Summary of Contents for Harman Kardon DVD 10
- Page 1 DVD10 Digital Versatile Disc Player USER’S MANUAL ® Power for the digital revolution. ™...
-
Page 2: Table Of Contents
Table of Contents Safety information Page Note: This unit can be used only where the power supply is AC 220- 240V, 50Hz. It cannot be used elsewhere. Safety Information Features and Accessories Front Panel CAUTION: Remote Control DVD/CD PLAYER IS A CLASS I LASER PRODUCT. HOWEVER, THIS DVD/CD Front Panel Information Display PLAYER USES A INVISIBLE LASER BEAM WHICH COULD CAUSE HAZ- Rear Panel... -
Page 3: Disc Formats Supported By This Player
72500 Château-du-Loir, FRANCE declare in own responsibility, that the product described in this owner’s manual is in compliance with technical standards: EN 60 065:1993 EN 55 013/A12/8.1994 EN 55 020/12.1994 EN 61000-3-2/4.1995 EN 61000-3-3/1.1995 Carsten Olesen Harman Kardon Europe 01/01... -
Page 4: Front Panel
Front Panel 1. MAIN POWER ON/OFF 5. DIMMER 2. POWER ON/OFF (Standby) 6. PLAY/PAUSE 3. OPEN/CLOSE 7. SEARCH (REV & FWD) 4. STOP 8. SKIP (PREV & NEXT) -
Page 5: Remote Control
Remote Control 1. POWER ON 2. POWER OFF 3. AUDIO 4. SUBTITLE 5. ANGLE 6. STATUS 7. TITLE 8. RETURN 9. SUBTITLE ON/OFF 10. ARROWS 11. ENTER 12. MENU 13. PLAY 14. SEARCH (REV) 15. SEARCH (FWD) 16. OPEN/CLOSE 17. PAUSE 18. - Page 6 1. POWER ON: Turns on the player when it is in standby mode 16. OPEN/CLOSE: Press to open or close the disc tray. (Harman Kardon logo appears on screen). 17. PAUSE: Freezes a picture when a disc is playing. Press again for 2.
- Page 7 FL Display RESUME RANDOM REPEAT A – B INTRO PROG. —±‚ TITLE CHAPTER TRACK HOUR 1. Illuminates in parental lock mode. 8. Illuminates and spins during search and slow playback & play and pause mode, indicating the play/search speed. 2. Illuminates when the player is ready to resume playback. 9.
-
Page 8: Rear Panel
8. Remote IR Input: Connect the output of a remote infrared sensor or Player to a compatible Dolby Digital or DTS receiver or decoder. Dolby the remote control output of another compatible Harman Kardon Digital and DTS offer theater-quality sound (5.1-Channels). -
Page 9: Setup And Connections
Setup and Connections • Ensure that the power switch of this unit and other equipment to be • Ensure that you observe the color coding when connecting audio and connected is set to off before commencing connection. video cables. • Do not block ventilation holes of any of the equipment and arrange •... -
Page 10: Dolby Digital Or Dts Decoder
Setup and Connections Connecting to a receiver/amplifier with Dolby • Note: With multiple video sources, your Audio/Video device can be Digital (AC-3) or DTS (Digital Theater Systems) used for selecting the video signal and routing it to the TV. Connect the video or S-video output of the DVD10 (whatever is provided with your decoder device) to the video or S-video input on your device and the video/S-... - Page 11 Setup and Connections Connecting to a TV set or monitor with SCART con- • The SCART connector for the TV provides the composite video signal as nectors well as the direct RGB signal, delivering the best video performance possible. To view RGB video on your TV, the RGB compatible SCART connector must be used.
-
Page 12: Remote Control Preparation
Remote control preparation Battery installation Insert the batteries while observing the correct (+) and (–) polarities. Service life of batteries • The batteries normally last for about one year, although this depends on how often, and for what operations, the remote control is used. Fig A. -
Page 13: Optional Audio Connections
Optional audio connections Audio from the optical/coaxial digital audio out- Caution for the optical/coaxial digital audio puts. outputs: • Remove the dust protection cap from the optical digital audio output • When connecting an amplifier (with an optical/coaxial digital input ) and connect the cable firmly so that the configurations of both the which does not contain the Dolby Digital (AC-3) or DTS decoder, be cable and the connector match. -
Page 14: Playing Dvd Disc
Playing DVD Discs Basic Play Disc Playback Features Preparation • Switch the TV ON and select “Video” as the TV input. Fast Motion Playback (Picture Search) To scan through the disc when you’re playing it, use the Picture Scan fea- •... -
Page 15: Using The On-Screen Banner Display
Playing DVD Discs Using the On-Screen Banner Display The invalid symbol Ø appears on the screen when you press a button that doesn’t have any function. If one of the icons is "grayed out," the The on-screen Banner Display contains many playback features. To see Banner Display feature isn’t available for the disc you’re playing. -
Page 16: Changing The Subtitle Language
Playing DVD Discs Changing the Audio Language or Track Changing the Subtitle Language If the disc was created with different language or audio tracks, you can You can change the Subtitle language while you’re watching a disc (but use the Banner Display to temporarily change the DVD player’s Audio only if the disc was created with subtitles). -
Page 17: Changing The Camera Angle
Playing DVD Discs Changing the Camera Angle Using Bookmarks Some discs contain multiple angles of a particular scene or sequence. If The bookmark feature lets you mark a point on the disc that you can go the disc only has one angle, this feature won’t work. to quickly. -
Page 18: Random Play
Playing DVD Discs Using the Repeat Feature Random Play There are four Repeat options: 1. While a disc is playing, press RANDOM on the remote (the Random Display appears). • Disc – Repeat the disc that is playing. • Title – Repeat the title that is playing. •... -
Page 19: Program Play
Playing DVD Discs Program Play Insert Chapter Inserting chapters is possible only if chapters are already programmed on Program Edit the playlist and will change the order of playback. 1. In Stop mode, press PROGRAM on the remote (Program Edit Display 1. -
Page 20: Set Up Menu
Playing DVD Discs Set Up Menu Select Other Language 1. Select Other and Press ENTER. During STOP mode, if you press MENU on the remote, current Set Up Menu Display appears on the screen. 2. Input first number of language code (see table on page 32) into the first digit by pressing ARROW (UP or DOWN) on the remote, then ENTER or ARROW (right) and enter the other 3 digits the same way. -
Page 21: Subtitle Language
Playing DVD Discs Subtitle Language Menu Language Select Subtitle Language Define the language of the menus and other short messages shown on With this set up you define the default subtitle language (if disc was cre- the screen. ated with different language tracks). Choosing a subtitle language from the Banner Display (see page 9) will overwrite this setting only 1. -
Page 22: Rating
Playing DVD Discs Rating The rating levels: The rating system is based on information encoded on the DVD disc being played, so movies may carry a rating symbol, the disc may or may not contain that rating in its software. In addition to the five standard This chapter is to disable the playing of some DVDs (particulary U.S. -
Page 23: Password
Playing DVD Discs Password 5. Press ENTER to finish password input (Confirm Password display appears below Enter Password Display). Input Password For disabling the playback of rated DVDs a password, consisting of four digits, must be entered: 1. Press ARROW (UP or DOWN) on the remote to select Password on the SET UP MENU DISPLAY. -
Page 24: Playing Dvd Discs
Playing DVD Discs Change Password 4. Press ARROW (UP or DOWN) on the remote to select Change Password can be changed a any time but first the current password must Password and press ENTER (Enter Password Display appears again). be entered: 5. - Page 25 Playing DVD Discs Clear Password Password can be cleared easily, but first the current password must be entered: 1. Press ARROW (UP or DOWN) on the remote to select Password on the SET UP MENU DISPLAY. 2. Press ENTER or ARROW (right), Enter Password Display appears. 3.
-
Page 26: Dynamic Range
Playing DVD Discs TV Aspect Dynamic Range This step selects the TV aspect, conventional screen shape (4:3) or This setting enables Dolby Digital recordings to be played back with full widescreen (16:9), according to your TV set: dialogue intelligibility while reducing peak levels and increasing low lev- els by 1/4 to 1/3. -
Page 27: Digital Audio Out
Playing DVD Discs Digital Audio Out Important : DTS information If you set the Digital Audio Out Menu to DTS, to listen to DTS you must have your DVD player connected to a receiver or DTS decoder with DTS decoding and the disc you play must contain DTS audio. If you choose This setting determines the digital signal format to be output from the DTS and you play a DTS disc, but your receiver or decoder doesn’t optical/coaxial digital audio output of the DVD10. -
Page 28: Playing Cds
Playing CDs Compatibility of Discs To Load and Play an Audio CD Before you load a disc, make sure that it is compatible with the player. Make sure that you have properly connected the DVD player 1. Press OPEN/CLOSE on the front of the DVD player or on the remote Note that the following discs CANNOT be used with this player. -
Page 29: Selecting A Track
Playing CDs Selecting a Track 4. To add marks, move the cursor (yellow frame) with the ARROW (DOWN) to the ”Mark” line (if not already there), then move the cur- 1. During disc playback, enter the track number directly with the NUM- sor to the next free frame with the ARROW (RIGHT). -
Page 30: Random Play
Playing CDs Using the Repeat Feature Random Play There are three Repeat options: 1. While a disc is playing, press RANDOM on the remote (the Random Display appears). Repeat Disc : Repeat the disc or program that is playing. Repeat Track : Repeat the Track that is playing. Repeat A-B : Set the beginning (point A) and the end (point B) to make this part of the CD play repeatedly. -
Page 31: Program Play
Playing CDs Program Play Insert Track Inserting Tracks is possible only if a track is already programmed. This will Program Edit change the order of playback. 1. In Stop mode, press PROGRAM on the remote (Program Edit Display 1. Press PROGRAM on the remote to insert Track (Program Edit Display appears). -
Page 32: Language Codes
Language Codes (for Audio Track and Subtitle Selection, see page 20-21) Don’t forget to press the ENTER on the remote after you enter the code. Language Code Language Code Language Code 6566 Hungarian 7285 Russian 8285 Abkhazian Afar 6565 Icelandic 7383 Samoan 8377... -
Page 33: Specifications
7 Kg All specifications subject to change without notice. Harman Kardon and Power for the digital revolution are trademarks of Harman Kardon, Inc. Manufactured under license from Dolby Laboratories. Dolby, AC-3, ProLogic and the double-D symbol are trademarks of Dolby Laboratories. - Page 34 250 Crossways Park Drive, Woodbury, New York 11797 www.harmankardon.com Harman Consumer International: 2, route de Tours, 72500 Château-du-Loir, France © 2000 Harman Kardon, Incorporated Part #0000-DVD10 OM...
