jWIN JD-VD755 Quick Start

Portable DVD Player

Quick Guide
Welcome
to the Portable DVD Player Quick Guide.
Please carefully follow the instructions to set up your
Portable DVD Player.
Getting to Know Your Portable DVD Player
FRONT VIEW DIAGRAM
LCD screen
SPEAKERS
POWER indicator
OPEN button
RIGHT SIDE DIAGRAM
1 2 3 4 5
1. Volume Control
2. Headphone jack
3. Coaxial output jack
4. Audio output jack
5. Video output jack
6. POWER Switch
7. S-Video/P-Scan output jack
8. DC IN jack
REMOTE CONTROL DIAGRAM
1
2
3
4
5
6
7
8
9
1. SETUP button
2. INFO. button
3. PAUSE/UP button
4. MENU button
5. F.REV/LEFT button
6. PLAY/SEL. button
7. PREVIOUS button
8. STOP/DOWN button
9. Number buttons
PLAY button
10. MODE button
PAUSE button
STOP button
SPEAKERS
Remote Sensor BATTERY INSTALLATION FOR THE
REMOTE CONTROL
Insert the battery and match the (+) and (-) on battery to the
marks inside the battery compartment.
First-time use:
Remember to remove the insulating
Mylon piece from the battery.
6 7 8
Service life of battery
1. The battery normally lasts for about one year although this
depends on how often and for what operations the remote
control is used.
2. If the remote control unit fails to work even when it is
operated near the player, replace the battery.
3. Use a 3V lithium battery, No. CR2025.
REMOTE CONTROL OPERATION RANGE
Point the remote control unit no more than 6 meters from the
remote control sensor and within 60
10
11
12
13
14
15
16
17
18
19
The operating distance may vary according to the brightness of
the room.
Note:
1.
11. LCD button
12. SUBTITLE button
2.
13. TITLE button
14. ANGLE button
3.
15. F.FWD/RIGHT button
16. AUDIO button
17. NEXT button
18. REPEAT 1/ALL button
19. MUTE button
Using the Battery Pack
"The shape of the following battery pack is only for reference; the actual shape
may differ."
CR2025
+
Before using the battery pack, make sure to charge it.
+
OPEN
You could choose to charge the battery pack directly or charge
it while attached to the portable DVD player.
PUSH
Battery Pack Information (Charge & Playback Time)
NiMH 3800mAh
(6S1P)
- 1 -
of the front of the unit.
0
remote sensor
30
Do not point bright lights at the remote control signal
sensor.
Do not place objects between the remote control unit and
the remote control signal sensor.
Do not use this remote control unit while simultaneously
operating the remote control unit of any other equipment.
Battery charge
indicator
Battery release
Battery
button
connectors
DC IN jack
Charge Time(hr) DVD Playback Time(hr)
3.5
JD-VD755QGV10M10EN05162005
2.7
