Page 1: Portable Dvd Player
JD-VD755 Portable DVD Player User Guide Playable Disk Format: English DVD/CD/CD-R/CD-RW JDTV755V10M11EN06072005... -
Page 2: Table Of Contents
Table of Contents FCC and Safety Information... 4 Important Safety Instructions...5 Precautions...6 Selecting the type of disc for the type of TV connected...7 Chapter 1. DVD 1-1 DVD Playback...8 Basic Playback...8 Stopping Playback and Returning to The Menu Screen (If a Menu Is Available on The Disc)..8 Stopping Playback... - Page 3 Table of Contents -continued Chapter 4. Setup 4-1 Language Setup...19 On Screen Display (OSD) Language Setting...19 DVD MENU Language Setting...20 AUDIO Soundtrack Language Selection [DVD]...21 SUBTITLE Language Selection [DVD]...22 4-2 Screen Setup...23 TV Type Setting...23 Video Out Setting...24 4-3 AUDIO Setup...26 Digital Out Setting...26 Analog Out Setting...27 4-4 Custom Setup...
-
Page 4: Fcc And Safety Information
FCC and Safety Information CAUTION: This unit employs a laser. Due to possible eye injury, only qualified service personnel should remove the cover or attempt to service this device. Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to part 15 of the FCC Rules. -
Page 5: Important Safety Instructions
Important Safety Instructions Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with a damp cloth. Do not block any of the ventilation openings. Install in accordance with the manufacturer’s instructions. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. -
Page 6: Precautions
Depending on the reception conditions of your TV, interference may appear on the TV monitor while you watch a TV broadcast with your JD-VD755 left on. This is not a malfunction of the JD-VD755 or the TV. To watch a TV broadcast, turn OFF your JD-VD755. -
Page 7: Selecting The Type Of Disc For The Type Of Tv Connected
Selecting the type of disc for the type of TV connected DVDs are recorded in PAL or NTSC formats. Please refer to the table below to find the appropriate format for your region. Connecting your JD-VD755 to a multi-system-capable TV Connecting to a NTSC TV Connecting to a PAL TV... -
Page 8: Chapter 1. Dvd
Press the power button of the TV set, and select “Video” as the TV's input. Press the power button of the stereo system if the JD-VD755 has been connected to one. For your reference: When “... -
Page 9: Stopping Playback
<PREVIOUS> during playback. When you press the button once midway through a chapter, the portable DVD player returns to the beginning of the chapter being played back. At this point, the player skips a chapter each time you press the button. -
Page 10: Repeat Viewing
When you turn on or remove the disc, the portable DVD player will playback the language which is selected at the initial setting. If you select a language which is not recorded on the disc, the portable DVD player will playback a prior language programmed on the disc. -
Page 11: Clearing/Displaying Subtitles (A)
When you turn on or remove the disc, the portable DVD player will playback the subtitle language which is selected at the initial setting. If you select a subtitle language which is not recorded on the disc, the portable DVD player will playback a prior subtitle language programmed on the disc. -
Page 12: Mute The Dvd Player
Mute the DVD Player Press <MUTE> button during playback. When “MUTE” appears on the screen, the portable DVD player is muted. To resume the sound, press the button until “MUTE OFF” appears on the screen. Using DVD Menu Some DVD discs have unique menu structures. For example, DVDs programmed with complex contents provide guide menus, and those recorded with various languages provide menus for audio and subtitle language. -
Page 13: Chapter 2. Audio Cd
Audio CD Playback Preparation Attach the battery or connect the portable DVD player to a wall outlet. If connecting to external equipment, please perform the following: Press on the power button of the TV set, and select “Video” as the TV's input. -
Page 14: Skipping Ahead Or Back To Tracks
<PREVIOUS> during playback. When you press the button once midway through a track, the portable DVD player returns to the beginning of the track being played. Each additional press of the <PREVIOUS> button will cause the player to skip a track backward. -
Page 15: Playing Kodak Picture Cds
You can play Kodak picture CDs for viewing on the screen. Load a Kodak picture CD. After few seconds, the portable DVD player starts to automatically play back the pictures in slide show format. You can press the number buttons corresponding to the order of the picture, then press <PLAY/SEL.>. -
Page 16: Thumbnail Mode
Playing Kodak Picture CDs Thumbnail Mode Press <TITLE> to enter Thumbnail mode. While in Thumbnail mode, there are 12 pictures per page for viewing. Press < the selected picture in its original size, press When you view the picture in its original size, you can press thumbnail mode. -
Page 17: Playing Jpeg Picture Cds
You can play JPEG picture CDs for viewing on the screen. Load a JPEG picture CD. After few seconds, the portable DVD player automatically starts to play back the pictures in slide show format You can press the number buttons corresponding to the order of the picture, then press <PLAY/SEL.>. -
Page 18: Thumbnail Mode
Playing JPEG picture CDs Slide Show Press <NEXT> to view the next picture or previous picture. Press <RIGHT> button or <RIGHT> button to rotate right by 90 degrees. Press <LEFT> button to rotate left by 90 degrees. Press *To pause playback <PAUSE>. -
Page 19: Chapter 4. Setup
Language Setup On Screen Display (OSD) Language Setting Allows you to set various languages for the on screen display (OSD). Press <SETUP> in the stop mode. Press <UP> button / then press <PLAY/SEL.>. Press <UP> button / <PLAY/SEL.>. Press <UP> button / Press <PLAY/SEL.>. -
Page 20: Dvd Menu Language Setting
Language Setup DVD Menu Language Setting You can select a language that has been recorded on the disc menu. Press <SETUP> in the stop mode. Press <UP> button / then press <PLAY/SEL.>. Press <UP> button / <PLAY/SEL.>. Press <UP> button / <PLAY/SEL.>. -
Page 21: Audio Soundtrack Language Selection [Dvd]
<SETUP> to exit from SETUP MENU screen. Press For your reference: If the language selected is not recorded on the disc, the portable DVD player will playback the disc's top-priority language. <DOWN> button to select “Language Setup”, and <DOWN> button to select “Audio”, and then press <DOWN>... -
Page 22: Subtitle Language Selection [Dvd]
*To finish the setup operation <SETUP> to exit from SETUP MENU screen. Press For your reference: If the language selected is not recorded on the disc, the portable DVD player will playback the disc's top-priority language. -continued <DOWN> button to select “Language Setup”, and <DOWN>... -
Page 23: Screen Setup
Screen Setup TV Type Setting Set the "TV Type" of TV connected to the JD-VD755 (if any) using its "aspect ratio" (Standard 4:3, or Wide Screen 16:9). Press <SETUP> in the stop mode. Press <UP> button / press <PLAY/SEL.>. Press <UP>... -
Page 24: Video Out Setting
Screen Setup Video Output Setting Please choose the preferred video output according to the output format. Press <SETUP> in the stop mode. Press <UP> button / press <PLAY/SEL.>. Press <UP> button / press <PLAY/SEL.>. Press <UP> button / output setting. Press <PLAY/SEL.>. - Page 25 If you choose “P-Scan” as the video output setting, make sure your TV set supports the P-Scan input feature and the YUV cable is properly connected to your TV and to the JD-VD755 player. If your TV doesn’t support P-Scan feature, press <<Troubleshooting>>...
-
Page 26: Audio Setup
Audio Setup Digital Out Setting The portable DVD player provides three options, “SPDIF/PCM”, “SPDIF/RAW” and “Off” for the digital out setting. Press <SETUP> in the stop mode. Press <UP> button / press <PLAY/SEL.>. Press <UP> button / press <PLAY/SEL.>. Press <UP>... -
Page 27: Analog Out Setting
Audio Setup -continued Analog Out Setting Press <SETUP> in the stop mode. Press <UP> button / press <PLAY/SEL.>. Press <UP> button / press <PLAY/SEL.>. Press <UP> button / setting. Press <PLAY/SEL.>. Audio Setup Digital Out Analog Out *To return to the SETUP MENU screen <LEFT>... -
Page 28: Custom Setup
<PLAY/SEL.>. << NOTE >> Whether the ANGLE MARK is set to “On” or “Off” with this setting, when you press <ANGLE> button, the JD-VD755 will still playback multi-angles that are available on the DVD discs. Custom Setup *To return to the SETUP MENU screen <LEFT>... -
Page 29: Default Setting
Custom Setup -continued Default Setting You may reset the previous settings in the CUSTOM SETUP to the factory default setting. Press <SETUP> in the stop mode. Press <UP> button / press <PLAY/SEL.>. Press <UP> button / press <PLAY/SEL.>. Press <RIGHT> button to select “Read”, and then press <<... -
Page 30: Lcd Setup
LCD Setup Panel Setting The JD-VD755 provides two panel adjustment options for its LCD screen: “16:9” and “4:3”. Press <LCD>, the LCD setting information shows on the screen. Press <LCD> as required, to select “PANEL”. Press <LEFT> button or setting, and then the panel will change to the selected setting. -
Page 31: Bright Setting
*To finish the setup operation <LCD> again until the LCD setting information disappears. Press Panel Close Setting (allows you to turn off the JD-VD755's LCD while using its Video Out function) Press <LCD>, the LCD setting information shows on the screen. Press <LCD>... -
Page 32: Troubleshooting
Troubleshooting Before requesting service for your portable DVD player, check the chart below for a possible cause of the problem you are experiencing. Some simple checkups or a minor adjustment on your part may eliminate the problem and restore proper operation. -
Page 33: Disc Handling And Maintenance
Disc Handling and Maintenance Handling Precautions Hold the disc by the edges so the surface will not be soiled with fingerprints. (A) Fingerprints, dirt and scratches can cause skipping and distortion. Do not write on the label side with a ball-point pen or any other writing utensils. Do not use record cleaning sprays, benzene, thinner, static electricity prevention liquids, or any other solvent. -
Page 34: Definition Of Terms
Definition of Terms Angle Recorded onto some DVD discs are scenes which have been simultaneously shot from a number of different angles (the same scene is shot from the front, from the left side, from the right side, etc.). With such discs, the ANGLE button can be used to view the scene from different angles.
