Installing the Chassis
•
•
•
•
•
•
•
•

Installation Options with Rack-Mount Kits

The rack-mount kit enables you to install the switch into racks of varying depths. You can position the switch
with easy access to either the port connections or the fan and power supply modules.
Install the switch using these rack-mount options:
The rack or cabinet that you use must meet the requirements listed the in
and Racks

Install a Rack

Before you install the switch, you must install a standard four-post, 19-inch EIA data center rack (or a cabinet
that contains such a rack) that meets the requirements listed in
Step 1
Bolt the rack to the concrete subfloor before moving the chassis onto it.
Install a Rack, on page 1
section.
You are responsible for verifying that your rack and rack-mount hardware comply with the guidelines that
are described in this document.
General Requirements for Cabinets
Overview of
Racks.
Installing the Chassis
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the N9K-C9300-RMK and is the answer not in the manual?

Questions and answers

Related Manuals for Cisco N9K-C9300-RMK

Summary of Contents for Cisco N9K-C9300-RMK

  • Page 1: Table Of Contents

    Installing the Chassis • Installation Options with Rack-Mount Kits, on page 1 • Install a Rack, on page 1 • Unpacking and Inspecting a New Switch, on page 2 • Planning How to Position the Chassis in the Rack, on page 3 •...

  • Page 2: Procedure

    Installing the Chassis Unpacking and Inspecting a New Switch Statement 1048 Rack Stabilization Warning The rack stabilizing mechanism must be in place, or the rack must be bolted to the floor before installation or servicing. Failure to stabilize the rack can cause bodily injury. Step 2 If the rack has bonded construction, connect it to the earth ground.

  • Page 3: Planning How To Position The Chassis In The Rack

    Installing the Chassis in a Four-Post Rack Before you install the chassis, be sure that the rack is fully secured to the data center floor. Installing the Switch using the N9K-C9300-RMK Rack-mount Kit Attaching the Bottom-Support Rails to the Rack The switch chassis that you are installing ships with two adjustable bottom-support rails that you can attach to a four-post rack to hold the chassis.
  • Page 4 Installing the Chassis Attaching the Bottom-Support Rails to the Rack 36 inches (91 cm). On each bottom-support rail, the rail half that slides into the other rail includes a chassis stop that fits into the module end of the chassis. Depending on direction of the chassis airflow, position the rail half with the chassis stop so that the fan and power supply modules end up in the appropriate aisle as follows: •...
  • Page 5 Installing the Chassis Attaching the Bottom-Support Rails to the Rack • If the fan modules have blue coloring (port-side exhaust modules), position the bottom support rails so that the chassis stop is positioned by the cold aisle. • If the fan modules have burgundy (port-side intake modules), position the bottom support rails so that the chassis stop is positioned by the hot aisle.
  • Page 6 Installing the Chassis Attaching Front-Mount Brackets to the Chassis Check the two installed bottom support rails to be sure that both have their chassis stops by the same aisle Note (either both by the hot aisle or both by the cold aisle) and that both rails are level and level with each other. If they are not level, adjust the higher rail down to the level of the lower rail.
  • Page 7 Installing the Chassis Installing the Chassis in a Four-Post Rack Step 3 Repeat Steps 1 and 2 to attach the second center-mount bracket to the other side of the chassis. What to do next You are ready to mount the chassis to the four-post rack. Installing the Chassis in a Four-Post Rack Slide the chassis onto the bottom-support rails so that the power supply end locks onto the chassis stops at the end of the rails and so that the front-mount brackets on the chassis come into contact with the front-mount...
  • Page 8 Installing the Chassis Installing the Chassis in a Four-Post Rack Warning Statement 1006 Chassis Warning for Rack-Mounting and Servicing To prevent bodily injury when mounting or servicing this unit in a rack, you must take special precautions to ensure that the system remains stable. The following guidelines are provided to ensure your safety: •...

  • Page 9: Installing The Airflow Vent Nxa-Acc-Bav4

    Installing the Chassis Installing the Airflow Vent NXA-ACC-BAV4 Slide the power-supply end of the chassis onto the Receiving hole on each side of the chassis for the bottom-support rails so that the chassis locks onto the chassis stops on the bottom-support rails. chassis stops at the end of the rails.
  • Page 10 Installing the Chassis Installing the Airflow Vent NXA-ACC-BAV4 Note An electrical conducting path shall exist between the product chassis and the metal surface of the enclosure or rack in which it is mounted or to a grounding conductor. Electrical continuity shall be provided by using thread-forming type mounting screws that remove any paint or non-conductive coatings and establish a metal-to-metal contact.

  • Page 11: Grounding The Chassis

    Installing the Chassis Grounding the Chassis c) Tighten the 10-32 screws to 20 in-lb (2.26 N·m) or tighten the 12-24 screws to 30 in-lb (3.39 N·m). Grounding the Chassis The switch chassis is automatically grounded when you properly install the switch in a grounded rack with metal-to-metal connections between the switch and rack.

  • Page 12: Starting The Switch

    Installing the Chassis Starting the Switch Before you begin Before you can ground the chassis, you must have a connection to the earth ground for the data center building. Procedure Step 1 Use a wire-stripping tool to remove approximately 0.75 inch (19 mm) of the covering from the end of the grounding wire.
  • Page 13 Installing the Chassis Starting the Switch Before you begin • The switch must be installed and secured to a rack or cabinet. • The switch must be adequately grounded. • The rack must be close enough to the dedicated power source so that you can connect the switch to the power source by using the designated power cables.
  • Page 14 A setup utility automatically launches the first time that you access the switch and guides you through the basic configuration. For instructions on how to configure the switch and check module connectivity, see the appropriate Cisco Nexus 9000 Series configuration guide.
