Irregular Type Installation Manual
LED Display
IWA / IFA Series
IWA ( LH0**IWA*W* )
IFA ( LH0**IFA*VS)
Ver. 2.1
LED R&D Team

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IWA Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Samsung IWA Series

Summary of Contents for Samsung IWA Series

  • Page 1 Irregular Type Installation Manual LED Display IWA / IFA Series IWA ( LH0**IWA*W* ) IFA ( LH0**IFA*VS) Ver. 2.1 LED R&D Team...
  • Page 2 Revision History Version Date (Y/M/D) Description 2021/09/13 New Release 2023/01/26 Add Square hole for Power Cord on the Curved Vertical frame (VAV2023001F) 2023/08/28 Change curvature specification LED R&D Team...

  • Page 3: Led Display

    LED Display 1) Curved Frame 1. Frame kit Configuration 2. Frame and Cabinet Installation 2) Outer L-TYPE Frame 1. Frame kit Configuration 2. Frame and Cabinet Installation 3) Inner L-TYPE Frame 1. Frame kit Configuration 2. Frame and Cabinet Installation 4) Appendix...
  • Page 4 1) Curved Frame * The curvature specification of IWA is up to 23,000R (±2˚) * Curved Frame cannot be assembled with Flat frame ※ Flat Frame can make some angle with L-Type Frame.
  • Page 5 1. Frame kit Configuration (CURVED)

  • Page 6: Table Of Contents

    Curved Frame kit Configuration (CURVED) □ Curved Frame kit Configuration Curved Frame Curved Frame Curved Frame ( 4 X 2 ) ( 4 X 3 ) ( 4 X 4 ) Item VG-LFAC2SCW VG-LFAC3SCW VG-LFAC4SCW ASSY FRAME-VERTICAL (Level 2) ASSY FRAME-VERTICAL (Level 3) ASSY FRAME-VERTICAL (Level 4) ASSY HOLDER-MAGNET HORIZONTAL SCREW-MACHINE (FH, M4, L6)

  • Page 7: Screw-Machine (Pwh, M4, L8)

    Curved Jig Kit Configuration- Product should be purchased together (CURVED) □ Curved Jig KIT Configuration Curved Jig Item CY-WJAPWC ASSY FRAME HORIZONTAL JIG SCREW-MACHINE (TH, M6, L10) L WRENCH (2mm) (-) SCREW DRIVER (vessel 9900 2.5x75) (-) SCREW DRIVER + GUIDE HEAD DETACH BOLT M8*L50 THICKNESS GAUGE 50um LED R&D Team...
  • Page 8 2. Frame and Cabinet Installation (CURVED) ※ Backside installation standard) 600mm work space is required on the rear of CABINET...
  • Page 9 Frame Installation (CURVED) ① After separating HINGE part from one ASSY FRAME V based on 4*4 Frame-kit and use it as both SIDEs. FRONT SIDE ASSY HINGE Remove 6EA M4 screws assembled in the ASSY HINGE. LED R&D Team...
  • Page 10 Frame Installation (CURVED) ※ The curvature specification of the IWA is up to 23,000R (±2˚). Although the curved frame kit can bend to ±8˚ (6,000R), the color difference between cabinets is noticeable when it exceeds ±2˚. ② Loosen screws on HINGEs of other ASSY FRAME Vs slightly and assemble the ANGLE BRACKET first. * Use the Angle Support Jig to make precise angle Before fix the Bracket Angle with Screw.
  • Page 11 Frame Installation (CURVED) ④ After assembling PROFILE BRACKET to ANGLE BRACKET, fix it to profile. * The ANGLE BRACKET and PROFILE BRACKET are manufactured by the installer depending on the installation environment. (The reference drawing will be provided through sales.) PROFILE SCREW is not fully fixed when assembling ANGLE BRACKET, Install and horizontally adjust the profile and fix it completely.
  • Page 12 Frame Installation (CURVED) ⑤ When installing FRAME in a profile, use ASSY FRAME HORIZONTAL JIG to adjust the horizontal position. * ASSY FRAME HORIZONTAL JIG is a part of separate product and consists of 6 units per 1SET. * After horizontal adjustment, complete the ANGLE BRACKET and SCREW for FRAME fixing ASSY FRAME HORIZONTAL JIG Screw spec: M6 L12 PITCH 1.0 Assemble and disassemble ASSY FRAME HORIZONTAL JIG to ASSY FRAME Vs...

  • Page 13: Side Sheet(Pet, 0.1T)

    Cabinet + Frame Installation (CURVED) ① Attach the SIDE SHEET to the side before installing CABINET. * In order to prevent collision between modules, the SIDE SHEET should be installed on the right side of each CABINET. * The attachment position is attached to the left and right end and the part where the module meets. SIDE SHEET Remove tape Attach to contact the module...

  • Page 14: Bracket-Support

    Cabinet + Frame Installation (CURVED) ② As shown in the figure, install the first CABINET from the left on the FRAME KIT assembled in PROFILE. * When installing the first stage, assemble the BRACKET SUPPORT like basic installation type. (Refer to the IWA / IFA installation manual) * The CABINET installation method is the same as the existing BASIC FRAME installation method.
  • Page 15 Cabinet + Frame Installation (CURVED) ③ Adjust the left and right Z SEAM using the SCREW of the ASSY FRAME V while installing the first stage CABINET. (Fig.1) * The SCREW is controlled using the JIG DRIVER (-) at the rear. (Fig.2) ※...
  • Page 16 Cabinet + Frame Installation (CURVED) ④ After installing the first stage CABINET, assemble the HOLDER MAGNET H first before installing the second stage. (Fig.1) * To maintain a constant gap between the upper and lower cabinets, cut the 0.05 mm filler gauge and insert it into 2 points as shown in the figure.
  • Page 17 Cabinet + Frame Installation (CURVED) ⑤ After assembling the HOLDER MAGNET H, install the CABINET again at the second end. * After installing the second stage CABINET, assemble the BRKT-REAR SUPPORT on the rear side first before removing the filler gauge. * The BRKT-REAR SUPPORT holds the screw in contact with the upper surface to fix the 0.05 mm interval between upper and lower CABINET.
  • Page 18 Cabinet + Frame Installation (CURVED) ⑥ After the second stage BRKT-REAR SUPPORT assembly is completed, remove the filler gauge from the rear of HOLDER MAGNET H. Feeler gauge 0.05mm LED R&D Team...
  • Page 19 Cabinet + Frame Installation (CURVED) ⑦ Z SEAM between upper and lower CABINET is controlled by HOLDER MAGNET H. (Fig.1) * Adjust it using (-) DRIVER on the back. (Fig.2) ※ Turn clockwise and move forward Top control on the right. ※...

  • Page 20: Screw-Machine (Bh, M4, L10)

    Cabinet + Frame Installation (CURVED) ⑧ The remaining 3 or 4 steps are installed in the same way based on 4X4. * Reorganize the cable formation in the rear space. * Fasten the left and right side screw to Fix the CABINET after installation. (Fig.1) ※...
  • Page 21 Cabinet + Frame Installation (CURVED) ※ Curved Frame Extension Method * Assemble the upper and lower frame using the BRACKET-LINK. * It is the same as 2 stages / 3 stages / 4 stages and uses screws (FH, M4, L6). * If it is not extended, remove the BRACKET-LINK.
  • Page 22 2) OUTER L Frame * L-Type cannot be installed alone (Combined installation with Flat BASIC FRAME KIT) * It can be installed minimum 2 level or more in Horizontal.
  • Page 23 1. Frame kit Configuration (OUTER L)
  • Page 24 Frame kit Configuration(OUTER L) □ Outer L Frame kit Configuration OUTER L Frame ( 2X4 ) Item VG-LFAO4SLW ASSY FRAME-HORIZONTAL ASSY FRAME-VERTICAL (Level 2) ASSY HOLDER-MAGNET HORIZONTAL BOLT-ETC (TH, M6, L10) (-) SCREW DRIVER BRACKET-SUPPORT BRACKET-SUPPORT SUB HEADLESS BOLT(HEX 2.0, M4, L5) SCREW-MACHINE (FH, M4, L10) SPACER-ETC ANCHOR...
  • Page 25 2. Frame and Cabinet Installation (OUTER L)
  • Page 26 Frame Installation (OUTER L) ① Assemble the ASSY FRAME V (Level 2) 2SET using the BRACKET LINK as of 4X4. (Fig.1) * It is possible to use 1, 2, and 3 stages using BRACKET LINK assembly and disassembly. (Fig.2) Disassemble two STUD BRACKET LINK Screw spec: M6 L10 PITCH1.0 Fasten two STUD first,...
  • Page 27 Frame Installation (OUTER L) ② Assemble the ASSY FRAME H to the assembled ASSY FRAME V. (Fig.1) * Put it on the shelf and assemble it as shown in the figure. (Fig.2) * Assemble in one direction and then lay down in the other direction. * Before install the L Frame on the wall, Assemble the FRAME VERTICAL LEFT / RIGHT to keep the distance between the ASSY FRAME H.
  • Page 28 Frame Installation (OUTER L) JOINT-HORIZONTAL ③ Fasten the assembled FRAME to the wall. (Fig.1) * First, attach to the wall according to the orthogonal structure and fasten the screw. * Connect L-FRAME and FLAT FRAME after remove the FRAME VERTICAL LEFT/RIGHT. * When extending, proceed in the same way as normal BASIC FRAME KIT installation.
  • Page 29 Frame Installation (OUTER L + CURVED Extension) ※ If OUTER L and CURVED FRAME are used together, ASSY HORIZONTAL JIG of CURVED ACC KIT is used. * Perform the same procedure as the CURVED FRAME KIT installation method. * PROFILE specification is 40X40. 40mm 40mm Screw spec: M6 L10 PITCH 1.0...
  • Page 30 Cabinet + Frame Installation (OUTER L) ① Install the cabinet from the left for cable operation .(Fig.1) * Before installing the cabinet, connect the OCM cable first and arrange the line to the right. (Fig.2) * After installation, plug a POWER CABLE on the side and shape it according to each HOLDER. (Fig.2) POWER CABLE HOLDER OCM CABLE HOLDER OCM CABLE...
  • Page 31 Cabinet + Frame Installation (OUTER L) ② The Z SEAM control of the L TYPE part is performed by disassembling module frame in front of the right CABINET. (Fig.1) * The left CABINET Z SEAM is adjusted by Fastening Ⓑ Screws as shown in the figure. (Fig.2) * The right CABINET Z SEAM is adjusted by Fastening Ⓐ...

  • Page 32: Manual

    Cabinet + Frame Installation (OUTER L) ③ The rest can be performed in the same way as the CABINET installation in BASIC FRAME. * For BASIC installation, refer to the IWA / IFA installation manual. Cabinet 2 ※ Corner part (Top view): Installed so that the module in the right cabinet covers the left cabinet module LED R&D Team...
  • Page 33 3) INNER L Frame * L-Type cannot be installed alone (Combined installation with Flat BASIC FRAME KIT) * It can be installed minimum 2 level or more in Horizontal.
  • Page 34 1. Frame kit Configuration (INNER L)
  • Page 35 Frame kit Configuration(INNER L) □ Frame kit Configuration INNER L Frame ( 2X4 ) Item VG-LFAI4SLW FRAME-HORIZONTAL INNER L ASSY FRAME-VERTICAL INNER L TYPE LEFT ASSY FRAME-VERTICAL INNER L TYPE RIGHT ASSY HOLDER-MAGNET HORIZONTAL ASSY JOINT LINK INNER L TYPE SCREW-MACHINE (FH, M4, L6) SCREW-MACHINE (FH, M4, L10) BOLT-ETC (TH, M6, L10)
  • Page 36 2. Frame and Cabinet Installation (INNER L)
  • Page 37 Frame Installation (INNER L) ① Assemble ASSY FRAME V L / R 2X2 2SET using BRACKET LINK based on 4X4. (Fig.1) * It is possible to use 1, 2, and 3 stages using BRACKET LINK assembly and disassembly. (Fig.2) * Removal BOLT-ETC (M6,L10,Pitch1.0) * Removal if BRKT is not installed at the end...
  • Page 38 Frame Installation (INNER L) ② Connect FRAME HORIZONTAL 2set using JOINT LINK. (Fig.1) ASSY JOINT LINK INNER L TYPE (L/R position needs to be checked) FRAME HORIZONTAL INNER L BOLT-ETC (M6,L10,Pitch1.0) FRAME HORIZONTAL INNER L Fig.1 LED R&D Team...
  • Page 39 Frame Installation (INNER L) 3-1. Assemble FRAME HORIZONTAL and FRAME VERTICAL LETF / RIGHT together with JOINT LINK. (Fig.1) ※ Assemble 3EA center JOINT LINKs and then assemble 2EA upper and lower. (Refer the next page) FRAME HORIZONTAL + JOINT LINK * I II of JOINT LINK is assembled according to the mark, Unify all JOINT LINK positions according to CABINET installation direction.
  • Page 40 Frame Installation (INNER L) 3-1-1. (Center) Assemble FRAME VERTICAL LETF and RIGHT together with 3 JOINT LINK. FRAME HORIZONTAL INNER L BOLT-ETC (M6,L10,Pitch1.0) ASSY JOINT LINK INNER L TYPE FRAME HORIZONTAL INNER R BOLT-ETC (M6,L10,Pitch1.0) ASSY JOINT LINK INNER L TYPE LED R&D Team...
  • Page 41 Frame Installation (INNER L) 3-1-2. (Top/Bottom) Assemble FRAME VERTICAL LETF and RIGHT together with 2 JOINT LINK. Disassemble two STUD Fasten four SCREW Fasten two STUD (BOLT-ETC, M6,L10,Pitch1.0) LED R&D Team...
  • Page 42 Frame Installation (INNER L) 3-2. Assemble the FRAME VERTICAL LEFT / RIGHT to the L-Type FRAME. * Before install the L Frame on the wall, Assemble the FRAME VERTICAL LEFT / RIGHT to keep the distance between the ASSY FRAME H. ①...
  • Page 43 Frame Installation (INNER L) ④ Fasten the assembled FRAME to the wall. (Fig.1) * Close to the wall according to the orthogonal structure, fasten one of the first positions, check horizontally, and fasten the remaining 2 / 3 position (Fig.2) * Insert and fasten (Fig.3) the enclosed sheet according to the flattening of the wall, adjust the height by adjusting the HOLDER-LEVEL, and then tighten the SCREW (Fig.4).
  • Page 44 Frame Installation (INNER L) ⑤ The extension installation is connected to the same BASIC FRAME KIT. * Connect L-FRAME and FLAT FRAME after remove the FRAME VERTICAL LEFT/RIGHT. * When extending, proceed in the same way as normal BASIC FRAME KIT installation. (Fig.2) JOINT-HORIZONTAL ※...
  • Page 45 Cabinet + Frame Installation (INNER L) ① For cable operation, install the cabinet in the following order from the bottom left. (Fig.1) * Install the cable inside the FRAME VERTICAL while connecting the power cable and the OCM cable in the cabinet (Fig.2) * Slide the right sliding bolts first ①, (Fig.3) and then slide in the lower direction of ②, (Fig.4 * To protect module while installment the cabinet, use Edge protection JIG on Cabinet side (Extra ACC) POWER...
  • Page 46 Cabinet + Frame Installation (INNER L) ② The Z SEAM control of L TYPE part is performed by disassembling the module frame FRONT of CABINET. (Fig.1, Fig.2) * If the rear access is possible due to the profile installation, it can be adjusted through the rear adjustment hole without separating the FRONT (Fig.3).
  • Page 47 Cabinet + Frame Installation (INNER L) ③ The rest can be performed in the same way as the CABINET installation in BASIC FRAME. * For BASIC installation, refer to the IWA / IFA installation manual. ※ Corner Part ( Top view) Gap : 0~2.0mm Overlap :...
  • Page 48 4) Appendix...
  • Page 49 1. Flat and L-Type installation with Curved Frame...
  • Page 50 Curved Frame Installation (FLAT type) * FLAT Installation FLAT can be installed using the existing shipment status. Set the profile thickness to 40mm or less so that the controller is not covered after installation. Horizontal bar: 40X40 Al Profile Frame kit & Al Profile Assembly FRONT ※...
  • Page 51 Curved Frame Installation (INNER L type) * INNER L Installation The HINGE of the ASSY FRAME H can be separated and used in the form of INNER L. Only the rear service installation is available and Inner L Frame (VG-LFAI4SLW) is used when installing the front service. Separate and use Curve Frame L / R Angle Fixing Bracket ※...
  • Page 52 2. Precautions for Curved Frame Structures...
  • Page 53 ※ Precautions When Creating Installation Structures (Curved Frame) 1. CURVED can be made by escaping the rear control part. Power socket vertical step adjustment bolt (1 socket apply per 3~4 cabinets) ① 1. Vertical zone Module loading prevention bracket Module seperating bolt (2 corners under the cabinet) ( 4 points per cabinet corner) ②...
  • Page 54 ※ Precautions When Creating Installation Structures (Curved Frame Flat Type) 1. The Curved Frame Kit is assembled with a horizontal Al Profile. * The horizontal Al profile does not need to be assembled at all fasteners, but can be partially applied. Frame kit is assembled with a horizontal Al Profile.
  • Page 55 ※ Precautions When Creating Installation Structures (Curved Frame Flat Type) 2. Vertical PROFILE is produced on a line different from FRAME KIT. * Interference prevention during back service ※ VERTICAL PROFILE ※ FRAME KIT LED R&D Team...
  • Page 56 ※ Prevent light leakage on the back of screen Necessary work to prevent light leakage behind the screen 1. Installation structure fixtures (aluminum profile, etc…), black paint application 2. Blacking the space between cabinets ( Attaching Black sheet, foam, etc…) Attaching Black sheet, foam INNER L FRAME CURVED FRAME...
  • Page 57 3. Module Service...
  • Page 58 ※ Precautions for Module Service To prevent damage to the module, follow the steps below to perform the service. * Reinstall must be attached using a bolt in reverse order. 1. Insert the hexagonal bolts provided as accessories into the rear of FRAME. 2.
  • Page 59 4. Frame Code...
  • Page 60 Frame Code 제품 유형 구분 구성 모델코드 2단 VG-LFAC2SCW Curved-type 3단 VG-LFAC3SCW Curved 4단 VG-LFAC4SCW Frame kit (이형) Curved Jig 1단 CY-WJAPWC Inner L-type 4단 VG-LFAI4SLW L-type Outer L-type 4단 VG-LFAO4SLW LED R&D Team...
  • Page 61 5. Special Installation Case...

  • Page 62: Stacking Installation

    Stacking Installation Stacking *Structure for Stacking (Produced by installer (SI)) 1. Stacking is installed in general structures except for wall hangers. (Fig.1) 2. Flat and Curved Frame Kit can be responded to and selected according to installation conditions. ※ Installation number is recommended to be 5x5 or less (Vertical Frame Extension X) -.
  • Page 63 Accessory required for separate sale Moving Installation * Refer to the reference for item and quantity Moving Reference 1. Responding to the moving structure by installing rails or wheels in the stacking structure. -. When selecting rail or wheel, considering the total load including the structure. (Fig. 1) -.

  • Page 64: Ceiling Installation

    Accessory required for separate sale Ceiling Installation * Refer to the reference for item and quantity Ceiling 1. Installation is possible only under limited conditions. (Management of temperature below 30 °C is required) Ceiling 10 mm It shall be managed with air conditioning devices, etc. so as to be below 30°C 2.
  • Page 65 Ceiling Installation 4. To prevent module departure, assemble the safety wire and install it in the frame. -. Refer to <Ref. 2> table for the required quantity of wire. Bottom Remove Fixing Safety Wire and Module Remove the screw (FH, M3). using M3, L6 BH Screw Using M3, L6 BH screw Fixing Safety Wire and BRACKET-FRAME...
  • Page 66 Ceiling Installation 5. After installing all the cabinets in the frame kit, assemble the bracket at the top/bottom center. -. After inserting the bracket, fix it using screws (M4 and L6). -. Push the top docking part inward to fix it. -.
  • Page 67 Ceiling Installation 6. Assemble the bracket to the frame kit to prevent Cabinet drop. Anti-drop bracket is applied only to the top. -. Fix with SCREW (BH, M6, L10) -. Refer to <Ref. 2> table Fix the Screw for the required quantity of brackets. 7.

  • Page 68: Hanging Installation

    Hanging Installation Hanging 1. Hanging is installed by attaching a frame kit to a profile structure (produced by installer(SI)). -. The profile structure need to consider the product load. (Designed by installer (SI)). -. Load design by referring to Frame or Cabinet weight information (61Page) -.
  • Page 69 <Ref. 1> Weight information Flat Frame Kit Set Weight [Kg] ± 5 % Curved Frame Kit Set Weight [Kg] ± 5 % VG-LFA33SWW 23.8 VG-LFAC2SCW 14.4 VG-LFA44SWW 39.9 VG-LFAC3SCW 21.8 VG-LFA55SWW 61.0 VG-LFAC4SCW 29.3 VG-LFAH1SWW CABINET (IWA) 11.2 VG-LFAH2SWW CABINET (IFA) 12.0 VG-LFAV1SWW VG-LFAV2SWW...
  • Page 70 <Ref. 2> Additional Accessory by Installation Type ※ The following parts need to be purchased separately. Figure Q‘ty Bracket-Support A x 2 A x 2 Bracket-Support SUB (Case1. A=Even) 0 Frame Bezel Bottom Single A x B Moving (Case2. A=Odd) 1 (Case1.
