetic electrical components, chemical and food processing equipment, marine equipment. Treatment of MP35N alloy samples with 10 % NaCl in HCl (pH 2.0 ) does not reveal any detectable corrosion.
Page 225 Appendix Material Information When used above room temperature, PEEK is sensitive to bases and various organic solvents, which can cause it to swell. Under such conditions, normal PEEK capillaries are sensitive to high pressure. Therefore, Agilent uses stainless steel clad PEEK capillaries in bio-inert systems. The use of stainless steel clad PEEK capillaries keeps the flow path free of steel and ensures pressure stability up to 600 bar.
Page 226 Appendix Material Information Stainless Steel (SST) Stainless steel is inert against many common solvents. It is stable in the presence of acids and bases in a pH range of 1 to 12.5 . It can be corroded by acids below pH 2.3 . It can also corrode in following solvents: •...
Page 227 Appendix Material Information Titanium is subject to corrosion in anhydrous methanol, which can be avoided by adding a small amount of water (about 3 %). Slight corrosion is possible with ammonia > 10 %. Diamond-Like Carbon (DLC) Diamond-Like Carbon is inert to almost all common acids, bases, and solvents. There are no documented incompatibilities for HPLC applications.
Page 228 Appendix Material Information Fluorinated Polymers (PTFE, PFA, FEP, FFKM, PVDF) Fluorinated polymers like PTFE (polytetrafluorethylene), PFA (perfluoroalkoxy), and FEP (fluorinated ethylene propylene) are inert to almost all common acids, bases, and solvents. FFKM is perfluorinated rubber, which is also resistant to most chemicals.
Page 229: At-A-Glance Details About Agilent Capillaries
Appendix At-a-Glance Details About Agilent Capillaries ag-textnode-version-id: 18014401512496395 ag-textnode-base-id: 3003014411 At-a-Glance Details About Agilent Capillaries The following section provides useful information about Agilent capillaries and its characteristics. Syntax for capillary description Type - Material - Capillary dimensions - Fitting Left/Fitting right Table 32: Example for a capillary description Code provided Meaing of the code...
Page 230 Appendix At-a-Glance Details About Agilent Capillaries Color Coding Guide Table 33: Color-coding key for Agilent capillary tubing Internal diameter in mm Color code 0.015 Orange 0.025 Yellow 0.05 Beige 0.075 Black 0.075 MP35N Black with orange stripe 0.1 Purple 0.12 0.12 MP35N Red with orange stripe 0.17 ...
Page 231 Appendix At-a-Glance Details About Agilent Capillaries Description Tube Tubing Heat exchanger Heat exchanger Abbreviation Guide for Material Table 35: Material (indicates which raw material is used for the capillary) Description Stainless steel Titanium PEEK FS/PK PEEK-coated fused silica PK/ST Stainless steel-coated PEEK PFFE PTFE Fused silica...
Page 232 Appendix At-a-Glance Details About Agilent Capillaries Abbreviation Guide for Fitting Left/Fitting Right Table 37: Fitting left/fitting right (indicates which fitting is used on both ends of the capillary) Description Swagelok + 0.8 mm Port id Swagelok + 1.6 mm Port id Metric M4 + 0.8 mm Port id Metric M3 + 1.6 mm Port id Swagelok union Long...
Page 233: Waste Electrical And Electronic Equipment (Weee) Directive
Appendix Waste Electrical and Electronic Equipment (WEEE) Directive ag-textnode-version-id: 3002258059 ag-textnode-base-id: 3002258059 Waste Electrical and Electronic Equipment (WEEE) Directive This product complies with the European WEEE Directive marking requirements. The affixed label indicates that you must not discard this electrical/electronic product in domestic household waste.
Page 234: Radio Interference
Radio Interference ag-textnode-version-id: 3002261771 ag-textnode-base-id: 3002261771 Radio Interference Cables supplied by Agilent Technologies are screened to provide optimized protection against radio interference. All cables are in compliance with safety or EMC regulations. Test and Measurement If test and measurement equipment is operated with unscreened cables, or used for measurements on open set-ups, the user has to assure that under operating conditions the radio interference limits are still met within the premises.
Page 235: Rfid Statement
Appendix RFID Statement ag-textnode-version-id: 18014403738255755 ag-textnode-base-id: 5228773771 RFID Statement Brasil Este equipamento não tem direito à proteção contra interferência prejudicial e não pode causar interferência em sistemas devidamente autorizados. Para mais informações, consulte o site da Anatel: https://www.gov.br/anatel/pt-br. Este produto não é apropriado para uso em ambientes domésticos, pois poderá causar interferências eletromagnéticas que obrigam o usuário a tomar medidas necessárias para minimizar estas interferências.
Page 236 Appendix RFID Statement Thailand เครื � อ งโทรคมนาคมและอุ ป กรณ์ น ี � ม ี ค วามสอดคล้ อ งตามมาตรฐานหรื อ ข้ อ กํ า หนดทางเทคนิ ค ของ กสทช. This telecommuinication equipment conforms to NTC/NBTC technical requirement. 1. User Information according to FCC 15.21:Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
Page 237: Sound Emission
Appendix Sound Emission ag-textnode-version-id: 3002271243 ag-textnode-base-id: 3002271243 Sound Emission Sound Pressure Sound pressure Lp < 70 db(A) according to DIN EN ISO 7779 Schalldruckpegel Schalldruckpegel Lp < 70 db(A) nach DIN EN ISO 7779 Multicolumn Thermostats User Manual...
Page 238: Agilent Technologies On Internet
Appendix Agilent Technologies on Internet ag-textnode-version-id: 3002266251 ag-textnode-base-id: 3002266251 Agilent Technologies on Internet For the latest information on products and services visit our worldwide web site on the Internet at: https://www.agilent.com Multicolumn Thermostats User Manual...
Page 239 • Introduction, • requirements and specifications, • using and optimizing, • troubleshooting and diagnose, • maintenance, • parts identification, • hardware information, • safety and related information. www.agilent.com © Agilent Technologies Inc. 2017-2024 Edition: 10/2024 Document No: SD-29000232 Rev. D...

This manual is also suitable for:

Infinitylab lc 1290 Infinitylab lc 1260 G1316a G1316b G1316c G7116b ... Show all
