Portable DVD Player

User Guide JD-VD736
Playable Disk Format:
DVD/VCD/Audio CD/CD-R/CD-RW/Kodak Picture CD/JPEG Picture CD
ENGLISH
JDVD736V10M10EN02222005

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the JD-VD736 and is the answer not in the manual?

Questions and answers

Related Manuals for jWIN JD-VD736

Summary of Contents for jWIN JD-VD736

  • Page 1: Portable Dvd Player

    Portable DVD Player User Guide JD-VD736 ENGLISH Playable Disk Format: DVD/VCD/Audio CD/CD-R/CD-RW/Kodak Picture CD/JPEG Picture CD JDVD736V10M10EN02222005...

  • Page 3: Table Of Contents

    I Table of Contents I FCC and Safety Information..................3 Important Safety Instructions..................5 Precautions......................7 Selecting the type of disc for the type of TV connected.........7 Chapter 1. DVD 1-1 DVD Playback....................9 Basic Playback......................9 Stopping Playback....................9 Stopping Playback and Returning to The Menu Screen (If a Menu Is Available on The Disc)...............10 Fast Reverse/Fast Forward..................10 Skipping Ahead or Back to Chapters..............11...
  • Page 4  Table of Contents-  continued 3-3 Playing a CD ontaining JPEG ictures ............29 Basic Playback ......................29 Playing Mode ......................30 Thumbnail Mode .....................30 Program Mode ......................31 Chapter 4. Setup 4-1 Language Setup ....................32 On Screen Display (OSD) Language Setting ............32 DVD MENU Language Setting ................33 Audio Soundtrack Language Selection [DVD] ..........34 Subtitle Language Selection [DVD] ..............35...

  • Page 5: Fcc And Safety Information

    I FCC and Safety Information I CAUTION: This unit employs a laser. Due to possible eye injury, only qualifi ed service personnel should remove the cover or attempt to service this de vice. Use of controls or ad just ments or per for mance of procedures other than those spec i fi ed herein may result in hazardous radiation exposure.
  • Page 6 I FCC and Safety Information I Since it is usual for DVD movies to be released at dif fer ent times in different regions of the world, all players have region codes and discs can have an op tion al region code. If you load a disc having a different region code from your own in your player, you will see the region code notice on the screen.

  • Page 7: Important Safety Instructions

    I Important Safety Instructions I Read these instructions. Keep these instructions Heed all warnings Follow all instructions. Do not use this apparatus near water. Clean only with a damp cloth. Do not block any of the ventilation openings. Install in accordance with the man u fac tur er’s instructions.
  • Page 8 I Important Safety Instructions I Outdoor use or wet location applications: An apparatus that does not comply with the requirements in Appendix A# (Outdoor Use and Wet Location Ap pa ra tus) shall be marked or the instruction manual packed with the word “WARNING” and the following or equiv a lent: To reduce the risk of fi re or electric shock, do not expose this apparatus to rain or moisture.

  • Page 9: Precautions

    I Precautions I Please read these precautions before op er at ing this unit. Power cord protection: To avoid any malfunctions of the unit, and to protect against electric shock, fi re or personal injury, please observe the fol low ing. Hold the plug fi rmly when con nect ing or dis con nect ing the AC power cord Keep the AC power cord away from heating appliances.

  • Page 10: Selecting The Type Of Disc For The Type Of Tv Connected

    I Selecting the type of disc for the type of TV con nect ed I DVD discs have the material recorded in the PAL and NTSC systems. Refer to the table below to select the correct disc type for the type of connected TV. Connecting to multi-system TV Connecting to...

  • Page 11: Dvd Playback

    <STOP> again to stop the player completely. Note: Prestop is similar to <PAUSE> except that the Prestop function will cause the display to produce the jWIN logo screen, rather than a still image of the movie being played. Press <Play/Sel.> to resume playback.

  • Page 12: Stopping Playback And Returning To The Menu Screen (If A Menu Is Available On The Disc)

    I 1-1 DVD Playback- continued Stopping Playback and Returning to the Menu Screen If a Menu Screen is Available on The Disc Press <Menu> to display the menu. Menu The portable DVD player stops playback, and then displays the menu screen. After operation When the portable DVD player is not in use, remove the disc and press POWER to turn off the player.

  • Page 13: Skipping Ahead Or Back To Chapters

    I 1-1 DVD Playback- continued Skipping Ahead or Back to Chapters You can skip a specifi c chapter or track playback. during l Skipping Ahead Press <Next> during playback. Skips a chapter each time you press the button. l Skipping Back Press <Previous>...

  • Page 14: Repeat Viewing

    I 1-1 DVD Playback- continued Repeat Viewing Press <1/ALL> during playback. Each time you press the button, the disc will repeat a chapter or title. Press once: CHAPTER (Repeat chapter) Press twice: TITLE (Repeat title) Press three times: DISC (Repeat disc) the entire Press four times:...

  • Page 15: Convenient Func Tions

    I 1-2 Convenient Functions I Displaying the Information of the Scene Press <Info.> during playback. Info. Press <Info.> a number of times to show the title number, chapter num ber, Info. and other information will show on the screen. Stop Displaying the Information of the Scene Press <Info.>...

  • Page 16: Clearing/Displaying Subtitles(A)

    I 1-2 Convenient Functions- continued Clearing/Displaying Subtitles (A) If a disc provides subtitles, you can choose to hide or display them. (This op- eration works only with discs that provide subtitles.) Press <Subtitle> during playback to display subtitles or hide them. When you press <Subtitle>...

  • Page 17: Viewing From Another Angle

    I 1-2 Convenient Functions- continued Viewing From Another Angle Some DVD discs may contain scenes which have been shot si mul ta neous ly from a number of different angles. For these discs, the same scenes can be viewed from each of these different angles using the <Angle>.

  • Page 18: Using A Dvd Menu

    I 1-2 Convenient Functions- continued Using a DVD Menu Some DVD discs have unique menu structures called DVD menus. For ex- ample, DVDs programmed with complex contents provide guide menus, and those recorded with various languages provide menus for audio and subtitle language.

  • Page 19: Chapter 2. Audio Cd 2-1 Audio Cd Playback

    I 2-1 Audio CD Playback I Preparations: Power on the portable DVD player to begin DVD playback. If connected with earphones/headphones or other external equipment that uses power, power off such devices before connecting or removing from the player. them Turn the TV set on and select "Video"...

  • Page 20: Skipping Tracks: Going Forward Or Reverse

    I 2-1 Audio CD Playback- continued Skipping Ahead or Back to Tracks You can skip a specifi c audio track during playback l Skipping Ahead Press <Next> during playback to advance to the next track. Mulitiple presses of <Next> skips a track each time the button is pressed. l Skipping Back Press <Previous>...

  • Page 21: Audio Cd Information

    I 2-2 Audio CD Information I Displaying the Information of the Playing Track Press <Info.> during playback. Info. Press <Info.> a number of times. The elapsed time, track number and Info. other information will show on the screen. Stop Displaying the Information of the Playing Track Press <Info.>...

  • Page 22: Playing Kodak Picture Cds

    I 3-1 Playing Kodak Picture CDs I Basic Playback There are two ways to play Kodak picture CDs for viewing on the screen. 1. Load a Kodak picture CD. After few seconds, the portable DVD player starts to play back the pictures in a slide show format automatically, or 2.

  • Page 23: Slide Show

    I 3-1 Playing Kodak Picture CDs- continued Mode switch There are four modes to play Kodak picture CDs: “Thumbnail Mode”, “Slide show”, “Rotate Mode” and “Program Mode”. 1. Press <Stop> to stop and exit the present mode, repeatedly, as required, then press <Right>...

  • Page 24: Rotate Mode

    I 3-1 Playing Kodak Picture CDs- continued Rotate Mode 1. Press <Next> or <Previous> to select the preferred page, then press < > to select the preferred picture. 2. Press <Play/Sel.> to rotate the picture.Every time you press <Play/Sel.>, the picture is rotated right by 90 degree l To stop Rotate mode,press <Stop>.

  • Page 25: Program Mode

    I 3-1 Playing Kodak Picture CDs- continued Program Mode 1. Press < > to choose the preferred picture, then press <Play/Sel.>; the selected picture is marked by the yellow frame adds it to the program list. To unmark the selected picture, press <Play/Sel.>...

  • Page 26: Thumbnail Mode

    I 3-1 Playing Kodak Picture CDs- continued Thumbnail Mode While in Thumbnail mode, there are 15 pictures per page for viewing. 1. Press < > to select the picture in thumbnail. If you want to view the picture in original size, press <Play/Sel.>.

  • Page 27: Playing Jpeg Picture Cds

    I 3-2 Playing JPEG Picture CDs I Basic Playback There are two ways to play JPEG picture CDs for viewing on the screen. 1. Load a JPEG picture CD. After few seconds, the portable DVD player starts to play back the pictures in slide show automatically, or format 2.

  • Page 28: File Manager

    I 3-2 Playing JPEG Picture CDs- continued File Manager 1. Under File Manager Menu, press < > to choose the preferred picture,then press <Play/Sel.> to playback the picture. 2. Press <Next> to skip the next six pictures or <Previous> to skip the previous six pictures.

  • Page 29: Program Mode

    I 3-2 Playing JPEG Picture CDs- continued Program Mode 1. Press < > to choose the preferred picture, then press <Play/Sel.>; the selected picture is marked by the yellow frame and add it in the program list. l To unmark the selected picture, press <Play/Sel.>...

  • Page 30: Thumbnail Mode

    I 3-2 Playing JPEG Picture CDs- continued Thumbnail Mode While in Thumbnail mode, there are 15 pictures per page for viewing. 1. Press < > to select the picture in thumbnail . If you mode want to view the selected picture in original size, press <Play/Sel.>.

  • Page 31: Playing A Cd C Ontaining Jpeg P Ictures

     3-3 Playing a CD containing JPEGs  Basic Playback Load a disc containing JPEG pictures. After few seconds, the unit will enter the File Manager and the portable DVD player will automatically start to play back the JPEG files in order. ...

  • Page 32: Playing Mode

    I 3-3 Playing a CD containing JPEGs I Playing Mode 1. Press <Next> to view the next picture or playback the next track. 2. Press <Previous> to view the previous picture or playback the ous track. previ For JPEG pictures only Press <Right>...

  • Page 33: Program Mode

    I 3-3 Playing a CD containing JPEGs I Program Mode 1. Press < > to choose the preferred fi le, then press <Play/Sel.> The selected fi le is marked by the yellow frame and the program list. it's added to l To unmark the selected fi le, press <Play/Sel.>...

  • Page 34: Chapter 4. Setup

    I 4-1 Language Setup I On Screen Display (OSD) Language Setting Allows you to set various languages for the on screen display (OSD). 1. Press <Setup> in the stop mode. Setup 2. Press <Right> to highlight “OSD.” 3. Press <Right> to enter "OSD" window. 4.

  • Page 35: Dvd Menu Language Setting

    I 4-1 Language Setup- continued DVD Menu Language Setting You can select a preferred language among various languages that has been recorded on discs for the disc menu messages display. 1. Press <Setup> in the stop mode. Setup 2. Press <Right>...

  • Page 36: Audio Soundtrack Language Selection [Dvd]

    I 4-1 Language Setup- continued Audio Soundtrack Language Selection [DVD] You can select a preferred soundtrack language among various languages that have been recorded on DVD discs. 1. Press <Setup> in the stop mode. Setup 2. Press <Right> to enter "Language Setup" window and press <Down>...

  • Page 37: Subtitle Language Selection [Dvd]

    I 4-1 Language Setup- continued Subtitle Language Selection [DVD] You can select a preferred language among various languages that has been recorded on DVD discs. 1. Press <Setup> in the stop mode. Setup 2. Press <Right> to enter "Language Setup" window and press <Down>...

  • Page 38: Screen Setup

    I 4-2 Screen Setup I TV Type Setting The kind of TV Set can be selected for viewing movies played by your DVD player. Choose between 4:3 or 16:9 screen ratios and a wide-screen picture type for a TV with a 4:3 screen ratio Setup 1.
  • Page 39 I 4-2 Screen Setup- continued TV Type Setting-continued 4:3 Pan&Scan Select 4:3 PS for a conventional size TV set. Video material formatted in the pan & scan style is played in that style (the left and right edg es are cut off). 4:3 Letter Box Select 4:3 LB for a conventional size TV set.

  • Page 40: Tv System Setting

    I 4-2 Screen Setup- continued TV System Setting The player provides “PAL”, “NTSC” and “AUTO” settings for your selection. When con nect ing the portable DVD player to your TV, set the “TV System” from the on-screen display to the format that is com pat i ble with your TV’s system.

  • Page 41: Screen Saver Setting

    I 4-2 Screen Setup- continued Screen Saver Setting If you have set the screen saver ON by the following method, then you may see it functioning in the stop mode. This function will ONLY function in the stop mode. 1. Press <Setup>...

  • Page 42: Video Out Setting

    I 4-2 Screen Setup- continued Video Output Setting Please choose the preferred video output according to the output format. 1. Press <Setup> in the stop mode. Setup 2. Press <Down> to select "Screen Setup" window. 3. Press <Right> to enter "Screen Setup" window and press <Down>...
  • Page 43 I 4-2 Screen Setup- continued Video Output Setting-continued If you choose "P-Scan", the following will be shown on the screen as a remind- Screen Setup S-Video TV Type P-SCAN Screen Saver Y o u r TV s u p p o rt P -S c an TV System Video Output Y E S...

  • Page 44: Custom Setup

    I 4-3 Custom Setup I MMC/SD Setting You can only change the MMC/SD setting to "On" or "Off" while there is no disc inside the DVD player. When the disc is being played back, you can only press <Mode>to switch to MMC/SD mode. Mode 1.

  • Page 45: Angle Mark Setting [Dvd]

    I 4-3 Custom Setup- continued Angle Mark Setting [DVD] You can choose to display or hide the angle mark “ ” on the screen. 1. Press <Setup> in the stop mode. Setup 2. Press <Down> to select "Custom Setup" window. 3.

  • Page 46: Default Setting

    I 4-3 Custom Setup- continued Default Setting You may reset the previous settings in CUSTOM SETUP to the default setting. 1. Press <Setup> in the stop mode. Setup 2. Press <Down> to select "Custom Setup" window. 3. Press <Right> to enter "Custom Setup" window and press <Down>...

  • Page 47: Lcd Setup

    I 4-4 LCD Setup I Color Setting You can adjust the video color characteristics with this setting for the most satisfying effect. 1. Press <LCD>, "Color: " will show on the screen. ß à 2. Press <Left> or <Right> to choose the pre ferred color setting, and then the panel will change to the selected setting.

  • Page 48: Brightness Setting

    I 4-4 LCD Setup- continued Bright Setting You can manually increase or decrease the brightness of the video. 1. Press <LCD> twice, "Bright: " will show on the screen. ß à 2. Press <Left>> or <Right> to choose the pre ferred brightness and then the panel will change to the selected setting.

  • Page 49: Mode Setting

    I 4-4 LCD Setup- continued Mode Setting There are four modes to choose for the portable DVD player: S-Video, P-SCAN, CARD S-Video, CARD P-SCAN By pressing <Mode>, you can switch to the preferred mode setting. Mode ault mode setting is S-Video. The def 1.

  • Page 50: Chapter 5.For Your Reference 5-1 Troubleshooting

    I 5-1 Troubleshooting I Before requesting service for the portable DVD player, check the chart below for a possible cause of the problem you are experiencing. Some simple checkups or a minor adjustment on your part may eliminate the problem and restore proper operation.
  • Page 51 I 5-1 Troubleshooting- continued SYMPTOM (COMMON) REMEDY Picture is distorted during • The picture will be somewhat distorted at times. This is rapid advance or rapid normal. reverse No rapid advance (or rapid • Some discs may have sections which prohibit rapid reverse) playback advance (or rapid reverse).

  • Page 52: Disc Handling And Maintenance

    I 5-2 Disc Handling and Maintenance I Handling Precautions Hold the disc by the edges so the surface will not be soiled with fi ngerprints. (A) Fingerprints, dirt and scratches can cause skipping and distortion. Do not write on the label side with a ball-point pen or other writing utensils.
  • Page 53 I 5-2 Disc Handling and Maintenance I If the disc is brought from a cold to a warm environment, moisture may form on the disc Wipe this moisture off with a soft, dry, lint-free cloth before using the disc. Improper disc storage You can damage discs if you store them in the following places: Areas exposed to direct sunlight Humid or dusty areas...

  • Page 54: Definition Of Terms

    I 5-3 Defi nition of Terms I Angle Recorded onto some DVD discs are scenes which have been si mul ta neous ly shot from a number of dif fer ent angles (the same scene is shot from the front, from the left side, from the right side, etc.).
