Lasercad Main Interface - LIGHT OBJECT LO-X7 Manual

Menu Bar:
Menu Bar includes 7 sub-menus: File, Edit, Draw, Tool, Options, View and Help.
Toolbar:
There are some functions completed by command buttons in the Toolbar. Most of these functions are
sorted from menu bar.
Object Bar:
Allows selecting object during operation and relevant properties during using tool. It can control the
change of object by setting relevant properties in property bar.
Draw Bar:
With draw tool in draw bar, it makes operation more flexible and convenient.
Control Panel:
Use control panel to finish several tasks of laser machining, including setting communication IP, setting
layer parameter, loading graphic and so on.
Align Bar:
Aligns multiple objects to perfect the layout of page.
Color Bar:
Changing different colors allow different options for each layer to be set.

LaserCAD Main Interface

11
