Page 1 HP70X Digital Portable Radio User Manual Hytera Communications Corporation Limited...
Page 2 Preface Welcome to the world of Hytera and thank you for purchasing this product. This manual includes a description of the functions and step-by-step procedures for use. To avoid bodily injury or property loss caused by incorrect operation, please carefully read the Safety Information Booklet before use.
Page 3: Copyright Information
Copyright Information Hytera is the trademark or registered trademark of Hytera Communications Corporation Limited (the Company) in the People's Republic of China (PRC) and/or other countries or areas. The Company retains the ownership of its trademarks and product names. All other trademarks and/or product names that may be used in this manual are properties of their respective owners.
Page 4: Compliance With Rf Exposure Standards
Operation is subject to the following two conditions:  This device may not cause harmful interference.  This device must accept any interference received, including interference that may cause undesired operation. Note: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
Page 5: Eu Regulatory Conformance
 Use of non-approved antennas, batteries, and accessories causes the radio to exceed the FCC RF exposure guidelines.  Contact your local dealer for the product's optional accessories. ISEDC Statement The device has been tested and complies with SAR limits, users can obtain Canadian information on RF exposure and compliance.
Page 6: Table Of Contents
User Manual Contents Contents Documentation Information ........................1 1. Packing List ............................2 2. Product Overview ..........................3 2.1 Product Layout........................... 3 2.2 Programmable Keys .......................... 4 3. Before Use ............................. 5 3.1 Charging the Battery .......................... 5 3.2 Installing the TF Card ........................5 3.3 Attaching the Belt Clip ........................
Page 7 Contents User Manual 7.4 Scan ..............................18 7.4.1 Conventional Mode ........................ 18 7.4.2 Trunking Mode ........................18 7.5 Positioning ............................19 7.5.1 Voice w/Location ........................20 7.5.2 GPS Report ........................... 20 7.6 BT ..............................20 7.6.1 Enabling the BT Feature ......................21 7.6.2 Connecting a BT Device ......................
Page 8: Documentation Information
User Manual Documentation Information Documentation Information This section describes the audience, conventions and revision history of this guide. Icon Conventions Icon Description Indicates references that can further describe the related topics. Indicates situations that could cause data loss or equipment damage. Indicates situations that could cause major personal injury or even death.
Page 9: Packing List
Packing List User Manual 1. Packing List Please unpack carefully and check that you have received the following items. If any item is missing or damaged, contact your dealer. Item Quantity (PCS) Item Quantity (PCS) Radio Antenna Battery Belt Clip Charger Strap Power Adapter...
Page 10: Product Overview
User Manual Product Overview 2. Product Overview 2.1 Product Layout Part Name Part Name On-Off Key Antenna Push-to-Talk (PTT) Key Microphone Side Key 1 (SK1) Battery Latch Side Key 1 (SK2) Strap Hole Top Key (TK) Accessory Connector Smart Knob Belt Clip...
Page 11: Programmable Keys
Product Overview User Manual Part Name Part Name OLED Display Battery Speaker Charging Contacts LED Indicator 2.2 Programmable Keys For enhanced convenience, you can request your dealer to program TK, SK1, and SK2 as shortcuts to radio features. For details, consult your dealer.
Page 12: Before Use
User Manual Before Use 3. Before Use 3.1 Charging the Battery  Use the approved charger to charge the battery.  Read the Safety Information Booklet before charging.  The remaining lithium-ion battery power is limited to 30% pursuant to the new lithium battery shipment regulation approved by the International Air Transport Association (IATA).
Page 13: Attaching The Belt Clip
Before Use User Manual 3.3 Attaching the Belt Clip Align the holder on the belt clip with the groove on the battery, and then press the belt clip downwards into place. You can press and hold the spring plate of the belt clip, and then push the belt clip upwards to remove it. 3.4 Attaching the Battery ...
Page 14: Attaching The Antenna
User Manual Before Use To remove the battery, make sure that the radio is turned off, and then lift the battery latch. 3.5 Attaching the Antenna Do not hold the radio by the antenna and swing it. This may affect the antenna performance and shorten the life span of the antenna.
Page 15 Before Use User Manual Loosen the screw on the accessory connector cover, and then remove the cover. Insert the audio accessory plug into the accessory connector. Tighten the screw on the audio accessory plug.
Page 16 User Manual Before Use...
Page 17: Basic Operations
Basic Operations User Manual 4. Basic Operations 4.1 Turning the Radio On or Off  To turn the radio on long press , or reattach the battery.  To turn the radio off, long press 4.2 Adjusting the Volume Rotate the Smart Knob clockwise to increase the volume, or counterclockwise to decrease the volume. 4.3 Switching the Operation Mode The radio can operate in conventional mode, or digital trunking mode (preprogrammed by your dealer).
Page 18: Trunking Mode
User Manual Basic Operations  Press the preprogrammed Preset Channel key. If the Voice Notify feature is enabled, the radio automatically announces the current channel upon power-on and channel change. 4.3.2 Trunking Mode In trunking mode, the radio automatically hunts for available base stations (BSs). During hunting, the LED indicator flashes orange.
Page 19: Status Indications
Status Indications User Manual 5. Status Indications 5.1 OLED Icons 5.1.1 Basic Status Icon Radio Status The radio detects no signal. The number of bars indicates the signal strength. In single BS mode, the number of bars indicates the signal strength. The radio is in emergency mode.
Page 20: Led Indications
User Manual Status Indications 5.2 LED Indications LED Indicator Radio Status Flashes green The radio is being turned on. Flashes green slowly The radio is standby in trunking mode. Glows green The radio is receiving. Glows red The radio is transmitting. The radio is establishing a call in trunking mode.
Page 21: Call Services
Call Services User Manual 6. Call Services When you are speaking during a call, keep the microphone about 2.5 cm to 5 cm away from your mouth. This ensures optimal voice quality on the receiving radio. In trunking mode, if the radio is not registered or attached, or an empty group is selected, you cannot initiate a call.
Page 22: Receiving A Call
User Manual Call Services key, and then press and hold the PTT key. Trunking Mode  On the home screen, press and then rotate the Smart Knob to select the contact, and then press the PTT key.  With the One Touch Call feature preprogrammed by your dealer, press the preprogrammed One Touch Call key.
Page 23: Call Without Signaling
Call Services User Manual 6.2.1 Call Without Signaling On an analog channel without signaling, you can initiate a call to all the other users on the channel. On the home screen, press and then rotate the Smart Knob to select the analog channel, and then press and hold the PTT key.
Page 24: Supplementary Features
User Manual Supplementary Features 7. Supplementary Features 7.1 Profiles Description The Profiles feature allows you to set the audio, alert tone, and vibration of the radio to suit your preference and work environments. The profiles include General, Meeting, Outdoor, Covert Mode, and custom mode. ...
Page 25: Noise Cancellation
Supplementary Features User Manual Option Description Operation option. When audio accessories are connected, the radio uses the External First external microphone and speaker. Otherwise, the radio uses the internal microphone and speaker. 7.2.2 Noise Cancellation The Noise Cancellation feature allows the radio to automatically eliminate ambient noise when receiving or transmitting voice.
Page 26: Positioning
User Manual Supplementary Features  Fixed Trunking Station Control Channel (Fixed TSCC) When the radio has unified frequency plans, it can use the Fixed TSCC.  Flexible Trunking Station Control Channel (Flexible TSCC). When the radio does not have unified frequency plans, it can use the Flexible TSCC. After being powered on, the radio automatically starts hunting.
Page 27: Voice W/Location
Supplementary Features User Manual This feature applies only to radios with GPS. 7.5.1 Voice w/Location The Voice w/Location feature allows the radio to report its location information to the dispatch station when initiating a private call, a group call, or an emergency call. This feature is preprogrammed by your dealer, and configured in either of the following ways: ...
Page 28: Enabling The Bt Feature
User Manual Supplementary Features The BT feature allows the radio to connect to a BT device for short-distance communication and data exchange. The BT feature applies only to radios with the BT module. 7.6.1 Enabling the BT Feature You can enable the BT feature in either of the following ways: ...
Page 29: Roam (Conventional Only)
Supplementary Features User Manual Mode Description Operation   Initiate a group, private, or all call. To initiate other services, press the  Send a quick text message or position preprogrammed One Touch Call key. message to a private or group contact. ...
Page 30: Priority Interrupt
User Manual Supplementary Features 7.12 Priority Interrupt The Priority Interrupt feature allows you to interrupt the ongoing activities (such as a call, a call hang status or remote monitor) on the current channel to release the channel, so as to initiate a new call or a new data service. This feature includes manual priority interrupt and auto priority interrupt.
Page 31: Initiating An Emergency Call
Supplementary Features User Manual In addition, you can request your dealer to set one of the following emergency modes: Emergency Mode Description Note If the emergency type is Call Only It allows you to initiate an emergency call. Siren Only or Alarm It allows you to send an emergency alarm and initiate an Alarm w/Call w/Siren, you do not need...
Page 32: Man Down
User Manual Supplementary Features  Switch the contact.  Turn off the radio. In conventional mode, with the Send Emergency Exit Message feature preprogrammed by your dealer, you can send an emergency exit message to the receiver when ending an emergency alarm or emergency call initiated by mistake.
Page 33: Stun, Revive, And Kill
Supplementary Features User Manual simultaneously with matching encryption key. The Encrypt key is preprogrammed by your dealer. 7.17 Stun, Revive, and Kill Conventional Mode You can send the Radio Disable command to a private contact to disable its radio. The disabled radio is incapable of any function except the remote monitor.
Page 34: Troubleshooting
User Manual Troubleshooting 8. Troubleshooting Phenomena Analysis Solution The battery may be installed improperly. Remove and reattach the battery. The battery power may have run out. Recharge or replace the battery. The radio cannot be turned The battery may suffer from poor contact caused by dirtied or damaged battery Clean the battery contacts.
Page 35 Troubleshooting User Manual Phenomena Analysis Solution cannot locate your so no position signal is received. again. position. The battery power of the BT device may be Recharge the BT device. low. The BT device cannot be paired. The BT device may be too far away from the Move the BT device towards the radio.
Page 36 User Manual Troubleshooting Phenomena Analysis Solution The radio may suffer from external Stay away from the equipment that may disturbance (such as electromagnetic cause interference. interference). If the above solutions cannot solve your problems, or you may have some other queries, please contact us or your local dealer for more technical support.
Page 37: Product Care
Product Care User Manual 9. Product Care 9.1 Radio If the radio is seriously wet inside, do not turn on it. Contact the dealer or maintenance center for maintenance in time. To guarantee optimum performance as well as a long service life of the radio, follow the tips below: ...
Page 38: Cleaning
User Manual Product Care  Use the approved charger to charge the battery.  Keep the radio turnned off during charging.  Do not use the radio during charging.  Charge the battery under the temperature from 0° C to 45° C . ...
Page 39: Sterilizing
Product Care User Manual 9.4 Sterilizing  Turn off the radio and remove the battery before sterilizing.  Ensure no external devices are connected to the radio.  Do not directly spray the alcohol on the radio.  Keep the radio away from the power supply and fire. ...
Page 40: Optional Accessories
User Manual Optional Accessories 10. Optional Accessories Use the accessories approved by the Company only. Otherwise, we will not be liable for any loss or damage arising out of the use of unauthorized accessories. Contact your local dealer for the optional accessories used with the product.
Page 41: Abbreviations
Abbreviations User Manual 11. Abbreviations Abbreviation Full Name Electronic Serial Number FOACSU Full Off Air Call Set-Up Global Positioning System Liquid-Crystal Display Light-Emitting Diode OACSU Off Air Call Set-Up Push-To-Talk Side Key TransFlash Top Key...
Page 42 Hytera Communications Corporation Limited. © 2021 Hytera Communications Corporation Limited. All Rights Reserved. Address: Hytera Tower, Hi-Tech Industrial Park North, 9108# Beihuan Road, Nanshan District, Shenzhen, People's Republic of China Postcode: 518057 https://www.hytera.com...
