HP56X Intrinsically Safe Digital
Portable Radio
User Manual
Hytera Communications Corporation Limited

Advertisement

loading
Need help?

Need help?

Do you have a question about the HP56X and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hytera HP56X

Summary of Contents for Hytera HP56X

  • Page 1 HP56X Intrinsically Safe Digital Portable Radio User Manual Hytera Communications Corporation Limited...
  • Page 2 Preface Welcome to the world of Hytera and thank you for purchasing this product. This manual includes a description of the functions and step-by-step procedures for use. To avoid bodily injury or property loss caused by incorrect operation, please carefully read the Safety Information Booklet before use.
  • Page 3 Copyright Information Hytera is the trademark or registered trademark of Hytera Communications Corporation Limited (the Company) in the People's Republic of China (PRC) and/or other countries or areas. The Company retains the ownership of its trademarks and product names. All other trademarks and/or product names that may be used in this manual are properties of their respective owners.
  • Page 4 Operation is subject to the following two conditions: This device may not cause harmful interference.  This device must accept any interference received, including interference that may cause undesired operation.  Note: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
  • Page 5 Use of non-approved antennas, batteries, and accessories causes the radio to exceed the FCC RF exposure  guidelines. Contact your local dealer for the product's optional accessories.  ISEDC Statement The device has been tested and complies with SAR limits, users can obtain Canadian information on RF exposure and compliance.
  • Page 6 American National Standards Institute (ANSI)/Institute of Electrical and Electronic Engineers (IEEE) C95. 1-  1992; Institute of Electrical and Electronic Engineers (IEEE) C95.1-1999;  International Commission on Non-Ionizing Radiation Protection (ICNIRP) 1998.  FCC Regulations Federal Communication Commission (FCC) requires that all radio communication products should meet the requirements set forth in the above standards before they can be marketed in the U.S, and the manufacturer shall post a RF label on the product to inform users of operational instructions, so as to enhance their occupational health against exposure to RF energy.
  • Page 7 No Misoperations Stop operating this product and leave the explosive atmosphere immediately when the safety or integrity of the product is endangered, and deliver it to your local dealer for examination. These items may endanger the product's safety or integrity: The radio is stored improperly;...
  • Page 8 Improper usage of the product other than it is intended to be used for will impair safety of the product, yourself  and surrounding environment.
  • Page 9 Renseignements l’homologation endroits dangereux Normes de conformité UL 913, 5th Ed. February 21, 1997  CAN/CSA C22.2 No. 157-92 (R2016) +Upd1 +Upd2  ANSI/TIA-4950-A, Rev. May 13, 2014  UL 121201, 9th Ed., Rev. September 15, 2017  CAN/CSA C22.2 No.213, 3rd Ed. April 2021 ...
  • Page 10 mortels, assurez-vous de suivre les instructions de sécurité suivantes: N’utilisez que la batterie Ex BL2301-Ex spécifiée par l’Entreprise. L’utilisation d’autres batteries peut entraîner  une défaillance de la protection Ex (sûreté intrinsèque). Chargez uniquement la batterie dans une zone ne présentant aucun risque, à l’aide du chargeur prévu à cet effet. ...
  • Page 11 User Manual Contents Contents Documentation Information ........................1 1. Packing List .............................. 2 2. Product Overview ............................. 3 2.1 Product Layout ............................. 3 2.2 Model Description ..........................4 3. Before Use ..............................5 3.1 Charge the Battery ..........................5 3.2 Install the Antenna ..........................6 3.3 Attach the Belt Clip ..........................
  • Page 12 Contents User Manual 8. Contacts ..............................18 9. Settings ..............................19 9.1 Basic Settings ............................. 19 9.1.1 Set the Display ......................... 19 9.1.2 Set the Keypad Lock ........................ 19 9.1.3 Set the Date and Time ......................20 9.1.4 Set MIC & SPK ......................... 20 9.1.5 Set the USB Path ........................
  • Page 13 User Manual Contents 11.3.3 Set BT ............................. 28 11.4 One Touch Call/Menu ........................29 11.5 Roam ..............................29 11.6 Priority Interrupt ..........................30 11.7 Emergency Services ........................30 11.7.1 Initiate an Emergency Call ..................... 31 11.7.2 Answer an Emergency Call ....................31 11.7.3 End an Emergency Call ......................
  • Page 14 User Manual Documentation Information Documentation Information This section describes the conventions of this document. Documentation Conventions Instruction Conventions Icon Description Indicates information that can help you make better use of your product. Indicates references that can further describe the related topics. Indicates situations that could cause data loss or equipment damage.
  • Page 15 Packing List User Manual 1. Packing List Unpack carefully and check that you have received the following items. If any item is missing or damaged, contact your dealer. Item Quantity (PCS) Item Quantity (PCS) Radio Antenna Battery Belt Clip Charger Strap Power Adapter Documentation Kit...
  • Page 16 User Manual Product Overview 2. Product Overview 2.1 Product Layout Part Name Part Name Part Name Push-to-Talk (PTT) Key P1 Key* Up Key* Side Key 1 (SK1)* Down Key* Battery Latch Side Key 2 (SK2)* P2 Key* Strap Hole Channel Selector Knob LED Indicator Accessory Connector On-Off/Volume Knob...
  • Page 17 The asterisk symbol (*) indicates the programmable key. To assign features to programmable keys, contact your dealer. 2.2 Model Description HP 56X XX ① ② ③ Description HP indicates Hytera portable radio. ① 56X indicates the products series. ② XX indicates the frequency range such as UHF 1, or VHF. ③...
  • Page 18 User Manual Before Use 3. Before Use 3.1 Charge the Battery  Do not charge the radio in hazardous area.  Read the Safety Information Booklet before charging.  The remaining lithium-ion battery power is limited to 30% pursuant to the new lithium battery shipment regulation approved by the International Air Transport Association (IATA).
  • Page 19 Before Use User Manual 3.2 Install the Antenna  Do not install or remove the antenna in hazardous area.  Do not hold the radio by the antenna and swing it. This may affect the antenna performance and shorten the life span of the antenna.
  • Page 20 User Manual Before Use 3.4 Attach the Battery  Do not attach or remove the battery in hazardous area.  Use the approved battery to avoid the risk of explosion.  Dispose of the used battery according to "Precautions for Disposal" in the Safety Information Booklet. Aligh the battery with the battery slot.
  • Page 21 Before Use User Manual Insert the audio accessory plug into the accessory connector. Rotate the screw clockwise until hand tight.
  • Page 22 User Manual Basic Operations 4. Basic Operations 4.1 Turn On or Off the Radio 4.2 Adjust the Volume 4.3 Select a Zone Through the Programmable Key Press the preprogrammed Zone Up or Zone Down key. Through the Menu On the home screen, press the Back key. Press the Up or Down key to select a zone, and then press the OK/Menu key.
  • Page 23 Basic Operations User Manual 4.4 Select a Channel You can rotate the knob or press keys to switch to a channel within the same zone by default. If Cross-Zone Switchover is turned on, you can switch to a channel in other zones. Through the Knob or Programmable Key Rotate the Channel Selector knob.
  • Page 24 User Manual Status Indications 5. Status Indications 5.1 LCD Icons Icon Radio Status More bars indicate more remaining battery power. The battery is low. The radio detects no signal. More bars indicate stronger signal. The radio operates in low power mode. The radio operates in high power mode.
  • Page 25 Status Indications User Manual Icon Radio Status The speaker is on. The radio operates in silent mode. 5.2 LED Indicator LED Indicator Radio Status Flashes green The radio is being turned on. Glows green The radio is receiving. Glows red The radio is transmitting.
  • Page 26 User Manual Call Services 6. Call Services To ensure optimal voice quality on the receiving radio, keep the microphone 2.5 cm to 5 cm away from your mouth during speaking. 6.1 Group Call A group call is a call from an individual user to other group members. 6.1.1 Initiate a Group Call Through the Preset Contact Select a digital channel with a preset group contact according to...
  • Page 27 Call Services User Manual 6.2.1 Initiate a Private Call Through the Preset Contact Select a digital channel with a preset private contact according to 4.4 Select a Channel. Press and hold the PTT key. Through the Menu Enter the Contact interface. Press the preprogrammed Contact List key.
  • Page 28 User Manual Call Services 6.3.1 Initiate an All Call Through the Preset Contact Select a digital channel with a preset all call contact according to 4.4 Select a Channel. Press and hold the PTT key. Through the Menu Enter the Contact interface. Press the preprogrammed Contact List key.
  • Page 29 Call Services User Manual Through the One Touch Call key  Press the preprogrammed One Touch Call key.
  • Page 30 User Manual Message Services 7. Message Services Message allows you to send and receive text messages. 7.1 View a Message New message  When you receive the message, press the OK/Menu key. Messages in the inbox  On the home screen, go to Menu > Message. Select a message, and then press the OK/Menu key.
  • Page 31 Contacts User Manual 8. Contacts To view contact information, do the following: Enter the Contact interface. On the home screen, go to Menu > Contact. Press the preprogrammed Contact List key. Select a contact. Press the OK/Menu key.
  • Page 32 User Manual Settings 9. Settings You can set radio parameters including Basic Settings, Call Settings, and Security Settings. 9.1 Basic Settings 9.1.1 Set the Display On the home screen, go to Menu > Settings > Basic Settings > Display, and then set any of the following: Backlight ...
  • Page 33 Settings User Manual  To preprogram Keypad Lock, contact your dealer.  It is recommended that you ask the dealer to assign the keypad lock feature to a programmable key so you can lock and unlock the keypad with the key. Select Locked Keys On the home screen, go to Menu >...
  • Page 34 User Manual Settings Option Description Operation Press the preprogrammed Mic Set  The radio uses only the microphone of the audio Only External Switch key to switch the audio path. accessory, such as earpieces. When the radio is connected to an audio accessory, radio uses...
  • Page 35 Settings User Manual 9.1.6 Set Language On the home screen, go to Menu > Settings > Basic Settings > Language. Press the Up or Down key to select the display language. Press the OK/Menu key. 9.2 Call Settings 9.2.1 Power Level You can set the TX power level to high or low.
  • Page 36 User Manual Settings Press the preprogrammed Encrypt key.   If you turn on this feature, the radio will encrypt the voice and data on the current channel. Whenever you switch to the current channel, the radio automatically turns on the Encrypt feature. ...
  • Page 37 Profiles User Manual 10. Profiles Profiles allows you to set the audio and alert tone of the radio for clear voice in various scenarios. The radio supports the following profiles: General: applies to the low-noise environment, such as a quiet street. ...
  • Page 38 User Manual Profiles 10.2.3 Set Audio Mode Audio Mode adds gain to audio signals at high, medium, and low frequency, thus optimizing the audio quality. On the home screen, go to Menu > Profiles > Setting > Audio Set > Audio Mode. Select an audio mode.
  • Page 39 Radio Features User Manual 11. Radio Features To preprogram or turn on features in this chapter, contact your dealer. 11.1 Scan Scan allows you to listen to activities on other channels, keeping track of your team members 11.1.1 Turn on Scan On the home screen, go to Menu >...
  • Page 40 User Manual Radio Features 11.2 Positioning Positioning allows you to collect the position information of the radio through satellites. Positioning applies only to radios with GPS, BDS, or GLONASS. 11.2.1 Turn on Positioning On the home screen, go to Menu > Position > GPS On/Off Press the OK/Menu key.
  • Page 41 Radio Features User Manual  To derive optimal communication quality, it is recommended that you use the BT devices approved by the Company.  If BT earpieces of other companies are used, you must use them with the wireless ring PTT of the Company. Otherwise, the earpieces cannot transmit voice.
  • Page 42 User Manual Radio Features To view the BT information, select Device Information, and then press the OK/Menu key.  11.4 One Touch Call/Menu One Touch Call/Menu allows you to initiate a preset service or switch to the function menu by pressing the preprogrammed One Touch Call/Menu key.
  • Page 43 Radio Features User Manual To add a new channel to the list, select Add CH, and then press the OK/Menu key.  11.6 Priority Interrupt Priority Interrupt allows you to interrupt the ongoing activities (such as a call, a call hang status or remote monitor) on the current channel to release it.
  • Page 44 User Manual Radio Features Emergency Type Description The radio transmits the emergency signal to the control center, and then emits siren and Alarm w/ Siren displays In addition, you can request your dealer to set one of the following emergency modes: Emergency Mode Description Note...
  • Page 45 Radio Features User Manual You can send a Radio Disable command to remotely disable a radio. Once disabled, this radio becomes inoperable but can still be monitored remotely. Radio Enable  You can enable the disabled radio again to resume normal operation by either of the following methods: Send a Radio Enable command to the radio.
  • Page 46 User Manual Troubleshooting 12. Troubleshooting Phenomena Analysis Solution The battery may be installed improperly. Remove and reattach the battery. The radio cannot be The battery power may have run out. Recharge or replace the battery. turned on. The battery may suffer from poor contact Clean the battery contacts.
  • Page 47 Troubleshooting User Manual The speaker may be blocked or damaged. Clean the surface of the speaker. The frequency or signaling type may be Set your TX/RX frequency and signaling inconsistent with that of other members. to the same as that of other members. The channel type (digital/analog) may be set Make sure all members are on the same The radio fails to...
  • Page 48 User Manual Product Care 13. Product Care 13.1 Radio If the product comes in contact with liquid, do not turn it on. Contact your local dealer or service center in time. To ensure optimal performance and maximize product lifespan, follow these instructions: Do not disassemble the product.
  • Page 49 Product Care User Manual Do not use the product during charging.  Charge the battery at the temperature from 0°C to 45°C .  When the low battery alert appears, replace or charge the battery in time.  When the battery is fully charged, disconnect the charger in time. ...
  • Page 50 User Manual Product Care 13.4 Sterilizing  Before sterilizing, turn off the product, remove the battery, and disconnect the cable, antenna, and accessory.  Do not directly spray the alcohol on the product.  Keep the product away from the power supply and fire source. ...
  • Page 51 Optional Accessories User Manual 14. Optional Accessories Use the accessories approved by the Company only. Otherwise, we will not be liable for any loss or damage arising out of the use of unauthorized accessories. Contact your local dealer for the optional accessories used with the product.
  • Page 52 User Manual Specifications 15. Specifications Item Description  136–174 MHz Frequency Range  400–470 MHz Channel Capacity Channel Spacing 12.5 kHz/20 kHz/25 kHz Operating Voltage 7.4 V DC Class I, Division 1, Groups C-D, T4;  Class II, Class III, Division 1, Groups E-G, T135°C; ...
  • Page 53 Specifications User Manual All specifications are subject to changes without notice.
  • Page 54 User Manual Abbreviations 16. Abbreviations Abbreviation Full Name Global Positioning System Liquid-Crystal Display Light-Emitting Diode Push-To-Talk Serial Number Side Key...
  • Page 55 Hytera Communications Corporation Limited. © 2024 Hytera Communications Corporation Limited. All Rights Reserved. Address: Hytera Tower, Hi-Tech Industrial Park North, 9108# Beihuan Road, Nanshan District, Shenzhen, People's Republic of China Postcode: 518057 https://www.hytera.com...
