Summary of Contents for D-Link DPH-150SE

  • Page 2: Safety Notices

    Safety Notices Please read the following safety notices before installing or using this phone. They are crucial for the safe and reliable operation of the device.  Please use the external power supply that is included in the package. Other power supplies may cause damage to the phone, affect the behavior or induce noise.

  • Page 3: Table Of Contents

    Table of Content INTRODUCING DPH-150SE VOIP PHONE..................5 DPH-150SE................5 HANK YOU FOR YOUR PURCHASING ........................... 5 ELIVERY ONTENT .............................. 5 EYPAD ........................7 ORT FOR CONNECTING INITIAL CONNECTING AND SETTING ....................7 ......................... 7 ONNECT THE PHONE ..........................8...
  • Page 4 4.3.3.3. DIAL PEER setting..........................33 4.3.4 Phone ............................. 36 4.3.4.1. DSP Config............................36 4.3.4.2. Call Service ............................37 4.3.4.3. Digital Map Configuration........................39 4.3.4.4. Phone Book............................41 4.3.5 Maintenance.......................... 41 4.3.5.1. Auto Provision............................. 41 4.3.5.2. Syslog Config ............................42 4.3.5.3. Config Setting............................43 4.3.5.4.

  • Page 5: Introducing Dph-150Se Voip Phone

    1 Introducing DPH-150SE VoIP Phone 1.1 Thank you for your purchasing DPH-150SE Thank you for your purchasing DPH-150SE, DPH-150SE is a full-feature telephone that provides voice communication over the same data network that your computer uses. This phone functions not only much like a traditional phone, allowing to place and receive calls, and enjoy other features that traditional phone has, but also it own many data services features which you could not expect from a traditional telephone.

  • Page 6: Function Description

    Key mapping: Key name Function Description In idle state，press the MENU key to call up the menu. Menu In idle mode, press the Phone Book key to check the Phone Book record list and add new records and revise the record. Press this key again will return to idle mode.

  • Page 7: Port For Connecting

    1.4 Port for connecting POWER Power switch Select ON/OFF. Power port Output: 5V/1.0A. Network port Connect it to PC. Network port Connect it to Network or POE switch. The phone has two Network ports: The WAN port and the LAN port. Before you connect the power source, please carefully read Safety Notices of this user manual.

  • Page 8: Initial Setting

    Step 2: Connect the handset to the handset port by the handset cable in the package. Step 3: connect the power supply plug to the DC port on the back of the phone. Use the power cable to connect the power supply to a standard power outlet in your workspace. Step 4: push the on/off switch on the back of the phone to the on side, then the phone’s LCD screen displays “Initializing…Wait Log On…”...

  • Page 9: Static Ip Mode

    6. Press the Soft3 (Quit) key for twice and press the down key, the LCD screen will display “1 Net Mode”. Press the Soft2 (Enter) key and then press the soft2 (Edit) key, you can choose the network mode what you want by the navigation key. Now please choose the PPPoE mode by the down key, the LCD screen will display “<>PPPoE”, With Soft2(Save) pressed again，...

  • Page 10: Basic Functions

    Hook off (screen will show the current using line, or you could use key to select), after getting dialing tone, you could begin to dial number. After finishing it, press # and DPH-150SE will send the number and call the number. When you hear a ringback tone and screen shows the callee’s number, it shows that the person you called is ringing.

  • Page 11: Ending A Call

     calls Multi line DPH-150SE supports 2 SIP lines max，that is user could use 2 SIP accounts to register and make down calls. System will use SIP 1 as default line to call. User can use the up key key to select the line to call.

  • Page 12: Calling Hold

    3.1.8 Call records DPH-150SE supports 100 items of missed call, 100 items of incoming call, and 100 items of outgoing call. If the records are full, the newest will replace the oldest. If phone’s power cut or reboot, call records will be discarded.

  • Page 13: The High-Level Operation

     Outgoing call down Press , and use key to select to “Outgoing Call”. Press Soft2 (Enter), phone down will show the number and time of dialed call. User can also use key to browse the dialed call records; or press Soft2 (Detail) to check the details of this record, then press Soft2 (Dial) again to change the current number.

  • Page 14: Realize Secondary Dial By Dialing For Only One Time

    User can pre-defined numbers in these keys (numeric key 0-9). Hook off, press the defined numeric key, and then input “#”. Your pre-defined numbers will send out. 3.2.4 Realize Secondary Dial by Dialing for only one time When you make secondary dial in off-hook/hands-free or standby pre-input mode, press button to postpone input, and screen display will show ^.

  • Page 15: Call Pickup

     /m MWI (Message waiting indication), means the number of this key is the number of voicemail User can configure MWI function according to the above chart: 8000 is mailbox number, @1 is using SIP1, user also can configure @2(SIP2),the rest lines can be deduced by analogy, if no use, is 8000/m,it will pass the SIP1 line in default,/m means MIW function is using.

  • Page 16: Click To Dial

    B), then user A’s phone will ring, after A hooks off, the phone will dial to B. 4 Setting 4.1 Introduction of configuration 4.1.1 Ways to configure DPH-150SE has three different ways to different users.  U se phone keypad. ...

  • Page 17: Setting Via Web Browser

    4.2 Setting via web browser When this phone and PC are connected to network, enter the IP address of the wan port in this phone as the URL (e.g. http://xxx.xxx.xxx.xxx/ or http://xxx.xxx.xxx.xxx:xxxx/). down If you do not know the IP address, you can look it up on the phone’s display by pressing key button.

  • Page 18: Wizard

    4.3.1.2. Wizard Wizard Field Name Explanation Please select the proper network mode according to the network condition. DPH-150SE provide three different network settings:  Static: If your ISP server provides you the static IP address, please select this mode, and then finish Static Mode setting.
  • Page 19 Static IP Address Input the IP address distributed to you. Netmask Input the Netmask distributed to you. Gateway Input the Gateway address distributed to you. DNS Domain Set DNS domain postfix. When the domain which you inputted can not be parsed, phone will automatically add this domain to the end of the domain which you inputted before and parse it again.

  • Page 20: Call Log

    PPPoE Server It will be provided by ISP. Username Input your ADSL account. Password Input your ADSL password. Notice: Click【Finish】button after finish your setting, IP Phone will save the setting automatically and reboot. After reboot, you can dial by the SIP account. 4.3.1.3.

  • Page 21: Network

    The current Netmask address. MAC Address The current MAC address of the phone. Current Gateway The current Gateway IP address. Get MAC Time Shows the time of getting MAC address. Please select the proper network mode according to the network condition. DPH-150SE provide...

  • Page 22: Lan Config

    three different network settings:  Static: If your ISP server provides you the static IP address, please select this mode, and then finish Static Mode setting. If you don’t know about parameters of Static Mode setting, please ask your ISP for them. ...

  • Page 23: Field Name

    LAN Config Field name explanation LAN IP Specify LAN static IP. Netmask Specify LAN Netmask. Select the DHCP server of LAN port or not. After user modify the LAN IP address, phone will amend and adjust the DHCP Lease Table and save the result amended automatically according to the IP address and DHCP Service Netmask.
  • Page 24 In chart 1, there is a layer 2 switch without setting VLAN. Any broadcast frame will be transmitted to the other ports except the send port. For example, a broadcast information is sent out from port 1 then transmitted to port 2,3and 4. In chart 2, red and blue indicate two different VLANs in the switch, and port 1 and port 2 belong to red VLAN, port 3 and port 4 belong to blue VLAN.

  • Page 25: Qos Configuration

    QOS Configuration Field name explanation Before select it to enable VLAN, you need enable Bridge mode in LAN VLAN Enable config. Enable VLAN ID check by selecting it. After enable VLAN ID check, if VLAN ID Check VLAN ID of a data package is not the same with the phone or a data Enable package do not have VLAN ID, the data package will be discarded.

  • Page 26: Dhcp Server

    SERVICE PORT Field name explanation set web browse port, the default is 80 port，if you want to enhance system safety，you'd better change it into non-80 standard port. HTTP Port Example: The IP address is 192.168.1.70. and the port value is 8090, the accessing address is http://192.168.1.70:8090.
  • Page 27 DHCP SERVER Field name explanation IP-MAC mapping table. If the LAN port of the phone connects to a DHCP Leased Table device, this table will show the IP and MAC address of this device. Shows the DHCP Lease Table， the unit of Lease time is Minute. Lease Table Name Specify the name of the lease table.

  • Page 28: Sntp

    1）The size of lease table can not be larger than the quantity of C network IP address. We recommend you to use the default lease table and not modify it. 2）If you modifies the DHCP lease table, you need save the configuration and reboot. 4.3.2.6.

  • Page 29: Voip

    Enable Daylight Enable daylight saving time. Time shift(minutes) Setup the variety length. Month Setup stat and end month. Week Setup start and end week. Setup start and end day. Hour Setup start and end hours. Minute Setup start and end minutes. Notice: You need specify the above all items.
  • Page 30 SIP Config Field name explanation Choose line to set info about SIP, there are 2 lines to choose. You can switch by 【Load】 button. Shows if the phone has been registered the SIP server or not; or so, Register Status show Unapplied.
  • Page 31 Set the sip domain if needed, otherwise this VoIP phone will use the Domain Realm Register server address as sip domain automatically. (Usually it is same with registered server and proxy server IP address). Enable Register Start to register or not by selecting it or not. Set expire time of SIP server register, default is 60 seconds.

  • Page 32: Stun Config

    Click to Talk Set click to Talk (need practical software support). Signal Encode Enable/Disable Signal Encrypt. RTP Encode Enable/Disable RTP Encrypt. Set Enable/Disable Session Timer, whether support RFC4028.It will Enable Session Timer refresh the SIP sessions. Answer With Single Enable/Disable the function when call is incoming, phone replies SIP Codec message with just one codec which phone supports.

  • Page 33: Dial Peer Setting

    STUN Field name explanation Shows STUN NAT Transverse estimation, true means STUN can STUN NAT Transverse penetrate NAT, while False means not. STUN Server Addr Set your SIP STUN Server IP address. STUN Server Port Set your SIP STUN Server Port. Set STUN Effective Time.
  • Page 34 To save the memory and avoid abundant input of user, add the follow functions: 1、x Match any single digit that is dialed. If user makes the above configuration, after user dials 11 digit numbers started with 13, the phone will send out 0 plus the dialed numbers automatically. 2、...
  • Page 35 dial the prefix and a phone number to realize calling to what your prefix number is mapped. The prefix number supports at most 30 digits. Set Destination address. This is optional config item. If you want to set peer to peer call, please input destination IP address or domain name. Destination If you want to use this dial rule in SIP2 line, you need input 255.255.255.255 or 0.0.0.2 in it.

  • Page 36: Phone

    according to delete length. This setting will realize speed When you dial “2”, the SIP1 dial function, after you dialing server will receive 33334444. the numeric key “2”, the number after all will be sent out. The phone will automatically When you dial “8309“, the send out alias number adding SIP1...

  • Page 37: Dsp Configuration

    DSP Configuration Field name explanation First Codec The fist preferential DSP codec: G.711A/u, G.723, G.729. Second Codec The second preferential DSP codec: G.711A/u, G.723, G.729. Third Codec The third preferential DSP codec: G.711A/u, G.723, G.729. Forth Codec The forth preferential DSP codec: G.711A/u, G.723, G.729. Fifth Codec The fifth preferential DSP codec: G.711A/u, G.723, G.729.
  • Page 38 Call Service Field name explanation Specify Hotline number. If you set the number, you can not dial any Hotline other numbers. No Answer Time Specify No Answer Time. Set Prefix in peer to peer IP call. For example: what you want to dial is 192.168.1.119, If you define P2P IP Prefix as 192.168.1., you dial only P2P IP Prefix #119 to reach 192.168.1.119.

  • Page 39: Digital Map Configuration

    be rejected. X and. are wildcard. X means matching any single digit. for example, 4xxx expresses any number with prefix 4 which length is 4 will be forbidden to dialed out. DOT (.) means matching any arbitrary number digit. For example, 6 expresses any number with prefix 6 will be forbidden to dialed out.
  • Page 40 Digital Map Configuration Field name explanation End with "#" Set Enable/Disable the phone ended with “#” dial. Fixed Length Specify the Fixed Length of phone ending with. Time out Set the timeout of the last dial digit. The call will be sent after timeout. Below is user-defined digital map rule: [] Specifies a range that will match digit.

  • Page 41: Phone Book

    4.3.4.4. Phone Book You can input the name, phone number and select ring type for each name here. Phone Book Field name explanation Shows the detail of current phonebook. Shows the name corresponding to the phone number. Name Number Shows the phone number. Ring Type Shows the ring type of the incoming call.

  • Page 42: Syslog Config

    Auto Provision Field name explanation Current Config Show the current config file’s version. Version Set FTP/TFTP/HTTP server IP address for auto update. The address Server Address can be IP address or Domain name with subdirectory. Set FTP server Username. System will use anonymous if username Username keep blank.

  • Page 43: Syslog Configuration

    environment and parameter. Level 6---info: the daily debugging info. Level 7---debug: the lowest debug info. At present, the lowest level of debug information send to Syslog is info; debug level only can be displayed on telnet. Syslog Configuration Field name explanation Server IP Set Syslog server IP address.

  • Page 44: Update

    Config Setting Field name explanation You can save all changes of configurations. Click the Save button, all Save Config changes of configuration will be saved, and be effective immediately. . Right clicks on “Right click here…” and select “Save Target As….” then Backup Config you will save the config file in .txt format.

  • Page 45: Account Config

    4.3.5.5. Account Config You can add or delete user account, change the authority of each user account in this web page Account Configuration Field name explanation Keyboard Password Set the password for entering the setting menu of the phone by the phone‘s key board.

  • Page 46: Reboot

    4.3.5.6. Reboot If you modified some configurations which need the phone’s reboot to be effective, you need click the Reboot, then the phone will reboot immediately. Notice: Before reboot, you need confirm that you have saved all configurations. 4.3.6 Security 4.3.6.1 MMI Filter MMI Filter User could make some device own IP, which is pre-specified, access to the MMI of the phone to...

  • Page 47: Firewall

    MMI Filter IP Table list: Add or delete the IP address segments that access to the phone. Set initial IP address in the Start IP column, Set end IP address in the End IP column, and click Add to add this IP segment. You can also click Delete to delete the selected IP segment. Select it or not to enable or disable MMI Filter.

  • Page 48: Nat Config

    supports two access lists: one for filtering input packets, and the other for filtering output packets. Each kind of list could be added 10 items. We will give you an instance for your reference. Field name explanation In_access enable Select it to Enable in_ access rule. out_access enable Select it to Enable out_ access rule.
  • Page 49 DMZ config： In order to make some intranet equipments support better service for extranet, and make internal network security more effectively, these equipments open to extranet need be separated from the other equipments not open to extranet by the corresponding isolation method according to different demands.

  • Page 50: Nat Configuration

    NAT Configuration Field name explanation It is an encryption technology. Select it to enable IPSec ALG, the default IPSec ALG is enable. FTP is a service of connection layer which can transform intranet IP into FTP ALG extranet IP when intranet IP is sending out packet. Select it to enable FTP ALG, the default is enable.

  • Page 51: Vpn Config

    Outside Port Set the WAN port of the NAT mapping. Notice: After finish setting, click the Add button to add new mapping table; click the Delete button to delete the selected mapping table. Shows the outside WAN port IP address and the inside LAN port IP address. Outside IP Set the outside Wan port IP address of DMZ.

  • Page 52: Vpn Configuration

    VPN Configuration Field name explanation VPN IP Shows the current VPN IP address. Enable VPN Select it or not to enable or disable VPN. VPN Server Addr Set VPN L2TP Server IP address. VPN User Name Set User Name access to VPN L2TP Server. VPN Password Set Password access to VPN L2TP Server.

  • Page 53: Settings Via Phones Keyboard

    4.4 Settings via phone’s keyboard. 4.4.1 How to set via the phone’s keyboard. User can do browse, modify or cancel via screen menu by using Soft1/Soft2/Soft3.  Use down and Soft1 to select the sub-menu.  Use down to adjust screen brightness and contrast, ring volume and voice volume.

  • Page 54: Appendix

    5 Appendix 5.1 Specification 5.1.1. Device specification Item DPH-150SE Adapter(Input/Output) Input：100-240VAC 50-60Hz Output：DC 5V/1A 10/100Base- T RJ-45 for LAN Port 10/100Base- T RJ-45 for PC Power Consumption Idle：1.5W/Active：1.8W LCD size 74 x 28mm dot-matrix LCD Operation 0～40℃ Temperature Relative Humidity 10～65%...

  • Page 55: Network Features

    5.1.3. Network Features  WAN/LAN: support Bridge and Router mode  Support basic NAT and NAPT  Support PPPoE for xDSL  support VLAN  Support NAT penetration, and Stun penetration  Support DMZ  Support VPN( L2TP)  Support DHCP get IP on WAN port ...
