  • Page 1 EN User Manual | Washing Machine EFI611W84W...

  • Page 2: Table Of Contents

    Welcome to Electrolux! Thank you for choosing our appliance. Get usage advice, brochures, trouble shooter, service and repair information: www.electrolux.com/support Subject to change without notice. CONTENTS 1. SAFETY INFORMATION................2 2. SAFETY INSTRUCTIONS................4 3. PRODUCT DESCRIPTION................6 4. TECHNICAL DATA..................7 5.

  • Page 3: General Safety

    the use of the appliance in a safe way and understand the hazards involved. • Children between 3 and 8 years of age and persons with very extensive and complex disabilities shall be kept away from the appliance unless continuously supervised. •...

  • Page 4: Safety Instructions

    • The ventilation opening in the base must not be covered by a carpet, mat, or any floor covering. • The appliance must be connected to the water mains using the new supplied hose sets, or other new hose sets supplied by the Authorised Service Centre.

  • Page 5: Water Connection

    2.4 Use • Always use a correctly installed shockproof socket. • Make sure that the parameters on the WARNING! rating plate are compatible with the Risk of injury, electric shock, fire, burns electrical ratings of the mains power or damage to the appliance. supply.

  • Page 6: Product Description

    repairers, and that not all spare parts are • Disconnect the appliance from the mains relevant for all models. electrical and water supplies. • Concerning the lamp(s) inside this product • Cut off the mains electrical cable close to and spare part lamps sold separately: the appliance and dispose of it.

  • Page 7: Technical Data

    Scan the QR code on the appliance to register your product and get the most out of it. • - Access your appliance details, documentation and articles on how to use the best features (User Manual also available at electrolux.com/manuals ) • - Get usage advice, troubleshooting, service and repair information (also available at electrolux.com/support )

  • Page 8: Information For Installation

    5.1 Unpacking WARNING! 1. Open the door. Remove all the items from It is possible to see water flowing the drum. from the drain hose. This is because the washing machine has been tested at the factory. 4. Remove the three transit bolts and pull out the plastic spacers.
  • Page 9 WARNING! Do not put cardboard, wood or equivalent materials below the appliance feet to adjust the level. 3/4” The inlet hose CAUTION! Make sure there is no damage to hoses 3/4” and there are no leaks from the couplings. Do not use an extension hose if the inlet hose is too short.

  • Page 10: Electrical Connection

    Make sure that the plastic guide cannot The end of the drain hose must always move when the appliance drains and the be ventilated , i.e. the inner diameter of drain hose end is not immersed in the the drain pipe (min. 38 mm - min. 1.5") water.

  • Page 11: Accessories

    6.4 Available in www.electrolux.com/shop or from authorised dealer Only appropriate accessories approved by ELECTROLUX ensure the safety standards of the appliance. If unapproved parts are used, any claims will be invalidated. 7. CONTROL PANEL 7.1 Special features...

  • Page 12: Control Panel Description

    programme duration in 30 seconds. The than necessary. Read the paragraph "The washing programme is tailored to the SensiCare load detection " for more laundry load and the type of fabric without details. consuming more time, energy and water 7.2 Control panel description Programme dial Temp.

  • Page 13: Multilingual Badges

    7.4 Multilingual badges Adhesive badges in different languages are supplied with the appliance. The desired badge can be glued next to the programme dial. 8. DIAL AND BUTTONS 8.1 Introduction delicate fabrics. The rinse phase uses more water for some washing programmes •...

  • Page 14: Programmes

    8.6 Delay Start With this option you can delay the start of a The appliance empties the water out programme to a more convenient time. automatically after approximately 18 Touch the button repeatedly to set the hours. required delay. The time increases in steps of 1 hour up to 20 hours.
  • Page 15 Programme Reference Maxi‐ Programme description Default tempera‐ spin speed (Type of load and level of soiling) ture Spin speed load Temperature range (rpm) range 1200 rpm 3 kg Synthetic items or mixed fabric items. Normal soil. Synthetics (1200 - 400) 30 °C 60 °C - Cold 800 rpm...
  • Page 16 Programme Reference Maxi‐ Programme description Default tempera‐ spin speed (Type of load and level of soiling) ture Spin speed load Temperature range (rpm) range 1200 rpm Do not use fabric softener and make sure that there is no 2,5 kg Outdoor (1200 - 400) softener residue in the detergent dispenser.
  • Page 17 Programme options compatibility Programme ■ ■ ■ ■ ■ ■ ■ Cottons ■ ■ ■ ■ ■ ■ ■ ■ ■ Synthetics ■ ■ ■ ■ ■ ■ Delicates ■ ■ ■ ■ Wool ■ ■ ■ ■ Rapid 14min ■...

  • Page 18: Settings

    Universal Liquid Univer‐ Liquid for col‐ Delicates Programme Special powder 1) oureds woolens ▲ ▲ Rapid 14min ▲ ▲ ▲ Jeans ▲ ▲ ▲ Sport ▲ ▲ Silk ▲ ▲ Duvet ▲ ▲ Outdoor ▲ ▲ ▲ Hygiene Eco 40-60 ▲...

  • Page 19: Before First Use

    10.2 Child Lock 4. After 3 seconds the total hours operated by the appliance are shown in the display: With this option you can prevent children from e.g. 1276 hours, the display shows the playing with the control panel. text Hr for 2 seconds, 12 (thousands and To activate/deactivate this option, hold down hundreds) for 2 seconds and 76 (tens and units).

  • Page 20: Daily Use

    12. DAILY USE WARNING! Refer to Safety chapters. 12.1 Activating the appliance 1. Connect the mains plug to the mains socket. 2. Open the water tap. 3. Press the On/Off button for a few seconds to activate the appliance. A short tune sounds. 12.2 Loading the laundry CAUTION! 1.

  • Page 21: Check The Position Of The Detergent Flap

    -Always follow the instructions that you find on the packaging of the detergent products, but we recommend that you do not exceed the maximum indicated level This quantity will however guarantee the best washing results. -After a washing cycle, if necessary, remove any detergent residue from the With the flap in the position DOWN: detergent dispenser.

  • Page 22: Starting A Programme With The Delay Start

    Changing the delay start after the countdown has started If a selection is not possible an acoustic signal sounds and the display shows To change the delay start: 1. Touch the Start/Pause button to pause the appliance. The related indicator 12.6 Starting a programme flashes.

  • Page 23: Interrupting A Programme And Changing The Options

    12.11 Opening the door - Adding garments The appliance can play a double beep to At the beginning of the programme or when indicate overload or unevenly distributed delay start operates, you can open the door. load. The tune sounds if acoustic signals are not disabled.

  • Page 24: Stand-By Function

    The option indicator Rinse Hold Silent disappears. After some minutes from the end of 3. When the programme is completed and the programme, the energy saving function deactivates the appliance the door locked indicator goes off, automatically. you can open the door. 4.

  • Page 25: Stubborn Stains

    13.3 Detergent type and quantity • A very small load can cause balance problems with the spin phase leading to The choice of detergent and use of correct excessive vibration. If this occurs: quantities not only affects your wash a. interrupt the programme and open the performance, but also helps to avoid waste door (refer to "Daily Use"...

  • Page 26: Care And Cleaning

    • Normally soiled laundry may be washed before drying your laundry in a tumble without prewash in order to save dryer. This will save energy during drying! detergent, water and time (the 13.5 Water hardness environment is protected too!). • Loading the appliance to the maximum If the water in your area is hard or medium capacity indicated for each hard, we recommend that you use a water...

  • Page 27: Cleaning The Detergent Dispenser

    use a scouring pads or any scratching Coins, buttons, other small items can be material. recovered at the end of the cycle. CAUTION! Do not use alcohol, solvents or chemical products. CAUTION! Do not clean the metal surfaces with chlorine-based detergent. 14.4 Descaling Clean it when needed, using ammonia cream cleanser agent without scratching the seal...

  • Page 28: Cleaning The Drain Pump

    drawer, once in a while carry out the following 4. Insert the detergent drawer into the guide cleaning procedure: rails and close it. Run the rinsing programme without any clothes in the 1. Open the drawer. Press the catch drum. downwards as indicated in the picture and pull it out.
  • Page 29 Proceed as follows to clean the pump: 180˚ ENGLISH...

  • Page 30: Cleaning The Inlet Hose And The Valve Filter

    WARNING! Make sure that the impeller of the pump can rotate. If it does not rotate, contact the Authorised Service Centre. Make sure also that you tighten the filter correctly to prevent leakages. 14.10 Cleaning the inlet hose and the valve filter It is recommended to clean both filters of the inlet hose and valve occasionally to remove any deposit collected over time.

  • Page 31: Troubleshooting

    WARNING! Make sure that the temperature is higher than 0 °C before you use the appliance again. The manufacturer is not responsible for damages caused by low temperatures. 15. TROUBLESHOOTING WARNING! WARNING! Refer to Safety chapters. Deactivate the appliance before carrying out any check.
  • Page 32 • Make sure that drum doors are properly closed. The appliance drum doors are open or not closed cor‐ rectly. • Wait until mains supply is stable. The mains supply is unsta‐ ble. • Disconnect the appliance and close the water tap. Contact the Authorised Service Centre.

  • Page 33: Consumption Values

    Potential failures Possible solution • Make sure the levelling of the appliance is correct. Refer to "Installation in‐ struction". The appliance makes an un‐ • Make sure that the packaging and/or the transit bolts are removed. Refer to usual noise and vibrates. "Installation instruction".
  • Page 34 16.2 According to Commission Regulation Eu 2019/2023 Eco 40-60 pro‐ rpm 1) Litres hh:mm °C gramme Full load 0.790 52.0 3:25 53.00 39.0 1351 Half load 0.420 42.0 2:40 53.00 30.0 1351 Quarter load 0.165 33.0 2:35 54.00 22.0 1351 Maximum spin speed.

  • Page 35: Quick Guide

    17. QUICK GUIDE 17.1 Daily use Connect the mains plug to the mains socket. 2. Set the desired options (1) by means of the corresponding touch buttons. To start Open the water tap. the programme, touch the button (2)Start/ Load the laundry. Pause Pour the detergent and other treatment in the 3.

  • Page 36: Environmental Concerns

    Programme Load Product description 1,5 kg Machine washable wool, hand washable wool and delicates. Wool 1,5 kg Cotton and synthetic items lightly soiled or worn only once. Rapid 14min All fabrics, except woollens and very delicate fabrics. Programme for 8 kg Rinse rinsing and spinning.
