Capture a Property

1. Place the PLANIX R1 in a suitable location and move yourself out
of view.
2. Tap the Scan button (see Figure 11) and wait for the chime
on your device. A 360° image and laser scan data will be captured
simultaneously.
3. Move the R1 to the next suitable location (maintaining line of
sight with the previous scan) and tap the Scan button again to
capture the next scan.
a. Note: If Auto Align mode is enabled in Survey Settings (the
default is enabled), the laser scan data will automatically align to
any previously captured data.
4. Tap the Left and Right arrows at the top to navigate and
view a previous or next scan.
5. Tap the Eye button to set the selected scan as hidden
(see Figure 12).
Figure 11 - Survey screen (split display)
Figure 12 - Scan hidden
