P O R TA B L E DV D P L AY E R
User Guide
• Before attempting to connect, operate or adjust this product, please save and read the User Guide completely.
• The style of the product shown in the User Guide may be different from the actual unit due to various models.
Playable Format:
DVD/DVD R/DVD RW/Audio CD/Kodak Picture CD/JPEG Picture CD/MPEG 4/DviX
JD-TV108
JDTV108V10M10EN04072005
Advertisement
Chapters
Table of Contents
Related Manuals for jWIN JD TV108
Summary of Contents for jWIN JD TV108
- Page 1 JD-TV108 P O R TA B L E DV D P L AY E R User Guide • Before attempting to connect, operate or adjust this product, please save and read the User Guide completely. • The style of the product shown in the User Guide may be different from the actual unit due to various models. Playable Format: DVD/DVD R/DVD RW/Audio CD/Kodak Picture CD/JPEG Picture CD/MPEG 4/DviX JDTV108V10M10EN04072005...
- Page 2 Manufactured under license from Dolby Laboratories. “Dolby” and the double-D symbol are trademarks of Dolby Laboratories.
-
Page 3: Table Of Contents
FCC and Safety Information ... 1 Important Safety Instruction ... 2 Precautions ... 3 Selecting the Type of Disc for the Type of TV Connected ... 4 About This User Guide ... 5 1-1 Getting Started ... 6 Front View ... 6 Top View ... - Page 4 Repeating Sections Between Two Specific Times (A-B Repeat) ... 19 2 Channel Audio Output Adjustment ... 19 3D Audio Output Adjustment ... 19 Searching Music During Playback ... 20 Programming Music Playback ... 20 2-3 Kodak and JPEG Picture CDs Operation ...
-
Page 5: Fcc And Safety Information
FCC and Safety Information CAUTION: This unit employs a laser. Due to possible eye injury, only qualified service personnel should re- move the cover or attempt to service this device. Use of controls, adjustments, or the performance of procedures other than those specified herein may result in hazardous radiation exposure. -
Page 6: Important Safety Instruction
Important Safety Instruction 1. Read and keep these instructions. Pay attention to all warnings. 3. Follow all instructions. 4. Do not use this apparatus near water. 5. Clean only with a damp cloth. 6. Do not block any of the ventilation openings. Install in accordance with the manufacturer’s instructions. 7. -
Page 7: Precautions
Please read these precautions before operating the unit. Power cord protection To avoid any malfunctions of the unit, and to protect against electric shock, fire or personal injury, please observe the following. Hold the plug firmly when connecting or disconnecting the AC power cord. Keep the AC power cord away from heating appliances. -
Page 8: Selecting The Type Of Disc For The Type Of Tv Connected
Selecting the Type of Disc for the Type of TV Connected Your JD-TV108 is capable of playing DVD discs and having their content viewed on the unit's LCD display, as well as on an external TV. While your JD-TV108 is primarily intended to play NTSC DVDs, it can also play PAL DVDs (NTSC and PAL are video formats);... -
Page 9: About This User Guide
About This User Guide Note: Before attempting to connect, operate or adjust this product, please read and save this User Guide completely. Thank you for buying the Portable DVD Player. Instructions in this User Guide describe mainly the use of the remote control. Buttons with the same or similar marking on your Portable DVD Player itself, have the same functions as those of the remote control. -
Page 10: Getting Started
Front View LCD Screen Speakers Power Indicator Remote Sensor Remote Control Carrier Base Top View 3. 4. 5.6.7. 8. 9.10. 11. VOLUME(-) Button CHANNEL(+) Button VOLUME(+) Button POWER Button PREVIOUS Button PLAY Button NEXT Button CHANNEL(-) Button TV/DVD Button EJECT Button STOP Button PORTABLE DVD PLAYER USER GUIDE Getting Started... -
Page 11: Remote Control
Getting Started Service life of battery: The battery normally lasts about one year although this depends on how often and for what operations the remote control is used. If the remote control unit fails to work even when it is operated near the player, replace the battery. -
Page 12: Connect To External Equipment
Connect to External Equipment Connect the Portable DVD Player to a source of power. onnect the supplied AC adapter to the DC IN jack on the right side of the unit. Connect the unit to external equipment and/or to earphones. If you want to enjoy better listening and viewing quality, you can connect the Portable DVD Player to external equipment,... -
Page 13: Input From External Equipment
Getting Started Input from External Equipment You could input images and sounds from external equipment by connecting the por- table DVD player to external equipment with the audio or video cable. AV IN Yellow White Red Video Audio Output Output White Red (White) (Red) (Yellow) -
Page 14: Receiving Antenna Tv Signal
Receiving Antenna TV Signal You could input images and sounds from external equipment by connecting the por- table DVD player to external equipment with the audio or video cable. Telescoping Antenna Outdoor Antenna Raise the JD-TV108's telescoping antenna and position the unit so it is set to receive the best TV signals. -
Page 15: To Select Preferred Available Channels
Getting Started Freq: Press Right to increase the fre- • quency or press Left to decrease the frequency for the best tuning. Favorite: Left / Right to select “Yes” Press • or “No”. Auto search: Right and tuner search starts Press •... -
Page 16: Dvd Operation
Preparations: Connect the Portable DVD Player to a source of Power and connect it to any external equipment if necessary. If external equipment is being used: • Turn the external TV ON and select its video input that is connected to the DVD player's Video Out. •... -
Page 17: Fast Forward And Backward
Fast Forward and Backward Fast Forward or Press Backward during playback. The speed of advance (FORWARD x4, FORWARD x8 and FORWARD (FORWARD x2, FORWARD x4, FORWARD x8 and FORWARD x20) changes for each press of Fast Forward or Fast Backward. To return to normal playback, press Play. -
Page 18: Changing Audio Soundtrack Language
Changing Audio Soundtrack Language Press Audio during playback. An audio display appears at the top of the screen. To change audio soundtrack languages, Left a number of times until a press preferred language is selected. When no audio languages are recorded, "INVALID KEY“... -
Page 19: Changing Subtitle Languages
DVD Operation Changing Subtitle Languages Press Subtitle during playback. Subtitle a number of times until Press the preferred language is selected. When no subtitles are recorded, “INVALID KEY“ will be displayed instead of the language number. To clear the subtitle display, press Subtitle until appears on the screen. -
Page 20: Searching Scenes During Playback
Searching Scenes During Playback Search during playback. A Press search display appears on the top of the screen. TT 02/05 CH 002/006 Left / Right to highlight Title Press Number, Chapter Number or Time. Press Number Button(s) to edit the Title Number, Chapter Number or Time. -
Page 21: Audio Cd Operation
Preparations: Connect your JD-TV108 to its source of power, and connect any external equipment to its outputs, if desired. If external equipment is connected: • Turn the TV on and select its video input source that will receive the JD-TV108's video output. Turn the stereo system on if the JD-TV108 has been •... -
Page 22: Stopping Playback
Stopping Playback To prestop the disc playback, press Stop once. To completely stop the disc playback, Stop again. press Pausing Playback Pause once to pause Press playback. To return to normal playback, press Pause again or Play. Muting the Player Mute once during playback Press to mute the audio output. -
Page 23: Repeating Sections Between Two Specific Times (A-B Repeat)
Audio CD Operation Repeating Sections Between Two Specific Times (A-B Repeat) Press Repeat during playback, and a repeat information box appears on the screen. LEFT REP AB RIGHT REP DISC Left during playback at the Press time where repeating section will be started (A). -
Page 24: Searching Music During Playback
Searching Music During Playback Search during playback. A Press search display appears on the top of the screen. TRK 0002/11 Press to highlight Track Number or Time. Press Number Button(s) to edit Track Number or Time. Music will be played after editing according to the change of track or time. -
Page 25: Kodak And Jpeg Picture Cds Operation
Kodak and JPEG Picture CDs Operation Preparations: Please connect the Portable DVD Player to its source of power and connect it to external equipment if desired. If external equipment is connected: Basic Playback Power on the top panel of the Press player to turn on the unit. -
Page 26: Stopping Playback
Kodak and JPEG Picture CDs Operation Stopping Playback To stop the disc playback, press Stop. Pausing Playback Pause once to pause Press playback. To return to normal playback, press Pause again or Play. Rotating Pictures Right during playback to rotate Press the picture clockwise by 90°... -
Page 27: Changing Slideshow Display
Kodak and JPEG Picture CDs Operation 1 – – – 5 – – – 9 – – – 2 – – – 6 – – – 10 – – – 3 – – – 7 – – – 11 – – – 4 –... -
Page 28: Initial Osd Setting
Major OSD Settings Press Setup to enter SETUP MENU. MAIN PAGE LANGUAGE SETUP AUDIO SETUP VIDEO SETUP SYSTEM SETUP EXIT SETUP Down to highlight an Press OK to enter its option and then press setup menu. Press Left / Right to highlight an icon to enter its setup menu. -
Page 29: Language Setup
OSD Language (OSD means On Screen Display) OSD Language is a function for setting an OSD Language according to the user’s needs. Setup to display the Setup Press Left / Menu. Press highlight LANGUAGE SETUP icon. LANGUAGE SETUP OSD LANGUAGE AUDIO LANG SUBTITLE LANG MENU LANG... -
Page 30: Subtitle Language
Subtitle Language Subtitle Language is a function for selecting subtitle language outputs of DVD discs. Setup to display the Setup Press Left / Menu. Press highlight LANGUAGE SETUP icon. LANGUAGE SETUP OSD LANGUAGE AUDIO LANG SUBTITLE LANG MENU LANG MAIN PAGE Press Down to highlight Subtitle LANGUAGE. -
Page 31: Audio Setup
Digital Out Digital Out is a function for selecting a proper audio output system to the applied amplifiers. Setup to display the Setup Press Left / Menu. Press highlight AUDIO SETUP icon. AUDIO SETUP DIGITAL OUT DOWNMIX NIGHT MODE MAIN PAGE Press Down to highlight DIGITAL OUT. -
Page 32: Night Mode
Right and then Press Down to highlight a preferred option. Press AUDIO SETUP DIGITAL OUT STEREO DOWNMIX NIGHT MODE MAIN PAGE - To leave SETUP MENU, press Note: If it's preferred to downmix multi-channel audio • signals into two channels for use with your stereo, select STEREO. -
Page 33: Video Setup
Video Output Video Output is a function for selecting a type of video output according to the output format. Press Setup to display the main Left / Setup Menu. Press to highlight VIDEO SETUP icon. VIDEO SETUP VIDEO OUTPUT TV TYPE BRIGHTNESS CONTRAST SATURATION... -
Page 34: Brightness
VIDEO SETUP VIDEO OUTPUT 4:3PS TV TYPE 4:3LB BRIGHTNESS 16:9 CONTRAST SATURATION TV SYSTEM MAIN PAGE - To leave SETUP MENU, press 4:3 Pan Scan Select “4:3 PanScan” for a conventional size TV set. • Video material formatted in the pan & scan style is played in that style (the left and right edges are cut off). -
Page 35: Contrast
Video Setup Contrast Contrast provides a function for adjusting the color contrast of the player’s LCD screen. Setup to display the main Press Setup Menu. Press Left / to highlight VIDEO SETUP icon. VIDEO SETUP VIDEO OUTPUT TV TYPE BRIGHTNESS CONTRAST SATURATION TV SYSTEM... -
Page 36: Saturation
Saturation Saturation provides a function for adjusting the saturation of the player’s LCD screen. Setup to display the main Press Setup Menu. Press Left / to highlight VIDEO SETUP icon. VIDEO SETUP VIDEO OUTPUT TV TYPE BRIGHTNESS CONTRAST SATURATION TV SYSTEM MAIN PAGE Down to highlight SATURATION. -
Page 37: System Setup
Screen Saver The Screen Saver will function only when the player is ON and stopped. Setup to display the main Press Setup Menu. Press Left / to highlight SYSTEM SETUP icon. SYSTEM SETUP SCREEN SAVER ANGLE MARK DEFAULT MAIN PAGE Down to highlight SCREEN Press SAVER. -
Page 38: Default
Note: This operation works only with discs on which • multiple viewing angles are recorded. Angle button will change cam- Pressing the • era angles for movies that support this feature regardless of whether the ANGLE MARK feature is “On” or “Off”. Default Default is a function for restoring the player to the default setting. -
Page 39: Lcd Setting
Panel Setting The player provides five options for panel adjustments, including “Normal”, “16:9”, 4:3”, “Zoom”, or “Close”. LCD. The LCD setting box Press appears on the screen. Panel Invert Color Bright Press Right to enter Panel Setting when Panel is highlighted. Panel Normal Invert... -
Page 40: Color Setting
Color Setting You can adjust the color of video with this setting to a soothing view for your eyes. LCD. The LCD setting box Press appears on the screen. Panel Invert Color Bright Press Down to highlight Color. Panel Invert Color Bright Right to enter Color Setting. -
Page 41: Troubleshooting
Before requesting service for the DVD Player, check the chart below for a possible cause of the problem you are experiencing. Some simple checkups or a minor adjustment on your part may eliminate the problem and restore proper operation. SYMPTOM (COMMON) No power. - Page 42 SYMPTOM (COMMON) Audio soundtrack and/or subtitle language is not the one selected at the initial settings. No subtitles. Alternative audio soundtrack (or subtitle) language available. Angle cannot change. No sound when connecting to 5.1 channel speakers No key operation (by the DVD Recorder and/or the remote control) is effective.
-
Page 43: Disc Handling And Maintenance
Disc Handling and Maintenance Handling Precautions • Hold the disc by the edges so the surface will not be soiled with finger- prints. (A) Fingerprints, dirt and scratches can cause skipping and distortion. • Do not write on the label side with a ball-point pen or other writing utensils. •...
