Charging

The charging instructions below assume all
1. Remove the battery, battery charger, USB-C cable, and USB power supply from the carrying
case.
2. Plug one end of the USB-C cable into the battery charger and the other end into the USB-C port
of the USB power supply.
3. Plug the USB power supply into a power outlet.
4. Insert the battery into the battery charger and leave until fully charged.
•
The battery is fully inserted into the battery charger if only the black battery door is
visible (i.e., the red part of the battery should be entirely hidden).
•
When the battery charger is flashing green, it is charging.
•
When the battery charger is a constant green, it is fully charged
5. To remove the battery from the battery charger, grip the battery with one hand and pull it
upwards while holding the battery charger down with the other hand.
6. Install the battery into the PLANIX R1 by aligning the pins and sliding it into the battery
compartment until you hear a click.
Notes
•
Use only the provided iGUIDE PLANIX R1 battery charger to charge the battery (refer to
Components).
•
Charge the battery in an environment within the specified operating temperature range; refer to
environmental
•
Use only a double-ended USB-C type cable as a USB-A type connection does not support the
necessary charging protocol.
•
When the battery charger is charging, the normal flashing interval is about a half-second on and
a half-second off.
•
A fully discharged battery with a normal internal temperature will charge in about 60 - 90
minutes. Heavily used batteries may take longer to charge completely.
steps to assemble the battery
specifications concerning PLANIX R1 operating and storage temperatures.
have already been completed.
