Hytera HP79XEx Quick Reference Manual

HP79XEx Intrinsically Safe Digital Portable Radio
Intrinsically Safe Radio Information
Caution:
● Observe the following safety instructions when
using the radio, so as to ensure safe and reliable
operations. Failure to observe the instructions
may result in danger or violation of applicable
regulations.
● To avoid possible interference with blasting
operations, keep the radio turned off when you are
near electrical blasting caps, in a blasting area, or
in areas posted "Turn off two-way radios". Obey all
signs and instructions.
Compliance Standards
This radio complies with the following standards:
Standard Edition
IECEx (International)
IEC 60079-0 Edition 7.0
IEC 60079-11 Edition 6.0
ATEX (EU)
EN 60079-0 Edition 7.0
EN 60079-11 Edition 6.0
NEC (US)
ANSI/UL 60079-0 Edition 7.0
ANSI/UL 60079-11 Edition 6.2
CEC (CA)
Quick Reference Guide
Standard
CAN/CSA C22.2 No.
60079-0
CAN/CSA C22.2 No.
60079-11
Product Marking
IIC Product Marking
The explosion-proof certification and rating of the radio are
displayed in the following table:
Certificate No.
IECEx FMG
23.0016X
Issue Date
2017
FM23ATEX0033X
2011
2018
2012
FM23UKEX0036X
2019
2018
FM23US0069X
Edition Issue Date
Edition 4.0 2019
Edition 6.0 2011
Marking
Ex ib I Mb
Ex ib IIC T4 Gb
Ex ib IIIC T120°C Db
IP66/IP68, –25°C≤Ta≤+60°C
I M2 Ex ib I Mb
II 2G Ex ib IIC T4 Gb
II 2D Ex ib IIIC T120°C Db
IP66/IP68, –25°C≤Ta≤+60°C
I M2 Ex ib I Mb
II 2G Ex ib IIC T4 Gb
II 2D Ex ib IIIC T120°C Db
IP66/IP68, –25°C≤Ta≤+60°C
Class I, Zone 1, AEx ib IIC T4 Gb
Zone 21, AEx ib IIIC T120°C Db
IP66/IP68, –25°C≤Ta≤+60°C
1
Certificate No. Marking
Ex ib IIC T4 Gb
FM23CA0051X Ex ib IIIC T158°C Db
IP66/IP68, –25°C≤Ta≤+60°C
IIA Product Marking
The explosion-proof certification and rating of the radio are
displayed in the following table:
Certificate No. Marking
Ex ib I Mb
IECEx FMG Ex ib IIC T4 Gb
23.0016X Ex ib IIIC T120°C Db
IP66/IP68, –25°C≤Ta≤+50°C
I M2 Ex ib I Mb
II 2G Ex ib IIC T4 Gb
FM23ATEX0033X
II 2D Ex ib IIIC T120°C Db
IP66/IP68, –25°C≤Ta≤+50°C
I M2 Ex ib I Mb
II 2G Ex ib IIC T4 Gb
FM23UKEX0036X
II 2D Ex ib IIIC T120°C Db
IP66/IP68, –25°C≤Ta≤+50°C
Class I, Zone 1, AEx ib IIC T4 Gb
FM23US0069X Zone 21, AEx ib IIIC T120°C Db
IP66/IP68, –25°C≤Ta≤+50°C
Ex ib IIC T4 Gb
FM23CA0051X Ex ib IIIC T158°C Db
IP66/IP68, –25°C≤Ta≤+50°C
