SME400A75; SMC400A75; SMD400A75; SFE400A75; SFC400A75; SFD400A75
Installation, Operation and Service Manual
Following installation, please forward this manual
to the appropriate operations person.
Follett Europe Polska sp. z o.o.
Mokry Dwór 26c, 83021 Wiślina
tel. +4858 7856140;
www.folletteurope.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Follett Chewblet SME400A75
Summary of Contents for Follett Chewblet SME400A75
- Page 1 Micro Chewblet Ice Icemaker SME400A75; SMC400A75; SMD400A75; SFE400A75; SFC400A75; SFD400A75 Installation, Operation and Service Manual Following installation, please forward this manual to the appropriate operations person. Follett Europe Polska sp. z o.o. Mokry Dwór 26c, 83021 Wiślina tel. +4858 7856140; www.folletteurope.com...
-
Page 2: Table Of Contents
Contents Welcome................. . . 3 Before You Begin . -
Page 3: Welcome
After uncrating and removing all packing material, inspect the equipment for concealed shipping damage. If damage is found, immediately notify the shipper and contact Follett Corporation so that we can help in the filing of a claim, if necessary. If needed, the serial number of your dispenser can be found by removing the grill and locating the serial number label (a) on the bin and on the bottom of the main frame (b). -
Page 4: Important Safety Information
Important Safety Information –––––––––––––––––––––––––––––––––––––––– CAUTION! • This appliance should be permanently connected by a qualified person in accordance with application codes. • If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. -
Page 5: Specifications
Notes: 3/4" drain line must slope 1/4" per foot. Drain to be hard piped and insulated. To prevent back flow, do not connect drains. Water shut-off recommended within 5 feet (1,5m), drain to be hard piped and insulated. Follett recommends installation of an activated carbon filter in ice machine inlet water line. Ambient CAUTION! The unit is for indoor use only. -
Page 6: Dimensions
Specifications –––––––––––––––––––––––––––––––––––––––––––– (continued) Dimensions SME400A75, SMC400A75 Width 59,5 cm (23.43") Depth 66,0 cm (25.98") Height 83,8 cm (32.99") Height with legs 98,8 cm (38.90") Unit Shipping Weight 70 kg (154 lb) Clearances § This unit is a front breathing device. No side and back clearances needed. Water WARNING! Connect to potable water supply only. -
Page 7: Detailed Drawing
Specifications –––––––––––––––––––––––––––––––––––––––––––– (continued) Detailed Drawing 1) Water inlet 2) Drain outlet 3) Power supply cable grommet 4) IEC power supply socket SME400A75; SMC400A75; SMD400A75; SFE400A75; SFC400A75; SFD400A75... -
Page 8: Installation
Installation –––––––––––––––––––––––––––––––––––––––––––––––––––––– Uncrating information o Carefully unpack and inspect the contents of your Follett icemaker. o Unscrew all 4 screws to put the machine out from the skid. Fig. 1 Slide the unit to one side of the skid and screw in supplied leveling feet or accessory leg set according to your machine setup Fig. -
Page 9: Undercounter Installation
Installation –––––––––––––––––––––––––––––––––––––––––––––––––––––– CAUTION! No service or maintenance should be performed until the technician has thoroughly read this service manual. Except for routine cleaning and sanitizing, only qualified technicians should attempt to service or maintain this equipment. Under counter Installation Installation instructions for freestanding model may be found on page o Unbolt unit from skid o Slide the unit to one side of skid... -
Page 10: Freestanding Installation
Installation ––––––––––––––––––––––––––––––––––––––––––––––– (continued) Freestanding model installation CAUTION! Use caution when tipping the dispenser during leg installation. Do not lay unit on back or side. DO NOT EXCEED 30° angle. Tipping more than 30° can result in compressor malfunction. o Unbolt unit from skid o Slide the unit to one side of skid o Tip unit and screw in supplied 150mm feet accessory Rough-in the electrical service and water line. -
Page 11: Start Up Procedure
Follett authorized service agent. Regardless of who performs the cleaning, it is the operator’s responsibility to see that this cleaning is performed according to the schedule below. Service problems resulting from lack of preventive maintenance will not be covered under the Follett warranty. -
Page 12: Cleaning/Descaling And Sanitizing
MAINTENANCE/CLN light will come on. (Fig. 7) Fig. 7 3. Mix 1 gallon (3,8l) of 100F (38̊ C ) hot water and 7 ounces (198g), (one packet of Follett SafeCLEAN ice machine cleaner, part# 00132001). SME400A75; SMC400A75; SMD400A75; SFE400A75; SFC400A75; SFD400A75... - Page 13 6. Press clean switch. The machine will drain and the LOW WATER and MAINTENANCE/CLN light will come 7. Mix 1 gallon (3,8l) of 100F (38̊ C ) hot water and 1.6 ounces (48 ml) NU-CALGON IMS-II SANITIZER. (Follett #00979674). Place one Sani-Sponge™ in remaining sanitizing solution.
- Page 14 Note: The next steps must be completed before machine flushes and start producing the ice! 10. Using disposable food service grade gloves, insert dry Sani-Sponge (kit part# 00132068). Next, insert Sani- ™ Sponge soaked in Nu-Calgon IMS-II sanitizer solution (from Step 7). Push both Sani-Sponges down ice transport tube (ice Shute outlet) with supplied pusher tube.
-
Page 15: Service
Overview How the machine works Follett’s automatic-load ice machine is equipped with Follett’s 400 lb (181kg)/day ice technology. In the continuous icemaking process, water freezes to the inside wall of the evaporator. A rotating stainless steel auger carries the ice to the top of the evaporator where it is compressed and extruded through an outlet port. -
Page 16: Accessing Internal Components
Accessing Internal Components –––––––––––––––––––––––––––––––––––– Ice bin removal CAUTION! Except for routine cleaning and sanitizing, only qualified technicians should attempt to service or maintain this equipment. Use caution when sliding out the bin. 1. Empty all the ice from the bin 2. -
Page 17: Water System
Service –––––––––––––––––––––––––––––––––––––––––––––––––– (continued) Water system The water level in the evaporator is controlled by a feed solenoid and level detecting sensors. Referencing the diagram below, water sensing rods extend down into the reservoir. The system works via electrical conductivity as follows: One of the longest probes is a common. - Page 18 Service –––––––––––––––––––––––––––––––––––––––––––––––––– (continued) 1. Push in water inlet 2. Check valve 3. Water feed solenoid valve 4. Water reservoir 5. Purge valve 6. Drain outlet 7. Evaporator and gearmotor assembly 8. Ice compression nozzle 9. Drain pan 10. Cleaning cup, sanitizer SME400A75;...
-
Page 19: Electrical System
Service –––––––––––––––––––––––––––––––––––––––––––––––––– (continued) Electrical system Normal control board operation The PC board indicator lights provide all the information necessary to determine the machine's status. Green indicator lights generally represent “go” or normal operation; Yellow indicators represent normal off conditions; Red indicators generally represent alarm conditions, some of which will lock the machine off. A flashing green light labeled POWER indicates power to the machine. - Page 20 A soft error can either be automatically reset should the condition rectify, or if power is cycled. Should an error occur, consult the troubleshooting guide in this manual or a Follett service technician. Soft errors: HI AMPS: The PC board monitors the amperage of the auger motor. Should the gear motor experience current draw above the allowable limit, the machine will shut down and the TIME DELAY and HI AMP will be illuminated.
-
Page 21: Starting Procedure
(continued) Starting procedure The wiring diagrams which follow illustrate the circuitry of Follett integrated ice machine during starting procedure. Normal operation – Stage 1 Power is supplied to L1 of the control board. The ice level control in the dispenser is closed and calling for ice (LOW BIN). - Page 22 Service –––––––––––––––––––––––––––––––––––––––––––––––––– (continued) Normal operation – Stage 3 In time of 0,5s the condenser fan starts Normal operation – Stage 4 In the time of 1,5s the compressor starts running thru its start relay SME400A75; SMC400A75; SMD400A75; SFE400A75; SFC400A75; SFD400A75...
- Page 23 Service –––––––––––––––––––––––––––––––––––––––––––––––––– (continued) Normal operation – Stage 5 As the compressor comes up to normal running speed, the compressor start relay contacts open, dropping out the start winding of the compressor. SME400A75; SMC400A75; SMD400A75; SFE400A75; SFC400A75; SFD400A75...
-
Page 24: Wiring Diagram 230V
Service –––––––––––––––––––––––––––––––––––––––––––––––––– (continued) Wiring diagram 230V SME400A75; SMC400A75; SMD400A75; SFE400A75; SFC400A75; SFD400A75... -
Page 25: Wiring Diagram 115V
Service –––––––––––––––––––––––––––––––––––––––––––––––––– (continued) Wiring diagram 115V SME400A75; SMC400A75; SMD400A75; SFE400A75; SFC400A75; SFD400A75... -
Page 26: Mechanical System
Service –––––––––––––––––––––––––––––––––––––––––––––––––– (continued) Mechanical system Evaporator disassembly (Fig. 7) Press CLEAN SWITCH to purge evaporator Disconnect power to ice machine when LOW WATER lights. Shut off water to ice machine. Disconnect plastic tubing from evaporator water inlet, drain pan stub, compression nozzle tubing and reservoir overflow tubing from secured clip. -
Page 27: Refrigeration System
Service –––––––––––––––––––––––––––––––––––––––––––––––––– (continued) Refrigeration system LOW PRESSURE LIQUID HIGH PRESSURE VAPOR HIGH PRESSURE LIQUID LOW PRESSURE VAPOR HIGH PRESSURE LIQUID SME400A75; SMC400A75; SMD400A75; SFE400A75; SFC400A75; SFD400A75... - Page 28 (500g) R404A Refrigerant replacement requirements Non-contaminated refrigerant removed from any Follett refrigeration system can be recycled and returned to the same system after completing repairs. Recycled refrigerant must be stored in a clean, approved storage container. If additional refrigerant is required, virgin or reclaimed refrigerant that meets ARI standard 700-88 must be used.
-
Page 29: Troubleshooting
Service –––––––––––––––––––––––––––––––––––––––––––––––––– (continued) Troubleshooting Corrective action Ice machine disposition Possible casuses Legend Ice machine is in running condition but not making ice Deffective compressor Replace compressor Defective start relay Replace start relay Defective start capacitor Replace start capacitor Defective run capacitor Replace run capacitor Defective main contactor Replace main contactor... - Page 30 Service –––––––––––––––––––––––––––––––––––––––––––––––––– (continued) Ice machine is making ice. Excessive water in bin from 1. Failed water sensors. Processor 1. Clean or replace water probe transport tube assumes there is no water when assembly. Check wiring there is water connections. 2. Blocked reservoir vent. 2.
-
Page 31: Replacement Parts
Service –––––––––––––––––––––––––––––––––––––––––––––––––– (continued) Replacement parts Evaporator assembly SME400A75; SMC400A75; SMD400A75; SFE400A75; SFC400A75; SFD400A75... - Page 32 Service –––––––––––––––––––––––––––––––––––––––––––––––––– (continued) Reference # Description Part # Coupling, vee band, includes nut 502735 Bearing assembly, top 502736 Loop, ice compression, beveled 502110 Loop, ice compression, notched (Flaker component) 00124115 Auger 502737 Auger , with paddle (Flaker component) 00171405 Evaporator assembly with insulation 502725 O-ring, bearing housing 500496...
- Page 33 Service –––––––––––––––––––––––––––––––––––––––––––––––––– (continued) Components assembly SME400A75; SMC400A75; SMD400A75; SFE400A75; SFC400A75; SFD400A75...
- Page 34 Service –––––––––––––––––––––––––––––––––––––––––––––––––– (continued) Reference # Description Part # Compressor, 230V 50Hz 01060755 Compressor, 220V 60Hz 01056019 Compressor, 115V 60Hz 01056001 Filter, dryer 00177527 High pressure switch 00117077 Expansion valve 01033174 Condenser 01060235 Condenser fan 230V 50/60Hz 01060110 Condenser fan 115V 50/60Hz 01060102 7, 8 Evaporator and gearmotor assembly 115V...
- Page 35 Service –––––––––––––––––––––––––––––––––––––––––––––––––– (continued) Electrical box Reference # Description Part # Side cover 01061118 Main board 115V 01056019 Main Board 230V 01056001 Capacitor, compressor start Capacitor, gearmotor start Relay, compressor start Mounting pin clip Clean switch grommet 00177907 Power supply IEC inlet Electric box frame 01061092 SME400A75;...
-
Page 36: External Components
Service –––––––––––––––––––––––––––––––––––––––––––––––––– (continued) External Components Reference # Description Part # 01056357 Front grille 01056365 Frame, door assembly 01056373 Door slide guider, left 01056381 Door slide guider, right 01056399 Sliding doors 01056407 Doors roller 01056415 Scoop 01056423 Scoop holder 01056431 Condenser filter 01056449 Top cover, lid Blende cover, front...
