- Page 1 HP71XEx Intrinsically Safe Digital Portable Radio User Manual Hytera Communications Corporation Limited...
- Page 2 Preface Welcome to the world of Hytera and thank you for purchasing this product. This manual includes a description of the functions and step-by-step procedures for use. To avoid bodily injury or property loss caused by incorrect operation, please carefully read the Safety Information Booklet before use.
-
Page 3: Copyright Information
Copyright Information Hytera is the trademark or registered trademark of Hytera Communications Corporation Limited (the Company) in the People's Republic of China (PRC) and/or other countries or areas. The Company retains the ownership of its trademarks and product names. All other trademarks and/or product names that may be used in this manual are properties of their respective owners. -
Page 4: Table Of Contents
User Manual Contents Contents Documentation Information ........................1 1. Intrinsically Safe Radio Information ...................... 2 1.1 Compliance Standards ......................... 2 1.2 Product Marking ........................... 2 1.2.1 IIC Product Marking ........................2 1.2.2 IIA Product Marking ........................3 1.3 Specific Conditions of Use ........................4 1.4 Connection with Other Intrinsically Safe Equipment Specific Conditions of Use ........ - Page 5 Contents User Manual 7.1.2 Answer a Call ........................... 26 7.1.3 End a Call ..........................26 7.2 Call on Analog Channel ........................26 7.2.1 Call Without Signaling ......................27 7.2.2 Call with Signaling ........................27 8. Supplementary Features ........................28 8.1 Profiles ..............................28 8.2 Audio Settings ............................
- Page 6 User Manual Contents 8.14.8 Emergency Erase Data ......................39 9. Troubleshooting ............................. 41 10. Product Care ............................44 10.1 Care ..............................44 10.2 Cleaning............................45 10.3 Sterilizing ............................46 10.4 Storing .............................. 46 11. Optional Accessories .......................... 47 12. Specifications ............................48 13.
-
Page 7: Documentation Information
User Manual Documentation Information Documentation Information Documentation Conventions Instruction Conventions Icon Description Indicates information that can help you make better use of your product. Indicates references that can further describe the related topics. Indicates situations that could cause data loss or equipment damage. Indicates situations that could cause minor personal injury. -
Page 8: Intrinsically Safe Radio Information
Intrinsically Safe Radio Information User Manual 1. Intrinsically Safe Radio Information Observe the following safety instructions when using the radio, so as to ensure safe and reliable operations. Failure to observe the instructions may result in danger or violation of applicable regulations. ... -
Page 9: Iia Product Marking
User Manual Intrinsically Safe Radio Information Certificate No. Marking Ex ib I Mb Ex ib IIC T4 Gb IECEx FMG 23.0016X Ex ib IIIC T120°C Db IP66/IP68, –25°C≤Ta≤+60°C I M2 Ex ib I Mb II 2G Ex ib IIC T4 Gb FM23ATEX0033X II 2D Ex ib IIIC T120°C Db IP66/IP68, –25°C≤Ta≤+60°C... -
Page 10: Specific Conditions Of Use
The radios shall only be used with optional adaptor, identified as Hytera Communications Co., Ltd. part number Model POA203P-Ex. The radios may also be used with the option Leather cases, identified as Hytera Communications Co., Ltd. part numbers LCY028 or LCY029. -
Page 11: Connection With Other Intrinsically Safe Equipment Specific Conditions Of Use
Pi ≥ 9.52 W. The connecting cable capacitance plus the Ci shall not exceed Co = 3.2 µF and the connecting cable inductance plus the Li shall not exceed 2.6 µH. 1.5 Warnings Warnings Substitution of components may impair Intrinsic Safety. Use only Hytera BL2105-Ex or BL1430-Ex battery. -
Page 12: Caution
Ne pas charger la batterie dans un endroit dangereux. Réparation uniquement par Hytera ou un centre de service agréé par Hytera. Pour éviter l'inflammation d'atmosphères inflammables ou combustibles, lisez, comprenez et respectez les procédures d'entretien en direct du fabricant, sauf s'il n'existe pas de procédures d'entretien. -
Page 13: Maintenance
Contact number: Tel: +86-755-2697299 Fax: +86-755-86137139 Contact Address: Hytera Communications Co., Ltd. Hytera Tower, Hi-Tech Industrial Park North, 9108# Beihuan Road, Nanshan District, Shenzhen, P.R.C., P 518057 1.9 Training Instructions Contact Person: Hytera Customer Training Center Contact number: Tel: +86-755-2697299 Fax: +86-755-86137139 Contact Address: Hytera Communications Co., Ltd. - Page 14 Intrinsically Safe Radio Information User Manual Ignition Source An element, which can cause a fire or explosion. Open flames, sparks, static electricity and hot surfaces are all possible ignition sources. Flammable substance Substance, which is itself flammable, or is capable of producing a flammable gas, vapor, or dust. ...
- Page 15 User Manual Intrinsically Safe Radio Information Zone 0: An area in which an explosive gas atmosphere is present continuously or for long periods or frequently. Zone 1: An area in which an explosive gas atmosphere is likely to occur periodically or occasionally in normal operation.
- Page 16 Intrinsically Safe Radio Information User Manual Temperature Class Maximum Surface Temperature ≤ 200°C ≤ 135°C ≤ 100°C ≤ 85°C...
-
Page 17: Packing List
User Manual Packing List 2. Packing List Please unpack carefully and check that you have received the following items. If any item is missing or damaged, contact your dealer. Item Quantity (PCS) Item Quantity (PCS) Radio Antenna Battery Belt Clip Charger Strap Power Adapter... -
Page 18: Product Overview
Product Overview User Manual 3. Product Overview 3.1 Product Layout Part Name Part Name Part Name On-Off Key Microphone Antenna Push-to-Talk (PTT) Key LCD Display Accessory Connector Side Key 1 (SK1) Speaker Battery Latch Side Key 2 (SK2) Strap Hole Battery NFC Tag Top Key (TK) -
Page 19: Programmable Keys
User Manual Product Overview 3.2 Programmable Keys For enhanced convenience, you can ask your dealer to program the following keys as shortcuts to radio features: TK, SK1, and SK2. For details, consult your dealer. -
Page 20: Before Use
Before Use User Manual 4. Before Use 4.1 Attach the Battery Make sure the grooves on the battery are aligned with the guiderails on the sides of battery compartment, otherwise the guiderails may deform. Use the approved battery to avoid the risk of explosion. ... -
Page 21: Charge The Battery
User Manual Before Use To remove the battery, make sure that the radio is turned off, and then lift the battery latch. During battery removal, slide the battery along the guiderails until the battery can no longer be moved, and then remove the battery. -
Page 22: Attach The Antenna
Before Use User Manual You can learn about the charging status through the LED indicator on the charger. LED Indicator Charging Status Glows red The battery is being charged. Glows green The battery is fully charged. Flashes red slowly No battery is inserted to the charger. Flashes red rapidly The battery fails to be charged. -
Page 23: Optional) Attach The Audio Accessory
User Manual Before Use 4.4 (Optional) Attach the Audio Accessory If you purchase an audio accessory from the Company, you can attach it to the radio. Keep the accessory connector cover properly after removing the cover. Place the accessory connector cover back and fasten the screw after removing the accessory. ... -
Page 24: Attach The Belt Clip
Before Use User Manual 4.5 Attach the Belt Clip Align the holder on the belt clip with the groove on the battery, and then press the belt clip downwards into place. To remove the belt clip, press and hold the spring plate of the belt clip and push the belt clip upwards. -
Page 25: Optional) Install The Tf Card
User Manual Before Use 4.6 (Optional) Install the TF Card If you purchase a TF card, you can install it on the radio. Use a screwdriver to loosen the screw on the card slot cover, and then remove the card slot cover. Install the TF card, put the card slot cover back in place, and then tighten the screw. -
Page 26: Basic Operations
Basic Operations User Manual 5. Basic Operations 5.1 Turn On or Off the Radio To turn on the radio, long press or reattach the battery. To turn off the radio, long press 5.2 Adjust the Volume Rotate the Smart Knob clockwise to increase the volume, or counter-clockwise to decrease the volume. 5.3 Switch the Operation Mode The radio can operate in conventional mode or digital trunking mode (preprogrammed by your dealer). -
Page 27: Trunking Mode
User Manual Basic Operations Press the preprogrammed Preset Channel key. If the Voice Notify feature is turned on, the radio automatically announces the current channel upon power- on and channel change. 5.3.2 Trunking Mode In trunking mode, the radio automatically hunts for available base station (BS). During hunting, the LCD displays "Hunting...". -
Page 28: Status Indications
Status Indications User Manual 6. Status Indications 6.1 LCD Icon Icon Status More bars indicate more remaining battery power. The radio is being charged. The battery power is running out. The battery power runs out. Conventional mode: The radio is standby or transmitting. ... - Page 29 User Manual Status Indications Icon Status The Over the Air Encryption feature is turned on. The Mode Auto Switch feature is turned on. The radio is scanning or hunting. The radio stays on an active channel. The radio stays on Priority Channel 1. The radio stays on Priority Channel 2.
-
Page 30: Led Indicator
Status Indications User Manual Icon Status The radio operates in covert mode. The battery is overheating. 6.2 LED Indicator LED Indicator Radio Status Flashes green The radio is being turned on. Flashes green slowly The radio is standby in trunking mode. Glows green The radio is receiving. -
Page 31: Call Services
User Manual Call Services 7. Call Services When you are speaking during a call, keep the microphone about 2.5 cm to 5 cm away from your mouth. This ensures optimal voice quality on the receiving radio. In trunking mode, if the radio is not registered or attached, or an empty group is selected, you will fail to initiate a call. -
Page 32: Answer A Call
Call Services User Manual Trunking Mode On the home screen, press and then rotate the Smart Knob to select the contact, and then press the PTT key. With the One Touch Call feature preprogrammed by your dealer, press the preprogrammed One Touch Call key. 7.1.2 Answer a Call Answer a Group/Broadcast/All Call You can answer a group call, broadcast call, or all call without any operation. -
Page 33: Call Without Signaling
User Manual Call Services 7.2.1 Call Without Signaling On an analog channel without signaling, you can initiate a call to all the other users on the channel. On the home screen, press and then rotate the Smart Knob to select the channel, and then press and hold the PTT key. -
Page 34: Supplementary Features
Supplementary Features User Manual 8. Supplementary Features 8.1 Profiles The Profiles feature allows you to set the audio, alert tone, and vibration of the radio to suit your preference and work environments. The profiles include: General: applicable to the low-noise environment, such as a quiet street. ... -
Page 35: Noise Cancellation
User Manual Supplementary Features When audio accessories are connected, the radio uses the External First external microphone and speaker. Otherwise, the radio uses the internal microphone and speaker. 8.2.2 Noise Cancellation The Noise Cancellation feature allows the radio to automatically eliminate ambient noise when receiving or transmitting voice. -
Page 36: Trunking Mode
Supplementary Features User Manual 8.5.2 Trunking Mode Pre-registration Hunt Before registering, the radio hunts through the control channels for available BS. Two hunting plans are adoptable: Fixed Trunking Station Control Channel (Fixed TSCC) (programmed by your dealer) When the radio has unified frequency plans, it can use the Fixed TSCC. ... -
Page 37: Positioning
User Manual Supplementary Features This feature allows the radio in idle to check the signal strength This feature is turned on by Vote Now of the BS assigned in a broadcast call, and decide whether to default. register with the BS. 8.6 Positioning The Positioning feature allows the radio to collect its location information through GPS. -
Page 38: Quick Gnss
Supplementary Features User Manual If the radio is turned on with the GNSS Report in Voice feature, the radio will report the location information during a call. 8.6.3 Quick GNSS The Quick GNSS feature improves channel utilization and efficiency of data transmission. With this feature turned on, the system divides the report interval into different time slices with the same time length. -
Page 39: Switch The Bt Audio Output
User Manual Supplementary Features On the radio, press the preprogrammed BT Pairing key. The radio searches for and connects to the BT device. After successful connection, the radio displays , and the LED indicator of the radio flashes blue every 1.5 seconds. You can also ask your dealer to configure connectivity between the radio and the BT device. -
Page 40: Roam
Supplementary Features User Manual 8.9 Roam 8.9.1 Conventional Mode In conventional mode, the Roam feature allows you to enjoy seamless communication across sites. With the Roam feature preprogrammed by your dealer, press the preprogrammed Roam key 8.9.2 Trunking Mode The Roam feature allows the radio to be registered with a non-home BS or network when the radio is on move. When the radio detects signal, it initiates the registration. -
Page 41: Security
User Manual Supplementary Features Auto Priority Interrupt Auto Priority Interrupt Triggered When You… Emergency Priority Interrupt Initiate an emergency call. Call Back Priority Interrupt Press and hold the PTT key to call back. Message Priority Interrupt Send a message. Radio Disable Priority Interrupt Send the Radio Disable command. -
Page 42: Man Down
Supplementary Features User Manual It allows you to send an emergency alarm and initiate an If the emergency type is Alarm w/Call emergency call. Siren Only or Alarm w/Siren, you do not need to set the emergency Alarm It allows you to send an emergency alarm. mode. -
Page 43: Lone Worker
User Manual Supplementary Features 8.14.3 Lone Worker The Lone Worker feature allows the radio to automatically send an emergency alarm to your companion or the control center in either of the following scenarios: You do not operate the radio within the preset time. ... - Page 44 Supplementary Features User Manual Stop Call Recording You can stop call recording in either of the following ways: Manually: Press the preprogrammed Call Recording key again. Automatically: The radio will automatically stop recording when: A higher priority service interrupts the ongoing call. ...
-
Page 45: Stun, Revive, And Kill
User Manual Supplementary Features Name Description Naming Rule Trunking mode: real-time clock when the call is recorded. zz: represents the sequence number for split recordings. With the Automatic Recording Deletion feature preprogrammed by your dealer, the radio automatically deletes the earliest recording files when the TF card reaches its storage capacity. - Page 46 Supplementary Features User Manual When the radio is killed, the data in the radio will be erased automatically.
-
Page 47: Troubleshooting
User Manual Troubleshooting 9. Troubleshooting Phenomena Analysis Solution battery installed Remove and reattach the battery. improperly. The radio cannot be The battery power may have run out. Recharge or replace the battery. turned on. The battery may suffer from poor Clean the battery contacts. - Page 48 Troubleshooting User Manual Change the frequency, or adjust the squelch You may be interrupted by radios There are unknown using the same frequency. level. voices or sounds on The radio may be set with no Set signaling for all member radios to avoid the channel.
- Page 49 User Manual Troubleshooting You may be too far away from the Move close to other members. group members. Make sure call participants are within the The signal may be weak. communication range. Make sure call participants are within the The signal may be weak. communication range.
-
Page 50: Product Care
Product Care User Manual 10. Product Care 10.1 Care Radio Do not care or clean the radio in a hazardous area. If the product comes in contact with liquid, do not turn it on. Contact your local dealer or service center in time. -
Page 51: Cleaning
User Manual Product Care Battery To ensure optimal performance and maximize battery life and lifespan, follow these instructions: Only use the charger approved by the Company to charge the battery. Keep the product turned off during charging. Do not use the product during charging. -
Page 52: Sterilizing
Product Care User Manual To clean the battery slot, use the non-mental brush to remove the dust or dirt, and then use the dry and soft lint-free cloth to clean up the battery contacts. 10.3 Sterilizing Before sterilizing, turn off the product, remove the battery, and disconnect the cable, antenna, and accessory. ... -
Page 53: Optional Accessories
User Manual Optional Accessories 11. Optional Accessories Use the accessories approved by the Company only. Otherwise, we will not be liable for any loss or damage arising out of the use of unauthorized accessories. Contact your local dealer for the optional accessories used with the product. -
Page 54: Specifications
7.4 V DC Analog: 0.16 μV (12 dB SINAD); 0.14 μV (Typical) (12 dB SINAD) Sensitivity Digital: 0.16 μV/BER5% HP71XEx IIA: 136–174 MHz: 5 W/1 W 330–400 MHz: 4 W/1 W 350–400 MHz: 4 W/1 W ... - Page 55 User Manual Specifications Item Description Ex Battery BL2105-Ex (2,150 mAh) Battery Life (5-5-90 duty HP71XEx IIA: 22 h cycle, with Location turned HP71XEx IIC: 24 h off) All specifications are subject to changes without notice.
-
Page 56: Abbreviations
Abbreviations User Manual 13. Abbreviations Abbreviation Full Name Automatic Gain Control DTMF Dual-tone Multi-frequency Electronic Serial Number FOACSU Full Off Air Call Set-Up Global Positioning System Liquid-Crystal Display Light-Emitting Diode OACSU Off Air Call Set-Up PABX Private Automatic Branch Exchange PSTN Public Switched Telephone Network Push-To-Talk... - Page 57 Hytera Communications Corporation Limited. © 2024 Hytera Communications Corporation Limited. All Rights Reserved. Address: Hytera Tower, Hi-Tech Industrial Park North, 9108# Beihuan Road, Nanshan District, Shenzhen, People's Republic of China Postcode: 518057 https://www.hytera.com...
