Kyocera TASKalfa 7353ci Service Manual page 1036

Troubleshooting > Image formation problems
Step Check description
6 Checking the DP relay
PWB
7 Checking the SATA cable
8 Replacing the SATA
cable
9 Checking the DPSHD
PWB
10 Replacing the DPSHD
PWB
11 Replacing the DPCIS
12 Replacing the DP relay
PWB
13 Replacing the main PWB
When scanning the first (front) side through DP
Step Check description
1 Checking the settings
2 Checking the settings
3 Setting Background
Density Adjustment
4 Setting Background
Density Adjustment
5 Checking the original
6 Checking the contact
glass
Assumed cause
The DP relay PWB is not
properly attached.
The connector is not
properly connected.
The SATA cable is
deformed or broken.
The DPCIS is not properly
connected to the DPSHD
PWB.
The DPSHD PWB is faulty.
The DPCIS is faulty.
The DP relay PWB is
faulty.
The main PWB is faulty.
Assumed cause
The Background Density
Adjustment is not set.
The background density is
dark.
The Background Density
Adjustment is not set.
The original background
density is dark. The
background density
adjustment is dark.
The original is raised at
scanning.
The shading plate is dirty.
7-6
Measures
Reattach the DP relay PWB.
Reinsert the connectors of
the SATA cable between the
DPSHD PWB and the DP
relay PWB.
Replace the SATA cable
between the DPSHD PWB
and the DP relay PWB.
Reconnect the DPCIS to the
DPSHD PWB.
Replace the DPSHD PWB.
Replace the DPCIS, and
then execute U091 and
U411.
Replace the DP relay PWB.
Replace the main PWB.
Measures
Set [Original Image] in
[System Menu/Counter]
key > [Common Settings]
> [Function Defaults].
Set [Original Image] in
[System Menu/Counter]
key > [Common Settings]
> [Function Defaults].
Set [Background Density
Adj.] to [Auto] in [Color/
Image Quality].
Set [Background Density
Adj.] to [Manual] in [Color/
Image Quality], and adjust
the background density.
Set the original during
pressing.
Clean the shading plate at
the backside of the contact
glass.
[CONFIDENTIAL]
Referenc
e
Wiring
diagram
Wiring
diagram
Detaching
and
Reattachin
g the
DPCIS
Detaching
and
Reattachin
g the main
PWB
Reference
