5.0R RECUMBENT BIKE OWNER'S MANUAL
Read the EXERCISE BIKE GUIDE before using this OWNER'S MANUAL.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 5.0R and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Horizon Fitness 5.0R

Summary of Contents for Horizon Fitness 5.0R

  • Page 1 5.0R RECUMBENT BIKE OWNER’S MANUAL Read the EXERCISE BIKE GUIDE before using this OWNER’S MANUAL.
  • Page 2 ENGLISH...
  • Page 3 ASSEMBLY WARNING There are several areas during the assembly process that special attention must be paid. It is very important to follow the assembly instructions correctly and to make sure all parts are firmly tightened. If the assembly instructions are not followed correctly, the Recumbent Bike could have parts that are not tightened and will seem loose and may cause irritating noises.

  • Page 4: Model Information

    MODEL INFORMATION Tablet holder Console (32) Console Handlebar Console Mast (33) Bottle holder Pedal Straps (39 L&R) Mast Cover (26) Pedals (37 L&R) Back Rest (22) Seat Frame (35) Main frame (20) Crank arms (38 L&R) Handlebar set (30) Seat cushion (23) Power Adapter Heart rate sensor Transport wheels...

  • Page 5: Pre-Assembly

    PRE ASSEMBLY MAIN PARTS INCLUDED: Main Frame (20) Front Stabilizer (21F) UNPACKING Rear Stabilizer (21R) Due to the weight of the Recumbent Bike, it is recommended that two people Handlebar Set (30) perform the assembly. Unpack the product where you will be using it. It is Mast Cover (26) recommended that you place a protective covering on your floor.

  • Page 6: Assembly Step

    ASSEMBLY STEP 1 STEP 1 HARDWARE : Bolt Spring Washer Flat Washer M8x20 Ø8 Ø8 Qty: 4 Qty: 4 Qty: 4 1.1 Open hardware for Step 1. 1.2 Attach the Front Stabilizer (21F) and Rear Stabilizer (21R) to the Main Frame (20) using 4 Bolts (1), 4 Spring Washers (2) and 4 Flat Washers (3), and tighten firmly.
  • Page 7 ASSEMBLY STEP 2 STEP 2 HARDWARE : Spring Washer Bolt Flat Washer M8x45 Ø10 Ø10 Qty: 8 Qty: 2 Qty: 2 Bolt Spring Washer Flat Washer M10x50 Ø8 Ø8 Qty: 2 Qty: 8 Qty: 8 2.1 Open hardware for Step 2. 2.2 Attach the Seat Cushion (23) and Seat Back (22) to the Seat Frame (35) using 8 Bolts (4), 8 Spring Washers (2), and 8 Flat Washers (3) on...
  • Page 8 ASSEMBLY STEP 3 3.1 Insert the Seat Slider Rail (34) through the Seat Frame (35). NOTE: Make sure the seat slider lever is in the open position when inserting the slider rail.
  • Page 9 ASSEMBLY STEP 4 STEP 4 HARDWARE : Bolt Spring Washer Flat Washer M8x15 Ø8 Ø8 Qty: 6 Qty: 6 Qty: 6 4.1 Open Hardware for Step 4. 4.2 Attach assembled Seat Set and Rear Cover Bracket (27) to the Main Frame (20) using 6 Bolts (8), 6 Spring washers (2), and 6 Flat Washers (3).
  • Page 10 ASSEMBLY STEP 5 STEP 5 HARDWARE : Bolt M4x15 Qty: 1 5.1 Connect Handlebar Cable (29) to Seat Cable (28). 5.2 Attach the Seat Slider Cover (24) to the Rear cover bracket (27) using 1 Bolt (11). NOTE: Be careful not to pinch any wires while assembling cover.
  • Page 11 ASSEMBLY STEP 6 STEP 6 HARDWARE : Spring Washer Flat Washer Bolt Ø8 Ø8 M8x15 Qty: 6 Qty: 2 Qty: 6 Bolt M8x65 Qty: 4 6.1 Open hardware for Step 6. 6.2 Wrap Lead Wire (24) around the Console Cable (25) and Heart Rate Cables (27).
  • Page 12 ASSEMBLY STEP 7 STEP 7 HARDWARE : Bolt M5x10 Qty: 4 7.1 Open hardware for Step 7. 7.2 Connect Console Cable (25), Heart Rate Cables (27), and Fan Cable (28) to Console (32). Tuck any wire slack into cutout on Console Mast (33). 7.3 Attach Console (32) to Console Mast (33) using 4 Bolts (10).
  • Page 13 ASSEMBLY STEP 8 8.1 Identify Left Pedal (37L) which is labeled L on spindle and Right Pedal (37R) labeled R. 8.2 Insert Left Pedal Strap (39L) into Left Pedal (37L) and Right Pedal Strap (39R) into Right Pedal (37R). 8.3 Insert Left Pedal (37L) into Left Crank Arm (38L), ensure screw threads are aligned.
  • Page 14 ASSEMBLY STEP 9 CONGRATULATIONS! You have successfully assembled your Recumbent Bike. Product Weight: 56 kg / 123 lbs. Max User Weight: 136 kg / 300 lbs. Assembled Dimensions (L x W x H): 168 x 64 x 133 cm / 66"...

  • Page 15: Console Operation

    CONSOLE OPERATION...
  • Page 16 CONSOLE LCD Display USB Port (Backside) Program Indicators Bluetooth Button Split Button Fan Speed Button Start/Stop Button Quick Keys Up/Down Keys NOTE: There is a thin protective sheet of clear plastic on the overlay of the console that should be removed before use.

  • Page 17: Console Display

    CONSOLE OPERATION LCD DISPLAY WINDOWS: time, remain, distance, calories, heart rate, timer, speed, cadence and resistance level. LCD DISPLAY INDICATORS: indicates what information is being displayed. START : press to begin exercising, start your workout, or resume exercising after pause. STOP : press to pause/end your workout.

  • Page 18: Program Information

    PROGRAM INFORMATION P1) MANUAL: Adjust your resistance manually during your workout. P2) DISTANCE: Push yourself and go further during your workout with 13 distance workouts. Choose from 1 mile, 2 miles, 5k, 5 miles, 10k, 8 miles, 15k, 10 miles, 20k, half marathon, 15 miles, 20 miles, and marathon goals. P3) CALORIES: Set goals for burning calories.
  • Page 19 GETTING STARTED Check to make sure no objects are nearby that will hinder the movement of the Bike. Plug in the power cord. NOTE: The Bike does not have a power switch and will turn on when power is supplied. QUICK START UP Simply press the START key to begin working out.
  • Page 20 HOW TO SWITCH BETWEEN APP MODE & BT HEART RATE MODE Home- P1 Connecting to an App (default mode) Connecting to HR Strap (off by default) If using a 3rd party App, please turn on your device’s In order to access to HR Strap mode, make sure the Bluetooth (BT) and follow the App pairing instructions.
  • Page 22 Horizon 5.0R | Rev. 1.0 E ©2023 Horizon Fitness...
