4. Ethernet
For an initial configuration made in a web browser, connect a PC by an Ethernet cable to
the default LAN interface, use the LAN1 port; see the figure above. By default, this interface
has the following configuration:
Connector Purpose
LAN1 LAN port (default)
Connect your PC to this port to get the
router web interface.
Configuration
1. Configuring the Device Using the Web Browser
You can use a web browser running on your PC to access the router web interface. Here
you can perform router monitoring, configuration, and administration. First, connect the PC to
the default LAN interface described in the Ethernet chapter. To get the router interface, enter
https://192.168.1.1
the
protocol for secure communication over the network is required.
By default, there is just the admin user account created on the router, having the initial
password set to "admin". Log in to the web interface by the admin user and his password.
See the configuration manual of the router for a detailed description and examples of the router
configuration.
2. Restoring and Backing up the Router Configuration
The default factory settings will replace the current configuration if you reset the router.
Therefore, we recommend you back up the router configuration before resetting the device.
Refer to the configuration manual for more information.
You can restore the default router configuration once the router boots up and the Status
LED starts blinking. To do so, press the Reset button on the router's front panel for more than
4 seconds. After you press this button, all settings reset to the default values, and the router
will reboot.
After logging on to the device for the first time, we strongly recommend changing the
default password due to security reasons.
For security reasons, we highly recommend updating the router's firmware to the latest
version regularly. Downgrading the firmware to an older version than the production
version or uploading firmware intended for a different device may cause the device's
malfunction.
QSG-0005-EN, November 14, 2024
address in a web browser. Please note that usage of the HTTPS
5
Start Guide
Default Setting
DHCP Server
IP Address: 192.168.1.1
NetMask: 255.255.255.0
