Ceiling Mount - InFocus IN3114 User Manual

Ceiling Mount

If you wish to install the projector on the ceiling:
• We strongly recommend using InFocus approved ceiling mounts for
proper fitting, ventilation and installation. Refer to the installation
guide that comes with the InFocus Ceiling Mount Kit (p/n SP-CEIL-
UNIV) for more information. The warranty does not cover any dam-
age caused by use of non-approved ceiling mount kits or by installing
in an improper location.
• The ceiling must be strong enough to support the projector and the
installation must be in accordance with any local building codes. Con-
sult your dealer for more information.
• Maximum supported physical pitch is +/-8º.
• Maximum supported physical horizontal roll is +/-8º.
• Keep all adjacent surfaces 3" (76mm) from sides, front and rear and
.87" (22mm) from the bottom of projector to preserve required airflow
around the projector.
8º
7
